Pos : 2 /D okumentati on allgemein/Ei nband/Ei nband H andbuch - Dec kbl att ohne Variantenfel d (Standar d) @ 9\mod_1285229289866_0.doc x @ 64941 @ @ 1
Manual
WAGO-I/O-SYSTEM 750
3-Phase Power Measurement Module
750-495(/xxx-xxx)
Version 1.0.0
Pos : 3 /Alle Serien (Allgemeine M odul e)/Hinweise z ur Dokumentation/Impres sum für Standardhandbüc her - allg. Angaben, Ansc hriften, Tel efonnummer n und E-Mail-Adres sen @ 3\mod_1219151118203_21.doc x @ 21060 @ @ 1

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAGO-I/O-SYSTEM 750 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WAGO WAGO-I/O-SYSTEM 750 Series

Summary of Contents for WAGO WAGO-I/O-SYSTEM 750 Series

  • Page 1 Pos : 2 /D okumentati on allgemein/Ei nband/Ei nband H andbuch - Dec kbl att ohne Variantenfel d (Standar d) @ 9\mod_1285229289866_0.doc x @ 64941 @ @ 1 Manual WAGO-I/O-SYSTEM 750 3-Phase Power Measurement Module 750-495(/xxx-xxx) Version 1.0.0 Pos : 3 /Alle Serien (Allgemeine M odul e)/Hinweise z ur Dokumentation/Impres sum für Standardhandbüc her - allg. Angaben, Ansc hriften, Tel efonnummer n und E-Mail-Adres sen @ 3\mod_1219151118203_21.doc x @ 21060 @ @ 1...
  • Page 2 WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module © 2013 by WAGO Kontakttechnik GmbH & Co. KG All rights reserved. WAGO Kontakttechnik GmbH & Co. KG Hansastraße 27 D-32423 Minden Phone: +49 (0) 571/8 87 – 0 Fax: +49 (0) 571/8 87 – 1 69 E-Mail: info@wago.com...

  • Page 3: Table Of Contents

    WAGO-I/O-SYSTEM 750 Table of Contents 750-495 3-Phase Power Measurement Module Pos : 5 /D okumentati on allgemein/Verzeic hnisse/Inhalts verz eichnis - Ü berschrift oG und Verzei chnis @ 3\mod_1219151230875_21.doc x @ 21063 @ @ 1 Table of Contents Notes about this Documentation ..............5 Validity of this Documentation ..............
  • Page 4 8.1.4 “I/O Module“ Tab................82 8.1.5 “Energy“ Tab ..................85 8.1.6 "Factory Settings" Tab ............... 87 Displaying the Measured Values via WAGO-I/O-CHECK ....89 Diagnostics ....................98 Appendix ..................... 99 10.1 Examples of CSV Data Files ..............99 10.1.1 Snapshot ..................... 99 10.1.2...

  • Page 5: Notes About This Documentation

    3-Phase Power Measurement Module R.C. Pos : 12 /Serie 750 ( WAGO-I/O-SYST EM)/Hi nweis e z ur D okumentati on/Hi nweise/Ac htung: Hinweis z ur D okumentati on Bus kl emmen 750- xxxx @ 4\mod_1237986979656_21.doc x @ 29023 @ @ 1...

  • Page 6: Symbols

    Reproduction, translation, electronic and phototechnical filing/archiving (e.g., photocopying) as well as any amendments require the written consent of WAGO Kontakttechnik GmbH & Co. KG, Minden, Germany. Non-observance will involve the right to assert damage claims. Pos : 15.2 /Dokumentation allgemei n/Glieder ungs elemente/---Seitenwechs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1 Pos : 15.3 /All e Seri en ( Allgemei ne Module)/Ü...

  • Page 7: Number Notation

    WAGO-I/O-SYSTEM 750 Notes about this Documentation 750-495 3-Phase Power Measurement Module Important Note! Indicates a potential malfunction which, if not avoided, however, will not result in damage to property. Pos : 15.4.8 /All e Serien ( Allgemei ne Module)/Wic htige Erläuterungen/Sicherheits- und sons tige Hinweis e/Infor mation/Infor mation: _Weiter e Infor mation allgemei n_ - Erl äuter ung @ 13\mod_1343310439814_21.doc x @ 101051 @ @ 1...

  • Page 8: Important Notes

    All changes to the coupler or controller should always be carried out by qualified personnel with sufficient skills in PLC programming. Pos : 18.5 /Serie 750 (WAGO-I/O-SYST EM)/Wic htige Erläuterungen/Bes timmungsgemäß e Verwendung 750- xxxx @ 3\mod_1224064151234_21.doc x @ 24070 @ 3 @ 1 2.1.3...

