Connectrix ED-64M

2 Gb Fibre Channel Director

USER GUIDE

P/N 069001204

REV A02

EMC Corporation

Corporate Headquarters:

Hopkinton, MA 01748-9103

(800) 424-EMC2

http://www.EMC.com

Table of Contents

Need help?

Do you have a question about the Connectrix ED-64M and is the answer not in the manual?

Questions and answers

Summary of Contents for EMC Connectrix ED-64M

Page 1 Connectrix ED-64M 2 Gb Fibre Channel Director USER GUIDE P/N 069001204 REV A02 EMC Corporation Corporate Headquarters: Hopkinton, MA 01748-9103 (800) 424-EMC2 http://www.EMC.com...
Page 2 Regulatory Agency Information The Connectrix ED-64M has been extensively tested and certified to meet UL1950, CSA 22.2 No 950, IEC 60950/EN60950; Safety of Information Technology Equipment including Electrical Business Equipment, FCC Rules Part 15 Subpart B; CISPR22 Class A; European EMC Directive 89/336/EEC on, electromagnetic compatibility.
Page 3 Any modifications to this device - unless expressly approved by the manufacturer - can void the user’s authority to operate this equipment under part 15 of the FCC rules. Trademark Information Connectrix ED-64M User Guide...
Page 4 Connectrix ED-64M User Guide...
Page 5: Table Of Contents
SBAR Card ................1-15 Backplane ................. 1-15 Embedded Web Server..............1-16 Hardware Operations..............1-17 Updating Firmware ..............1-17 Blocking and Unblocking Ports ..........1-17 Director Operational States ........... 1-17 IML Function................1-18 IPL Function ................1-19 Connectrix ED-64M User Guide...
Page 6 Identifying FRUs ..............4-2 Monitoring Director Operation ..........4-2 Obtaining Hardware Information.......... 4-8 Using Menu Options.............. 4-10 Using the Port Card View............4-14 Using the Port List View ............... 4-23 Displaying Port Properties ............ 4-25 Menu Options ................. 4-25 Connectrix ED-64M User Guide...
Page 7 Open Systems Management Server........5-35 FICON Management Server..........5-36 Configuring Feature Keys............5-39 Configuring the Date and Time ..........5-42 Configuring Threshold Alerts ............. 5-44 Creating New Alerts.............. 5-45 Modifying Alerts..............5-50 Activating or Deactivating Alerts........5-51 Deleting Alerts................ 5-52 Connectrix ED-64M User Guide...
Page 8 Backing Up and Restoring the Configuration ......7-12 Backup..................7-13 Restore..................7-14 Automatic Backup to Zip Disk ..........7-14 Using QuikSync ..............7-16 Resetting the Configuration ............7-18 Note on IP Address ..............7-18 Procedure................. 7-18 viii Connectrix ED-64M User Guide...
Page 9 ..............A-51 Firmware Table..............A-57 Sensor Table ................A-58 The Port Table................ A-60 The Event Table ..............A-69 Link Table ................A-71 Port Statistics Table ............... A-74 Name Server Table ..............A-81 Trap Registration Group............A-83 Connectrix ED-64M User Guide...
Page 10 Entering CLI Commands ............E-4 login ..................E-11 logout ..................E-12 commaDelim ................E-13 Handling Command Line Interface Errors......E-14 Using CLI Help ..............E-14 Commenting Scripts.............. E-15 The config Branch ................ E-16 config.enterpriseFabMode.setState........E-16 config.features.installKey ............. E-17 Connectrix ED-64M User Guide...
Page 11 ......E-37 config.security.userRights.operator ........E-38 config.security.userRights.show.......... E-39 config.snmp.addCommunity ..........E-39 config.snmp.authTraps ............E-40 config.snmp.deleteCommunity ........... E-41 config.snmp.show ..............E-41 config.switch................E-42 config.switch.bbCredit ............E-42 config.switch.domainRSCN ..........E-43 config.switch.insistDomainId ..........E-43 config.switch.edTOV ............. E-44 config.switch.interopMode........... E-44 Connectrix ED-64M User Guide...
Page 12 E-60 maint ....................E-62 maint.port.beacon..............E-62 maint.port.reset..............E-62 maint.system.beacon............. E-63 maint.system.clearSysError ..........E-63 maint.system.ipl..............E-64 maint.system.resetConfig............. E-64 maint.system.setOnlineState..........E-64 perf ....................E-66 perf.class2 ................E-66 perf.class3 ................E-67 perf.clearStats ................. E-68 perf.errors ................E-69 perf.link................... E-70 Connectrix ED-64M User Guide...
Page 13 ..............E-89 show.port.info ................ E-90 show.port.status ..............E-91 show.port.technology............E-94 show.security.fabricBinding..........E-95 show.security.portBinding ........... E-95 show.security.switchBinding ..........E-96 show.switch ................E-97 show.system................E-99 show.thresholdAlerts.alert ..........E-100 show.thresholdAlerts.log............ E-102 show.zoning................E-103 Appendix F Specifications Specifications .................. F-2 Connectrix ED-64M User Guide xiii...
Page 14 Overview of Detecting and Resolving Problems ...... G-2 Troubleshooting the Problem ............G-3 Before Calling the Customer Support Center ......G-4 Documenting the Problem ............G-5 Reporting a New Problem ............G-6 Sending Problem Documentation ..........G-7 Glossary ........................g-1 Index ..........................i-1 Connectrix ED-64M User Guide...
Page 15 Node List View ................... 4-27 Define Nickname Dialog Box ..............4-30 4-10 Performance View ..................4-31 4-11 Clear Threshold Alert(s) Window ............4-38 4-12 FRU List View ..................... 4-39 4-13 Clear Link Incident Alert Window ............4-42 Connectrix ED-64M User Guide...
Page 16 QuikSync Icon in Windows System Tray ..........7-16 Iomega QuikSync Dialog Box ..............7-16 Iomega QuikSync Dialog Box (Advanced Tab) ........7-17 MIB Tree ......................A-3 SNMP MIB-II Support ................. A-7 Fibre Channel Fabric Element MIB Supported ........A-29 Connectrix ED-64M User Guide...
Page 17 ED-64M Port Card Map ................C-2 User Name and Password Dialog Box ............. D-3 Web Server Interface — View Window ........... D-4 Web Server Interface — Configure User Rights ........D-5 Problem Detection and Resolution Process ..........G-2 xvii Connectrix ED-64M User Guide...
Page 18 Figures xviii Connectrix ED-64M User Guide...
Page 19 Fabric Element MIB Modules ..............A-32 A-20 FxPort Configuration Table ..............A-34 A-21 FxPort Operation Table ................A-37 A-22 FxPort Physical Level Table ..............A-38 A-23 FxPort Fabric Login Table ................ A-40 A-24 FxPort Error Table ..................A-43 Connectrix ED-64M User Guide...
Page 20 Active Zone Member Table ..............A-97 A-49 Threshold Alert Table ................A-98 A-50 Enterprise-Specific Traps ................. A-99 A-51 Port State Descriptions ................A-100 CLI Command Tree Navigation Conventions ......... E-5 CLI Command Tree ..................E-6 Threshold Alert Counters ................. E-72 Connectrix ED-64M User Guide...
Page 21: Preface
Manager. This includes using status indicators, menu options, dialog boxes, and performance and error data available through the various views. Chapter 5, Configuring the Director, describes how to use the options available through the Product Manager Configure menu. Connectrix ED-64M User Guide...
Page 22 Server. Appendix F, Specifications, lists the physical characteristics and operating environment of the ED-64M. Appendix G, Customer Support, describes the EMC process for detecting and resolving software problems, and provides essential questions that you should answer before contacting the EMC Customer Support Center.
Page 23 Connectrix DS-32M2 Fibre Channel Switch User Guide, P/N 069001206 Connectrix ED-64M Fibre Channel Director User Guide, P/N 069001096 Connectrix ED-64M 2 Gb Fibre Channel Director User Guide, P/N 069001204 Connectrix ED-140M Fibre Channel Director User Guide, P/N 069001202 Conventions Used in...
Page 24 Options in command line syntax Where to Get Help For questions about technical support, call your local sales office or service provider. If you have a valid EMC service contract, contact EMC Customer Service at: United States: (800) 782-4362 (SVC-4EMC) Canada:...
Page 25 Preface Sales and Customer For the list of EMC sales locations, please access the EMC home page Service Contacts http://www.EMC.com/contact/ For additional information on the EMC products and services available to customers and partners, refer to the EMC Powerlink Web site at: http://powerlink.EMC.com...
Page 26 Preface xxvi Connectrix ED-64M User Guide...
Page 27: Warnings And Cautions
The following warnings and cautions pertain throughout this guide. WARNING Trained service personnel only. This EMC product has more than one power supply cord. To reduce the risk of electric shock, disconnect all power supply cords before servicing. Ground circuit continuity is vital for safe operation of the machine.
Page 28 This product operates at high voltages. To protect against physical harm, power off the system whenever possible while servicing. WARNING In case of fire or other emergency involving the EMC product, isolate the product’s power and alert appropriate personnel. CAUTION Trained personnel are advised to exercise great care at all times when working on the EMC hardware.
Page 29 Warnings and Cautions Static Precautions EMC incorporates state-of-the-art technology in its designs, including the use of LSI and VLSI components. These chips are very susceptible to damage caused by static discharge and need to be handled accordingly. CAUTION Before handling printed circuit boards or other parts containing LSI and/or VLSI components, observe the following precautions: Store all printed circuit boards in antistatic bags.
Page 30 Warnings and Cautions Connectrix ED-64M User Guide...
Page 31: Ed-64M Director Operating Features
Invisible Body Tag ED-64M Director Operating Features This chapter introduces the operating features of the EMC Connectrix ED-64M Director, including hardware features and components. The chapter describes management, service, and operation features, and hardware operations. Overview .....................1-2 Director Components ..............1-11 Embedded Web Server ..............1-16...
Page 32: Overview
Up to four directors are delivered in a EMC-supplied EC-1200 equipment cabinet. (Refer to Figure 1-1 on page 1-3.) The Connectrix service processor is mounted inside the front door of the cabinet.
Page 33: Ec-1200 Cabinet With Ed-64Ms And Connectrix Service Processor
ED-64M Director Operating Features Up to four ED-64Ms in a single EC-1200, providing up to 256 director-class ports per cabinet. Web browser , CLI, and SNMP support. Ethernet ED-64M Drive Connectrix Service Processor ED-64M ED-64M ED-64M Figure 1-1 EC-1200 Cabinet with ED-64Ms and Connectrix Service Processor Overview...
Page 34: Performance Features
(with no port contention). Low communication overhead — Fibre Channel protocol provides efficient use of transmission bandwidth, reduces interlocked handshakes across the communication interface, and efficiently implements low-level error recovery mechanisms. This Connectrix ED-64M User Guide...
Page 35: Director Management
SAN. Multiple topology support —The director supports single-switch and multiswitch fabric topologies. Refer to the EMC Connectrix Enterprise Storage Network System Planning Guide for more information on creating a multiswitch fabric. Director...
Page 36: High-Availability
If one power supply fails, the other supply handles the full load. Separate receptacles at the rear of the director provide facility input power to each supply. For full redundancy, input power for each receptacle should come from a different source. Connectrix ED-64M User Guide...
Page 37: Connectivity
A zone contains a set of devices that can access each other. A zone member can be a port or the WWN of ® the device attached to a port. (EMC recommends that zones contain only WWNs.) Ports and devices spread throughout switches in a multiswitch fabric can be grouped into the same zone.
Page 38: Security
ED-64M Director Operating Features Refer to the EMC Connectrix Enterprise Storage Network System Planning Guide for more information on creating a multiswitch fabric. Members of a zone can see each other, but members in different zones cannot. HBAs with EMC-approved device drivers will discover only those storage devices in their zone.
Page 39: Serviceability
ED-64M Director Operating Features Zoning — System administrators can create zones that provide director access control to increase network security, differentiate between operating systems, and prevent data loss or corruption. Zoning can be implemented in conjunction with server-level access control and storage device access control. Serviceability The ED-64M, Connectrix Manager, and Product Manager applications offer these serviceability features:...
Page 40 SNMP trap messages. The trap messages indicate operational state changes and failure conditions. Data collection through the Product Manager application to help isolate system problems. The data includes a memory dump file and audit, hardware, and engineering logs. 1-10 Connectrix ED-64M User Guide...
Page 41: Director Components
ED-64M Director Operating Features Director Components The ED-64M Director’s modular design allows quick removal and replacement of field replaceable units (FRUs). Figure 1-3 and Figure 1-4 show some of these FRUS, as well as some LEDs and connectors. (Refer to Connectors, Controls, and Indicators on page 2-4 for more information on the LEDs and connectors.) Power and System Error LEDs...
Page 42: Ctp Card
A backup CTP card can take over operation if the active card fails. Failover from a faulty card to the backup card is transparent to attached devices. A backup CTP card can be added while the director is powered on and operating. 1-12 Connectrix ED-64M User Guide...
Page 43: Upm Card
(SFP) shortwave optic transceivers. Any or all of the transceivers can be upgraded to longwave using an upgrade kit available from EMC. UPM cards use non-Open Fiber Control (OFC) Class 1 laser transceivers that comply with Section 21 of the Code of Federal Regulations (CFR), Subpart (J) as of the date of manufacture.
Page 44: Power Supplies
264 VAC. A power switch (circuit breaker) that controls AC power distribution to both power supplies. The breaker is set manually, or is automatically tripped by internal software if thermal sensors indicate the director is overheated. 1-14 Connectrix ED-64M User Guide...
Page 45: Fan Modules
ED-64M Director Operating Features A 9-pin maintenance port that provides a connection for a local terminal or dial-in connection for a remote terminal. Although the port is typically used by authorized maintenance personnel, and for operations personnel to set IP addresses. An input filter and AC system harness (internal to the FRU) that provides the wiring to connect the AC power connectors to the power switch and power supplies (through the backplane).
Page 46: Embedded Web Server
The Embedded Web Server is not intended to be the primary means of management for ED-64Ms. It is recommended that the Web Server be disabled (using Connectrix Manager). This is specially important if the ED-64M is configured to reside on a public LAN. 1-16 Connectrix ED-64M User Guide...
Page 47: Hardware Operations
ED-64M Director Operating Features Hardware Operations This section introduces hardware operations that affect the ED-64M. Updating Firmware The Connectrix service processor’s fixed disk can contain a library of firmware versions for downloading to any ED-64M managed by the Connectrix service processor. Because the CTP card contains two memory regions for storing firmware, new firmware can be loaded (sent) to the director without disrupting port operation.
Page 48: Iml Function
A Link Loss Status table appears. A gray square appears in the alert panel. The FRUs illustrated in the Hardware view disappear, and then reappear as the connection is reestablished. 1-18 Connectrix ED-64M User Guide...
Page 49: Ipl Function
ED-64M Director Operating Features IPL Function To perform an IPL, click Maintenance on the Product Manager menu bar and select IPL on the drop-down menu. CAUTION An IPL is not intended for ordinary or casual use and should only be performed if the active CTP card is suspect or if directed by next-level support or documentation.
Page 50 To perform the test, the attached device must be quiesced and disconnected from the port, and a multimode or singlemode wrap plug must be inserted in the port receptacle. 1-20 Connectrix ED-64M User Guide...
Page 51: Chapter 2 Operating The Director
Invisible Body Tag Operating the Director This chapter describes the operation of the ED-64M Director and identifies the controls and indicators. Power Procedures ................2-2 Connectors, Controls, and Indicators..........2-4 Operating the Director...
Page 52: Power Procedures
LED on the active CTP card, and green PWR OK LEDs on both power supplies remain illuminated. 4. If a POST error or other malfunction occurs, contact EMC Customer Support. When powering on the director after removing and replacing a faulty FRU, the amber system error LED may remain illuminated.
Page 53: Powering The Director Off
Operating the Director Powering the Follow these steps to switch power off to the ED-64M or to power Director Off cycle (turn power off and on). Notes Do not switch the power off to remove FRUs or to connect fiber optic cables to and from ports.
Page 54 PS 0 ED-64M, Front View Figure 2-1 Fan Module LEDs SBAR LEDs Serial Crossbars (SBARs) AC Power Connector AC Power Connector for PS 0 for PS 1 Maintenance Port AC Power Switch ED-64M, Rear View Figure 2-2 Connectrix ED-64M User Guide...
Page 55: Connectors, Controls, And Indicators
AC power. Check the AC power source and power cords. If the cords are plugged in and the AC source is functional, contact EMC Customer Support. Error — The amber system error LED illuminates if system errors occur. The LED flashes if unit beaconing is enabled (through the Product Manager).
Page 56: Upm Cards
On, Off, or Blinking The port is beaconing or running on-line Blinking diagnostics. Port Connectors UPM Card Indicators and Connectors Figure 2-3 Connectrix ED-64M User Guide...
Page 57: Ctp Cards
Operating the Director CTP Cards CTP cards contain LEDs, an IML button, and an Ethernet connector, as illustrated in Figure 2-4. Card LED Port LED IML Button Ethernet Connector CTP Card LEDs, Connectors, and Controls Figure 2-4 CTP cards for 2 Gb ED-64Ms have CTP2 silkscreened on the bezel, where the earlier 1 Gb CTPs said CTP.
Page 58: Power Supplies
Amber Power supply has failed. TEMP Amber Power supply has shut down due to high temperature. ILIM Amber Power supply is overloaded and is operating at current limit of 15.6 Amps. Figure 2-5 Power Supply LEDs Connectrix ED-64M User Guide...
