Connectrix DS-24M2

Fibre Channel Switch

USER GUIDE

P/N 069001203

REV A02

EMC Corporation

Corporate Headquarters:

Hopkinton, MA 01748-9103

(800) 424-EMC2

http://www.EMC.com

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Connectrix DS-24M2 and is the answer not in the manual?

Questions and answers

Summary of Contents for EMC Connectrix DS-24M2

Page 1 Connectrix DS-24M2 Fibre Channel Switch USER GUIDE P/N 069001203 REV A02 EMC Corporation Corporate Headquarters: Hopkinton, MA 01748-9103 (800) 424-EMC2 http://www.EMC.com...
Page 2 Copyright © 2002, 2003 EMC Corporation. All rights reserved. Printed April 2003 EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice. THE INFORMATION IN THIS PUBLICATION IS PROVIDED "AS IS." EMC CORPORATION MAKES NO...
Page 3 Class 1 laser products are not considered hazardous. The transceivers are designed such that there is never human access to laser radiation above a Class 1 level during normal operation or prescribed maintenance conditions. Trademark Information Connectrix DS-24M2 User Guide...
Page 4 Connectrix DS-24M2 User Guide...
Page 5: Table Of Contents
Performance Features............... 1-9 Switch Management............... 1-10 High-Availability Features ............ 1-11 Connectivity Features ............1-12 Security Features..............1-12 Serviceability Features ............1-13 Hardware Operations..............1-15 Updating Firmware ..............1-15 Switch Operational States............1-15 IML.................... 1-16 IPL ..................... 1-17 Connectrix DS-24M2 User Guide...
Page 6 Menu Options ................. 4-19 Using the Node List View............. 4-21 Displaying Node Properties..........4-23 Displaying Port Properties ............ 4-23 Defining Nicknames .............. 4-24 Using the Performance View ............4-25 Bar Graph Display..............4-26 Port Statistics ................4-27 Connectrix DS-24M2 User Guide...
Page 7 Exporting a Configuration Report..........5-41 Report Data ................5-41 Export Procedure ..............5-41 Enabling the Embedded Web Server.......... 5-43 Enabling Telnet ................5-44 Chapter 6 Using Logs Using Logs..................6-2 Button Function................ 6-2 Expanding Columns..............6-3 Sorting Entries ................6-3 Connectrix DS-24M2 User Guide...
Page 8 The Interfaces Group .............. A-9 The Address Translation Group/Table ......A-13 The IP Group ................A-14 The ICMP Group ..............A-20 The TCP Group ..............A-22 The UDP Group ..............A-25 The SNMP Group ..............A-26 viii Connectrix DS-24M2 User Guide...
Page 9 Port Table (Port Group) ............A-91 Port Binding Table ..............A-96 Zoning Variables ..............A-96 Active Zone Table ..............A-97 Active Member Table ............A-97 Threshold Alert Table............A-98 Enterprise Specific Traps ............. A-99 Port State Descriptions ............A-100 Connectrix DS-24M2 User Guide...
Page 10 ................D-13 Handling Command Line Interface Errors......D-14 Using CLI Help ..............D-14 Commenting Scripts.............. D-15 The config Branch ................ D-16 config.enterpriseFabMode.setState........D-16 config.features.installKey ............. D-17 config.features.enterpriseFabMode ........D-17 config.features.openSysMS ..........D-18 config.features.show ............. D-18 Connectrix DS-24M2 User Guide...
Page 11 .......... D-39 config.snmp.show ..............D-39 config.switch................D-40 config.switch.domainRSCN ..........D-40 config.switch.insistDomainId ..........D-41 config.switch.edTOV ............D-41 config.switch.interopMode..........D-42 config.switch.prefDomainId..........D-42 config.switch.priority ............D-43 config.switch.raTOV............. D-44 config.switch.rerouteDelay..........D-44 config.switch.show ............... D-45 config.switch.zoningRSCN..........D-46 config.system.contact ............D-47 Connectrix DS-24M2 User Guide...
Page 12 D-61 perf ....................D-63 perf.class2 ................D-63 perf.class3 ................D-64 perf.clearStats ................. D-65 perf.errors ................D-66 perf.link................... D-67 perf.thresholdAlerts .............. D-68 perf.thresholdAlerts.counter.addAlert....... D-70 perf.thresholdAlerts.counter.addPort ........ D-71 perf.thresholdAlerts.counter.deleteAlert......D-72 perf.thresholdAlerts.counter.removePort......D-72 perf.thresholdAlerts.counter.setCounter ......D-73 perf.thresholdAlerts.counter.setParams ......D-73 Connectrix DS-24M2 User Guide...
Page 13 Troubleshooting the Problem ............F-3 Before Calling the Customer Support Center ......F-4 Documenting the Problem ............F-5 Reporting a New Problem ............F-6 Sending Problem Documentation ..........F-7 Glossary ........................g-1 Index ..........................i-1 Connectrix DS-24M2 User Guide xiii...
Page 14 Contents Connectrix DS-24M2 User Guide...
Page 15 Set Online State Window ................5-4 Configure Switch Parameters Dialog Box ..........5-5 Configure Fabric Parameters Dialog Box ..........5-8 Switch Binding — State Change Dialog Box .......... 5-12 Switch Binding — Membership List ............5-14 Connectrix DS-24M2 User Guide...
Page 16 Embedded Web Server — View Window ..........C-6 Embedded Web Server— Configure Ports Window ......C-7 Embedded Web Server — Configure Switch Identification ....C-9 Embedded Web Server — Configure Switch Date/Time ....C-11 Embedded Web Server — Configure Switch Parameters ....C-12 Connectrix DS-24M2 User Guide...