  • Page 9: Technical Condition Of Specified Devices

    Pos : 18.10 /Serie 750 ( WAGO-I/O-SYST EM)/Wichtig e Erl äuter ung en/Sic her hei ts- und s onstige Hinweise/Gefahr/Gefahr: Berührungssc hutz vorsehen 750-0493/0494/Gefahr: Ber ühr ungss chutz vors ehen 750- 0493/0494/0495 @ 15\mod_1366120208015_21.doc x @ 117160 @ @ 1...
  • Page 10 Important Notes WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Note the max. continuous measuring current of 1 A resp. 5 A! The max. continuous measuring current of the module is 1 A resp. 5 A. If the used current transformers allow greater secondary currents than 1 A resp. 5 A install additional transformers with an appropriate transforming ratio! Pos : 18.13.1 /Alle Serien (Allgemeine D okumente) (Allgemeine M odul e)/Wichtige Erläuter ungen/Sic herheits hinweise/Ac htung/Ac htung: Defekte oder besc hädigte Ger äte aus tausc hen! @ 6\mod_1260180857358_21.doc x @ 46743 @ @ 1...
  • Page 11 WAGO-I/O-SYSTEM 750 Important Notes 750-495 3-Phase Power Measurement Module Avoid electrostatic discharge! The devices are equipped with electronic components that you may destroy by electrostatic discharge when you touch. Pay attention while handling the devices to good grounding of the environment (persons, job and packing).

  • Page 12: Device Description

    Device Description Pos : 21 /Serie 750 ( WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Ei nlei tung/Analogei ngangs klemmen/Gerätebeschr eibung - Ei nleitung 750- 0495 @ 16\mod_1376321299425_21.doc x @ 128508 @ @ 1 The 3-Phase Power Measurement Module (also called I/O Module) measures the electrical data in a 3-phase supply network.

  • Page 13: View

    Figure 1: View of 750-495 and 750-495/000-001 (left) and 750-495/000-002 (right) Pos : 25 /Serie 750 ( WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Ansic ht/Ansic ht C ageCl amp® _Leg ende mit LED s_ohne Leis tungs kontakte @ 16\mod_1371816091053_21.doc x @ 124052 @ @ 1 Table 5: Caption acc.

  • Page 14: Connectors

    Pos : 29.3 /Serie 750 (WAGO-I/O-SYST EM)/Wic htige Erläuterungen/Sicherheits- und sonstig e Hinweis e/Achtung/Achtung: ESD - Auf g ute Erdung der U mgebung ac hten! @ 7\mod_1266318538667_21.doc x @ 50708 @ @ 1 Ensure that the environment is well grounded! The modules are equipped with electronic components that may be destroyed by electrostatic discharge.

  • Page 15: Cage Clamp Connectors

    Device Description 750-495 3-Phase Power Measurement Module Pos : 33 /Serie 750 ( WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Ansc hl üss e/CAGE CLAMP- Anschl üss e - Ü berschrift 3 @ 6\mod_1256296337770_21.doc x @ 43674 @ 3 @ 1 ® 3.2.3...

  • Page 16: Table 7: Cage Clamp

    Device Description WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module ® Figure 4: CAGE CLAMP connectors 750-495/000-002 ® Table 7: CAGE CLAMP connectors 750-495/000-002 Connector Function Voltage L1 Voltage L2 Voltage L3 Neutral conductor (reference for all measurements) RC1+ and RC1− Current L1 via ‘Rogowski coil’...

  • Page 17: Display Elements

    Operating Elements Pos : 39 /Serie 750 ( WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Bedienel emente/Bedi enel emente Bus kl emme 750- xxxx nic ht vor handen @ 4\mod_1236322031125_21.doc x @ 28063 @ @ 1 The I/O module 750-495 has no operating elements.

  • Page 18: Schematic Diagram

    Schematic Diagram Pos : 42 /Serie 750 ( WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Schematisc he Sc haltbil der/Anal ogeing angs kl emmen/Sc hematisc hes Sc haltbild 750-0495 @ 16\mod_1376382441894_21.doc x @ 128560 @ @ 1 Figure 6: Schematic circuit diagram for 750-495 and 750-495/000-001 Manual Version 1.0.0...

  • Page 19: Figure 7: Schematic Circuit Diagram For 750-495/000-002

    WAGO-I/O-SYSTEM 750 Device Description 750-495 3-Phase Power Measurement Module Figure 7: Schematic circuit diagram for 750-495/000-002 Manual Version 1.0.0...
  • Page 20 Device Description WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Function Earth FE! In order to get a function earth, the connection N is connected to the mounting rail via a 1 nF capacitor and a spring contact. If the rail is correctly connected to PE, the immunity to interference is increased.

  • Page 21: Technical Data

    Pos : 44 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Gerätebesc hreibung/Technisc he Daten - Ü berschrift 2 @ 3\mod_1232967587687_21.doc x @ 26924 @ 2 @ 1 Technical Data Pos : 45.1 /Serie 750 (WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/T echnisc he Daten/Anal ogeing angs kl emmen/T ec hnis che D aten 750-0495 @ 16\mod_1376382793919_21.doc x @ 128564 @ 33333 @ 1 3.6.1 Dimensions and Weight Table 8: Technical data ‒...

  • Page 22: Measured Values

    Device Description WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module 3.6.4 Measured Values Table 11: Technical data ‒ measured values Measuring procedure Calculation of true RMS for voltages and currents, sample rate 8 kHz synchronous on all 7 measuring inputs, 24 bits resolution...

  • Page 23: Internal Bus Communication

    Pos : 45.4 /Serie 750 (WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/T echnisc he Daten/Ansc hluss tec hni k/T ec hnisc he D aten Verdr ahtungsebene CC - 0,08 bis 2,5mm2 @ 17\mod_1380121238809_21.doc x @ 132780 @ @ 1 Table 14: Technical Data – Field Wiring ®...