Page 59: Fan Modules
Operating the Director Fan Modules Each fan module has one amber LED. The LED illuminates when a fan fails or is rotating insufficiently. Refer to Figure 2-2 for LED locations. SBAR Cards As seen from the rear of the director, the SBAR card carriage contains a green LED and amber LED indicator.
Page 60 Operating the Director 2-10 Connectrix ED-64M User Guide...
Page 61 Invisible Body Tag Product Manager Overview This chapter is an introduction and overview of the ED-64M Product Manager. It is intended as a quick reference for using features available through the main Product Manager window. Product Manager Overview .............3-2 Using the Product Manager..............3-5 Product Manager Menu Bar ............3-12 Product Manager Views..............3-18 User Rights..................3-23...
Page 62: Product Manager Overview
Configure port address configurations (FICON mode only). Configure SNMP trap recipients and community names. Configure the FICON and Open Systems Management Server features (if installed). Configure switch binding if the optional Enterprise Fabric Extensions feature is installed. Connectrix ED-64M User Guide...
Page 63 Product Manager Overview Configure the management style between Open Systems and FICON. Configure the interoperability mode for multiswitch fabrics. Configure the director name, location, description, and contact person. Configure the data speed for the director and individual ports. Configure threshold alerts for ports. Enable LIN alerts on ports.
Page 64: Connectrix Service Processor And Remote Workstation Configuration
Configuring Remote Workstations in the Connectrix Manager User Guide. Connectrix Manager Client Workstations E-Mail Server 10/100 Mb/s Corporate LAN SNMP Management Station Switch/Hub Connectrix Manager Server Running on Connectrix Service Processor Figure 3-1 Connectrix Service Processor and Remote Workstation Configuration Connectrix ED-64M User Guide...
Page 65: Using The Product Manager
Product Manager Overview Using the Product Manager This section provides a general overview of the Product Manager and its functions. For details on performing specific tasks and using specific dialog boxes, refer to the appropriate chapters in this manual. Using Dialog Boxes Dialog boxes, such as the one in Figure 3-2, display when you select options from the pop-up menus.
Page 66: Logging Into The Connectrix Manager
[root@evtcom2 /root]# ConnectrixManager a. Windows 95, Windows 98, Windows NT, or Windows 2000. b. These steps assume the Connectrix Manager is in your home directory. If you saved it to a different location, enter the appropriate directory names. Connectrix ED-64M User Guide...
Page 67: Connectrix Manager Login Window
Product Manager Overview 2. On the Connectrix Manager Login window (Figure 3-3), enter your user name and password. (User names and passwords are case-sensitive.) If user names have not been established, use the default user name (Administrator) and password (password). Connectrix Manager Login Window Figure 3-3 3.
Page 68: Connectrix Manager Products View
48 product icons. Product Icons Information in each product icon includes the following: Director Speed (Gb/s) Attention Indicator Product Illustration Number Status Indicator of Ports Product Name or Network Address Connectrix ED-64M User Guide...
Page 69 Product Manager Overview Object descriptions: Director data speed, either 1 Gb/s or 2 Gb/s, is configured through the Product Manager application for the specific director. Attention indicator — A yellow triangle means that product requires attention. Open the Product Manager application for the director by double-clicking on the icon to find out more information.
Page 70: Opening The Product Manager
Click the product icon to highlight it; then press or click CTRL-O the Open Product icon on the Connectrix Manager toolbar: Open 120.20.150.10 Product The Product Manager opens to the Hardware view (Figure 3-5). Figure 3-5 Product Manager Window 3-10 Connectrix ED-64M User Guide...
Page 71: Closing The Product Manager
Product Manager Overview The Connectrix Manager window is still available as a separate window. You can drag the Product Manager window away from the Connectrix Manager window and view both windows on your PC desktop (or minimize one or both of them to icons if desired). You can have up to four Product Manager windows open concurrently.
Page 72: Product Manager Menu Bar
• FRU — Contains the following items; refer to Port Card Menu on page 4-11 for descriptions: – Open Port Card View – FRU Properties – Enable Beaconing – Block All Ports – Unblock All Ports 3-12 Connectrix ED-64M User Guide...
Page 73 Product Manager Overview – Diagnostics • Clear System Error Light — Turns off the amber system error LED, located below the green power LED on the front of the director. • Enable Unit Beaconing — Causes a system error light on the front of the director to blink, to help users locate the actual unit in an equipment room.
Page 74 • Management Server — Allows you to configure the open systems inband management program to function with the director. (The Open Systems Management Server feature must be installed in order to perform this procedure.) 3-14 Connectrix ED-64M User Guide...
Page 75 Product Manager Overview Refer to Configuring Management Server Control on page 5-35 for more information. • Features — Allows you to validate an installed feature for use. Refer to Configuring Feature Keys on page 5-39 for more information. • Date/Time — Allows you to set the date and time on the director, and to set the director to synchronize with the date and time on the Connectrix service processor.
Page 76 Refer to Setting the Online State on page 7-8 for more information. • Firmware Library — Displays all firmware versions currently installed on the Connectrix service processor that can be downloaded to directors. Refer to Managing Firmware Versions on page 7-9 for more information. 3-16 Connectrix ED-64M User Guide...
Page 77 Product Manager Overview • Enable E-Mail Notification — Allows you to enable e-mail notification for a specific director. Refer to Enabling E-Mail Notification on page 7-10 for more information. • Enable Call Home Notification — Allows you to enable the call-home function for the director.
Page 78: Product Manager Views
Product Manager. For details on navigating and monitoring via the Hardware view, refer to Chapter 4. Windows Title Bar Menu Bar View Selector Main Panel Status Indicator Figure 3-8 Product Manager Hardware View 3-18 Connectrix ED-64M User Guide...
Page 79 Product Manager Overview In the Hardware view, color-coded indicators reflect the status of actual LEDs on the director FRUs. The status indicator at the lower left displays a symbol to represent the most degraded status currently reported by any of the director FRUs. For example, for a port failure (indicated by a red and yellow diamond on a port), a yellow triangle appears on the alert panel to indicate a degraded condition.
Page 80 (FICON mode only) Enable/disable channel wrap. (FICON mode only) Swap ports. Clear Link Incident Alert(s). Reset the port. Display port binding information. Refer to Using the Port Card View on page 4-14 for detailed information on this view. 3-20 Connectrix ED-64M User Guide...
Page 81: Node List View
Product Manager Overview Node List View Clicking the Node List tab on the Product Manager window (refer to Figure 3-7 on page 3-18) displays a table of information about all node attachments or N_Ports that have logged into existing F_Ports on the director.
Page 82: Performance View
Figure 4-12 on page 4-39 shows an example of the FRU List view. For details on navigating and monitoring via the FRU List view, refer to Using the FRU List on page 4-39. 3-22 Connectrix ED-64M User Guide...
Page 83: User Rights
Product Manager Overview User Rights The Connectrix Manager’s system administrator can assign levels of access, or user rights, to Product Manager users through the Connectrix Manager application. The Connectrix Manager’s system administrator has view rights only while operating in a specific Product Manager application. Conversely, a Product Manager’s product administrator only has view rights while operating in the Connectrix Manager application.
Page 84: User Rights For Product Manager
(FICON mode only) Configure Date/Time Configure Feature Key Configure Identification Configure Management Server Configure Switch Parameters Configure Fabric Parameters Configure Port Binding Configure Ports Configure SNMP Configure Switch Binding Configure Threshold Alerts Configure Zoning Data Collection 3-24 Connectrix ED-64M User Guide...
Page 85 Product Manager Overview Table 3-1 User Rights for Product Manager (continued) Product Product Manager Rights Administrator Operator Maintenance Date/Time Sync Configuration Enable Call Home Notification Enable E-Mail Notification Enable Telnet Enable Web Server Export Configuration Report FRU Beaconing FRU Switchover Manage Firmware Port Diagnostics Port Beaconing...
Page 86 Product Manager Overview 3-26 Connectrix ED-64M User Guide...
Page 87 Invisible Body Tag Monitoring and Managing the Director This chapter describes how to use the features available in the various Product Manager views to monitor and manage director operation. The views are accessible from the tabs shown here: View Tabs Using the Hardware View ..............4-2 Using the Port List View ..............4-23 Using the Node List View...............4-27...
Page 88: Using The Hardware View
Two power supply modules. Two cooling fan modules. Two serial crossbars (SBARs). Monitoring Director This section describes the ED-64M Status table and status symbol Operation (shown below), which indicate the operating status of the director: Status Table Status Symbol Connectrix ED-64M User Guide...
Page 89 Monitoring and Managing the Director Status Refer to Table 4-3 on page 4-15 for the meaning of the text in the Status field and the corresponding symbol in the lower left corner of the Product Manager window State The State field displays one of the following: OFFLINE —...
Page 90 The status depends on specific hardware component failures, which are indicated by status symbols that appear over component graphics in the Hardware view. Table 4-1 shows the various alert panel symbols and their meanings. Connectrix ED-64M User Guide...
Page 91: Operating Status - Status Symbol And Director Status
Monitoring and Managing the Director Table 4-1 Operating Status - Status Symbol and Director Status Status Symbol Operator Panel Text Director Status Table Text Meaning Green Circle: Online or Offline Fully Operational All components and installed ports are operational; no failures. Yellow Triangle: Degraded Redundant Failure...
Page 92: Monitoring Hardware Operation
Figure 4-1 illustrates the Hardware view with examples of symbols and simulated LED indicators that can help you monitor hardware operation. Numbers by each example are keyed to descriptions that follow the figure. ED-64M Status Figure 4-1 Monitoring Hardware Operation Connectrix ED-64M User Guide...
Page 93 Monitoring and Managing the Director Table 4-2 Legend for Figure 4-1 The yellow triangle status symbol indicates that the port card is in a degraded state. This could indicate a problem with an individual port, such as a link failure or service-required status.
Page 94: Obtaining Hardware Information
The FRU Properties window shows: FRU name Slot position relative to identical FRUs installed in the chassis State: active or failed Beaconing state (CTP cards, port cards, SBAR cards) Part number Serial number Speed capability (CTP card only) Connectrix ED-64M User Guide...
Page 95 Monitoring and Managing the Director Displaying Port To display a Port Properties window for a port on a port card, you Properties must be in the port card view. Refer to Using the Port Card View on page 4-14 for details. Displaying Director Tto display a Director Properties window, double-click on the Properties...
Page 96: Using Menu Options
Time on page 5-42 for more information. Set Director Online State — Displays the current state (off line or on line) and provides a button for changing the state. Refer to Setting the Online State on page 7-8 for more information. 4-10 Connectrix ED-64M User Guide...
Page 97 Monitoring and Managing the Director CAUTION Before setting the director off line, warn administrators and users currently operating attached devices that the director is going off line and that there will be a disruption of port operation. Also, request that the devices affected by an interruption of data flow be set off line.
Page 98: Switchover Ctp Window
SBAR card. Enabling beaconing causes the amber LED on the card to flash to help you locate it in the unit. Switchover — Allows you to switch operation from the active SBAR card to the backup card. 4-12 Connectrix ED-64M User Guide...
Page 99: Switchover Sbar Window
Monitoring and Managing the Director You must have maintenance authorization rights to access this feature. Click Switchover on the Switchover SBAR window (Figure 4-3) button to switch operation to the backup card. When switchover occurs, the green LED illuminates on the backup SBAR card to indicate that it is now the active card.
Page 100: Using The Port Card View
A port card fails if one or more individual ports fail. Four sets of green and amber LEDs beneath the amber card status indicator correspond to the four port connectors installed vertically down the port card. 4-14 Connectrix ED-64M User Guide...
Page 101: Port States
Monitoring and Managing the Director Table 4-3 describes the port states and the LED indicators and status symbols that appear in the Hardware view and Port List view. Table 4-3 Port States Port Indicators Green Amber Status Symbol Port State Description None On line...
Page 102 E_Port via an ISL. Operating Speed — The current data speed for the port: 1 Gb/sec, 2 Gb/sec, or Not Established. Not Established appears if Negotiate was set for the port through the Configure Ports 4-16 Connectrix ED-64M User Guide...
Page 103 Monitoring and Managing the Director dialog box and the data speed has not been resolved between the port and the attached device, or if the port and device are not communicating. Fibre Channel Address — The port’s Fibre Channel address identifier, except on E_Ports, for which this value does not apply.
Page 104 – — 07 Non-McDATA switch at other end of the ISL The cable is connected to a non-EMC switch and the Interop Mode for this switch is set to McDATA Fabric. – — The 08 ISL connection not allowed on this port port is configured as an F_Port, but attaches to another switch.
Page 105 Monitoring and Managing the Director – — Possible 11 Unresponsive node connected to port causes are: • Hardware problem on switch or on a connected node where ELP frames are not delivered, the response is not received, or a fabric login in (FLOGI) cannot be received.
Page 106 • Speed: 1 GBit, or 2 GBit,1 GBit. Block Port — Allows you to block port transmission. If blocked, a node attached to the port is prevented from logging into the director or communicating with other devices attached to switch 4-20 Connectrix ED-64M User Guide...
Page 107 Monitoring and Managing the Director ports. A blocked port continuously transmits off-line sequences (OLS). Click to remove the checkmark and unblock the port. If unblocked, a node attached to the port can communicate with the switch and communicate with other nodes attached to the switch. Enable Beaconing —...
Page 108: Clear Threshold Alert(S) Window
This action also restarts the notification interval and the cumulative minutes for utilization % interval. Clear Threshold Alert(s) Window Figure 4-5 For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-44. 4-22 Connectrix ED-64M User Guide...
Page 109: Using The Port List View
Monitoring and Managing the Director Using the Port List View To display the Port List view (Figure 4-6), select the Product Manager Port List tab. ED-64M: Loc12a Figure 4-6 Port List View The Port List view displays the following information on all ports that can be installed in the director.
Page 110 For more information on these states and corresponding status symbol and LED indicator operations in the Hardware view, refer to Table 4-3 on page 4-15. Type: • F_Port if an N_Port is attached • E_Port if another E_Port is attached 4-24 Connectrix ED-64M User Guide...
Page 111: Displaying Port Properties
Monitoring and Managing the Director • G_Port if the port is capable of acting as either an F_Port or an E_Port, but nothing is currently attached Operating Speed — The current data speed for the port: 1 Gb/sec, 2 Gb/sec, or Not Established. Not Established appears if Negotiate was set for the port through the Configure Ports dialog box and the data speed has not been resolved between the port and the attached device, or if the port and device are not...
Page 112: Clear Threshold Alert(S) Window
This action also restarts the notification interval and the cumulative minutes for utilization % interval. Clear Threshold Alert(s) Window Figure 4-7 For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-44. 4-26 Connectrix ED-64M User Guide...
Page 113: Using The Node List View
Monitoring and Managing the Director Using the Node List View To display the Node List view (Figure 4-8), select the Product Manager Node List tab. This view displays information about all node attachments to any F_Ports on the director, sorted by port number. All data is updated automatically as devices log in and out.
Page 114 When the device logs back in, the unit type is updated. BB_Credit — Buffer-to-buffer credit that the attached node has available. 4-28 Connectrix ED-64M User Guide...
Page 115: Displaying Node Properties
Monitoring and Managing the Director Displaying Node To display a Node Properties window for the attached node, Properties double-click the node’s row (or right-click the row and click Node Properties on the pop-up menu). Information for the node includes: Port Number — Physical port number on the director to which the node is connected.
Page 116: Defining Nicknames
To change a node’s display between the WWN and nickname: 1. Right-click the node’s row in the Node List view. 2. On the pop-up menu, move the cursor over Display Options. 3. Click the desired option on the pop-up sub-menu. 4-30 Connectrix ED-64M User Guide...
Page 117: Using The Performance View
Monitoring and Managing the Director Using the Performance View To display the Performance view (Figure 4-10), select the Product Manager Performance tab. This view displays a bar graph for each port. The lower portion of the view displays statistical values for a selected port.
Page 118: Bar Graph Display
(Refer to Table 4-3 on page 4-15.) If the port is an F_Port and is logged in, the message displays the attached port’s WWN or nickname. If the port is an E_Port and is logged in, the message says E_Port 4-32 Connectrix ED-64M User Guide...