Page 17 C-14 Embedded Web Server — Configure Security ........C-25 C-15 Embedded Web Server — Configure Port Binding ....... C-27 C-16 Embedded Web Server — Feature Installation ........C-29 Problem Detection and Resolution Process ..........F-2 xvii Connectrix DS-24M2 User Guide...
Page 18 Figures xviii Connectrix DS-24M2 User Guide...
Page 19 Fabric Element MIB Objects ..............A-32 A-19 Fabric Element MIB Modules ..............A-32 A-20 FxPort Configuration Table ..............A-34 A-21 FxPort Operation Table ................A-37 A-22 FxPort Physical Level Table ..............A-38 A-23 FxPort Fabric Login Table ................ A-40 Connectrix DS-24M2 User Guide...
Page 20 Threshold Alert Table ................A-98 A-50 Enterprise-Specific Traps ................. A-99 A-51 Port State Descriptions ................A-100 Management Support Table ............... C-3 CLI Command Tree Navigation Conventions ........D-5 CLI Command Tree ..................D-6 Threshold Alert Counters ................ D-69 Connectrix DS-24M2 User Guide...
Page 21: Preface
Preface As part of its effort to continuously improve and enhance the performance and capabilities of the Connectrix product line, EMC periodically releases new versions of hardware and software. Therefore, some functions described in this guide may not be supported by all versions of Connectrix currently in use.
Page 22 Web Server. Appendix E, Specifications, lists the physical characteristics and operating environment of the DS-24M2. Appendix F, Customer Support, describes the EMC process for detecting and resolving software problems, and provides essential questions that you should answer before contacting the EMC Customer Support Center.
Page 23 Connectrix ED-64M 2 Gb Fibre Channel Director User Guide, P/N 069001204 Connectrix ED-140M Fibre Channel Director User Guide, P/N 069001202 Conventions Used in EMC uses the following conventions for notes, cautions, and this Guide warnings. A note presents information that is important, but not hazard-related. CAUTION A caution contains information essential to avoid data loss or damage to the system or equipment.
Page 24 Options in command line syntax Where to Get Help For questions about technical support, call your local sales office or service provider. If you have a valid EMC service contract, contact EMC Customer Service at: United States: (800) 782-4362 (SVC-4EMC) Canada:...
Page 25 Preface Sales and Customer For the list of EMC sales locations, please access the EMC home page Service Contacts http://www.EMC.com/contact/ For additional information on the EMC products and services available to customers and partners, refer to the EMC Powerlink Web site at: http://powerlink.EMC.com...
Page 26 Preface xxvi Connectrix DS-24M2 User Guide...
Page 27: Warnings And Cautions
The following warnings and cautions pertain throughout this guide. WARNING Trained service personnel only. This EMC product has more than one power supply cord. To reduce the risk of electric shock, disconnect all power supply cords before servicing. Ground circuit continuity is vital for safe operation of the machine.
Page 28 This product operates at high voltages. To protect against physical harm, power off the system whenever possible while servicing. WARNING In case of fire or other emergency involving the EMC product, isolate the product’s power and alert appropriate personnel. CAUTION Trained personnel are advised to exercise great care at all times when working on the EMC hardware.
Page 29 Warnings and Cautions Static Precautions EMC incorporates state-of-the-art technology in its designs, including the use of LSI and VLSI components. These chips are very susceptible to damage caused by static discharge and need to be handled accordingly. CAUTION Before handling printed circuit boards or other parts containing LSI and/or VLSI components, observe the following precautions: Store all printed circuit boards in antistatic bags.
Page 30 Warnings and Cautions Connectrix DS-24M2 User Guide...
Page 31: Switch Operating Features
Invisible Body Tag Switch Operating Features This chapter introduces the operating features of the EMC Connectrix DS-24M2 2 Gb/s fabric switch, including hardware features and components. It describes operator controls, management, service, and operation features, and hardware operations. Also provided is an overview of creating multiswitch fabrics with multiple switches.
Page 32: Overview
Internet connection to the Embedded Web Server interface installed on the switch. The DS-24M2 can be installed on a table or desk top, mounted in an EMC EC-1200 equipment cabinet, or mounted in any standard 19-inch equipment rack. The DS-24M2 implements Fibre Channel technology that provides high-performance scalable bandwidth (2 Gb/s), highly available operation, and high device population.
Page 33: Ds-24M2 Description
DS-24M2 from 8 ports to 16 ports to 24 ports. For more information on enabling the FlexPort feature: 1. Login into PowerLink at: http://powerlink.emc.com 2. Click the Services tab. 3. Select Asset Management Application under License Asset Management.
Page 34: Front Panel
Web browser, CLI, and SNMP support. Support for all operating systems, HBAs, and drivers supported by the Connectrix ED-1032 in the current EMC Support Matrix. Front Panel Figure 1-1 illustrates the front view of the DS-24M2. From left to right, the switch front panel includes: Green power and amber system error LEDs.
Page 35 Switch Operating Features IML Button If you press and hold the IML button for three seconds, the switch performs an Initial Machine Load (IML), which takes approximately 30 seconds and: Resets the microprocessor and functional logic for the control processor (CTP) subsystem, causing a firmware reload from flash memory.
Page 36: Ctp
Rear Panel The switch rear panel (Figure 1-2) includes two power supply modules and an RS-232 maintenance port. Maintenance Port Power Supply Module 1 Power Supply Module 0 DS-24M2, Rear View Figure 1-2 Connectrix DS-24M2 User Guide...
Page 37 Switch Operating Features Power Supplies The switch contains two power supply assemblies with internal cooling fans. The redundant, load-sharing power supply assemblies step down and rectify facility input power to provide 3.3 volts direct current (VDC), 5 VDC, and 12 VDC to the control processor (CTP). The power supplies also provide input filtering, overvoltage protection, and overcurrent protection.
