GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series Instruction Manual page 8

CT Burden Due to Connection of 269 Relay
CT INPUT
(AMPS)
1
PHASE CT 4
(1A) 13
5
PHASE CT 20
(5A) 65
G/F CT 5
(5A) 10
G/F CT 0.025
(50:0.025) 0.1
0.5
CT Thermal Withstand
Phase CT & G/F 5 amp tap: 3 × - continuous
G/F 50:0.025 mA
Control Power (Includes Tolerances)
frequency:
24 VDC, range:
48 VDC, range:
120 VAC/125 VDC, range:
240 VAC/250 VDC, range:
max. power consumption:
Voltage low ride-through time:
100ms (@ 120VAC/125VDC)
NOTE: Relay can be powered from either AC or DC
source. If Control Power input exceeds 250 V,
an external 3A fuse must be used rated to the
required voltage.
Fuse Specifications
T3.15A H 250V
Timelag high breaking capacity
Dielectric Strength
2200 VAC, 50/60 Hz for 1 sec.
GROUND (Terminal 42) to
Output Contacts (Terminals 29 through 40)
Control Power (Terminals 41 & 43)
Current Transformer Inputs (Terminals 72
through 83)
NOTE: If Hi-Pot tests are performed, jumper J201
beside terminal 43 should be placed in the "HI-
POT" position. Upon completion of Hi-Pot tests, the
jumper should be placed in the "GND" position.
See Fig. 4.3.
BURDEN
(VA)
(mΩ)
0.04 43
0.5 31
4.8 28
0.06 2.4
1 2.5
8.5 2.01
0.08 3
0.3 3
696 Ω
0.435
329 Ω
3.29
200 Ω
50
6 × - 40 sec
12 × - 3 sec
6 × - continuous
50/60 Hz
20-30 VDC
30-55 VDC
80-150 VAC/VDC
160-300 VAC/VDC
20 VA
Type Tests
Dielectric Strength: 2.0 kV for 1 minute to relays,
CTs, power supply
Insulation Resistance:IEC255-5,500Vdc
Transients: ANSI C37.90.1 Oscillatory 2.5kV/1MHz
ANSI C37.90.1 Fast Rise 5kV/10ns
Ontario Hydro A-28M-82
IEC255-4 Impulse/High
Frequency Disturbance
Class III Level
Impulse Test: IEC 255-5 0.5 Joule 5kV
RFI: 50 MHz/15W Transmitter
EMI: C37.90.2 Electromagnetic Interference
@ 150 MHz and 450 MHz, 10V/m
Static: IEC 801-2 Static Discharge
Humidity: 95% non- condensing
Temperature: -25°C to +60°C ambient
Environment: IEC 68-2-38 Temperature/Humidity
Cycle
Dust/Moisture: NEMA 12/IP53
Ambient Temperature and Storage Temperature
-25°C to +60°C
Packaging
Shipping box: 11.40" x 7.50" x 16.00" (WxHxD)
290mm x 190mm x 410mm (WxHxD)
Ship weight: 3.5 kg
7.75 lb.
269 Plus drawout:
Shipping box: 13.25" x 12.50" x 20.50" (LxHxD)
340mm x 320mm x 520mm
Ship weight: 12 kg
26.4 lb.
Certifications
ISO: Manufactured to an ISO9001 certified program
UL: UL recognized under E83849
CSA: Approved under LR41286
CE: Conforms to IEC 947-1, IEC 1010-1
Overvoltage Category:
Pollution Degree:
IP Code:
Note: 269 Drawout does not meet CE compliance.
WARNING: HAZARD may result if the product is
not used for intended purposes.
This equipment can only be serviced
by trained personnel.
1 INTRODUCTION