Page 119: Port Statistics
Monitoring and Managing the Director Port Statistics To select and display more detailed performance information for a port, click the port’s bar graph. A darker background highlights the bar graph for that port, and the lower portion of the Performance view displays the statistics values for the port.
Page 120 Discarded Frames — The number of Class 3 frames discarded, including multicast frames with bad D_IDs. The director increments this count when it discards a frame that cannot be routed. This occurs most frequently when a destination becomes unavailable without the source realizing it. 4-34 Connectrix ED-64M User Guide...
Page 121 Monitoring and Managing the Director There are no thresholds for this value. Typically, this occurs when the destination is not available due to the destination device’s action. Four Byte Words Rx — The number of four-byte words received. Four Byte Words Tx — The number of four-byte words transmitted.
Page 122 BB_Credit or on any port in order to recover lost BB_Credit. The director receives a link reset from an attached device if the device wishes to initiate the link reset or recover from a link timeout. 4-36 Connectrix ED-64M User Guide...
Page 123: Menu Options
Monitoring and Managing the Director Traffic Statistics The Traffic Statistics table show two sets of values: Receive and Transmit. The bar graphs displays the larger of the two values: Link utilization % —The percentage of the maximum link utilization (100%) currently being used. Link utilization is calculated over one-second intervals.
Page 124: Clear Threshold Alert(S) Window
This action also restarts the notification interval and the cumulative minutes for utilization % interval. Clear Threshold Alert(s) Window Figure 4-11 For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-44. 4-38 Connectrix ED-64M User Guide...
Page 125: Using The Fru List
Monitoring and Managing the Director Using the FRU List To display the FRU List view (Figure 4-12), select the Product Manager FRU List tab. This view displays information about all installed FRUs on the director. All data is updated automatically as the software detects changes.
Page 126 • Backup — Appears on the backup CTP and SBAR cards. • Failed — Appears if the FRU is not functional Part Number — The FRU part number. Serial Number — The FRU serial number. 4-40 Connectrix ED-64M User Guide...
Page 127: Alerts
Monitoring and Managing the Director Alerts The system can generate two types of alerts: Link incident alerts, which are generated because of a problem. Threshold alerts, which are generated when throughput reaches a predetermined level. Link Incident Alerts A link incident (LIN) is a problem detected on a fiber-optic link; for example, loss of light, or invalid sequences.
Page 128: Threshold Alerts
An attention indicator (yellow triangle) that appears by the Threshold Alerts field in the Port Properties window. Detailed threshold alert data recorded in the Threshold Alert log. For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-44. 4-42 Connectrix ED-64M User Guide...
Page 129: Configuring The Director
Invisible Body Tag Configuring the Director This chapter describes the options that appear on the drop-down menu when you select Configure on the Product Manager’s menu bar. Configuring the Management Style ..........5-2 Configuring Director Identification ..........5-3 Configuring Operating Parameters..........5-5 Configuring Switch Binding............5-14 Configuring Ports................5-19 Configuring the SNMP Agent............5-32 Configuring Management Server Control........5-35...
Page 130: Configuring The Management Style
You cannot change the management style from FICON to Open Systems if the FICON Management Server feature enabled. To set the management style, select Product, Management Style, from the Product Manager menu bar, and select the desired mode from the pop-up menu. Connectrix ED-64M User Guide...
Page 131: Configuring Director Identification
Configuring the Director Configuring Director Identification This section describes the procedure for configuring parameters that identify the director in various displays. To configure identification for the director, follow these steps: 1. Click Configure on the Product Manager menu bar and select Identification on the drop-down menu.
Page 132 3. Click Activate to save the data and close the dialog box. 4. If you are finished configuring the director, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-12. Connectrix ED-64M User Guide...
Page 133: Configuring Operating Parameters
Configuring the Director Configuring Operating Parameters Use the procedures in this section to configure parameters on the director for operation over Fibre Channel. These parameters are stored in NV-RAM on the director. Ordinarily, you do not need to change these values from their defaults. The only exception is the Preferred Domain ID.
Page 134: Switch Parameters
Set a Preferred Domain ID value in the range 1 through 31. (The default value is 1.) CAUTION The Domain ID must be unique for each director/switch in a fabric. If two directors/switches have the same Domain ID, the E_Ports (and the fabric) become segmented. Connectrix ED-64M User Guide...
Page 135 Configuring the Director When a director/switch comes on line with a preferred domain ID, it requests an ID from the fabric’s principal switch (indicating its preferred value as part of the request). If the requested domain ID is not allocated to the fabric, the domain ID is assigned to the requesting director/switch.
Page 136 However, some HBAs might log out, and then log back in to the fabric when they receive an RSCN, thereby disrupting Fibre Channel traffic. Consult your HBA vendor and your Connectrix ED-64M User Guide...
Page 137 Configuring the Director EMC representative to determine if fabric-format RSCNs will cause problems with your HBA or storage products. Director Speed Click the drop-down list, and select either 1 Gb/sec or 2 Gb/sec. This option sets the system-wide internal data speed through the director.
Page 138: Fabric Parameters
Resources are allocated to a circuit when errors are detected and are not released for reuse until the time set by the R_A_TOV value expires. Set a value in the range 5-10 Connectrix ED-64M User Guide...
Page 139 (tenths of a second, or 0.2 through 60 seconds). (The default value is 20 tenths, or 2 seconds.) EMC recommends leaving the timeout values at their defaults. These are the defaults used for all HBA and Symmetrix microcode testing for both benign and fault injection cases.
Page 140 (including any others that were previously set to Principal) automatically changes to Default. In some two-tier fabrics (consisting of backbone and edge switches), EMC recommends configuring all backbone switches as Principal, to provide backup in the event of a failure. (This prevents an edge switch from becoming principal.) For more information, consult your EMC...
Page 141 Configuring the Director Interop Mode This parameter is applicable only if the Management Style is set to Open Systems. Select one of the following options: McDATA Fabric 1.0 — if all switches in the fabric are in this list: – ED-1032 –...
Page 142: Configuring Switch Binding
Figure 5-5. Switch Binding — State Change Dialog Box Figure 5-5 2. If the Enable Switch Binding check box is checked, switch binding is enabled. Click the box to add or remove a checkmark. 5-14 Connectrix ED-64M User Guide...
Page 143 Configuring the Director 3. Once you have enabled switch binding, you can specify the port types that will be affected. Select an option under Connection Policy (or leave it at the default setting of Restrict All Ports). Selection Result Restrict E_Ports All switches connected to E_Ports on the director will be prohibited access to the director except those switches you add to the Switch Membership List (described under Editing the Switch Membership...
Page 144: Editing The Switch Membership List
Membership List, select the WWN/nickname in the Membership List and click Remove. • To allow connection to a port not in the list, select the WWN/nickname in the Node List and click Add. 5-16 Connectrix ED-64M User Guide...
Page 145: Switch Binding: Rules And Guidelines
Configuring the Director • To add a WWN/nickname for a device/switch not currently connected to the director, click Detached Node. On the Add Detached Node dialog box, enter the appropriate WWN or nickname (if configured through the Connectrix Manager) and click OK.
Page 146: Zoning With Switch Binding Enabled
However, if a device WWN is in a specific zone but the WWN is not in the Switch Membership List, the device cannot log in to the director port and cannot connect to other devices in the zone with switch binding enabled. 5-18 Connectrix ED-64M User Guide...
Page 147: Configuring Ports
Configuring the Director Configuring Ports Use the procedures in this section to configure identification and operating parameters for director ports. Port configuration data is stored in NV-RAM on the director. Follow these steps to configure a port: 1. Click Configure on the Product Manager menu bar and select Ports on the drop-down menu.
Page 148: Port Parameters
If you want to delete all port names from the director, right-click anywhere in the Name column; then click Clear All Port Names on the pop-up menu. 5-20 Connectrix ED-64M User Guide...
Page 149 Configuring the Director Blocked Open Systems mode only; to block ports in FICON mode, use the Configure Addresses dialog box, described under Configuring Port Addresses on page 5-26. This setting determines whether port operation is enabled (if the box is checked) or disabled. Click a checkbox to add or remove a checkmark.
Page 150 Nickname is specified in the Bound WWN column. You can also enable or disable binding through right-click menus (described later in this section) or through a Bind WWN dialog box (described under Configuring Port Binding on page 5-24.) 5-22 Connectrix ED-64M User Guide...
Page 151 Configuring the Director Binding to the Attached Device To bind a port to the device that is logged in to the port, right-click the port’s Port Binding column; then click Bind Port to Attached WWN on the pop-up menu. The Bound WWN column will display that device’s WWN.
Page 152: Configuring Port Binding
If Port Binding is enabled, only the device whose WWN or Nickname is entered in the WWN field can attach to the port. (If the WWN field does not contain a valid WWN or Nickname, no 5-24 Connectrix ED-64M User Guide...
Page 153 Configuring the Director device can attachh to the port.) If Port Binding is disabled (the box is not checked), any device can attach to the port, even if a WWN or Nickname is specified in the WWN field. Attached WWN — This is the device currently logged in to the director port.
Page 154: Configuring Port Addresses
All port addresses for the director are listed across the top of the matrix to the right of the first three columns. The same addresses are also listed down the left side of the dialog box. If a cell 5-26 Connectrix ED-64M User Guide...
Page 155: Save Address Configuration Dialog Box
Configuring the Director (square) in the matrix contains a red circle-and-line symbol (shown in several cells in Figure 5-10), connection is prohibited between the two addresses whose row and column intersect at that cell. In Figure 5-10, for example, port address 07 is prohibited from communicating with port address 05.
Page 156: Address Parameters
• Unblock all ports — Unblocks all port addresses that are currently blocked. This allows communication from all port addresses in the director. • Clear all — Clears the prohibit status of all port addresses and unblocks all ports. 5-28 Connectrix ED-64M User Guide...
Page 157: Prohibited Port Connection Symbol
Configuring the Director Port connection array — Port address matrix used to allow or prohibit connections.. If a cell (square) in the matrix contains the symbol shown in Figure 5-12, connection is prohibited between the two addresses whose row and column intersect at that cell. Prohibited Port Connection Symbol Figure 5-12 Click a cell to add or remove a symbol.
Page 158: Managing Stored Address Configurations
• Activate — Sends a stored configuration to the director for immediate use. (A warning appears before the action occurs.) If Active=Saved is enabled in through the Configure Management Server dialog box, this overwrites the current IPL address configuration. 5-30 Connectrix ED-64M User Guide...
Page 159 Configuring the Director • Modify — Displays the Configure Addresses dialog box for the configuration. Refer to Configuring the SNMP Agent on page 5-32 for details on using this dialog box. • Delete — Deletes a stored configuration. (A warning appears before deletion.) •...
Page 160: Configuring The Snmp Agent
To configure SNMP traps and assign community names, follow these steps: 1. Click Configure on the Product Manager menu bar and select SNMP Agent on the drop-down menu. This displays the Configure SNMP dialog box (Figure 5-14). 5-32 Connectrix ED-64M User Guide...
Page 161: Configure Snmp Dialog Box
Configuring the Director Configure SNMP Dialog Box Figure 5-14 2. If the box beside Enable Authorization Traps is checked, traps will be sent to SNMP management stations when unauthorized stations try to access SNMP information from the director. Click the box to add or remove a checkmark. 3.
Page 162 The SNMP configuration is stored in NV-RAM on the director. 8. If you are finished configuring the director, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-12. 5-34 Connectrix ED-64M User Guide...
Page 163: Configuring Management Server Control
Configuring the Director Configuring Management Server Control This section describes the procedure to configure a management server (assuming the Management Server feature is installed). The procedures are different for Open Systems and FICON management styles. Open Systems In the current Connectrix release, the Open Systems Management Server feature is available only through RPQ.
Page 164: Ficon Management Server
4. If you are finished configuring the director, you can back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-12. FICON The FICON Management Server feature is not available on all EMC switch/director models. Consult your EMC sales representative for more Management information.
Page 165 Configuring the Director 2. Configure the paramaters as follows: • Switch Clock Alert Mode — If this is enabled (box is checked), the following occurs when users set the date and time through the Configure Date and Time dialog box: –...
Page 166: Available Code
3. Click Activate to activate changes and close the dialog box. 4. If you are finished configuring the switch, you can back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-12. 5-38 Connectrix ED-64M User Guide...
Page 167: Configuring Feature Keys
Configuring the Director Configuring Feature Keys A feature key is a string of alphanumeric characters that validates an installed feature for use. Each feature key is encoded with a director’s serial number; therefore, it can be configured only on the director to which it is assigned.
Page 168: Configure Feature Key Window
To display the Director Properties window, click on the director, away from any FRUs. 5. After you sucessfully enter a feature key (and press OK), the Enable Feature Key dialog box (Figure 5-20) appears. 5-40 Connectrix ED-64M User Guide...
Page 169: Enable Feature Key Dialog Box
Configuring the Director Open Systems Management Server Enable Feature Key Dialog Box Figure 5-20 The left side contains a list of features that are active on the director. The right side contains a list of features that come with the new feature key. All of the features that are active are included in the new feature list.
Page 170: Configuring The Date And Time
Activate. Click Activate to synchronize the date and time at the next update period. Click Sync Now to synchronize the date and time immediately. 5-42 Connectrix ED-64M User Guide...
Page 171 Configuring the Director 2. Perform one of the following steps: • To immediately synchronize the director date and time with the Connectrix service processor, click Sync Now. Make sure that the Periodic Date/Time Synchronization checkbox is checked. If you click Activate, the date and time synchronize at the next update period.
Page 172: Configuring Threshold Alerts
Ports for which you are configuring threshold alerts You can configure up to 16 alerts, and any number of alerts can be active at one time. 5-44 Connectrix ED-64M User Guide...
Page 173: Creating New Alerts
Configuring the Director Creating New Alerts Follow these steps to create a new threshold alert: 1. Click Configure on the Product Manager menu bar and select Threshold Alerts on the drop-down menu. This displays the Configure Threshold Alerts window (Figure 5-22).
Page 174: New Threshold Alerts Window - First Screen
5. Click Next. A new window (Figure 5-24) appears, with additional parameters. The name configured for the alert appears at the top of the window. (Click Previous if you need to return to the previous window.) 5-46 Connectrix ED-64M User Guide...
Page 175: New Threshold Alerts Window - Second Screen
Configuring the Director New Threshold Alerts Window — Second Screen Figure 5-24 6. Enter a percentage for % utilization, 1 through 100. If throughput reaches this percentage of a port’s total throughput capacity, a threshold alert occurs. 7. Enter the number of cumulative minutes in which the % utilization should exist during the notification interval before an alert is generated.
Page 176: New Threshold Alerts Window - Third Screen
11. Click Next. A final window appears to provide a summary of your alert configuration. To make any changes, use the Previous/Next buttons to move backwards and forwards through the configuration windows. 5-48 Connectrix ED-64M User Guide...
Page 177: New Threshold Alerts Window - Summary Screen
Configuring the Director New Threshold Alerts Window — Summary Screen Figure 5-26 12. Click Finish. The Configure Threshold Alerts window (Figure 5-27) appears, listing the name, type, and state of the alert that you just configured. 13. At this point, the alert is not active. To activate the alert, select the alert information that displays in the Configure Threshold Alerts table and select Activate.
Page 178: Modifying Alerts
If the alert is active, an error message displays prompting you deactivate the alert. 5. An initial Modify Threshold window appears, where you can change the threshold type. Select a threshold type from the drop-down list. 5-50 Connectrix ED-64M User Guide...
Page 179: Activating Or Deactivating Alerts
Configuring the Director 6. Select Next when you are done. A Modify Threshold window appears, where you can change the % utilization, cumulative minutes for the threshold to occur before notification, and the time interval for measuring throughput and for alert notification. 7.