Page 38: Connectrix Service Processor
The Connectrix service processor and Connectrix Manager application are a dedicated hardware and software solution that should not be used for other tasks. EMC tests the Connectrix Manager application installed on the Connectrix service processor, but does not test other third-party software for compatibility .
Page 39: Hardware Features
Switch Operating Features Hardware Features The DS-24M2 is an enterprise-class Fibre Channel switch that provides high performance, high-availability connectivity, and enterprise-class manageability for an Open Systems environment. The DS-24M2 provides 24 Fibre Channel G_Ports for attachment to device N_Ports or NL_Ports, or switch E_Ports, through fiber-optic links.
Page 40: Switch Management
Product Manager application. Administrators launch the Web Server from a remote PC by entering the switch’s IP address as the URL, then entering a user name and password at a login screen. The PC browser then becomes a management console. 1-10 Connectrix DS-24M2 User Guide...
Page 41: High-Availability Features
Switch Operating Features Figure 1-3 illustrates the switch management access methods. Connectrix Manager Client Workstations E-Mail Server 10/100 Mb/s Corporate LAN SNMP Management Station Switch/Hub Connectrix Manager Server Running on Connectrix Service Processor Switch Management Figure 1-3 High-Availability Dual power supplies and spare unused ports ensure high availability. Features Power supplies —...
Page 42: Connectivity Features
A zone contains a set of devices that can access each other. A zone member can be a port or the WWN of the device attached to a port. (EMC recommends that zones contain only WWNs.) Ports and devices spread throughout switches in a multiswitch fabric can be grouped into the same zone.
Page 43: Serviceability Features
Switch Operating Features configured through the Product Manager application. If configured, the agent can send authorization failure traps when unauthorized SNMP workstations attempt to access the switch. Audit log tracking — Configuration changes to the switch are recorded in an audit log stored on the Connectrix service processor.
Page 44 SNMP trap messages. The trap messages indicate operational state changes and failure conditions. Data collection through the Product Manager application to help isolate system problems. The data includes a memory dump file and audit, hardware, and engineering logs. 1-14 Connectrix DS-24M2 User Guide...
Page 45: Hardware Operations
Switch Operating Features Hardware Operations This section introduces hardware operations that affect the DS-24M2. Updating Firmware The Connectrix service processor’s fixed disk can contain a library of firmware versions for downloading to any DS-24M2 managed by the Connectrix service processor. Refer to Managing Firmware Versions on page 7-7 for instructions on changing switch firmware.
Page 46: Iml
• The Link Loss Status table appears. • A gray square appears in the alert panel. • The FRUs illustrated in the Hardware view disappear, and then reappear as the connection is re-established. 1-16 Connectrix DS-24M2 User Guide...
Page 47: Ipl
Switch Operating Features CAUTION An IPL is not intended for ordinary or casual use and should be performed only if the active CTP is suspect or if directed by next-level support or documentation. An IPL interrupts the link between the Connectrix service processor and switch. To perform an IPL (Initial Program Load), select IPL from the Product Manager Maintenance menu.
Page 48 Switch Operating Features 1-18 Connectrix DS-24M2 User Guide...
Page 49: Chapter 2 Operating The Switch
Invisible Body Tag Operating the Switch This chapter describes the operation of the DS-24M2 and identifies the controls and indicators. Power Procedures ................2-2 FRU LEDs and Connectors ...............2-4 Operating the Switch...
Page 50: Power Procedures
After successful POSTs, the green power LED remains illuminated and all other front panel LEDs go dark. If any of the following occurs, contact EMC Customer Support: The amber system error LED remains on. The green power LED is off. Connectrix DS-24M2 User Guide...
Page 51 Operating the Switch The amber LED for either power supply on the rear of the unit is on (and the power cord on that power supply is plugged into a working AC power source). Powering the Switch You do not need to power the switch off to remove FRUs or to connect fiber-optic cables to and from ports.
Page 52: Fru Leds And Connectors
IML Button Power LED Error LED Ethernet Connector SFP Transceivers (24) Port LEDs Figure 2-2 Front Panel LEDs and Connectors Maintenance Port Power Supply Module 1 Power Supply Module 0 Figure 2-3 Rear Panel LEDs and Connectors Connectrix DS-24M2 User Guide...
Page 53 Operating the Switch LEDs Table 2-1 Color State Function Power Green The switch is receiving power. The switch may not be receiving AC power. Check the AC power source and power cords. Error Amber The switch has detected an event requiring immediate operator attention, such as a FRU failure.
Page 54: Connectors
Port Connects the switch to user devices and other switches. AC power Supplies AC power to the two supplies, providing single-phase connections with input rated up to 264 VAC. Connectrix DS-24M2 User Guide...
Page 55 Invisible Body Tag Product Manager Overview This chapter is an introduction and overview of the DS-24M2 Product Manager application. It is intended as a quick reference for using features available through the main Product Manager window. Product Manager Overview .............3-2 Using the Product Manager..............3-5 Product Manager Menu Bar ............3-12 Product Manager Views..............3-17...
Page 56: Product Manager Overview
Configure SNMP trap recipients and community names. Configure Open Systems Management Server features (if installed). Configure switch binding if optional Enterprise Fabric Extensions feature is installed. Configure an interoperability mode for multiswitch fabrics. Connectrix DS-24M2 User Guide...
Page 57 Product Manager Overview Configure the switch name, location, description, and contact person. Configure threshold alerts for ports. Enable LIN alerts on ports. Control individual Fibre Channel ports by blocking/unblocking operation, enabling LIN alerts, enabling port binding, and setting data speeds. Display FRU properties such as the FRU name, physical position in the switch, active failed state, part number, and serial number.