  • Page 24: Approvals

    Pos : 48 /Serie 750 ( WAGO-I/O-SYST EM)/Ger ätebesc hrei bung/Z ulass ungen/Allgemei n/Z ulass ungen Bus kl emme 750- xxxx Allgemein, Standardversi on und all e Vari anten - Einl eitung @ 3\mod_1233911570312_21.doc x @ 27390 @ @ 1...

  • Page 25: Function Description

    Pos : 60 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/F unktions bes chr eibung - Ü berschrift 1 @ 4\mod_1239025975389_21.doc x @ 30003 @ 1 @ 1 Function Description Pos : 61 /Serie 750 ( WAGO-I/O-SYST EM)/F unktions beschr eibung/Funkti onsbesc hrei bung 750-0495 @ 16\mod_1376383129418_21.doc x @ 128568 @ 2222 @ 1 Measuring Principle...
  • Page 26 Function Description WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module • Active energy total • Active energy acquisition total • Active energy delivery total • Reactive energy Lx • Reactive energy inductive Lx • Reactive energy capacitive Lx • Reactive energy total •...

  • Page 27: Description Of Measured Values

    WAGO-I/O-SYSTEM 750 Function Description 750-495 3-Phase Power Measurement Module Power factors: • cos phi Lx (fundamental wave) • Power factor PF Lx (all harmonics) • Power factor LF Lx (all harmonics) Phase angle: • phi Lx Rotary field: • Direction of rotation Limit values: •...

  • Page 28: Figure 8: Rms Value Calculation (Example, Not To Scale)

    The arithmetic mean value for phase current and voltage is generated on the basis of the RMS values. You can set the time interval during which the mean value is to be generated using WAGO-I/O-CHECK, or parameters 34, 35, 36. The RMS minimum and maximum values for current and voltage are also determined over a configurable time interval (WAGO-I/O-CHECK or parameters 37, 38, 39).

  • Page 29: Figure 9: Allocation Of Active And Reactive Energy In The 4 Quadrants

    ‘Rogowski’ coils are reversed! Active power minimum and maximum values are determined over a configurable time interval (WAGO-I/O-CHECK or parameters 37, 38, 39). In real supply networks, not all electrical loads are purely ohmic. Phase shifting occurs between current and voltage. However, this does not affect the method for determining the RMS values for current voltage previously described.
  • Page 30 The representation of the energy values can be scaled using a defined factor in the process image (PI). This factor can be set by the user with WAGO-I/O-CHECK or register 35 and can be changed at any time. The two examples below illustrate the...
  • Page 31 WAGO-I/O-SYSTEM 750 Function Description 750-495 3-Phase Power Measurement Module Harmonics analysis The I/O module calculates the frequency spectrum for the periodic input signals and analyzes the fundamental component and the next 40 harmonics for each phase. This analysis can be conducted on one of the three phases (L1 or L2 or L3).

  • Page 32: Figure 10: 4-Quadrant Display For Active And Reactive Power

    The 4-quadrant display appears as follows: Figure 10: 4-quadrant display for active and reactive power The 4-quadrant display is also shown in WAGO- I/O-CHECK for the measured value views "Overview", "Phase Lx" and "Power" in the dialog "3-phase power measurement".

  • Page 33: Measuring Errors And Accuracy

    The result is the fault current (t) - i SUM Lx If it is higher than the set threshold (WAGO-I/O-CHECK or Parameter 32/33), signaling is carried out in the process image (PI). Type of current transformer!

  • Page 34: Table 16: Ac Measuring Errors

    Function Description WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Table 16: AC measuring errors Measured Value AC Measuring Errors Voltage <= 0.3 % of full-scale value Current <= 0.5 % of full-scale value Active power <= 0.5 % of full-scale value Phase angle ±...

  • Page 35: Figure 11: Input Overdrive (Clipping)

    WAGO-I/O-SYSTEM 750 Function Description 750-495 3-Phase Power Measurement Module status word 1 in the process image and by LED C (current) or LED G (voltage) in diagnostics. Figure 11: Input overdrive (Clipping) Pos : 62 /D okumentation allgemei n/Glieder ungs elemente/---Seitenwechs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1 Manual Version 1.0.0...

  • Page 36: Process Image

    Process Image Pos : 64 /Serie 750 ( WAGO-I/O-SYST EM)/Proz ess abbild Kl emmenbus /Analogei ngangs klemmen/Pr ozessabbild 750- 0495 @ 16\mod_1376315309447_21.doc x @ 128468 @ 22332332333233332 @ 1 The I/O module provides, on 1 logical channel, 24 bytes input and 24 bytes output process data to a fieldbus coupler/controller.

  • Page 37: Output Data

    WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Output Data The output data is transmitted to the I/O module by the fieldbus coupler/controller. This data consists of 4 control words and 8 data words. 5.2.1 Definition of Control Words Control word Control word –...

  • Page 38: Definition Of Output Data Words

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Expanded control word 2 Expanded control word 2 – Byte 4 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 MET_ID_1 MET_ID_1 ID for selection of the measured value from the collection COL_ID, which is delivered with process value 1 of the input data.