Page 180: Deleting Alerts
2. Select the alert that you want to delete by selecting the alert information in the table. 3. Select Delete. 4. A message displays asking you to confirm the deletion. Select Yes. The alert is removed from the dialog box. 5-52 Connectrix ED-64M User Guide...
Page 181: Exporting A Configuration Report
Configuring the Director Exporting a Configuration Report Use this option to save an ASCII file of configuration data currently saved in director NV_RAM to your hard drive or a diskette. Use any desktop publishing application to open the ASCII file for viewing or printing.
Page 182: Export Configuration Dialog Box
2. Select the folder into which you want to save the file. 3. Type a file name and extension into the File name field. 4. Click Save. This saves the file to the specified folder as an ASCII text file. 5-54 Connectrix ED-64M User Guide...
Page 183: Enabling The Embedded Web Server
Configuring the Director Enabling the Embedded Web Server Select this option from the Configure menu to enable or disable remote access to the Embedded Web Server Interface on the director. (Refer to Appendix D for more information on using the Web Server.) If the Enable Web Server box is checked, access to the interface is enabled.
Page 184: Enabling Telnet
Connectrix Manager. If you do plan to use the CLI, change the default passwords in order to prevent others from logging in to the director via the CLI. (This also applies to the Embedded Web Server. Refer to Enabling the Embedded Web Server on page 5-55.) 5-56 Connectrix ED-64M User Guide...
Page 185 Invisible Body Tag Using Logs This chapter describes the ED-64M logs. Using Logs ..................6-2 Audit Log ....................6-4 Event Log ....................6-6 Hardware Log..................6-8 Link Incident Log................6-9 Threshold Alert Log................. 6-11 Using Logs...
Page 186: Button Function
Save window will then be those that are stored in your home directory. If you choose, you can create a folder for your home directory and save the file there. Connectrix ED-64M User Guide...
Page 187: Expanding Columns
Using Logs To save a log file in ASCII format to a location on your system’s hard drive or to a diskette, use the following steps. You can open this file in any desktop publisher for viewing or printing. a. Click Export on the log window. b.
Page 188: Audit Log
Connectrix Manager following the audit log’s stamp of the Connectrix service processor’s date and time. If the string Connectrix Manager does not appear, the time stamp is from the switch. Connectrix ED-64M User Guide...
Page 189 Using Logs Action — User action that caused the configuration change, such as off-line status, port name change, or change of address. Source — Identifies the user making the change through the switch Product Manager and IP or DNS host name address of the remote user’s workstation: •...
Page 190: Event Log
All detected firmware faults and hardware failures are sent to the Connectrix service processor and recorded in the event log. The log provides a maximum of 1000 log entries before it wraps and overwrites the oldest entries. Connectrix ED-64M User Guide...
Page 191 Using Logs Each log entry includes the following: Date/Time — The date and time of the event on the director. Event — A unique code that identifies the event. The same code that appears in the Product Manager Event log also appears on the operator panel Event log.
Page 192: Hardware Log
• UPM — 2 Gb port card with longwave or shortwave LC tranceivers Position — Slot position in the chassis relative to identical components installed. Action — Inserted or Removed. Part Number — Part number of the component. Serial Number — Serial number of the component. Connectrix ED-64M User Guide...
Page 193: Link Incident Log
Using Logs Link Incident Log The Link Incident log displays the 1000 most recent link incidents with the date the incident occurred, the time it occurred, and the port on which the incident took place. The information in this log is useful to maintenance personnel for isolating port problems (particularly E_Port segmentation problems) and repair verification.
Page 194 NOS receive state and after NOS is no longer recognized. • Invalid primitive sequence received for the current link state — Either a link reset or a link reset response primitive sequence was recognized while waiting for the offline sequence. 6-10 Connectrix ED-64M User Guide...
Page 195: Threshold Alert Log
Using Logs Threshold Alert Log This log provides details of threshold alert notifications. Besides the date and time that the alert occurred, the log also displays details about the alert as configured through the Configure Threshold Alert(s) option under the Configure menu. (Refer to Configuring Threshold Alerts on page 5-44) Threshold Alert Log Figure 6-6...
Page 196: Configure Threshold Alerts Window
This is set through the Configure Threshold Alerts window. Interval — The time interval during which the throughput is measured and an alert can generate. This is set through the Configure Threshold Alerts window. 6-12 Connectrix ED-64M User Guide...
Page 197 Invisible Body Tag Using Maintenance Features Invisible Body Tag This chapter describes the options that appear on the Product Manager Maintenance menu. Running Port Diagnostics ..............7-2 Swapping Ports ..................7-3 Collecting Maintenance Data ............7-5 Executing an IPL ................7-6 Setting the Online State ..............7-8 Managing Firmware Versions ............7-9 Enabling E-Mail Notification............7-10 Enabling Call-Home Notification ..........
Page 198: Running Port Diagnostics
To perform the test, the attached device must be quiesced and disconnected from the port. Also, a multimode or single-mode wrap plug must be inserted into the port receptacle. Connectrix ED-64M User Guide...
Page 199: Swapping Ports
Using Maintenance Features Swapping Ports This operation applies only if the director’s Management Style is set to FICON. (Refer to Configuring the Management Style on page 5-2.) The Swap Ports operation allows you to exchange one port address for another. For example, if the current address for port 0 is 04 and the address for port 1 is 05, you can swap so that the address for port 0 has address 05 and port 1 has address 04.
Page 200 8. Follow the on-screen instructions and click Next to continue through to the next screen. 9. If you are finished configuring the director, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-12. Connectrix ED-64M User Guide...
Page 201: Collecting Maintenance Data
Using Maintenance Features Collecting Maintenance Data The Collect Maintenance Data option is used by service personnel to collect maintenance data that can help diagnose system problems. Store this data on the Connectrix service processor hard disk or send it to another network PC using file transfer protocol (FTP). You can also save the maintenance data to a Zip disk and mail it to the technical support personnel.
Page 202: Executing An Ipl
A director IML is initiated by pressing and holding the white IML button (on the faceplate of either CTP card) for three seconds. Loads firmware from the CTP card flash memory without cycling director power. Connectrix ED-64M User Guide...
Page 203 Using Maintenance Features Resets the Ethernet LAN interface on the active CTP card, causing the connection to the Connectrix service processor to drop momentarily until the connection automatically recovers. Automatically sets the director on line. The blocked/unblocked state of each port remains intact. After the IPL: All fabric services databases containing information about current fabric logins, name server registrations, and other data...
Page 204: Setting The Online State
State field of the OFFLINE ED-64M Status table in the Hardware view. LED indicators on all ports with attached devices stay green, but the director is sending off-line sequences (OLS) to these devices. Connectrix ED-64M User Guide...
Page 205: Managing Firmware Versions
Using Maintenance Features Managing Firmware Versions Firmware refers to the internal operating code for the director. Up to eight firmware versions can be maintained on the Connectrix service processor for downloading to a director. This option is for use by service personnel. Managing Firmware Versions...
Page 206: Enabling E-Mail Notification
To enable or disable e-mail notification, Enable E-Mail Notificationenu. When the box to the left of Enable E-Mail Notification is checked, notification is enabled. To change the enabled/disabled state of e-mail notification, click the box to remove/add the checkmark. 7-10 Connectrix ED-64M User Guide...
Page 207: Enabling Call-Home Notification
Enabling Call-Home Notification The call-home feature enables the Connectrix service processor to automatically dial out to the EMC Support Center to report system problems. The support center server accepts calls from the Connectrix service processor, logs reported events, and notifies one or more support center representatives.
Page 208: Backing Up And Restoring The Configuration
You cannot modify the location or file name of the saved configuration. Also, you can restore the configuration only to a director with the same IP address. 7-12 Connectrix ED-64M User Guide...
Page 209: Backup
Using Maintenance Features Backup Follow these steps fo perform a backup: 1. Backup & Restore Configuration on the drop-down menu. This displays the window in Figure 7-3. Backup and Restore Configuration Window Figure 7-3 Following is a list of configurations that are backed up to the Connectrix service processor: •...
Page 210: Restore
Connectrix service processor to fully recover the preferred operating environment. The mirroring operation will only occur while a user is logged in to Windows NT on the Connectrix service processor PC (independent of the Connectrix Manager login). 7-14 Connectrix ED-64M User Guide...
Page 211 Using Maintenance Features The data contained in the directory and mirrored to the Zip EfcData disk includes the following: All Connectrix Manager configuration including: • Product definitions • User names, encrypted passwords, and user rights. • Nicknames • Session options •...
Page 212: Using Quiksync
1. From the Windows taskbar, click Start, Programs, Iomega QuikSync, QuikSync. This displays the Iomega QuikSync dialog box (Figure 7-5). Iomega QuikSync Dialog Box Figure 7-5 2. To enable QuikSync, select On and click OK. 7-16 Connectrix ED-64M User Guide...
Page 213: Iomega Quiksync Dialog Box
Using Maintenance Features QuikSync Settings Do not change the default settings for automatic backup of the directory. If you feel that QuikSync is not functioning EfcData properly, check the settings using the following steps: 1. Open the QuikSync dialog box using one of these steps: •...
Page 214: Resetting The Configuration
All optional features will also be disabled. The director must be off line to continue. 2. Set the director off line. For instructions, refer to Setting the Online State on page 7-8. 7-18 Connectrix ED-64M User Guide...
Page 215: Data Default Values
Using Maintenance Features 3. To continue the reset operation, click Reset on the Reset Configuration dialog box. If you want to cancel the operation, click Cancel. Since the IP address is reset, you may not recover the Ethernet connection to the director if you have changed the director‘s IP addressing from the default value.
Page 216 Number of Zone Members Number of Zones Number of Zone Sets Zone Names None Zone Sets Names None Zone Members None Default Zone State Disabled Active Zone Set State Disabled Active Zone Set Name NULL string 7-20 Connectrix ED-64M User Guide...
Page 217 Invisible Body Tag Using SNMP to Manage the Switch This appendix describes Connectrix support for the Simple Network Management Protocol (SNMP). Introduction ..................A-2 MIB-II Support ..................A-7 Fabric Element MIB Support ............A-29 Fibre Alliance MIB (fcmgmt.mib) ..........A-49 Connectrix Private Enterprise MIB (fceos.mib) ......A-86 Using SNMP to Manage the Switch...
Page 218: Using Snmp To Manage The Switch
Refer to Fabric Element MIB Support on page A-29. Connectrix Private Enterprise MIB. Refer to Connectrix Private Enterprise MIB (fceos.mib) on page A-86. All groups and variables in the supported MIBs are read-only by SNMP management stations unless noted otherwise. Connectrix ED-64M User Guide...
Page 219: Snmp Tree Structure
Using SNMP to Manage the Switch You can download all of these MIBs from the Connectrix Manager’s web page. The URL for the web page depends on the Connectrix service processor’s host name on your network. SNMP Tree Structure Each group is a branch and each variable is a leaf within the MIB tree. The tree begins with the root.
Page 220: Snmp Commands
— Reports that the SNMP agent is reinitializing due to a power-on reset. warmStart — Reports that the agent is reinitializing due to an Initial Machine Load (IML) or Initial Program Load (IPL). authorizationFailure — Reports access by an unauthorized SNMP manager. Connectrix ED-64M User Guide...
Page 221: Protocol Definition
Using SNMP to Manage the Switch Protocol Definition The SNMP agent supports the SNMPv1 protocol and data formats as defined in RFCs 1157 and 1155 respectively. The SNMPv2C protocol is not supported. Configuring an Use the Identification and SNMP Agent options on the Configure SNMP Agent menu to configure the following parameters: Identification:...
Page 222 No changes were made to this MIB with the 7.01 release. Connectrix Enterprise Connectrix Enterprise-specific MIB V2.0 (fceos.mib) is implemented by the SNMP agent that runs on Connectrix M-series Fibre Channel switch products. No changes were made to this MIB with the 7.01 release. Connectrix ED-64M User Guide...
Page 223: Mib-Ii Support
Using SNMP to Manage the Switch MIB-II Support mgmt (2) mib-2 (1) system (1) interface (2) at (3) ip (4) icmp (5) tcp (6) udp (7) snmp (11) SNMP MIB-II Support Figure A-2 The switch agent supports eight groups specified in MIB-II: System Group —...
Page 224: The System Group
DisplayString(0..255) A textual description of the entity. This value should include the full name and version identification of the system's hardware type, software operating system, and networking software. This description must contain only printable ASCII characters. Connectrix ED-64M User Guide...
Page 225: The Interfaces Group
Using SNMP to Manage the Switch The Interfaces Group Table A-2 Interfaces Group MIB-2 Object Name Type Access Description ifNumber INTEGER The number of network interfaces (regardless of their current state) present on this system. The Interfaces Table The Interfaces table contains information on the entity's interfaces. Each interface is thought of as being attached to a subnetwork.
Page 226: Interfaces Table
The size of the largest datagram which can be sent/received on the interface, specified in octets. For interfaces that are used for transmitting network datagrams, this is the size of the largest network datagram that can be sent on the interface. Connectrix ED-64M User Guide A-10...
Page 227 Using SNMP to Manage the Switch Table A-3 Interfaces Table (continued) MIB-2 Object Name Type Access Description ifSpeed Gauge An estimate of the interface's current bandwidth in bits per second. For interfaces which do not vary in bandwidth or for those where no accurate estimation can be made, this object should contain the nominal bandwidth ifPhysAddress PhysAddress...
Page 228 If this information is not present, its value should be set to the OBJECT IDENTIFIER { 0 0 }, which is a syntactically valid object identifier, and any conforming implementation of ASN.1 and BER must be able to generate and recognize this value. Connectrix ED-64M User Guide A-12...
Page 229: The Address Translation Group/Table
Using SNMP to Manage the Switch The Address Implementation of the Address Translation group is mandatory for Translation all systems. Note however that this group is deprecated by MIB-II. Group/Table That is, it is being included solely for compatibility with MIB-I nodes, and will most likely be excluded from MIB-III nodes.
Page 230: The Ip Group
(for example, for lack of buffer space). Note that this counter does not include any datagrams discarded while awaiting re-assembly. ipInDelivers Counter The total number of input datagrams successfully delivered to IP user-protocols (including ICMP) Connectrix ED-64M User Guide A-14...
Page 231 Using SNMP to Manage the Switch Table A-5 IP Group Table (continued) MIB-2 Object Name Type Access Description ipOutRequests Counter The total number of IP datagrams which local IP user-protocols (including ICMP) supplied to IP in requests for transmission. Note that this counter does not include any datagrams counted in ipForwDatagrams.
Page 232: Ip Address Table
An alternate routing metric for this route. The semantics of this metric are determined by the routing-protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1. Connectrix ED-64M User Guide A-16...
Page 233 Using SNMP to Manage the Switch Table A-7 IP Routing Table (continued) MIB-2 Object Name Type Access Description ipRouteMetric3 INTEGER An alternate routing metric for this route. The semantics of this metric are determined by the routing-protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Page 234 If this information is not present, its value should be set to the OBJECT IDENTIFIER { 0 0 }, which is a syntactically valid object identifier, and any conforming implementation of ASN.1 and BER must be able to generate and recognize this value. Connectrix ED-64M User Guide A-18...
Page 235: Ip Address Translation Table
Using SNMP to Manage the Switch The IP Address The IP address translation table contains the IpAddress to physical Translation Table address equivalences. Some interfaces do not use translation tables for determining address equivalences (e.g., DDN-X.25 has an algorithmic method); if all interfaces are of this type, then the Address Translation table is empty;...
Page 236: The Icmp Group
The number of ICMP Destination Unreachable messages sent. icmpOutTimeExcds Counter The number of ICMP Time Exceeded messages sent icmpOutParmProbs Counter The number of ICMP Parameter Problem messages sent. icmpOutSrcQuenchs Counter The number of ICMP Source Quench messages sent. Connectrix ED-64M User Guide A-20...
Page 237 Using SNMP to Manage the Switch Table A-10 ICMP Group Table (continued) MIB-2 Object Name Type Access Description icmpOutRedirects Counter The number of ICMP Redirect messages sent. For a host, this object will always be zero, since hosts do not send redirects. icmpOutEchos Counter The number of ICMP Echo (request) messages sent...
Page 238: The Tcp Group
The number of times TCP connections have made a direct transition to the CLOSED state from either the ESTABLISHED state or the CLOSE-WAIT state. tcpCurrEstab Gauge The number of TCP connections for which the current state is either ESTABLISHED or CLOSE- WAIT. Connectrix ED-64M User Guide A-22...