Page 58: Connectrix Service Processor And Remote Workstation Configuration
Product Manager Overview Connectrix Manager Client Workstations E-Mail Server 10/100 Mb/s Corporate LAN SNMP Management Station Switch/Hub Connectrix Manager Server Running on Connectrix Service Processor Figure 3-1 Connectrix Service Processor and Remote Workstation Configuration Connectrix DS-24M2 User Guide...
Page 59: Using The Product Manager
Product Manager Overview Using the Product Manager This section provides a general overview of the Connectrix Manager and its functions. For details on performing specific tasks and using specific dialog boxes, refer to the appropriate chapters in this manual. Using Dialog Boxes Dialog boxes, such as the one in Figure 3-2, appear when you select options from the pop-up menus.
Page 60: Logging Into The Connectrix Manager
ENTER a. Windows 95, Windows 98, Windows NT, or Windows 2000. b. These steps assume the Connectrix Manager is in your home directory. If you saved it to a different location, enter the appropriate directory names. Connectrix DS-24M2 User Guide...
Page 61: Connectrix Manager Login Window
Product Manager Overview 2. On the Connectrix Manager Login window (Figure 3-3), enter your user name and password. (User names and passwords are case-sensitive. ) If user names have not been established, use the default user name (Administrator) and password (password). Version: 06.03.00.x Figure 3-3 Connectrix Manager Login Window...
Page 62: Connectrix Manager Products View
The Products view provides a graphical overview of all the products that can be managed and monitored through the Connectrix Manager. In a full-screen environment on an 800 x 600 resolution monitor, this panel displays up to 48 product icons. Connectrix DS-24M2 User Guide...
Page 63 Product Manager Overview Product Icons Information in each product icon includes the following: Switch Speed (Gb/s) Attention Indicator Product Illustration Number Status Indicator of Ports MySwitch 5 Product Name or Network Address Object descriptions: Switch data speed: 2 Gb/s. Attention indicator — A yellow triangle means that product requires attention.
Page 64: Opening The Product Manager
Open Product icon on the Connectrix Manager toolbar: Open 120.20.150.10 Product The Product Manager opens to the Hardware view (Figure 3-5). Windows Title Bar ABC 123 Menu Bar View Selector ABC 123 Main Panel Status Indicator Product Manager Window Figure 3-5 3-10 Connectrix DS-24M2 User Guide...
Page 65: Closing The Product Manager
Product Manager Overview The Connectrix Manager window is still available as a separate window. You can drag the Product Manager window away from the Connectrix Manager window and view both windows on your PC desktop (or minimize one or both to icons if desired). You can have up to four Product Manager windows open concurrently.
Page 66: Product Manager Menu Bar
• Properties — Displays such information as the switch name, description, location, and contact person. Refer to Displaying Switch Properties on page 4-13. • Close — Closes the Product Manager window. 3-12 Connectrix DS-24M2 User Guide...
Page 67 Product Manager Overview Configure: • Identification — Allows you to specify information that will appear in the identification table at the top of the Hardware view and in the Connectrix Manager Products view (if the Products view is configured to display names) Refer to Configuring Switch Identification on page 5-2.
Page 68 Web Server interface on the switch. Refer to Enabling the Embedded Web Server on page 5-43. • Enable Telnet — Allows you to enable Telnet access to the switch. Refer to Enabling Telnet on page 5-44. 3-14 Connectrix DS-24M2 User Guide...
Page 69 Product Manager Overview Logs: • Audit Log — Provides a record of all configuration changes made on the switch. Refer to Audit Log on page 6-4. • Event Log — Provides a record of significant events that have occurred on the director, such as hardware failures, degraded operation, and port problems.
Page 70 Refer to Resetting the Configuration on page 7-16. Help: • Contents — Displays online help for the Product Manager. • About — Displays the version number for the Product Manager and copyright information. 3-16 Connectrix DS-24M2 User Guide...
Page 71: Product Manager Views
Product Manager Overview Product Manager Views DS-24M2: ABC123 View Tabs DS-24M2 Status ABC 123 Product Manager View Selector Tabs Figure 3-7 The Product Manager offers four main views, accessible by clicking the tabs. Hardware View The Hardware view (Figure 3-8) is the default view that appears in the main panel when you open the Product Manager.
Page 72: Port List View
Figure 3-7 on page 3-17) displays a table listing: # — Port number Name — Port name Block Config — Blocked/unblocked configuration State — Operating state Type — Port type Operating speed Alert — Identification of any ports with outstanding alert conditions 3-18 Connectrix DS-24M2 User Guide...
Page 73: Node List View
Product Manager Overview Other options available on the Port List view allow you to: Block/unblock ports Display port properties Display port technology: connector and transceiver types, distance, media, and speed Configure port binding Run port diagnostics Enable port beaconing Clear Link Incident Alert(s) Clear Threshold Alert(s) Reset the port For details on these menu options, refer to Port Menu on page 4-15.
Page 74: Performance View
Figure 4-9 on page 4-33 shows an example of the FRU List view. For details on navigating and monitoring via the FRU List view, refer to Using the FRU List View on page 4-33. 3-20 Connectrix DS-24M2 User Guide...
Page 75: User Rights
Product Manager Overview User Rights The Connectrix Manager’s system administrator can assign levels of access, or user rights, to Product Manager users through the Connectrix Manager application. Note that the Connectrix Manager’s system administrator only has view rights while operating in a specific Product Manager application. Conversely, a Product Manager’s product administrator only has view rights while operating in the Connectrix Manager application.
Page 76: User Rights For Specific Functions
Clear LIN Log Clear System Error Light Configure Date/Time Configure Feature Key Configure Identification Configure Management Server Configure Switch Parameters Configure Fabric Parameters Configure Port Binding Configure Ports Configure SNMP Configure Switch Binding Configure Zoning 3-22 Connectrix DS-24M2 User Guide...