  • Page 39: Input Data

    WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Input Data The input data are transmitted to the fieldbus coupler/controller by the I/O module. This data consists of 4 status words and 8 data words (process values 1 … 4).
  • Page 40 Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module OVER_2 Range limiting for process value 2: 0 = Ok 1 = The measured value shown in process value 2 is situated outside the defined value range. OVER_3 Range limiting for process value 3:...
  • Page 41 WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module If STAT_SEL = Status I/O module: -No significance- STAT4 If STAT_SEL = Status Lx = L1 / L2 / L3: - Status Zero crossings: 0 = Signal zero crossings at the phase Lx...

  • Page 42: Definition Of Input Data Words

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Expanded status word 2 Expanded status word 2 – Byte 4 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 MET_ID_1_SEL MET_ID_1_SEL ID for the measured value from the collection COL_ID_SEL which is in process value 1 of the input data.
  • Page 43 WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Process value 1 – Byte 9 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 PROC1[15:8] PROC1[15:8] => See Process value 1 – Byte 8 Process value 1 –...
  • Page 44 Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Process value 2 – Byte 15 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 PROC2[31:24] PROC2[31:24] => See Process value 2 – Byte 12 Process value 3 Process value 3 –...
  • Page 45 WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Process value 4 Process value 4 – Byte 20 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 PROC4[7:0] PROC4[7:0] Byte of the measured value with the MET_ID "MET_ID_4_SEL"...

  • Page 46: Process Image Descriptions

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Process Image Descriptions The I/O module provides a large number of measured values for a three-phase supply network. These measured values are organized into collections which can be selected by specifying the COL_ID. The following collections are available: COL_ID = 010 –...

  • Page 47: Collection Ac Measured Values (010)

    WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module 5.4.1 Collection AC Measured Values (010) The collection is selected in the I/O module output data via the COL_ID and four measured values from this collection are selected via the corresponding MET_IDs.

  • Page 48: Collections For Harmonics Analysis (020, 021, 022)

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module 5.4.2 Collections for Harmonics Analysis (020, 021, 022) The corresponding harmonics analysis collection for the selected phase L the MET_IDs are set in the output data. Three measured values are made available in the input data with every cycle.
  • Page 49 WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Ueff – 1st harmonic L1 [7:0] Ueff – 1st harmonic L1 [15:8] Ueff – 1st harmonic L1 [23:16] Ueff – 1st harmonic L1 [31:24] Ueff – 2nd harmonic L1 [7:0] Ueff – 2nd harmonic L1 [15:8] Ueff –...

  • Page 50: Building-Up The Measured Values

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module HD current – 37th harmonic L3 [7:0] HD current – 37th harmonic L3 [15:8] HD current – 37th harmonic L3 [23:16] HD current – 37th harmonic L3 [31:24] A status query was also set in the examples given here. In example 1, the status query is made for the I/O module.

  • Page 51: Collections Of Measured Values

    WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Collections of Measured Values 5.5.1 Collection 010 – AC Measured Values Wait to the end of build-up time! The selected measured values of the collection are stable after approx. 1400 ms!
  • Page 52 Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Current RMS current L1 UInt32 0.0001A 0.0005A RMS current L2 UInt32 0.0001A 0.0005A RMS current L3 UInt32 0.0001A 0.0005A Max. RMS current L1 UInt32 0.0001A 0.0005A Max. RMS current L2 UInt32 0.0001A...
  • Page 53 WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Energy Setup with WAGO-I/O- Active energy L1 Int32 CHECK or in Register 35 Setup with WAGO-I/O- Active energy L2 Int32 CHECK or in Register 35 Setup with WAGO-I/O- Active energy L3...
  • Page 54 Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Setup with WAGO-I/O- Reactive energy capacitive L2 UInt32 CHECK or in Register 35 Setup with WAGO-I/O- Reactive energy capacitive L3 UInt32 CHECK or in Register 35 Setup with WAGO-I/O- Reactive energy total...
  • Page 55 WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Power factor cos phi L1 Int32 0.01 0.01 cos phi L2 Int32 0.01 0.01 cos phi L3 Int32 0.01 0.01 Power factor PF L1 Int32 0.01 0.01 Power factor PF L2 Int32 0.01...

  • Page 56: Collection 020 - Harmonics Analysis On L1

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module 5.5.2 Collection 020 – Harmonics Analysis on L1 Wait to the end of build-up time! The selected measured values of the collection are stable after approx. 1100 ms! When switching to another harmonic (1 … 40) a build-up time of 1100 ms must...

  • Page 57: Collection 021 - Harmonics Analysis On L2

    WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module 5.5.3 Collection 021 – Harmonics Analysis on L2 Wait to the end of build-up time! The selected measured values of the collection are stable after approx. 1100 ms! When switching to another harmonic (1 … 40) a build-up time of 1100 ms must...

  • Page 58: Collection 022 - Harmonics Analysis On L3

    Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module 5.5.4 Collection 022 – Harmonics Analysis on L3 Wait to the end of build-up time! The selected measured values of the collection are stable after approx. 1100 ms! When switching to another harmonic (1 … 40) a build-up time of 1100 ms must...