Page 239 Using SNMP to Manage the Switch Table A-11 TCP Group Table (continued) MIB-2 Object Name Type Access Description tcpInSegs Counter The total number of segments received, including those received in error. This count includes segments received on currently established connections. tcpOutSegs Counter The total number of segments sent, including those on current connections but...
Page 240: Tcp Connection Table
0.0.0.0 is used. tcpConnLocalPort INTEGER The local port number for this TCP connection (0..65535 tcpConnRemAddress IpAddress The remote IP address for this TCP connection tcpConnRemPort INTEGER The remote port number for this TCP connection (0..65535) Connectrix ED-64M User Guide A-24...
Page 241: The Udp Group
Using SNMP to Manage the Switch Additional TCP Objects Additional TCP Objects Table A-13 MIB-2 Object Name Type Access Description tcpInErrs Counter The total number of segments received in error (e.g., bad TCP checksums). tcpOutRsts Counter The number of TCP segments sent containing the RST flag. The UDP Group Table A-14 UDP Group...
Page 242: The Snmp Group
`readOnly'. It should be noted that it is a protocol error to generate an SNMP PDU which contains the value `readOnly' in the error-status field, as such this object is provided as a means of detecting incorrect implementations of the SNMP. Connectrix ED-64M User Guide A-26...
Page 243 Using SNMP to Manage the Switch Table A-16 SNMP Group (continued) MIB-2 Object Name Type Access Description snmpInGenErrs Counter The total number of SNMP PDUs which were delivered to the SNMP protocol entity and for which the value of the error-status field is `genErr'. snmpInTotalReqVars Counter The total number of MIB objects which have been retrieved successfully...
Page 244 Note that it is strongly recommended that this object be stored in non-volatile memory so that it remains constant between re-initializations of the network management system. Values: enabled(1), disabled(2) Connectrix ED-64M User Guide A-28...
Page 245: Fabric Element Mib Support
Using SNMP to Manage the Switch Fabric Element MIB Support experimental fibre channel (42) fcFabric (2) fcFe (1) fcConfig (1) fcFeOp (2) fcFeError (3) fcFeAcct (4) fcFeCap (5) Fibre Channel Fabric Element MIB Supported Figure A-3 The Fibre Channel Fabric Element MIB enables users on network management stations to monitor, control, and configure the switch remotely using functions specifically for Connectrix switches and directors.
Page 246: Predefined Types
0 – other, bit 1 – oneEighth, bit 2 – quarter, bit 3 – half, bit 4 – full, bit 5 – double, (0..127) bit 6 – quadruple, bit 7 – reserved for future. Connectrix ED-64M User Guide A-30...
Page 247: Fabric Element Mib Support
Using SNMP to Manage the Switch Table A-17 Fabric Element Management MIB: Predefined Types (continued) Type Syntax Description Fc0MediaCap INTEGER bit 0 – unknown, bit 1—single mode fibre (sm), bit 2 – multi-mode fibre 50 micron (0..65535) (m5), bit 3 -- multi-mode fibre 62.5 micron (m6), bit 4 –...
Page 248: Mib Objects Defined In The Fabric Element Mib
For example, this object could take the value 1.3.6.1.4.1.99649.3.9 if vendor ‘Neufe Inc.’ was assigned the subtree 1.3.6.1.4.1.99649, and had assigned the identifier 1.3.6.1.4.1.99649.3.9 to its ‘FeFiFo-16 PlugInCard. This is a fixed object identifier assigned from the McDATA enterprise subtree (1.3.6.1.4.1.289.2.1.1.2). Connectrix ED-64M User Guide A-32...
Page 249 Using SNMP to Manage the Switch Table A-19 Fabric Element MIB Modules (continued) Fabric Element MIB Provided Object Name Type Access Description fcFeModuleOperStatus INTEGER SNMP This object indicates the operational status of the module: online(1) – the module is functioning properly;...
Page 250: Fxport Configuration Table
The total number of receive buffers available for holding Class 1 connect-request, Class 2 or 3 frames from the attached NxPort. It is for buffer-to-buffer flow control in the direction from the attached NxPort (if applicable) to Fport. Connectrix ED-64M User Guide A-34...
Page 251 Using SNMP to Manage the Switch Table A-20 FxPort Configuration Table (continued) Fabric Element MIB Object Provided Name Type Access Description FcFxPortRxBufSize FcRxDataFieldSize LOGIN The largest Data_Field Size (in octets) for an FT_1 SERVER frame that can be received by the FxPort. This is fixed at 2112.
Page 252 1, unknown (long distance laser) 2, Longwave Laser (LC version) 3, Shortwave Laser 6 Shortwave Laser-no OFC FcFxPortDistance Fc0Distance The FC-0 distance range of the FxPort transmitter: 1, Unknown 2, Long 3, Intermediate 4, Short Connectrix ED-64M User Guide A-36...
Page 253: Fxport Operation Table
Using SNMP to Manage the Switch FxPort Operation A table that contains, one entry for each FxPort in the Fabric Element, Table operational status and parameters of the FxPorts. FxPort Operation Table Table A-21 Fabric Element MIB Provided Object Name Type Access Description fcFxPortOperFxPortIndex...
Page 254: Fxport Physical Level Table
The pstateUNBLOCKD and pstateBLOCKD indicate the online(1) and offline(2) respectively. If the port cannot be set to testing because it is inactive or in a failed state, the return value will be resource_unavailable(13). Connectrix ED-64M User Guide A-38...
Page 255 Using SNMP to Manage the Switch Table A-22 FxPort Physical Level Table (continued) Fabric Element MIB Provided Object Name Type Access Description FcFxPortPhysOperStatus INTEGER FPM, The current operational status of the FxPort. The SNMP testing(3) indicates that no operational frames can be passed.
Page 256: Fxport Fabric Login Table
128 to 2112 inclusive. FcFxPortCosSuppAgreed FcCosCap Login A variable indicating that the attached Server NxPort has requested the FxPort for the support of classes of services and the FxPort has granted the request. Connectrix ED-64M User Guide A-40...
Page 257: Fxport Fabric Login Table
Using SNMP to Manage the Switch Table A-23 FxPort Fabric Login Table (continued) Provided Fabric Element MIB Object Name Type Access Description FcFxPortIntermixSuppAgreed INTEGER SNMP A variable indicating that the attached NxPort has requested the FxPort for the support of Intermix and the FxPort has granted the request.
Page 258 FC-PH [1] is used between the F_Port and the N_Port. For FL_Ports, the Alternate Buffer-to-Buffer flow control mechanism as defined in FC-AL [4] is used between the FL_Port and any attached NL_Ports. This is fixed at regular(1). Connectrix ED-64M User Guide A-42...
Page 259: Fxport Error Table
Using SNMP to Manage the Switch FxPort Error Table A table that contains one entry for each FxPort, counters that record the numbers of errors detected. FxPort Error Table Table A-24 Fabric Element MIB Object Provided Name Type Access Description fcFxPortErrorFxPortIndex FcFeFxPortIndex SNMP...
Page 260: Class 1 Accounting Table
This value is not supported; therefore it is always zero. FcFxPortC2FbsyFrames Counter PSCC The number of F_BSY frames generated by this FxPort against Class 2 frames. FcFxPortC2FrjtFrames Counter PSCC The number of F_RJT frames generated by this FxPort against Class 2 frames. Connectrix ED-64M User Guide A-44...
Page 261: Class 3 Accounting Table
Using SNMP to Manage the Switch Class 3 Accounting A table that contains one entry for each FxPort in the Fabric Element, Table Class 3 accounting information recorded since the management agent has re-initialized. Class 3 Accounting Table Table A-26 Fabric Element MIB Object Provided Name...
Page 262: Fxport Capability Table
This value is fixed at 1. FcFxPortCapRxDataFieldSizeMax FcRxDataFieldSize SNMP The maximum size in bytes of the Data Field in a frame that the FxPort is capable of receiving from its attached NxPort. This value is fixed at 2112. Connectrix ED-64M User Guide A-46...
Page 263 Using SNMP to Manage the Switch Table A-27 FxPort Capacity Table (continued) Provided Fabric Element MIB Object Name Type Access Description FcFxPortCapRxDataFieldSizeMin FcRxDataFieldSize SNMP The minimum size in bytes of the Data Field in a frame that the FxPort is capable of receiving from its attached NxPort.
Page 264 A value indicating the set of baud rates that the FxPort is capable of supporting. This variable has been deprecated and may be implemented for backward compatibility. FcFxPortCapMedia Fc0MediaCap A value indicating the set of media that the FxPort is capable of supporting. Connectrix ED-64M User Guide A-48...
Page 265: Fibre Alliance Mib (Fcmgmt.mib
Using SNMP to Manage the Switch Fibre Alliance MIB (fcmgmt.mib) Type Definitions FibreAlliance MIB Type Definitions Table A-28 Type Syntax Description FcNameId OCTET STRING (SIZE(8)) Represents the Worldwide Name (WWN; IEEE 60-bitvariety; standard part of T11 definitions for fibre channel) associated with a Fibre Channel (FC) entity. FcGlobalId OCTET STRING (SIZE(16)) Represents the Worldwide Name (WWN;...
Page 266: Connectivity Unit Group
URL to invoke or launch the program referenced. FcConnUnitSnsMaxRows Unsigned32 The number The maximum number of rows in the (Same as entries in the Name fcConnUnitSnsTable table. Gauge). Server Table. Connectrix ED-64M User Guide A-50...
Page 267: Fcconnunittable
Using SNMP to Manage the Switch fcConnUnitTable Contains general information on the system’s units. Table A-30 fcConnUnitTable FA MIB Object Name Type Product Mapping Access Description *fcConnUnitId OCTET STRING Switch WWN The unique identification for this connectivity unit among those within this proxy domain.
Page 268 PCCard, the hub should have an independent ID. FcConnUnitType FcUnitType switch(4) The type of this connectivity unit. FcConnUnitNumports Unsigned32 Number of ports from Number of physical ports in the PROD_CNFG. connectivity unit (internal/embedded, external). Connectrix ED-64M User Guide A-52...
Page 269 Using SNMP to Manage the Switch Table A-30 fcConnUnitTable (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitState INTEGER online and coming-online This object reports the overall state of will indicate online state the connectivity unit. The meaning of all (2), and offline and values is essentially self-explanatory.
Page 270 Writable and persistent between boots. across IPL. FcConnUnitInfo SnmpAdminString A textual description of the Information about this connectivity unit. product. This object value should be persistent between boots. Writable and persistent across IPL. Connectrix ED-64M User Guide A-54...
Page 271 Using SNMP to Manage the Switch Table A-30 fcConnUnitTable (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitControl INTEGER Always return unknown (1) This object is used to control the on read operation. addressed connectivity unit. ResetConnUnitWarmStart NOTE: ‘ColdStart’ and ‘WarmStart’ are (4), offlineConnUnit (5), as defined in mib-2 and are not meant and onlineConnUnit (6) will...
Page 272 The current event index is The last used event id used as the last used event (fcConnUnitEventIndex) recorded in the fcConnUnitEventTable. When no events are presently recorded in the fcConnUnitEventTable, the value of this object MUST be zero. Connectrix ED-64M User Guide A-56...
Page 273: Firmware Table
Using SNMP to Manage the Switch Firmware Table The revisions table lists the revisions supported by the associated connectivity units. Firmware Table Table A-31 FA MIB Object Name Type Product Mapping Access Description *fcConnUnitRevsIndex Unsigned32 Not accessible A unique value among all fcConnUnitRevsEntrys with the same value of fcConnUnitId, in the range between 1 and...
Page 274: Sensor Table
(5) B indicates the unit is non-functional. FcConnUnitSensorInfo SnmpAdminString The serial number of the Miscellaneous static information FRUs. It’s not supported about the sensor such as its serial if the module is failed. number. Connectrix ED-64M User Guide A-58...
Page 275: Sensor Table
Using SNMP to Manage the Switch Table A-32 Sensor Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitSensorMessage SnmpAdminString The textual description This describes the status of the of the FRU status, such sensor as a message. It may also as “active”...
Page 276: The Port Table
(13) – parallel SCSI Gx_Port = gPort(10) port, escon (14) – escon port, lan G_Port = gPort(10) (15) – LAN port, wan (16) – WAN port. Fx_Port = flPort(7) F_Port = fPort(8) E_Port = ePort(9) Connectrix ED-64M User Guide A-60...
Page 277 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortFCClassCap FcPortFCClass If the port is not Bit mask that specifies the classes installed, of service capability of this port. If fcConnUnitPortFCClas this object is not applicable, the sCap = 0...
Page 278 Any value for this object may co-exist with any value for the fcConnUnitPortStatus object. The values are defined as follow: unknown (1), online (2), offline (3), bypassed (4). Connectrix ED-64M User Guide A-62...
Page 279 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortStatus INTEGER Refer to Port State The current overall protocol status Descriptions on for the port. The warning value (4) page A-100.
Page 280 SnmpAdminString Not applicable. The port vendor (e.g., for a GBIC). FcConnUnitPortSpeed Gauge32 Return 100000 The speed of the port in kilobytes kilobytes for 1 Gb/s per second. switches and 200000 kilobytes for 2 Gb/s switches. Connectrix ED-64M User Guide A-64...
Page 281 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortControl INTEGER ResetConnUnitPort(3), This object is used to control the offlineConnUnitPort(6), addressed fcConnUnit’s port. Valid onlineConnUnitPort(7), commands are: and portFailure(42501) Unknown (1) and invalid (2) are are the only only used as values that are read.
Page 282 For Sets specifying varbinds for instances of this object and values not supported by a given implementation, the agent will return the SNMP WrongValue PDU error code. FcConnUnitPortName SnmpAdminString Port Name A string describing the addressed port. Connectrix ED-64M User Guide A-66...
Page 283 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortPhysicalNumber Unsigned32 Physical port number This is the internal port number this from 0 to Maximum port is known by. In many port number –...
Page 284 (3) – FCAL bypass, loop only, active (4) – connected to a device, loopback (5) – Port in ext loopback, txfault (6) – Transmitter fault, noMedia (7) – media not installed, linkDown (8) – waiting for activity (rx sync). Connectrix ED-64M User Guide A-68...
Page 285: The Event Table
Using SNMP to Manage the Switch The Event Table The table of connectivity unit events. Errors, warnings, and information should be reported in this table. Event Table Table A-34 FA MIB Object Name Type Product Mapping Access Description *fcConnUnitEventIndex Unsigned32 An event index.
Page 286 It can be the supported. OID of a connectivity unit or of another object like fcConnUnitPortStatus[...] fcConnUnitEventDescr SnmpAdminString “Reason code XX”, XX The description of the event. is the event reason code. Connectrix ED-64M User Guide A-70...
Page 287: Link Table
Using SNMP to Manage the Switch Link Table The link table is intended to organize and communicate any information the agent which would assist a management application to discover the Connectivity Units in the framework and the topology of their interconnect. That is, the goal is to assist the management application not only to list the elements of the framework, but to map them.
Page 288 F ports. E port SNMP agent then the value of this nodeIdY can be object must be equal to its retrieved from fcConnUnitId. RNID, F port NodeIdY is supported by FLOGI. Connectrix ED-64M User Guide A-72...
Page 289 Using SNMP to Manage the Switch Table A-35 Link Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitLinkPortNumberY Integer32 The attached port The port number on the unit number on the link. specified by This information is fcConnUnitLinkNodeIdY if known, available only for E otherwise –1.
Page 290: Port Statistics Table
The number of frames/packets/Ios/etc that have been received by this port. Note: A Fibre Channel frame starts with SOF and ends with EOF. FC loop devices should not count frames passed through. This value represents the sum total for all other Rx objects. Connectrix ED-64M User Guide A-74...
Page 291 Using SNMP to Manage the Switch Table A-36 Port Statistics Table (continued) FA MIB Object Name Type Access Product Mapping Description FcConnUnitPortStatCountTxElements Counter64 stTxOctets (64 bit counter) The number of octets or bytes that have been transmitted by this port. One second periodic polling of the port.
Page 292 Counter64 Not supported Count of times that FRJT was returned to this port as a result of a Class 1 Frame that was rejected by the fabric. Note, this is a Fibre Channel only stat. Connectrix ED-64M User Guide A-76...
Page 293 Using SNMP to Manage the Switch Table A-36 Port Statistics Table (continued) FA MIB Object Name Type Access Product Mapping Description FcConnUnitPortStatCountClass1PRJTFrames Counter64 Not supported Count of times that FRJT was returned to this port as a result of a Class 1 Frame that was rejected at the destination N_Port.
Page 294 Note, this is a Fibre Channel only stat. FcConnUnitPortStatCountRxOfflineSequences Counter64 stOlssIn (Supports only low 32 bits of Count of Offline Primitive OLS received at this port. Note, this is a Fibre counter; high 32 bits are set to zero). Channel only stat. Connectrix ED-64M User Guide A-78...
Page 295 Using SNMP to Manage the Switch Table A-36 Port Statistics Table (continued) FA MIB Object Name Type Access Product Mapping Description FcConnUnitPortStatCountTxOfflineSequences Counter64 stOlssOut (Supports only low 32 bits of Count of Offline Primitive OLS transmitted by this port. Note, this is a Fibre counter;...
Page 296 2 start and a class 3 at the end. Note, this is a Fibre Channel only stat. FcConnUnitPortStatCountEncodingDisparityErrors Counter64 Not supported. Count of disparity errors received at this port. Note, this is a Fibre Channel only stat. Connectrix ED-64M User Guide A-80...
Page 297: Name Server Table
Using SNMP to Manage the Switch Name Server Table This table is accessed either directly (if the management software has an index value) or via GetNexts. The value of the indexes need not be contiguous. Each entry created in this table will be assigned an index. This relationship is kept presistent until the entry is removed from the table or the system is reset.
Page 298 DisplayString Symbolic port name The Symbolic Port Name of this (SIZE (0..79) entry in the SNS table. fcConnUnitSnsSymbolicNodeName DisplayString Symbolic node name The Symbolic Node Name of (SIZE (0..79)) this entry in the SNS table. Connectrix ED-64M User Guide A-82...
Page 299: Trap Registration Group