Page 77 Product Manager Overview Table 3-1 User Rights for Product Manager Functions (continued) Product Product Manager Rights Administrator Operator Maintenance Data Collection Date/Time Sync Configuration Enable Call Home Notification Enable E-Mail Notification Export Configuration Report Manage Firmware Port Diagnostics Port Beaconing Set Online State Reset Configuration Reset Statistics Counters...
Page 78 Product Manager Overview 3-24 Connectrix DS-24M2 User Guide...
Page 79 Invisible Body Tag Monitoring and Managing the Switch This chapter describes how to use the features available in the various Product Manager views to monitor and manage switch operation. The views are accessible from the tabs shown here: DS-24M2: ABC123 View Tabs DS-24M2 Status ABC 123...
Page 80: Using The Hardware View
ABC 123 Status Symbol Status Refer to Table 4-3 on page 4-35 for the meaning of the text in the Status table and the corresponding symbol in the lower left corner of the Product Manager window. Connectrix DS-24M2 User Guide...
Page 81 Monitoring and Managing the Switch State The State field displays one of the following: OFFLINE — When the switch is off line, all ports are off line. The ports cannot accept a login from an attached device or cannot connect to other switches. Refer to Setting the Online State on page 7-6 for instructions on setting the switch on line or off line.
Page 82 Properties. The IP address appears in the Network Address field. Incorrect Product Type — The product at the configured network address is not a switch. Verify address, configuration, and product type. Connectrix DS-24M2 User Guide...
Page 83: Operating Status - Alert Panel And Switch Status
Monitoring and Managing the Switch Status Symbol The status symbol in the lower left of the Hardware view indicates the overall operating status of the switch. The status depends on specific hardware component failures, which are indicated by status symbols that appear over component graphics in the Hardware view. Table 4-1 shows the alert panel symbols and their meanings.
Page 84: Monitoring Hardware Operation Using The Hardware View
4-2 on page 4-7. For more details on the meanings of symbols and indicators, refer to Table 4-3 on page 4-35. ABC 123 ABC 123 NOT OPERATIONAL OFFLINE Monitoring Hardware Operation Using the Hardware View Figure 4-1 Connectrix DS-24M2 User Guide...
Page 85 Monitoring and Managing the Switch Table 4-2 Legend for Figure 4-1 Port attention indicator — A yellow triangle alert symbol can indicate any of these: A link incident occurred. The port is not operational. The port is in a non-standard mode of operation. For a link incident, the status table at the top of the Hardware view changes to reflect the reason for the alert.
Page 86: Legend For Figure 4-1
The switch operates with one power supply; however, you should replace a failed power supply as soon as possible to retain redundancy. Connectrix DS-24M2 User Guide...
Page 87: Obtaining Hardware Information
Monitoring and Managing the Switch This section explains how to access the FRU Properties, Port Obtaining Hardware Properties, and Switch Properties windows. Information Displaying FRU You can display a FRU Properties window for a power supply (AC Properties connector) in any of these ways: Double-click the FRU in the Hardware view.
Page 88 Link Incident — Description of the last link incident that occurred on the port. Operational State: • Beaconing • Inactive • Invalid Attachment • Link Incident • Link Reset • No Light • Not Operational 4-10 Connectrix DS-24M2 User Guide...
Page 89 – — 07 Non-McDATA switch at other end of the ISL The cable is connected to a non-EMC switch and the Interop Mode for this switch is set to McDATA Fabric. – — The 08 ISL connection not allowed on this port port is configured as an F_Port, but attaches to another switch.
Page 90 Threshold Alert — If a threshold alert exists for the port, an alert indicator (yellow triangle) appears by the Threshold Alert field, and the configured name for the last alert received appears in the field. 4-12 Connectrix DS-24M2 User Guide...
Page 91 Monitoring and Managing the Switch Displaying Switch To display a Switch Properties window, double-click the front view Properties of the switch away from any ports (or right-click the switch away from any ports and click Properties on the pop-up menu). The Switch Properties window displays: Switch name, description, location, and contact, as configured through the Configure Identification dialog box...
Page 92: Using Menu Options
Time on page 5-31 for the procedure. Set Switch Online State —Displays the current state (off line or on line) and provides a button for changing the state. Refer to Setting the Online State on page 7-6 for more information. 4-14 Connectrix DS-24M2 User Guide...
Page 93 Monitoring and Managing the Switch CAUTION Before setting the switch off line, warn administrators and users currently operating attached devices that the switch is going off line and that there will be a disruption of port operation. Also, request that the devices affected by an interruption of data flow be set off line.
Page 94: Clear Threshold Alert(S) Window
This action also restarts the notification interval and the cumulative minutes for utilization % interval. Clear Threshold Alert(s) Window Figure 4-2 For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-33. 4-16 Connectrix DS-24M2 User Guide...
Page 95: Using The Port List View
Monitoring and Managing the Switch Using the Port List View To display the Port List view (Figure 4-3), select the Product Manager Port List tab. DS-24M2: S34-A Port List View Figure 4-3 The Port List view displays the following information on all ports that can be installed in the switch.
Page 96 F_Port or FL_Port. • Gx Port if the port is an unconfigured Gx_Port, which is a configurable port type that restricts a port to operate either as an F_Port, FL_Port, or E_Port. 4-18 Connectrix DS-24M2 User Guide...
Page 97: Displaying Port Properties
Monitoring and Managing the Switch Operating Speed — The current data speed for the port: 1 Gb/sec, 2 Gb/sec, or Not Established. Not Established appears if Negotiate was set for the port through the Configure Ports dialog box and the data speed has not been resolved between the port and the attached device, or if the port and device are not communicating.
Page 98: Clear Threshold Alert(S) Window
Monitoring and Managing the Switch Clear Threshold Alert(s) Window Figure 4-4 For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-33. 4-20 Connectrix DS-24M2 User Guide...