  • Page 59: Examples Of Calculating The Measured Values From The Process Values59

    WAGO-I/O-SYSTEM 750 Process Image 750-495 3-Phase Power Measurement Module Examples of Calculating the Measured Values from the Process Values The format of the measured values with sign (Int16) is the two's complement. Generally, use the following equation to calculate the measured values from the...
  • Page 60 001) are possible. Thus, the corresponding current transformer ratios (CTR) are 1:45 and 1:40. The I/O module allows you to set user scaling via WAGO-I/O-CHECK or Register 32, bits 12 … 15. If the bit is set to 0, user scaling is disabled and the transformation ratio of the current is 1:1.

  • Page 61: Table 29: Register 35

    * Register 35: The set value defines the scaling factor PI for energy values. When using the ‘Rogowski’ variants 750-495/000-002 the type of coils is set in WAGO-I/O-CHECK or in register 32, bits 4 and 5. The I/O module calculates the measured values according to the coils’ characteristic curve stored. Current transformer ratio and user scaling are not used.
  • Page 62 Process Image WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module ‘Rogowski’ coils. Similar to current transformers, ‘Rogowski’ coils are used to measure high currents. They have a specific shape, which can be opened and positioned around wires or bars, even subsequently.

  • Page 63: Mounting

    Pos : 67.2 /Serie 750 (WAGO-I/O-SYST EM)/Wic htige Erläuterungen/Sicherheits- und sonstig e Hinweis e/Vorsic ht/Vorsicht: Verl etz ungsgefahr durc h s charfkantige M ess er kontakte! @ 6\mod_1256193279401_21.doc x @ 43414 @ @ 1 Risk of injury due to sharp-edged male contacts! The male contacts are sharp-edged.

  • Page 64: Inserting And Removing Devices

    WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Pos : 67.6 /Serie 750 (WAGO-I/O-SYST EM)/M ontieren/D emontieren/Geräte einfüg en und entfer nen - Ü berschrift 2 @ 3\mod_1231768483250_21.doc x @ 25950 @ 2 @ 1 Inserting and Removing Devices Pos : 67.7 /All e Seri en ( Allgemei ne Module)/Wic htige Erläuterungen/Sicherheits- und sons tige Hi nweis e/Ac htung/Achtung: Arbeiten an Ger äten nur s pannungsfr ei durc hführ en! @ 6\mod_1256193963573_21.doc x @ 43426 @ @ 1 Perform work on devices only if the system is de-energized! Working on devices when the system is energized can damage the devices.

  • Page 65: Removing The I/O Module

    WAGO-I/O-SYSTEM 750 Mounting 750-495 3-Phase Power Measurement Module Pos : 67.10 /Serie 750 ( WAGO-I/O-SYST EM)/Monti eren/D emonti eren/Bus kl emme entfer nen @ 4\mod_1239169375203_21.doc x @ 30334 @ 3 @ 1 6.2.2 Removing the I/O Module Remove the I/O module from the assembly by pulling the release tab.

  • Page 66: Connect Devices

    Pos : 69 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Ansc hließ en/Ger äte ansc hließen - Ü bers chrift 1 @ 3\mod_1234172889468_21.doc x @ 27460 @ 1 @ 1 Connect Devices Pos : 70 /Serie 750 ( WAGO-I/O-SYST EM)/Ans chli eßen/Leiter an C AGE C LAM P ans chli eßen - Ü berschrift 2 und T ext @ 3\mod_1225448660171_21.doc x @ 24928 @ 2 @ 1 ®...

  • Page 67: Voltage Measurement

    Voltage Measurement Pos : 73 /Serie 750 ( WAGO-I/O-SYST EM)/Ans chli eßen/Anschl uss beispi ele/Anal ogei ngangs kl emmen/Spannungsmess ung 750-0495 @ 16\mod_1376384543239_21.doc x @ 128572 @ @ 1 In order to measure the 3 phase voltages of the supply network, connect its 4 ®...

  • Page 68: Current Measurement

    Pos : 75 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Strommess ung - Ü berschrift 2 @ 13\mod_1346248472189_21.doc x @ 102101 @ 2 @ 1 Current Measurement Pos : 76 /Serie 750 ( WAGO-I/O-SYST EM)/Ans chli eßen/Anschl uss beispi ele/Anal ogei ngangs kl emmen/Str ommess ung 750-0495 @ 16\mod_1376384688583_21.doc x @ 128576 @ 33444433 @ 1 7.3.1...

  • Page 69: Current Transformers

    WAGO-I/O-SYSTEM 750 Connect Devices 750-495 3-Phase Power Measurement Module 7.3.2 Current Transformers Normally, the selection of the current transformers is not a critical factor. The internal resistance in the current path of the 3-phase power measurement module is so low that it can be neglected when considering the overall resistance of the current loop.
  • Page 70 Connect Devices WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Note the max. continuous measuring current of 1 A resp. 5 A! The max. continuous measuring current of the module is 1 A resp. 5 A. If the used transformers allow greater secondary currents than 1 A resp. 5 A install additional transformers with an appropriate transforming ratio! 7.3.2.4...

  • Page 71: Rogowski' Coils

    WAGO-I/O-SYSTEM 750 Connect Devices 750-495 3-Phase Power Measurement Module 7.3.3 ‘Rogowski’ Coils Similar to current transformers, ‘Rogowski’ coils are used to measure high currents. They have a specific shape which can be opened and positioned around wires or bars, even subsequently.