Using SNMP to Manage the Switch Trap Registration Group Table A-38 Trap Registration Group FA MIB Object Name Type Product Mapping Access Description fcTrapMaxClients Unsigned32 The maximum number of SNMP The maximum number of SNMP trap trap recipients can be supported recipients supported by the in the system.
Page 300 (6): supplied by a management application wishing to delete an existing conceptual row. Connectrix ED-64M User Guide A-84...
Page 301: Trap Types
Using SNMP to Manage the Switch Trap Types Table A-40 Trap Types FA MIB Object Name Type Product Mapping Number OID and Value Description fcConnUnitStatusChange Generated when the switch’s online status or operational status changes. “.1.3.6.1.2.1.8888.1.1.3.1.6” + unitId The overall status of the connectivity unit has changed. fcConnUnitStatus, “.1.3.6.1.2.1.8888.1.1.3.1.5”...
Page 302: Connectrix Private Enterprise Mib (Fceos.mib
Connectrix Private Enterprise MIB (fceos.mib) private (4) enterprise (1) McDATA (289) commDev (2) fibrechannel fcSwitch (1) fcEos (2) fcEos fcEosZoning fcEosTA (6) fcEosSys (1) fcEosFru (2) fcEosPort (3) PortBinding (4) Private Enterprise MIB Support Figure A-4 Connectrix ED-64M User Guide A-86...
Page 303: Private Enterprise Mib Table
Using SNMP to Manage the Switch The fcEos Private Enterprise MIB defines and supports six groups: System group ( fcEosSys Field replaceable unit (FRU) group ( fcEosFru Fibre Channel port group ( fcEosPort Port binding group ( fcEosPortBinding Zoning group ( fcEosZoning Threshold alert group ( fcEosTA...
Page 304: System Group
The ASCII manufacturer of the switch. (SIZE (1..64)) fcEosSysPlantOfMfg DisplayString McK DEV-TBL The ASCII plant of manufacturer of the (SIZE (1..64)) switch. fcEosSysEcLevel DisplayString McK DEV-TBL The ASCII EC level ID of the switch. (SIZE (1..64)) Connectrix ED-64M User Guide A-88...
Page 305 Using SNMP to Manage the Switch Table A-42 System Group Variables (continued) FCEOS MIB Object Name Type Provided By Access Description fcEosSysSerialNum DisplayString McK DEV-TBL The ASCII system serial number of the (SIZE (1..64)) switch. Returns the switch OEM serial number. fcEosSysOperStatus FcEosSysOperStatus The current operational status of the switch.
Page 306: Fru Table (Module Group
The number of the hours that the FRU has been in DEV-TBL operation. For the fan FRU, the returned value is NULL. fcEosFruTestDate DisplayString The final test date of the module. For the fan FRU, the (SIZE (0..64)) DEV-TBL returned value is NULL. Connectrix ED-64M User Guide A-90...
Page 307: Port Table (Port Group
Using SNMP to Manage the Switch Port Table (Port Group) Table A-44 Port Table FCEOS MIB Object Provid Name Type ed By Access Description fcEosPortIndex fcEosPortIndex SNMP The fixed physical port number on the switch. It ranges from 1 to the number of physical ports that can be supported in the switch.
Page 308 (Primitive signals and primitive sequence are not included.) fcEosPortRxWords32 Counter PSCC A 32 bit counter for the number of words within frames that the port has received. (Primitive signals and primitive sequence are not included.) Connectrix ED-64M User Guide A-92...
Page 309 Using SNMP to Manage the Switch Table A-44 Port Table (continued) FCEOS MIB Object Provid Name Type ed By Access Description fcEosPortTxFrames32 Counter PSCC A 32 bit counter for the number of (Fibre Channel) frames that the port has transmitted. fcEosPortRxFrames32 Counter PSCC...
Page 310 A 64 bit counter for the number of (Fibre Channel) frames (SIZE (8)) that the port has transmitted. fcEosPortRxFrames64 OCTET STRING PSCC A 64 bit counter for the number of (Fibre Channel) frames (SIZE (8)) that the port has received. Connectrix ED-64M User Guide A-94...
Page 311 Using SNMP to Manage the Switch Table A-44 Port Table (continued) FCEOS MIB Object Provid Name Type ed By Access Description fcEosPortTxC2Words64 OCTET STRING PSCC A 64 bit counter for the number of class 2 4-byte words that (SIZE (8)) the port has transmitted.
Page 312: Port Binding Table
The count of zones included in the active zone set. fcEosDefaultZoneSetState ZoneSetState The state of the default zone set fcEosActiveZoneSetState ZoneSetState The state of the active zone set fcEosHardwareEnforcedZoning INTEGER Indicates if zoning is hardware enforced (1=Hardzoning, 0=Nameserver zoning only). Connectrix ED-64M User Guide A-96...
Page 313: Active Zone Table
Using SNMP to Manage the Switch Active Zone Table Table A-47 Active Zone Table FCEOS MIB Object Name Type Provided By Access Description fcEosZoneIndex INTEGER Zone index number. This number will range from 1 to the number of zones specified by the ActiveZoneCount.
Page 314: Threshold Alert Table
INTEGER This only applies when the alert type is a Counter Threshold Alert. It specifies statistical counter or counter set to be monitored. (This object is not supported in the current release.) Connectrix ED-64M User Guide A-98...
Page 315: Enterprise Specific Traps
Using SNMP to Manage the Switch Enterprise Specific Traps Table A-50 Enterprise-Specific Traps Type FCEOS MIB Object Name Number Product Mapping OID and Value Description fcEosPortScn Generated when fcEosPortOpStatus An fcEosPortScn(1) is Fibre Channel port generated whenever a operational state Fc_Port changes its changes.
Page 316: Port State Descriptions
STAT_BLOCKED Offline offline(3) ok(3) active(4) offline(2) The Director port has been configured as “Blocked” and is transmitting the Fibre Channel Offline Sequence (OLS) to the attached device. Connectrix ED-64M User Guide A-100...
Page 317 Using SNMP to Manage the Switch Table A-51 Port State Descriptions (continued) Port Status Used Port State in Connectrix Connectrix Manager Green Amber Internally by Connectrix Manager Alert Symbol Port LEDS Port LEDs Manager FibreAlliance MIB FibreAlliance MIB FibreAlliance MIB connUnitPortState connUnitPortStatus connUnitPortHWState...
Page 318 View, and in the Alert column of the Port List View. It indicates that a corrective action is required to return the port back to a normal operating state. b. connUnitPortState(1)unknown, (2)online, (3)offline, (4)bypassed connUnitPortStatus(1)unknown, (2)unused, (3)ok, (4)warning, (5)failure, (6)notparticipating, (7)initializing, (8)bypassed connUnitPortHWState(1)unknown, (2)failed, (3)bypassed, (4)active, (5)loopback, (6)txfault, (7)noMedia, (8)linkDown c. fcFxPortPhysOperStatus(1)online, (2)offline, (3)testing, (4)link-failure Connectrix ED-64M User Guide A-102...
Page 319: Configuring Network Addresses
Ivisible Body Tag Configuring Network Addresses This appendix describes the procedure for configuring unique addresses for each director. • Configuring Network Addresses ........... B-2 Configuring Network Addresses...
Page 320 If multiple directors/switches, other managed products, and the Connectrix Service Processor are delivered in an EMC EC1200 cabinet, all devices are configured with unique IP addresses that do not require change. The addresses require change only if multiple equipment cabinets are LAN-connected.
Page 321 Configuring Network Addresses If multiple directors/switches (or multiple EC-1200s) are installed or a public LAN segment is used, network addresses must be changed to conform to the customer’s LAN addressing scheme. The following tools are required: A maintenance terminal (desktop or notebook PC) with: •...
Page 322: Connection Description Dialog Box
Figure B-2 6. Ensure that the Connect using field displays COM1 or COM2 (depending on the serial communication port connection to the switch); then click OK. This displays the COM1 (or 2) Properties dialog box (Figure B-3). Connectrix ED-64M User Guide...
Page 323: Com 1, 2 Properties Dialog Box
Configuring Network Addresses Com 1, 2 Properties Dialog Box Figure B-3 7. Configure the Port Settings parameters as follows: • Bits per second — 57600 • Data bits — 8 • Parity — None • Stop bits — 1 • Flow control — Hardware When the parameters are set, click OK.
Page 324: Hyperterminal Window
10. Change the IP address, subnet mask, and gateway address as directed by the customer’s network administrator. To change the director’s network addresses, type the following at the { }> prompt and press NTER ipconfig xxx.xxx.xxx.xxx yyy.yyy.yyy.yyy zzz.zzz.zzz.zzz Connectrix ED-64M User Guide...
Page 325 Configuring Network Addresses The IP address is always , the subnet mask is xxx.xxx.xxx.xxx always , and the gateway address is always yyy.yyy.yyy.yyy , where the octets , and zzz.zzz.zzz.zzz decimals, 0 through 255. If a network address is to remain unchanged, type the current address in the respective field.
Page 326 Configuring Network Addresses Connectrix ED-64M User Guide...
Page 327: Port Card Map
Invisible Body Tag Port Card Map This appendix contains a diagram of physical port numbering in the ED-64M, in the following section: • Port Numbering ................C-2 Port Card Map...
Page 328: Port Numbering
Connectrix Manager, and the smaller numbers represent logical addresses (in hexadecimal notation) as they will be displayed by Symmetrix and/or a Fibre Channel analyzer. P15 P14 P13 P12 P11 P10 P9 Figure C-1 ED-64M Port Card Map Connectrix ED-64M User Guide...
Page 329: Configuring Embedded Web Server Passwords
Ivisible Body Tag Configuring Embedded Web Server Passwords This appendix describes the procedures for configuring passwords for the Embedded Web Server in the ED-64M. • Introduction ..................D-2 • Configuring Passwords..............D-5 Configuring Embedded Web Server Passwords...
Page 330: Introduction
ED-64M via the EWS. Therefore, if you configure the ED-64M with a public IP address, EMC recommends that the EWS be disabled, using Connectrix Manager. If you intend to use the EWS (even though EMC does recommend and/or support its use), verify that it is enabled in Connectrix Manager;...
Page 331: Opening The Web Server Application
Configuring Embedded Web Server Passwords Opening the Web To open the Web Server application: Server Application 1. Ensure that the PC and the Ethernet LAN segment (with the director attached) are connected through the Internet. 2. At the PC, launch the browser application. 3.
Page 332: Web Server Interface - View Window
Configuring Embedded Web Server Passwords Web Server Interface — View Window Figure D-2 The Name is taken from the director configuration. Connectrix ED-64M User Guide...
Page 333: Configuring Passwords
Configuring Embedded Web Server Passwords Configuring Passwords The operation described here allows you to to configure the administrator-level and operator-level passwords (as specified by the customer’s network administrator) used to access the Embedded Web Server application. 1. Click Configure at the left side of the Web Server interface. 2.
Page 334 Configuring Embedded Web Server Passwords Connectrix ED-64M User Guide...
Page 335: Command Line Interface
Invisible Body Tag Command Line Interface This appendix describes the commands that can be entered through the command line interface (CLI) for the ED-64M. Access through a Telnet client is presumed. Telnet Sessions ................... E-2 CLI Overview ..................E-3 The config Branch ................E-16 maint ....................
Page 336: Telnet Sessions
Open an Embedded Web Server or Connectrix Manager Product Manager window. c. Toggle the enabled state of the CLI, thereby clearing the client connection. d. Restart the client connection. Once the client connection is reestablished, verify your configuration’s completeness and accuracy. Connectrix ED-64M User Guide...
Page 337: Cli Overview
Because the CLI is not an interactive interface, no prompts are displayed to guide the user through a task. If an interactive interface is needed, use the Connectrix Manager or Embedded Web Server. For day-to-day operations, EMC recommends using the Connectrix Manager, not the CLI, unless absolutely necessary. CLI Overview...
Page 338: Entering Cli Commands
CLI. Therefore, if you configure the director with a public IP address, EMC recommends that the CLI be disabled, using Connectrix Manager. If you intend to use the CLI (even though EMC does recommend and/or support its use), verify that it is enabled in Connectrix Manager;...
Page 339 Command Line Interface Navigation Basic command line navigation conventions are supported. Table E-1 Conventions includes the asynchronous commands that are recognized by the CLI. Table E-1 CLI Command Tree Navigation Conventions Character Sequence Common Name Action or Description <CR> Carriage Return Pass a completed line to the parser.
Page 340: Cli Command Tree Navigation Conventions
CLI Command Tree Table E-2 config -------------------- enterpriseFabMode setState features ----------------- installKey enterpriseFabMode ficonMS openSysMS show ficonMS ----------------- setState ip -------------------------- ethernet show port ----------------------- blocked extDist name speed Connectrix ED-64M User Guide...
Page 341 Command Line Interface Table E-2 CLI Command Tree (continued) show type openSysMS ----------- setState security ----------------- fabricBinding ----------- activatePending addMember clearMemList deleteMember replacePending setState showActive showPending portBinding ------------- bound show switchBinding ---------- addMember deleteMember setState show userRights -------------- administrator operator show snmp --------------------- addCommunity authTraps...
Page 342 ------------------- setDefZoneState activateZoneSet deactivateZoneSet replaceZoneSet clearZoneSet addZone deleteZone renameZoneSet addWwnMem addPortMem clearZone deleteWwnMem deletePortMem renameZone showPending showActive maint --------------------- port ----------------------- beacon reset system ------------------ beacon clearSysError resetConfig setOnlineState perf ----------------------- class2 class3 clearStats errors link traffic Connectrix ED-64M User Guide...
Page 343 Command Line Interface Table E-2 CLI Command Tree (continued) thresholdAlerts -------- setState deleteAlert counter ------------------ addAlert addPort removePort setCounter setParams show show --------------------- eventLog features frus ip -------------------------- ethernet loginServer nameServer nameServerExt port ----------------------- config info status technology security ----------------- fabricBinding portBinding switchBinding switch...
Page 344 Because the command is not recorded in the history, a subsequent asynchronous command (navigation command) cannot depend on it. Root> config zoning addWwnMem TheUltimateZone 10:00:00:00:C9:22:9B:64 Connectrix ED-64M User Guide E-10...
Page 345: Login
Command Line Interface Root> Whenever the position in the CLI command tree moves to a new branch (for example, config to maint, config to config.port, or config.port to config), the history log is cleared. In this case, any asynchronous commands (for example, the up-arrow command <ESC>[A or the up-arrow keyboard symbol) cannot move the position back towards the root, as shown in this example: Root>...
Page 346: Logout
The CLI does not require that the user names and passwords set through the CLI commands match those set through the director’s Embedded Web Server. Parameters This command has no parameters. Command Examples login Username: Administrator Password: password login Username: Operator Password: password logout Syntax logout Connectrix ED-64M User Guide E-12...
Page 347: Commadelim
Command Line Interface Purpose This command allows a Telnet client to disconnect from the director. Description This command logs out the single Telnet client connected to the director. This command can be entered at any point in the command tree. Parameters This command has no parameters.
Page 348: Handling Command Line Interface Errors
- password <password> If the question mark is used after one or more characters of a keyword, any keywords at that level of the CLI command tree appear. Root> config s? security snmp switch system Connectrix ED-64M User Guide E-14...
Page 349: Commenting Scripts
Command Line Interface Commenting Scripts The pound sign (#) can be used to add comments in a script file. The pound sign must be the first character in the line; the CLI ignores everything after the pound sign in that line. The following lines are valid: Root>...
Page 350: The Config Branch
Syntax setState enterpriseFabModeState Purpose This command sets the Enterprise Fabric Mode state for the fabric. The EMC Enterprise Fabric Extensions feature key must be installed to activate the Enterprise Fabric Mode state. Parameters This command has one parameter: Specifies whether entrepriseFabMode enterpriseFabModeState is active.
Page 351: Config.features.installkey
Syntax enterpriseFabMode enterpriseFabModeState Purpose This command sets the Enterprise Fabric Mode state for the fabric. The EMC Enterprise Fabric Extensions feature key must be installed to activate the Enterprise Fabric Mode state. Parameters This command has one parameter: Specifies whether entrepriseFabMode enterpriseFabModeState is active.
Page 352: Config.features.ficonms
This command sets the enabled state of the Open Systems Management Server. The Open Systems Management Server feature key must be installed in order to enable the openSysMS State. If the FICON Management Server is enabled, the Open Systems Management style cannot be used. Connectrix ED-64M User Guide E-18...
Page 353: Config.features.show
Command Line Interface Parameters This command has one parameter. Specifies whether the Open Systems osmsState Management Server is enabled. Valid values are enable and disable. Boolean 1 and 0 may be substituted as values. Command Example Root> config features openSysMS 1 config.features.show Syntax show...
Page 354: Config.ficonms.setstate
The Telnet connection can be lost when these Ethernet network settings are changed. If the IP address is reconfigured, your Telnet client must be reconnected to the new IP address. A new login will be requested. Connectrix ED-64M User Guide E-20...
Page 355: Config.ip.show
Command Line Interface Parameters This command has three parameters: Specifies the new IP address for the director. ipAddress The address must be entered in dotted decimal format (for example, 10.0.0.0). Specifies the new gateway address for the gatewayAddress Ethernet interface. The address must be entered in dotted decimal format (for example, 0.0.0.0).
Page 356: Config.port.extdist
0 may be substituted as values. Command Examples Root> config port extDist 4 false Root> config port extDist 4 0 config.port.name Syntax name portNumber “portName” Purpose This command sets the name for a port. Connectrix ED-64M User Guide E-22...
Page 357: Config.port.speed
Command Line Interface Parameters This command has two required parameters: Specifies the port number. Valid values for the portNumber ED-64M are 0 through 63. Specifies the name for the port. The port name portName must not exceed 24 characters in length. Command Example Root>...
Page 358: Config.port.type
ED-64M are 0 through 63. Command Example Root> config port show 4 Output The port configuration is displayed as a table that includes the following properties: Port number Port name Blocked state — true or false Connectrix ED-64M User Guide E-24...