Page 99: Using The Node List View
Monitoring and Managing the Switch Using the Node List View To display the Node List view (Figure 4-5), select the Product Manager Node List tab. This view displays information about all node attachments to any F_Ports on the switch, sorted by port number. All data is updated automatically as devices log in and log out.
Page 100 When the device logs back in, the unit type is updated. BB_Credit — The buffer-to-buffer credit that the attached node has available. 4-22 Connectrix DS-24M2 User Guide...
Page 101: Displaying Node Properties
Monitoring and Managing the Switch Displaying Node To display a Node Properties window for the attached node, Properties double-click the node’s row (or right-click the row and click Node Properties on the pop-up menu). Information for the node includes: Port Number — Physical port number on the switch to which the node is connected Node Type —...
Page 102: Defining Nicknames
To change a node’s display between the WWN and nickname: 1. Right-click the node’s row in the Node List view. 2. On the pop-up menu, move the cursor over Display Options. 3. Click the desired option on the pop-up sub-menu. 4-24 Connectrix DS-24M2 User Guide...
Page 103: Using The Performance View
Monitoring and Managing the Switch Using the Performance View To display the Performance view (Figure 4-7), select the Product Manager Performance tab. This view displays a bar graph for each port. The lower portion of the view displays statistical values for a selected port.
Page 104: Bar Graph Display
(Refer to Table 4-3 on page 4-35.) If the port is an F_Port and is logged in, the message displays the attached port’s WWN or nickname. If the port is an E_Port and is logged in, the message says E_Port 4-26 Connectrix DS-24M2 User Guide...
Page 105: Port Statistics
Monitoring and Managing the Switch Port Statistics To select and display more detailed performance information for a port, click the port’s bar graph. A darker background highlights the bar graph for that port, and the lower portion of the Performance view displays the statistics values for the port.
Page 106 Discarded Frames — The number of Class 3 frames discarded, including multicast frames with bad D_IDs. The switch increments this count when it discards a frame that cannot be routed. This occurs most frequently when a destination becomes unavailable without the source realizing it. 4-28 Connectrix DS-24M2 User Guide...
Page 107 Monitoring and Managing the Switch There are no thresholds for this value. Typically, this occurs when the destination is not available due to the destination device’s action. Four Byte Words Rx — The number of 4-byte words received. Four Byte Words Tx — The number of 4-byte words transmitted. Error Statistics Error statistics show whether or not a port is operating correctly.
Page 108 BB_Credit or on any port in order to recover lost BB_Credit. The director receives a link reset from an attached device if the device wishes to initiate the link reset or recover from a link timeout. 4-30 Connectrix DS-24M2 User Guide...
Page 109: Menu Options
Monitoring and Managing the Switch Traffic Statistics The Traffic Statistics table show two sets of values: Receive and Transmit. The bar graphs displays the larger of the two values: Link utilization % —The percentage of the maximum link utilization (100%) currently being used. Link utilization is calculated over one-second intervals.
Page 110: Clear Threshold Alert(S) Window
Monitoring and Managing the Switch Clear Threshold Alert(s) Window Figure 4-8 For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-33. 4-32 Connectrix DS-24M2 User Guide...
Page 111: Using The Fru List View
Monitoring and Managing the Switch Using the FRU List View To display the FRU List view (Figure 4-9), select the Product Manager FRU List tab. This view displays information about all installed FRUs on the switch. All data is updated automatically as the software detects changes.
Page 112 • Active — Always appears unless the FRU has failed. • Failed — Appears if the FRU is not functional. Part Number — Part number of the FRU. Serial Number — Serial number of the FRU. 4-34 Connectrix DS-24M2 User Guide...
Page 113: Port Operational States
Monitoring and Managing the Switch Port Operational States Table 4-3 describes the port states and the LED indicators and alert symbols that appear in the Hardware view and Port List view. Port States Table 4-3 Port Indicators Green/Blue Amber Alert Symbol Port State Description None...
Page 114 Reason field of the Port Properties dialog box. Note that if port optics have also failed, the amber LED will be on. Not Installed The port optics are not installed or the feature that provides additional port function is not enabled. 4-36 Connectrix DS-24M2 User Guide...
Page 115: Alerts
Monitoring and Managing the Switch Alerts The system can generate two types of alerts: Link incident alerts, which are generated because of a problem. Threshold alerts, which are generated when throughput reaches a predetermined level. Link Incident Alerts A link incident (LIN) is a problem detected on a fiber-optic link; for example, loss of light, or invalid sequences.
Page 116: Threshold Alerts
An attention indicator (yellow triangle) that appears by the Threshold Alerts field in the Port Properties window. • Detailed threshold alert data recorded in the Threshold Alert Log. For more information on threshold alerts, refer to Configuring Threshold Alerts on page 5-33. 4-38 Connectrix DS-24M2 User Guide...
Page 117: Configuring The Switch
Invisible Body Tag Configuring the Switch This chapter describes the options that appear in the drop-down menu when you select Configure on the Product Manager’s menu bar. Configuring Switch Identification ...........5-2 Configuring Operating Parameters..........5-4 Configuring Switch Binding............5-12 Configuring Ports................5-17 Configuring the SNMP Agent............5-24 Configuring Management Server Control........5-27 Configuring Feature Keys...............5-28 Configuring the Date and Time .............5-31...
Page 118: Configuring Switch Identification
– Switch icon label in the Connectrix Manager Products view, if the display options are set to display product names – Product Manager window title panel – Identification table at the top of the Hardware view – Switch Properties window Connectrix DS-24M2 User Guide...
Page 119 Configuring the Switch • Description — Enter a description that will further identify the switch. The entry can be longer than 24 characters; however, the size of user’s display determines how much of a lengthy entry will appear. This description will appear in the following locations: –...