  • Page 72: Power Measurement

    Pos : 78 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Leistungsmess ung - Übersc hrift 2 @ 13\mod_1346327054898_21.doc x @ 102149 @ 2 @ 1 Power Measurement Pos : 79 /Serie 750 ( WAGO-I/O-SYST EM)/Ans chli eßen/Anschl uss beispi ele/Anal ogei ngangs kl emmen/Leistungs mess ung 750-0495 @ 16\mod_1376384790047_21.doc x @ 128580 @ @ 1 ®...

  • Page 73: Commissioning

    Commissioning Pos : 82 /Serie 750 ( WAGO-I/O-SYST EM)/In Betrieb nehmen/Parametrier en mit WAGO- I/O-CH ECK/Parametrier en mit WAGO-I/O-CH ECK 750-0495 @ 16\mod_1376385001614_21.doc x @ 128584 @ 2333333 @ 1 The I/O module latched in the bus node and wired for the measurement can be put into operation using the WAGO-I/O-CHECK software for Windows.

  • Page 74: Configuration With Wago-I/O-Check

    Configuration with WAGO-I/O-CHECK Right-click on the image of the I/O module and select the [Settings] menu item. See the figure below: Figure 20: WAGO-I/O-CHECK user interface, bus node with I/O module 750-495 The "3-Phase Power Measurement" dialog opens. See figure below. Manual...

  • Page 75: Figure 21: „3-Phase Power Measurement" Dialog

    [Calibration] Opens the calibration dialog. More information is available from the WAGO Support. The buttons for the individual measured value views appear in the menu (2). The status bar (3) displays the connection icon and IP address of the fieldbus coupler/controller or the name of the COM port.

  • Page 76: Figure 22: „Settings" Dialog

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Click [Settings] to open the "Settings" dialog in which you can configure the application and I/O module. Figure 22: „Settings“ dialog The main menu (1) with the Application, Phase L1, Phase L2, Phase L3, Neutral Conductor, I/O Module, Energy and Factory Settings tabs are on the left side.

  • Page 77: Application" Tab

    =milli or 10 =1 or 10 =kilo. In addition, you specify the storage path for the measured value records. See "Measurement Recording" in the following section "Displaying the Measured Values via WAGO-I/O-CHECK". Manual Version 1.0.0...

  • Page 78: Figure 23: „Application" Tab

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Figure 23: „Application“ tab Manual Version 1.0.0...

  • Page 79: Phase L1", "Phase L2", "Phase L3" Tabs

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module 8.1.2 "Phase L1”, “Phase L2”, “Phase L3” Tabs Use the "Phase L1", "Phase L2", "Phase L3" tabs to configure user scaling, min.- /max. values and general parameters. These settings are saved to the I/O module.
  • Page 80 Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Settings for ‚Rogowski‘ coils! If you use the ‚Rogowski‘ variant 750-495/000-002 user scaling cannot be enabled. Consequently, the transformation ratio is 1:1. Otherwise you would get wrong measured values! For „Min.-/Max. values“ specify the thresholds for undervoltage, overvoltage and overcurrent.

  • Page 81: Neutral Conductor" Tab

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module 8.1.3 “Neutral Conductor” Tab Here make the settings for the neutral conductor, user scaling and threshold value for tamper detect. These settings are saved to the I/O module. Settings for ‚Rogowski‘ coils! If you use the ‚Rogowski‘...

  • Page 82: I/O Module" Tab

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module 8.1.4 “I/O Module“ Tab On the "I/O Module" tab you can do general settings for the entire I/O module, delete min.-/max. values and configure the energy measurement. For „General“ choose the frequency of the supply grid and the phase for the peak value measurement (only one phase).

  • Page 83: Figure 26: „I/O Module" Tab For 750-495 And 750-495/000-001

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module Figure 26: „I/O Module“ tab for 750-495 and 750-495/000-001 Manual Version 1.0.0...

  • Page 84: Figure 27: „I/O Module" Tab For 'Rogowski' Variant 750-495/000-002

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Figure 27: „I/O Module“ tab for ‚Rogowski‘ variant 750-495/000-002 Manual Version 1.0.0...

  • Page 85: Energy" Tab

    After entering a password, you can set or reset the energy values per phase on the "Energy" tab. The initial password is: wago. Please change this password on first use by clicking [Change password]. Should you have forgotten the password deinstall and install again the application “3-Pase Power Measurement”.

  • Page 86: Figure 28: "Energy" Tab

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Figure 28: “Energy” tab Manual Version 1.0.0...

  • Page 87: Factory Settings" Tab

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module 8.1.6 "Factory Settings" Tab After entering a password (see "Energy" tab above), you can reset all parameters of the I/O module to their factory settings on the "Factory Settings" tab. List of factory settings A list of factory settings may be found in section “Appendix”.

  • Page 88: Figure 29: "Factory Settings" Tab

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Figure 29: “Factory Settings” tab Pos : 83 /D okumentation allgemei n/Glieder ungs elemente/---Seitenwechs el--- @ 3\mod_1221108045078_0.doc x @ 21810 @ @ 1 Manual Version 1.0.0...

  • Page 89: Displaying The Measured Values Via Wago-I/O-Check

    750-495 3-Phase Power Measurement Module Pos : 84 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Anz eigen der M ess werte mit WAGO-I/O-CHEC K - Ü bersc hrift 2 @ 13\mod_1355494395030_21.doc x @ 107680 @ 2 @ 1...