Page 359: Config.opensysms.setstate
Command Line Interface Extended distance — true or false Type — F Port, E Port, or G Port Speed — 1 Gb/sec, 2 Gb/sec, or Negotiate Output Example The output of config.port.show appears as in this example: Port Number: Name: Sam’s tape drive Blocked: false...
Page 360: Config.security.fabricbinding.activatepending
This command takes effect immediately. The CLI verifies the list before activating it to the fabric and adds the managed switch to the list if it is not already present. Parameters This command has no parameters. Root> config security fabricBinding activatePending Connectrix ED-64M User Guide E-26...
Page 361: Config.security.fabricbinding.addmember
Command Line Interface config.security.fabricBinding.addMember Syntax addMember wwn domainId Purpose This command adds a new member to the Fabric Member List in the pending fabric binding work area. The number of entries is limited to the maximum available domain IDs for the fabric (31). Changes from this command are not activated to the fabric until the activatePending command is issued.
Page 362: Config.security.fabricbinding.deletemember
Root> config security fabricBinding deleteMember 2 config.security.fabricBinding.replacePending Syntax replacePending Purpose This command replaces the pending working area with the fabric binding configuration that is currently loaded on the fabric. Parameters This command has no parameters. Root> config security fabricBinding replacePending Connectrix ED-64M User Guide E-28...
Page 363: Config.security.fabricbinding.setstate
Command Line Interface config.security.fabricbinding.setState Syntax setState fabricBindingState Purpose This command sets the fabric binding state for the pending fabric binding configuration work area. This state is not saved to the fabric until the activatePending command is issued. Parameters This command has one parameter: Specifies the fabric binding state for the fabricBindingState pending fabric binding configuration work...
Page 364: Config.security.fabricbinding.showactive
If no changes have been made to the pending environment, the CLI displays the active membership list. Parameters This command has no parameters. Connectrix ED-64M User Guide E-30...
Page 365: Config.security.portbinding.bound
Command Line Interface Output The fabric binding configuration data is displayed as a table that includes the following properties. Fabric Binding The pending fabric binding state: Inactive or State Active Restricting fabric The pending fabric membership list. membership list Output Example The output from the config.security.fabricBinding.showPending command displays as follows.
Page 366 If the boundWwn is configured and the portBindState is: Active — Only the device described by boundWwn is able to connect to the specified port. Inactive — The WWN is retained, but any device can connect to the specified port. Connectrix ED-64M User Guide E-32...
Page 367: Config.security.portbinding.show
Command Line Interface Instead of the WWN, either of two values can be boundWwn entered in this parameter: (continued) attached — Automatically configures the currently attached device WWN as the bound WWN. remove — Changes the WWN to the default value, 00:00:00:00:00:00:00:00.
Page 368: Config.security.switchbinding.addmember
Root> config security switchBinding addMember AA:99:23:23:08:14:88:C1 config.security.switchBinding.deleteMember Syntax deleteMember wwn Purpose This command removes a member from the Switch Member List. The user cannot remove a member that is currently logged in to the director. Connectrix ED-64M User Guide E-34...
Page 369: Config.security.switchbinding.setstate
Command Line Interface Parameters This command has one parameter: Specifies the switch or N_Port device WWN of the member to be removed from the switch membership list. The value of the WWN must be in colon-delimited hexadecimal notation (for example, AA:00:AA:00:AA:00:AA:00). The user may also enter all for this argument to clear the switch membership list completely.
Page 370 — Enable switch binding and restrict E_Port and F_Port connections. Both E_Ports and F_Ports prohibit connections with all devices unless explicitly identified in the switch membership list. Root> config security switchBinding setState allRestrict Connectrix ED-64M User Guide E-36...
Page 371: Config.security.switchbinding.show
Command Line Interface config.security.switchBinding.show Syntax show Purpose This command displays the switch binding configuration. Parameters This command has no parameters. Output This command displays the following switch binding configuration data: Disabled switchBindingState Enabled and Restricting F_Ports Enabled and Restricting E_Ports Enabled and Restricting All Ports.
Page 372: Config.security.userrights.operator
The default is set to password. This parameter is 1 to 15 characters. Valid characters include all characters in the USASCII character set, excluding control characters. Command Example Root> config security userRights operator “Operator” “newpassword” Connectrix ED-64M User Guide E-38...
Page 373: Config.security.userrights.show
Command Line Interface config.security.userRights.show Syntax show Purpose This command shows the user rights for the CLI access levels. Parameters This command has no parameters. Command Example Root> config security userRights show Output The user rights configuration data is displayed as a table, as shown in the following example.
Page 374: Config.snmp.authtraps
Root> config snmp addCommunity 1 "CommunityName1" enabled 123.123.123.123. 162 config.snmp.authTraps Syntax authTraps enabledState Purpose This command enables or disables the authorization traps to be sent to SNMP management stations when unauthorized stations try to access SNMP information from the director. Connectrix ED-64M User Guide E-40...
Page 375: Config.snmp.deletecommunity
Command Line Interface Parameters This command has one parameter. Specifies whether the authorization traps are enabledState enabled. Valid values are true and false. Boolean 1 or 0 may be substituted as values. Command Examples Root> config snmp authTraps true Root> config snmp authTraps 1 config.snmp.deleteCommunity Syntax deleteCommunity commIndex...
Page 376: Config.switch
This command sets the buffer-to-buffer credit value for all ports, except those ports configured for extended distance. Description The director must be off line before issuing this command. Use maint.system.setOnlineState to set the director off line. Connectrix ED-64M User Guide E-42...
Page 377: Config.switch.domainrscn
Command Line Interface Parameters This command has one parameter. Specifies the new buffer-to-buffer credit value. bbCreditValue This parameter must be an integer in the range 1 through 60. Command Example Root> config switch bbCredit 2 config.switch.domainRSCN Syntax domainRSCN domainRSCNState Purpose This command sets the domain RSCN state for the director.
Page 378: Config.switch.edtov
Parameters This command has one parameter. Specifies the interoperability mode. Valid interopMode values are mcdata (McDATA Fabric 1.0) and open (Open Fabric 1.0) Command Example Root> config switch interopMode open Connectrix ED-64M User Guide E-44...
Page 379: Config.switch.prefdomainid
Command Line Interface config.switch.prefDomainId Syntax prefDomainId domainId Purpose This command sets the preferred domain ID for the director. Description The director must be off line before issuing this command. Use maint.system.setOnlineState to set the director off line. Parameters This command has one parameter. Specifies the new preferred domain ID value.
Page 380: Config.switch.ratov
This command sets the R_A_TOV for the director. Description The director must be off line before issuing this command. Use maint.system.setOnlineState to set the director off line. Special care should be used when scripting this command due to its relationship with E_D_TOV. Connectrix ED-64M User Guide E-46...
Page 381: Config.switch.reroutedelay
Command Line Interface Parameters This command has one parameter. Specifies the new R_A_TOV value. The units for timeoutValue this value are tenths of a second. This parameter must be an integer in the range 10 through 1200 (1 second to 120 seconds), and it must be larger than the E_D_TOV.
Page 382: Config.switch.show
Speed — Data rate set on the director. Rerouting Delay — A delay that ensures that frames are delivered in order through the fabric to their destination. Values are Enabled or Disabled. Interop Mode — Interoperability mode for the director. Connectrix ED-64M User Guide E-48...
Page 383: Config.switch.zoningrscn
Command Line Interface Insistent Domain ID — When enabled, ensures that the embedded firmware cannot change a switch's preferred domain Domain RSCN — When enabled, allows domain RSCNs to be sent to registered members of the fabric. Zoning RSCN — When enabled, allows zoning RSCNs to be sent to registered members of the fabric.
Page 384: Config.system.contact
This command sets the system contact attribute. Parameters This command has one parameter. Specifies the new system contact string for the systemContact director. The contact can contain up to 255 characters. Command Example Root> config system contact “Joe” Connectrix ED-64M User Guide E-50...
Page 385: Config.system.date
Command Line Interface config.system.date Syntax date sysDate sysTime Purpose This command sets the system date and time. Parameters This command has two required parameters. Specifies the new system date. The format of the sysDate date parameter must be mm:dd:yyyy or mm/dd/yyyy.
Page 386: Config.system.location
Purpose This command shows the system configuration. Parameters This command has no parameters. Command Example Root> config system show Output The system configuration is displayed as a table similar to that shown under Output Examples. Connectrix ED-64M User Guide E-52...
Page 387: Config.zoning
Command Line Interface Output Examples The output from config.system.show appears as shown in the following example: Name: Joe’s director Description: ED-64M Fibre Channel Director Contact: Location: Everywhere Date/Time: 04/16/2001 10:34:01 config.zoning Note that the config.zoning commands function in a different way from most other CLI commands, which are single action commands that take effect immediately.
Page 388: Config.zoning.activatezoneset
Root> config zoning deactiveZoneSet config.zoning.replaceZoneSet Syntax replaceZoneSet Purpose This command replaces the work area with the active zone set that is currently loaded on the fabric. Parameters This command has no parameters. Command Example Root> config zoning replaceZoneSet Connectrix ED-64M User Guide E-54...
Page 389: Config.zoning.clearzoneset
Command Line Interface config.zoning.clearZoneSet Syntax clearZoneSet Purpose This command clears the zone set contained in the work area, removing all zones, and takes effect immediately. Description This command does not change the zone set name. Parameters This command has no parameters. Command Example Root>...
Page 390: Config.zoning.deletezone
Specifies the new name for the zone set. The zoneSetName zoneSetName must contain 1 to 64 characters. Valid characters are: ABCDEFGHIJKLMNOPQRSTUVWXYZabcd efghijklmnopqrstuvwxyz0123456789$-^_ Spaces are not permitted, and the first character must be alphabetical. Command Example Root> config zoning renameZoneSet TheUltimateZoneSet Connectrix ED-64M User Guide E-56...
Page 391: Config.zoning.addwwnmem
Command Line Interface config.zoning.addWwnMem Syntax addWwnMem “zoneName” wwn Purpose This command adds a World Wide Name zone member to the specified zone in the work area. Description The CLI supports the number of zones members per zone specified for a given product. Parameters This command has two parameters.
Page 392: Config.zoning.clearzone
Specifies the World Wide Name of the member to be deleted from the zone. The value of the WWN must be in colon-delimited hexidecimal notation (for example, AA:00:AA:00:AA:00:AA:00). Command Example Root> config zoning deleteWwnMem TheNotSoUltimateZone 10:00:00:00:C9:22:9B:AB Connectrix ED-64M User Guide E-58...
Page 393: Config.zoning.deleteportmem
Command Line Interface config.zoning.deletePortMem Syntax deletePortMem “zoneName” domainId portNumber Purpose This command deletes a domain ID and port number for a zone member in the specified zone in the work area. Parameters This command has three parameters. Specifies the name of the zone that contains the zoneName member to be deleted.
Page 394: Config.zoning.showpending
Parameters This command has no parameters. Command Example Root> config zoning showActive Output The zoning configuration data is displayed as a table that includes the enabled/disabled status, name, and member zones of the zone set. Connectrix ED-64M User Guide E-60...
Page 395 Command Line Interface Output Example The output from config.zoning.showActive is similar to the following: Active Zone Set Default Zone Enabled: False ZoneSet: TheUltimateZoneSet Zone: TheUltimateZone ZoneMember: Domain 10, Port 6 ZoneMember: Domain 15, Port 2 ZoneMember: Domain 2, Port 63 ZoneMember: 10:00:00:00:C9:22:9B:64 ZoneMember: 10:00:00:00:C9:22:9B:BD Zone:...
Page 396: Maint
This command resets an individual port without affecting any other ports. However, if a device is attached to the port and the device is online, the reset causes a link reset to occur. If the port is in a failed Connectrix ED-64M User Guide E-62...
Page 397: Maint.system.beacon
Command Line Interface state (that is, after failing a loopback test), the reset restores the port to an operational state. The reset also clears all statistics counters and disables port beaconing for the specified port. Parameters This command has one parameter. Specifies the port number to be reset.
Page 398: Maint.system.ipl
The default values are set in the firmware of the director. Parameters This command has no parameters. Command Example Root> maint system resetConfig maint.system.setOnlineState Syntax setOnlineState onlineState Purpose This command sets the director on line or off line. Connectrix ED-64M User Guide E-64...
Page 399 Command Line Interface Parameters This command has one parameter. Specifies whether the director is on line. Valid onlineState values are true and false. Boolean 1 or 0 may be substituted as values. Command Examples Root> maint system setOnlineState true Root> maint system setOnlineState 1 maint E-65...
Page 400: Perf
Rx Words — The number of Class 2 4-byte words within frames the port has received. TX Words — The number of Class 2 4-byte words within frames the port has transmitted. Connectrix ED-64M User Guide E-66...
Page 401: Perf.class3
Command Line Interface Busied Frms — The number of times that FBSY was returned to this port as a result of a Class 2 frame that could not be delivered to the other end of the link. This occurs if either the fabric or the destination port is temporarily busy.
Page 402: Perf.clearstats
This command resets all port statistics for an individual port or for all ports. Parameters This command has one parameter. Specifies the port number to be reset. Valid portNumber values for the ED-64M are 0 through 63. Command Example Root> perf clearStats 4 Root> perf clearStats all Connectrix ED-64M User Guide E-68...
Page 403: Perf.errors
Command Line Interface perf.errors Syntax errors Purpose This command displays port error counters for a single port. Parameters This command has one parameter. Specifies the port number to be reset. Valid portNumber values for the ED-64M are 0 through 63. Command Example Root>...
Page 404: Perf.link
Link Flrs — The number of times the port has detected a link error resulting from an invalid link state transition or timeout. Sync Losses — The number of times the port has detected a loss of synchronization timeout while not in an offline or LF2 state. Connectrix ED-64M User Guide E-70...
Page 405: Perf.thresholdalerts
Command Line Interface Sig Losses — The number of times the port has detected a loss of signal while not in an offline or LF2 state. Output Example The output from perf.link is similar to the following: Port 2 Statistic Count ----------- ----------...
Page 406: Threshold Alert Counters
Link Sequence Counts Set (refer to Summed Sets) Logical Link Errors Set (refer to Summed Sets) Summed Sets Some of the threshold alerts consist of groups of related items called summed sets. When any items in the summed set is encountered, the Connectrix ED-64M User Guide E-72...
Page 407 Command Line Interface total value of the summed set counter is incremented. The items that make up the summed sets are: Physical Link Errors Summed Set • Link Failures • Sync Losses • Signal Losses • Protocol Errors • Invalid Tx Words •...
Page 408: Perf.thresholdalerts.counter.addport
Valid values for the ED-64M are eport and fport. A counter threshold alert is not allowed to specify both port types and individual port numbers. Command Example Root> perf thresholdAlerts counter addPort linkresets 12 Connectrix ED-64M User Guide E-74...
Page 409: Perf.thresholdalerts.counter.deletealert
Command Line Interface perf.thresholdAlerts.counter.deleteAlert Syntax deleteAlert name Purpose This command deletes a specified counter threshold alert. Parameters This command has one parameter. The name of a counter threshold alert as name defined by the command perf.thresholdAlerts.counter.addAlert. (Refer to perf.thresholdAlerts.counter.addAlert on page E-73.) Command Example Root>...
Page 410: Perf.thresholdalerts.counter.setcounter
1 perf.thresholdAlerts.counter.setParams Syntax setParams name increment interval Purpose This command sets the increment and interval times for a specified counter threshold alert. An alert cannot be modified unless it is in the disabled state. Connectrix ED-64M User Guide E-76...
Page 411 Command Line Interface Parameters This command has the following parameters. The name of a counter threshold alert as name defined by the command perf.thresholdAlerts.counter.addAlert. (Refer to perf.thresholdAlerts.counter.addAlert on page E-73.) This sets the number of times a counter must increment increment during the interval period to trigger the alert.
Page 412: Perf.thresholdalerts.counter.show
This command displays the table of different statistic counters that can be added to a counter threshold alert. This table is used for reference only. This command has no parameters. Command Example Root> perf ThreshAlerts counter showStatisticTable Connectrix ED-64M User Guide E-78...
Page 413: Perf.thresholdalerts.setstate
Command Line Interface Output Example The output from perf.traffic is similar to the following: Number Counter or Counter Set ------ ---------------------- Link Resets Sent Link Resets Received OLS Sent OLS Received Link Failures Sync Losses Signal Losses Protocol Errors Invalid Tx Words CRC Errors Discarded Frames Frames Too Short...
Page 414: Perf.traffic