Page 120: Configuring Operating Parameters
Parameters on page 5-5 for descriptions of the parameters. 4. Click Activate to save the configuration and close the dialog box. 5. Click Configure on the Product Manager menu bar and select Operating Parameters, then Fabric Parameters, from the drop-down menus. Connectrix DS-24M2 User Guide...
Page 121: Switch Parameters
Configuring the Switch 6. Configure the fabric parameters as necessary. Refer to Fabric Parameters on page 5-8 for descriptions of the parameters: 7. Click Activate to save the configuration and close the dialog box. 8. Set the switch on line. a.
Page 122 Enterprise Fabric Mode or Fabric Binding.) If you enable the Insistent option while the switch is on line, the Preferred Domain ID changes to the current active domain ID if the IDs are different. Connectrix DS-24M2 User Guide...
Page 123 Configuring the Switch Rerouting Delay This option is applicable only if the switch is in a multiswitch fabric, and must be enabled if Enterprise Fabric Mode (an optional Enterprise Fabric Extensions feature) is enabled. Enabling (checking) this option ensures that frames are delivered in order through the fabric to their destination.
Page 124: Fabric Parameters
Configuring the Switch disrupting Fibre Channel traffic. Consult your HBA vendor and your EMC representative to determine if fabric-format RSCNs will cause problems with your HBA or storage products. Fabric Parameters The fabric parameters are described below: Configure Fabric Parameters Dialog Box...
Page 125 (tenths of a second; in other words, 0.2 through 60 seconds). (The default value is 20 tenths, or 2 seconds.) EMC recommends leaving the timeout values at their defaults. These are the defaults used for all HBA and Symmetrix microcode testing for both benign and fault injection cases.
Page 126 (including any others that were previously set to Principal) automatically changes to Default. In some two-tier fabrics (consisting of backbone and edge switches), EMC recommends configuring all backbone switches as Principal, to provide backup in the event of a failure. (This prevents an edge switch from becoming principal.) For more information, consult your EMC...
Page 127 Configuring the Switch Interop Mode Select one of the following options: McDATA Fabric 1.0 — if all switches in the fabric are in this list: – ED-1032 – ED-64M – ED-140M – DS-16M – DS-16M2 – DS-24M2 – DS-32M – DS-32M2 Open Fabric 1.0 —...
Page 128: Configuring Switch Binding
Figure 5-5. Switch Binding — State Change Dialog Box Figure 5-5 2. If the Enable Switch Binding checkbox is checked, switch binding is enabled. Click the box to add or remove a checkmark. 5-12 Connectrix DS-24M2 User Guide...
Page 129 Configuring the Switch 3. Once you have enabled switch binding, you can specify the port types that will be affected. Select an option under Connection Policy (or leave it at the default setting of Restrict All Ports). Selection Result Restrict E_Ports All switches connected to E_Ports on the DS-24M2 will be prohibited access to the DS-24M2 except those switches you add to the Switch Membership List (described under Editing the Switch...
Page 130: Editing The Switch Membership List
If nicknames are configured for WWNs (through the Connectrix Manager) and you want these to appear instead of WWNs in this window, click Display Options. On the Display Options dialog box, select Nickname and click OK. 5-14 Connectrix DS-24M2 User Guide...
Page 131: Switch Binding: Rules And Guidelines
Configuring the Switch 2. The Node List on the left lists the WWNs of all switches/devices connected to the switch, and the Switch Membership List on the right lists all switches/devices that are allowed access to the switch. • To prohibit connection to a switch port from a WWN currently in the Membership List, select the WWN/nickname in the Membership List and click Remove.
Page 132: Zoning With Switch Binding Enabled
However, if a device WWN is in a specific zone but the WWN is not in the Switch Membership List, the device cannot log in to the switch port and cannot connect to other devices in the zone with switch binding enabled. 5-16 Connectrix DS-24M2 User Guide...
Page 133: Configuring Ports
Configuring the Switch Configuring Ports Use the procedures in this section to configure identification and operating parameters for ports on the switch. Port configuration data is stored in NV-RAM on the switch. When adding and/or configuring ports, refer to Figure 5-7 for the physical locations of the ports.
Page 134: Bound Wwn Mismatch Warning
Bound WWN column. 4. If you are finished configuring the switch, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-10. 5-18 Connectrix DS-24M2 User Guide...
Page 135: Port Parameters
Configuring the Switch Port Parameters The port parameters are described below: Port # This is the physical port number: 0 through 23. You cannot edit this field. Name Port names appear in several Product Manager windows. Enter a name here to identify the end device connected to the port. For example, if the server name is XYZ, you might use XYZ Server.
Page 136 Set the speed to 2 Gb/sec only on ports that support this speed. EMC recommends that only 2 Gb/s optics be installed in DS-24M2s. If a 1 Gb/s optic is inserted and the port speed is configured for 1 Gb/sec, the optic will operate.
Page 137 Configuring the Switch If enabled — The only device that can attach to the port is the one specified by the WWN or nickname in the Bound WWN column. (If the Bound WWN column is blank, no device can connect to the port.) If disabled —...
Page 138: Adding Flexports
16 through 23. To enable the optics, you must install the appropriate FlexPort feature key. Once you have obtained the correct feature key from the EMC Powerlink Web site ( ), follow the steps http://powerlink.emc.com...
Page 139 Configuring the Switch If no device is logged in, no WWN appears on the Attached WWN line. If the user then enables port binding, the port will be bound to a WWN of 0, essentially preventing any device from logging in until binding is disabled,or the bound WWN is updated to a new WWN setting.
Page 140: Configuring The Snmp Agent
To configure traps and assign community names, follow these steps: 1. Click Configure on the Product Manager menu bar and select SNMP Agent on the drop-down menu. This displays the Configure SNMP dialog box (Figure 5-11). 5-24 Connectrix DS-24M2 User Guide...