  • Page 90: Figure 30: Measured Values - Overview

    Change of the Measuring Units! Specify the prefixes of the measuring units by selecting Home > Settings > Application. See section "Configuration with WAGO-I/O-CHECK" > "Application" Tab. The units can only be changed in the lists with the same physical variables. For lists with different variables, base units are always used! Figure 30: Measured values –...

  • Page 91: Figure 31: Measured Values - Phases

    Note: Peak values are only displayed if this phase was selected for peak value measurement. See section "Configuration with WAGO-I/O-CHECK" > "I/O module" Tab. Overcurrent, under and overvoltage are identified as a red square, if not present as a green one.

  • Page 92: Figure 32: Measured Values - Currents And Voltages

    Note: Peak values are only displayed for the phase which was selected for peak value measurement. See section "Configuration with WAGO-I/O-CHECK" > "I/O module" Tab. Overcurrent, under- and overvoltage and tamper detect are identified as a red square, if not present as a green one.

  • Page 93: Figure 33: Measured Values - Power

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module If you select Power, you see active, reactive and apparent power of all 3 phases with min. and max. values, the power factors and the 4-quadrant displays. • Active power • Reactive power •...

  • Page 94: Figure 34: Measured Values - Energies

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module If you select Energies, you see the active energies with supply and delivery, reactive energies with capacitive and inductive component and the apparent energies that have been consumed/generated since the beginning of the measurement.

  • Page 95: Figure 35: Measured Values - Harmonics Chart

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module If you select Harmonics you get a chart or a table regarding the 40 harmonics of the phases. The tab „Harmonics analysis“ opens. Here you select chart or table view, the phase to be analyzed and the measured value (voltage or current).

  • Page 96: Figure 36: Measured Values - Harmonics Table

    Commissioning WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module The Table View shows the following values of 1st harmonic (fundamental wave) and another 3 selectable harmonics of the selected phase: • Current • Harmonic distortion THD and HD current • Voltage •...

  • Page 97: Figure 37: Measured Values - Recording

    WAGO-I/O-SYSTEM 750 Commissioning 750-495 3-Phase Power Measurement Module On the Measurement Recording view, 3 measured variables are represented in chronological sequence. You can select the measured variables you want to see in the 3 drop-down lists. Figure 37: Measured values – recording In general, you can select in the 3 waveforms whether: •...

  • Page 98: Diagnostics

    Pos : 87 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Diag nos e, Ser vice/Diag nos e - Ü berschrift 1 @ 4\mod_1240831069471_21.doc x @ 31372 @ 1 @ 1 Diagnostics Pos : 88 /Serie 750 ( WAGO-I/O-SYST EM)/Di agnose/Bus kl emmen/Di agnose 750-0494, - 0495 @ 13\mod_1348662372924_21.doc x @ 103550 @ @ 1 LED A indicates the operating status, LEDs B … H indicate possible errors.

  • Page 99: Appendix

    Pos : 90 /All e Seri en (Allgemei ne Module)/Ü berschriften für alle Serien/Anhang - Ü bersc hrift 1 @ 4\mod_1239874070437_21.doc x @ 30560 @ 1 @ 1 Appendix Pos : 91 /Serie 750 ( WAGO-I/O-SYST EM)/Anhang/Beis piel e für C SV-D ateien 750- 495 @ 16\mod_1376385572540_21.doc x @ 128596 @ 233 @ 1 10.1 Examples of CSV Data Files 10.1.1...
  • Page 100 Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module cos phi L3 0,99 Power Factor PF L1 0,99 Power Factor PF L2 0,99 Power Factor PF L3 0,99 Quadrant L1 Quadrant L2 Quadrant L3 Average Value Current (eff.) L1 0,0007 A Average Value Current (eff.) L2...
  • Page 101 WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Active Energy Supply L3 50 Wh Active Energy Delivery L1 0 Wh Active Energy Delivery L2 0 Wh Active Energy Delivery L3 0 Wh Reactive Energy L1 30 varh Reactive Energy L2...
  • Page 102 Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Parameter Phase L2 Overvoltage threshold value 410 V Overcurrent threshold value 5000000 A Interval observation : arithm. mean 60 s Interval observation : peak value 10 Half-Wave(s) Heed transformer ratio False Automatic reset of the min./max. values...

  • Page 103: Measurement Recording

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module 10.1.2 Measurement Recording The following table shows an example CSV data file generated in the view „Measurement Recording“ with [Start]. In this example the variable „Voltage (eff.) L1-N“ was selected shown as measuring series with 20 values.

  • Page 104: Factory Settings

    10.2 Factory Settings Pos : 94 /Serie 750 ( WAGO-I/O-SYST EM)/Anhang/Wer ksei nstellungen (D efault) 750- 495 @ 16\mod_1376385779929_21.doc x @ 128600 @ @ 1 The following values are stored in registers and parameters at delivery: Table 25: Factory settings R32 ≙...
  • Page 105 WAGO-I/O-SYSTEM 750 Appendix 0x1004 ≙ 410 V 750-495 3-Phase Power Measurement Module 0xC350 ≙ 5 000 mA 0xC350 ≙ 5 000 mA P26, P27 0xC350 ≙ 5 000 mA P28, P29 0x000A ≙ 1 mA P30, P31 0x0004 ≙ 60 s P32, P33 0x0004 ≙...

