Parts List - DeVilbiss Compact Series Operation Manual

E
E
Ref. No
1 Air Cap/Retaining ring
COM-522 or COM-510
+ 2 Nozzle
+ 3 Separator
+ 4 Packing
5 Spreader Valve
6 Stud and Screw
7 Needle Adjusting Screw
+ 8 Spring
Needle
+ 9
Needle—Plastic tipped
10 Airvalve housing + seal
+ 11 Spindle
12 Trigger
13 Connector
14 Airflow Valve
15 Fluid Inlet Connector and
seal
+ 16 Air Valve Service Kit
17 Retaining Ring and Seals
+ 18 Spreader/ Cheater
Service Kit
19 Circlip
+ 20 Air valve assembly Tool
21 Spanner
Spraygun Service Kit
(parts included marked + )
© 2003 ITW Finishing Systems and Products

Parts List

Description Part Number Qty
SP-100-***-K
SP-200S-**-K
SP-623-K5
GTI-445-K2
SP-401-K
GTI-408-K5
SP-614-K
SP-622-K5
SP-300S-**-K
SP-300P-**-K
SP-612-K
SP-617-K
SP-611-K
SP-402-K
SP-610–K
SPK-101-K
SPK-102-K
Gti-428-K5
25746-007-K5
-
SPN-5
SPK-401-**
4
Options
1 522, 510, 505,523
e.g *** = 522
1 085,10,11,12,13,14,
16,18,20,22
e.g ** =14 =1.4 mm
5
2
1
5
1
1
1 085,10,11,12,13,14,
16,18,20,22
e.g ** =14 =1.4 mm
10, 12, 14
e.g ** =14 =1.4mm
1
1
1
1
1
1
1
1
5
5
1
1
1 085,10,11,12,13,14,
16,18,20,22
e.g ** =14 =1.4 mm