Tx Words — The number of 4-byte words in Class 2 and Class 3 frames that the port has transmitted. Output Example The output from perf.traffic is similar to the following: Port 2 Statistic Wrap Count ----------- ---------- ---------- RxFrames 2953184 TxFrames 1842953 RxWords 2953184 TxWords 1842953 Connectrix ED-64M User Guide E-80...
Page 415: Show
Command Line Interface show The show branch of the CLI command tree contains commands that display, but do not change, stored data values.The displayed output that results from these commands might not be identical to the output from the show commands that are within the other CLI command tree branches;...
Page 416: Show.features
The output from the show.features command displays as follows. Installed Feature Set Feature State ---------------------------- --------------- ---- Open Systems Management Server OSMS Enabled Enterprise Fabric Extensions Fabric Binding Active Enterprise Fabric Extensions Switch Binding Enabled Enterprise Fabric Extensions Enterprise Fabrics Active Connectrix ED-64M User Guide E-82...
Page 417: Show.frus
Command Line Interface show.frus Syntax frus Purpose This command displays information about all FRUs. Parameters This command has no parameters. Command Example Root> show frus Output The FRU information is displayed as a table that includes the following properties. FRU — The FRU name. means the Unknown Not Installed...
Page 418: Show.ip.ethernet
Subnet Mask — The subnet mask for the Ethernet adapter as set in the config.lan.subnetMask command. Output Example The output from show.ip.ethernet is similar to the following: LAN Information IP Address: 144.49.10.15 Gateway Address: 144.49.10.1 Subnet Mask: 255.255.255.0 Connectrix ED-64M User Guide E-84...
Page 419: Show.loginserver
Command Line Interface show.loginServer Syntax loginServer Purpose This command displays information from the login server database for devices attached to this director. Parameters This command has no parameters. Command Example Root> show loginServer Output The device information is displayed as a table that includes the following properties: Port —...
Page 420: Show.nameserver
COS — The class of service (for example, 1; 2; 3; 4; 5; 6; F; 1,2; 2,3). FC4 Types — The FC4 types registered for this device. The numbers in this field correspond to the list at the bottom of the table. Connectrix ED-64M User Guide E-86...
Page 421 Command Line Interface Output Example The output from show.nameServer is similar to the following: Type Port Id Port Name Node Name FC4 Types ---- ------- ----------------------- ----------------------- --------- 010400 00:11:22:33:44:55:66:77 20:11:22:33:44:55:66:77 010500 00:11:22:33:44:55:66:78 20:11:22:33:44:55:66:78 010600 00:11:22:33:44:55:66:79 20:11:22:33:44:55:66:79 010700 00:11:22:33:44:55:66:80 20:11:22:33:44:55:66:80 010800 00:11:22:33:44:55:66:81 20:11:22:33:44:55:66:81...
Page 422: Show.nameserverext
FC4 Types — The FC4 types registered for this device. The numbers in this field correspond to the list at the bottom of the table. SymNodeName — 255-character representation of the Symbolic Node Name. SymPortName — 255-character representation of the Symbolic Port Name. Connectrix ED-64M User Guide E-88...
Page 423: Show.port.config
Command Line Interface Output Example The output from show.nameServerExt is similar to the following: Type, Port Id, Port Name, Node Name, COS, FC4 Types, SymNodeName, SymPortName, 010400, 00:11:22:33:44:55:00:77, 20:11:22:33:44:55:66:77, 2-3, 2, Node Name A, Port Name A, 010500, 00:11:22:33:44:55:01:77, 20:11:22:33:44:55:66:77, 2-3, 0, This Is Symbolic Node Name B, Symbolic Port Name B Is Slightly Longer N, 010600, 00:11:22:33:44:55:66:02, 20:11:22:33:44:55:66:77, 2-3, 2, , ,...
Page 424: Show.port.info
Port — The port number. WWN — The World Wide Name of the port. OpSpeed — The current operating speed (1 Gb/sec, 2 Gb/sec, or Not Established). SpeedCap — The current transceiver capability speed (1 Gb/sec or 2 Gb/sec). Connectrix ED-64M User Guide E-90...
Page 425: Show.port.status
Command Line Interface Output Example The output from show.port.info is similar to the following: Port OpSpeed SpeedCap ---- ----------------------- -------- -------- 10:00:80:00:11:22:33:44 1 Gb/sec 2 Gb/sec 10:00:80:01:11:22:33:44 1 Gb/sec 2 Gb/sec 10:00:80:02:11:22:33:44 1 Gb/sec 2 Gb/sec 10:00:80:03:11:22:33:44 1 Gb/sec 2 Gb/sec 10:00:80:04:11:22:33:44 2 Gb/sec 2 Gb/sec...
Page 426 13 = External loopback adapter connected to the port 14 = N_Port connection not allowed on this port 15 = Non-EMC switch at other end of the ISL 16 = ISL connection not allowed on this port 17 = ISL connection not allowed to external fabrics 18 = Port binding violation—unauthorized WWN...
Page 427 Command Line Interface 21 = Fabric Binding violation 22 = Authorization failure 23 = Switch Binding violation • If the operational state is Inactive: 24 = Inactive – RC 0 25 = No Serial Number 26 = Feature Not Enabled Output Example The output from show.port.status is similar to the following: Port...
Page 428: Show.port.technology
Lng LC Long M-M 50um Long LC Long M-M 50um Long LC Long M-M 50um Long LC Long M-M 50um Long LC Long M-M 50um Long LC Long M-M 50um Long LC Long M-M 50um Connectrix ED-64M User Guide E-94...
Page 429: Show.security.fabricbinding
Command Line Interface show.security.fabricBinding Syntax fabricBinding Purpose This command displays the fabric binding configuration saved on the fabric. The command performs the same function as config.security.fabricBinding.showActive. Parameters This command has no parameters. Command Example Root> show security fabricBinding Output The fabric binding configuration data is displayed as a table that includes the following properties.
Page 430: Show.security.switchbinding
Inactive 00:00:00:00:00:00:00:00 Inactive 00:00:00:00:00:00:00:00 Inactive 00:00:00:00:00:00:00:00 Inactive 00:00:00:00:00:00:00:00 Inactive 00:00:00:00:00:00:00:00 Inactive 00:00:00:00:00:00:00:00 show.security.switchBinding Syntax switchBinding Purpose This command displays the switch binding configuration. Parameters This command has no parameters. Command Example Root> show security switchBinding Connectrix ED-64M User Guide E-96...
Page 431: Show.switch
Command Line Interface Output The switch binding configuration data is displayed as a table that includes the following properties. Switch Binding Disabled State Enabled and Restricting F_Ports Enabled and Restricting E_Ports Enabled and Restricting All Ports Switch The active switch membership list. Membership List Output Example The output from the show.security.switchBinding command appears...
Page 432 Switch Priority: Default Speed: 2 Gb/sec Rerouting Delay: Enabled Operating Mode: Open Systems Interop Mode: Open Fabric 1.0 Active Domain Id: World Wide Name: 10:00:08:00:88:00:21:07 Insistent Domain Id: Enabled Domain RSCN: Enabled Zoning RSCN: Enabled Connectrix ED-64M User Guide E-98...
Page 433: Show.system
Command Line Interface show.system Syntax system Purpose This command displays a set of system attributes. Parameters This command has no parameters. Command Example Root> show system Output The system attributes are displayed as a table that includes the following properties. Name —...
Page 434: Show.thresholdalerts.alert
• Tx Util — (TTA) Transmit Utilization • Rx Util — (TTA) Receive Utilization • Tx/Rx Util — (TTA) Transmit or Receive Utilization • Link Resets Sent — (CTA) Link Resets Sent • Link Resets Received — (CTA) Link Resets Received Connectrix ED-64M User Guide E-100...
Page 435 Command Line Interface • OLS Sent — (CTA) OLS Sent • OLS Received — (CTA) OLS Received • Link Failures — (CTA) Link Failures • Sync Losses — (CTA) Sync Losses • Signal Losses — (CTA) Signal Losses • Protocol Errors — (CTA) Primitive Sequence Errors/Protocol Errors •...
Page 436: Show.thresholdalerts.log
• Link Failures — (CTA) Link Failures • Sync Losses — (CTA) Sync Losses • Signal Losses — (CTA) Signal Losses • Protocol Errors — (CTA) Primitive Sequence Errors/Protocol Errors • Invalid Tx Words — (CTA) Invalid Tx Words Connectrix ED-64M User Guide E-102...
Page 437: Show.zoning
Command Line Interface • CRC Errors — (CTA) CRC Errors • Discarded Frames — (CTA) Discarded Frames • Frames Too Short — (CTA) Frames Too Short • Delimiter Errors — (CTA) Delimiter Errors • Address ID Errors — (CTA) Address ID Errors •...
Page 438 TheUltimateZone ZoneMember: Domain 10, Port 6 ZoneMember: Domain 15, Port 2 ZoneMember: Domain 2, Port 63 ZoneMember: 10:00:00:00:C9:22:9B:64 ZoneMember: 10:00:00:00:C9:22:9B:BD Zone: TheNotSoUltimateZone ZoneMember: 10:00:00:00:C9:22:9B:AB ZoneMember: 10:00:00:00:C9:22:9B:C6 ZoneMember: 10:00:00:00:C9:22:9B:AB Zone: TheNotUltimateAtAllZone ZoneMember: Domain 2, Port 63 Connectrix ED-64M User Guide E-104...
Page 439: Specifications
Invisible Body Tag Specifications This appendix lists the physical characteristics and operating environment of the ED-64M. Specifications ..................F-2 Specifications...
Page 440 Consumption • 220Vrms Irms = 2.43 A Power for the ED-64M is provided by the EMC EC-1200 Connectrix cabinet. Refer to the specification for the EC-1200 cabinet in the Connectrix Enterprise Storage Network System Planning Guide. Connectrix ED-64M User Guide...
Page 441 Specifications Storage and Protective packaging must be provided to protect the DS-16M Shipping under all shipping methods (domestic and international). Environment ° ° ° ° Shipping Temperature F to 140 F (-40 C to 60 ° ° ° ° Storage Temperature F to 140 F (1 C to 60...
Page 442 Specifications Connectrix ED-64M User Guide...
Page 443 Body Tag Customer Support This appendix reviews the EMC process for detecting and resolving software problems, and provides essential questions that you should answer before contacting the EMC Customer Support Center. Overview of Detecting and Resolving Problems ......G-2 Troubleshooting the Problem ............G-3 Before Calling the Customer Support Center .......G-4...
Page 444: Appendix G Customer Support
Customer Support Overview of Detecting and Resolving Problems EMC software products are supported directly by the EMC Customer Support Center in the United States. EMC uses the following process to resolve customer problems with its software products (Figure G-1). Problem...
Page 445: Troubleshooting The Problem
3. Run some test cases to reproduce the problem. If you encounter a problem that requires technical programming or analysis, call the nearest EMC office or contact the EMC Customer Support Center at one of the following numbers: United States: (800) 782-4362 (SVC-4EMC)
Page 446: Before Calling The Customer Support Center
For an MVS problem, the JESLOG, SYSPRINT, all STDOUT DD members of the server job output and similar output for the client, and the relevant portion of the SYSLOG Connectrix ED-64M User Guide...
Page 447: Documenting The Problem
Customer Support Documenting the Problem If the EMC Customer Support Center requests information regarding the problem, please document it completely, making sure to include the following information: Your company name and address Your name Your telephone number The importance of the problem, so that it can be assigned a...
Page 448: Reporting A New Problem
Message numbers and complete text of any messages that the system produced Log file dated near the time the error occurred Results from tests that you have run Other related system output Other information that may help solve the problem Connectrix ED-64M User Guide...
Page 449: Sending Problem Documentation
Customer Support Sending Problem Documentation Use one of the following methods to send documentation of the problem to the EMC Customer Support Center: E-mail U.S. mail to the following address: EMC Customer Support Center 45 South Street Hopkinton, MA 01748-9103...
Page 450 Customer Support Connectrix ED-64M User Guide...
Page 451: Glossary
Glossary This glossary contains terms related to EMC Connectrix. Many of these terms are used in this manual. The glossary includes terms and definitions from: • The Dictionary of Computing, ZC20-1699. • The American National Standard Dictionary for Information Systems, ANSI X3.172-1990, copyright 1990, by the American National...
Page 452: Audit Log
A log containing summaries of actions taken by a Connectrix Management software user, recording an audit trail of changes. For example: adding, modifying, or deleting user or product administration records the operation, including the date and time, in the audit log. Connectrix ED-64M User Guide...
Page 453 Storage area for data in transit. Buffers compensate for differences in processing speeds between devices. Buffer-to-Buffer Credit The maximum number of frames a port can transmit without receiving a receive ready signal from the receiving device. Connectrix ED-64M User Guide...
Page 454 Information that specifies which management objects are available to what management domain or SNMP community name. Connectionless Nondedicated link. Typically used to describe a link between nodes that allows the switch to forward Class 2 or Class 3 frames as Connectrix ED-64M User Guide...
Page 455 Connectrix switch or a similar product. A device as defined here is not controlled by the Connectrix Product Manager and its operating parameters. (2) In EMC Symmetrix, a uniquely addressable physical or logical part of the Symmetrix subsystem, such as a disk.
Page 456 This is in contrast with a conventional fiber optic system in which only one channel is carried over a single wavelength traveling through a single fiber. EBCDIC Extended Binary-Coded Decimal Interchange Code. E_D_TOV See Error Detect Time Out Value. Connectrix ED-64M User Guide...
Page 457: Event Log
Fibre Adapter, another name for a Symmetrix Fibre Channel director. Fabric One or more switching devices that interconnect Fibre Channel N_Ports, and route Fibre Channel frames based on destination IDs in the frame headers. Fabric Element Any active switch or director in the fabric. Connectrix ED-64M User Guide...
Page 458 Fabric Manager Software application that is the system management framework and the user interface for managing EMC Fibre Channel connectivity products. The Connectrix Manager can run either locally on the Connectrix service processor or remotely on a user workstation.
Page 459 G_Port A physical interface within the fabric capable of acting either as an F_Port or an E_Port (extension port) depending on the port type at the other end of the link. Graphical user interface. Connectrix ED-64M User Guide...
Page 460 (2) Pertaining to a functional unit or channel involved in an input process, output process, or both (concurrently or not), and to the data involved in such a process. (3) Pertaining to input, output, or both. g-10 Connectrix ED-64M User Guide...
Page 461 (generally) an optical resonant cavity to provide positive feedback. Laser radiation can be highly coherent temporally, spatially, or both. Light-emitting diode. Link The physical connection between two devices on a switched fabric. g-11 Connectrix ED-64M User Guide...
Page 462 A unit of measure for storage size, loosely one million bytes. One megabyte actually equals 1,048,576 bytes. Management Information Base, a related set of objects (variables) containing information about a managed device and accessed via SNMP from a network management station. g-12 Connectrix ED-64M User Guide...
Page 463 Domain Name Service (DNS) name as administered on a customer network. All DNS names have a host name component and (if fully qualified) a domain component, such as host1.emc.com. In this example, host1 is the host name and EMC.com is the domain component. Nickname A name representing one or more port numbers or World Wide Names.
Page 464: Out-Of-Band Management
HBA and storage port WWN. Port (1) An access point for data entry or exit. (2) A receptacle on a device to which a cable for another device is attached. g-14 Connectrix ED-64M User Guide...
Page 465 Managed Products. Protocol (1) A set of semantic and syntactic rules that determines the behavior of functional units in achieving communication. (2) A specification for the format and relative timing of information exchanged between communicating parties. g-15 Connectrix ED-64M User Guide...
Page 466 SMTP protocols specify how messages are passed across a link from one system to another. They do not specify how the mail application accepts, presents or stores the mail. g-16 Connectrix ED-64M User Guide...
Page 467 To change the state of a feature/function that has only two states. For example, if a feature/function is enabled, toggling changes the state to disabled. Upper Layer Protocol, the protocol user of FC-4, including IPI, SCSI, IP, and SBCCS. g-17 Connectrix ED-64M User Guide...
Page 468 Zoning allows an administrator to group several devices by function or by location. All devices connected to a connectivity product, such as a Connectrix switch, may be configured into one or more zones. Zone Set A set of zones. g-18 Connectrix ED-64M User Guide...
Page 469 FPM card, enabling via Product buffer-to-buffer credit. See BB_Credit Manager 4-11 beaconing, port, enabling/disabling via CLI E-62 call-home notification, enabling 7-11 via Product Manager (Port menu) 4-21 channel wrap 4-21 via Product Manager (right-click) 4-17 Clear System Error Light 4-10 Connectrix ED-64M User Guide...
Page 470 3-5 via Product Manager 5-19 director. See also ED-64M director management 1-5 director properties 4-9 director speed, setting via Product Manager 5-9 domain ID, insistent. See insistent domain ID, preferred. See preferred domain ID Connectrix ED-64M User Guide...
Page 471 Product Manager 5-3 port binding table A-96 IML 1-18 port table (port group) A-91 initial machine load See IML system group variables A-88 initial program load See IPL threshold alert table A-98 zoning variables A-96 Connectrix ED-64M User Guide...
Page 472 UDP listener table A-25 via Embedded Web Server D-3 MIBs, downloading A-3 logging out of switch via CLI E-12 monitoring hardware operation 4-6 logs audit 6-4 event 6-6 expanding columns 6-3 hardware 6-8 link incident 6-9 Connectrix ED-64M User Guide...
Page 473 Product Manager (Configure Ports) 5-19 configuring D-5 ports, configuring default D-3 via CLI E-16 password, Hyperterminal B-6 via Product Manager 5-19 perf command E-66 ports, resetting performance features 1-4 via CLI E-62 performance services E-66 via Product Manager 4-21 Connectrix ED-64M User Guide...
Page 474 CLI E-46 clearing via Product Manager 5-5 via CLI E-68 described 5-10 via Product Manager 4-33 rerouting delay described 4-33 configuring stored address configurations 5-30 via CLI E-47 subnet mask B-2 via Product Manager 5-5 described 5-8 Connectrix ED-64M User Guide...
Page 475 Embedded Web Server D-5 enabling 5-56 sessions E-2 Threshold Alert Log 6-11 web server. See Embedded Web Server zoning RSCNs. See RSCNs on zone set activations zoning, configuring via CLI E-53 via Connectrix Manager. See Connectrix Manager User Guide Connectrix ED-64M User Guide...
Page 476 Index Connectrix ED-64M User Guide...