  • Page 106: Register Assignment

    WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Pos : 96 /Serie 750 ( WAGO-I/O-SYST EM)/In Betrieb nehmen/Parametrier en über Register kommuni kation/R egister bel egung und Parameterbel. 750- 495 @ 16\mod_1376316291064_21.doc x @ 128472 @ 22 @ 1 10.3 Register Assignment The tables below show the assignments and factory settings for the registers written during configuration and during operation.

  • Page 107: Table 27: Register 5

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Table 27: Register 5 Register 5 – Command interface response Function Data type Access Factory setting Command Interface Response UINT 0x0000 High byte Sequence number (Session ID) Low byte Response Request A mirror image of the request command is created when the command is successfully applied.

  • Page 108: Table 30: Register 36

    Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Bit 10: Activation of automatic reset of min/max values for phase L3 Automatic deleting of minimum and maximum current, voltage and power values is not activated (factory settings). Automatic deleting of minimum and maximum current, voltage and power values is activated.

  • Page 109: Table 31: Register 37

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Table 31: Register 37 Register 37 – Undervoltage threshold phase L2 Function Data type Access Factory setting Undervoltage threshold phase L2, UINT 0 x 0000, 0 V Resolution: 0.1 V Checking of undervoltage threshold is deactivated.

  • Page 110: Table 36: Register 42

    Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Table 36: Register 42 Register 42 – Current transformer ratio neutral conductor N Function Data type Access Factory setting Divisor for the current transformer ratio, UINT 0x0001 neutral conductor N, Activation via Register 32, Bit 15 required -not permitted- ≥1:...

  • Page 111: Table 41: Register 47

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Table 41: Register 47 Register 47 – Error register for the parameter channel Function Data type Access Factory setting Error register for the parameter channel UINT 0x0000 No error 1 … 15:...

  • Page 112: Parameter Assignment

    Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Table 48: Register 54 Register 54 – Container 7 Function Data type Access Factory setting Container 7, UINT 0x0000 for energy preset and calibration Table 49: Register 55 Register 55 – Container 8...

  • Page 113: Manual

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Table 55: Parameter 15 Parameter 15 – Current transformer ratio phase L1 Function Data type Access Factory setting -Corresponds to register 39. (See section above.) Table 56: Parameter 16 Parameter 16 – Current transformer ratio phase L2...

  • Page 114: Manual

    Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Table 63: Parameter 23 Parameter 23 – Overvoltage threshold phase L1 Function Data type Access Factory setting Overvoltage threshold phase L1, UINT 0x1004 (410 V) Resolution: 0.1 V Overvoltage is not checked.

  • Page 115: Manual

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Table 68: Parameter 30 and 31 Parameter 30 und 31 – Overcurrent threshold phase L3 Function Data type Access Factory setting Overcurrent threshold phase L3, UINT 0x0000C350 Resolution: 0.1 mA (5000 mA) Overcurrent is not checked.

  • Page 116: Manual

    Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Table 71: Parameter 35 Parameter 35 – Calculation interval arithmetic mean values phase L2 Function Data type Access Factory setting Calculation interval arithmetic mean values UINT 0x0004 phase L2 10 s 15 s...

  • Page 117: Manual

    WAGO-I/O-SYSTEM 750 Appendix 750-495 3-Phase Power Measurement Module Table 75: Parameter 39 Parameter 39 – Interval of automatically resetting the min/max values phase L3 Function Data type Access Factory setting Interval of automatically resetting the min/max values phase L3, resolution 200 ms,...

  • Page 118: Manual

    Appendix WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module === Ende der Liste für T extmar ke Inhalt_mitte === Manual Version 1.0.0...

  • Page 119: List Of Figures

    Figure 18: Connection of ‘Rogowski‘ coil ............71 Figure 19: Power measurement with current transformers (left) resp. ‘Rogowski’ coils (right) ....................72 Figure 20: WAGO-I/O-CHECK user interface, bus node with I/O module 750-495 ........................74 Figure 21: „3-Phase Power Measurement“ dialog ..........75 Figure 22: „Settings“...

  • Page 120: List Of Tables

    List of Tables WAGO-I/O-SYSTEM 750 750-495 3-Phase Power Measurement Module Pos : 100 /Dokumentati on allgemei n/Verz eichniss e/T abellenverzeic hnis - Ü bers chrift oG und Verzeic hnis @ 3\mod_1219222958703_21.doc x @ 21084 @ @ 1 List of Tables Table 1: Variants .....................
  • Page 121 WAGO-I/O-SYSTEM 750 List of Tables 750-495 3-Phase Power Measurement Module Table 49: Register 55 ..................112 Table 50: Parameter 10 ..................112 Table 51: Parameter 11 ..................112 Table 52: Parameter 12 ..................112 Table 53: Parameter 13 ..................112 Table 54: Parameter 14 ..................
  • Page 122 Pos : 102 /Dokumentati on allgemei n/Ei nband/Ei nband Handbuc h - R üc ks eite @ 9\mod_1285229376516_21.doc x @ 64944 @ @ 1 WAGO Kontakttechnik GmbH & Co. KG Postfach 2880 • D-32385 Minden Hansastraße 27 • D-32423 Minden Phone: +49/5 71/8 87 –...

Table of Contents