Page 141: Configure Snmp Dialog Box
Configuring the Switch Configure SNMP Dialog Box Figure 5-11 2. If the box beside Enable Authorization Traps is checked, traps will be sent to SNMP management stations when unauthorized stations try to access SNMP information from the director. Click the box to add or remove a checkmark. 3.
Page 142 Configuring the Switch 8. If you are finished configuring the switch, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-10. 5-26 Connectrix DS-24M2 User Guide...
Page 143: Configuring Management Server Control
Configuring the Switch Configuring Management Server Control This section describes the procedure to configure a management server (assuming the Management Server feature is installed). In the current Connectrix release, the Open Systems Management Server feature is available only through RPQ. The Open System Management Server (OSMS) is a keyed feature that allows host control and inband management of the switch through a management application that resides on an open-systems...
Page 144: Configuring Feature Keys
This displays the window in Figure 5-13. Set Online State Window Figure 5-13 b. Click Set Offline. 3. Click Configure on the Product Manager menu bar and select Features on the drop-down menu. This displays the window in Figure 5-14. 5-28 Connectrix DS-24M2 User Guide...
Page 145: Configure Feature Key Window
Configuring the Switch Configure Feature Key Window Figure 5-14 4. Click New to add a new feature key. This displays the New Feature Key dialog box (Figure 5-15). New Feature Key Dialog Box Figure 5-15 5. The feature key is a string of alphanumeric characters with dashes.
Page 146: Enable Feature Key Dialog Box
On the Set Online State window, click Set Online. 9. If you are finished configuring the switch, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-10. 5-30 Connectrix DS-24M2 User Guide...
Page 147: Configuring The Date And Time
Configuring the Switch Configuring the Date and Time Use the procedures in this section to display and change the date and time set on the switch. You must set the current date and time on the switch so the various logs display the correct time stamps. 1.
Page 148 Click Activate to set the date and time on the switch. 3. If you are finished configuring the switch, back up the configuration data. For more information, refer to Backing Up and Restoring the Configuration on page 7-10. 5-32 Connectrix DS-24M2 User Guide...
Page 149: Configuring Threshold Alerts
Configuring the Switch Configuring Threshold Alerts A threshold alert notifies users when the transmit (Tx) or receive (Rx) throughput reaches specified values for specific switch ports or port types, (E_Ports or F_Ports). You are notified of a threshold alert in four ways: An attention indicator (yellow triangle) that appears on the port in the Hardware view.
Page 150: Creating New Alerts
Figure 5-23 on page 5-39), showing the name of the alert, type of alert (Rx, Tx, or Rx or Tx), and alert state (Active or Inactive). 2. Click New. This displays the New Threshold Alert window (Figure 5-19). 5-34 Connectrix DS-24M2 User Guide...
Page 151: New Threshold Alerts Window - First Screen
Configuring the Switch New Threshold Alerts Window — First Screen Figure 5-19 3. Enter a name, 1 to 64 characters. All characters in the ISO Latin-1 character set, excluding control characters, are allowed. 4. Select one of the following from the drop-down Threshold Type list: •...
Page 152: New Threshold Alerts Window - Second Screen
The valid range is 5 to 70,560 minutes. When throughput reaches the threshold value and remains constant for the specified time, an alert is generated. 9. Click Next. A new window appears for selecting ports for the alerts. 5-36 Connectrix DS-24M2 User Guide...
Page 153: New Threshold Alerts Window - Third Screen
Configuring the Switch New Threshold Alerts Window — Third Screen Figure 5-21 10. Select either Port Type or Port List. • If you select Port Type, selecting E_Ports, F_Ports, or FL_Ports will cause this alert to generate for all ports configured as E_Ports, F_Ports, or FL_Ports respectively.
Page 154: New Threshold Alerts Window - Summary Screen
13. At this point, the alert is not active. To activate the alert, select the alert information that displays in the Configure Threshold Alerts table and select Activate. 5-38 Connectrix DS-24M2 User Guide...
Page 155: Modifying Alerts
Configuring the Switch Figure 5-23 Configure Threshold Alerts Window — Activate Alert Modifying Alerts Use the following steps to modify an existing threshold alert configuration. 1. Click Configure on the Product Manager menu bar and select Threshold Alerts on the drop-down menu. This displays the Configure Threshold Alerts window (Figure 5-18 on page 5-34).
Page 156: Activating Or Deactivating Alerts
5-18 on page 5-34). 2. Select the alert that you want to delete by selecting the alert information in the table. 3. Select Delete. 4. A message displays asking you to confirm the deletion. Select Yes. 5-40 Connectrix DS-24M2 User Guide...
Page 157: Exporting A Configuration Report
Configuring the Switch Exporting a Configuration Report Use this option to save an ASCII file of all configuration data currently saved in switch NV_RAM to your hard drive or a diskette. Use any desktop publishing application to open the ASCII file for viewing or printing.
Page 158: Export Configuration Report Window
2. Select the folder where you want to save the file. 3. Type in a file name and extension in the File name field. 4. Click Save. This saves the file to the specified folder as an ASCII text file. 5-42 Connectrix DS-24M2 User Guide...
Page 159: Enabling The Embedded Web Server
Embedded Web Server interface on the switch. (Refer to Appendix C for more information on using the Web Server.) EMC recommends using the Connectrix Manager to manage the switch. However, the Embedded Web Server can be used if the Connectrix Manager is not available.
Page 160: Enabling Telnet
Connectrix Manager. If you do plan to use the CLI, change the default password in order to prevent others from logging in to the switch via the CLI. (Refer to login on page D-11 for information on changing the CLI passwords.) 5-44 Connectrix DS-24M2 User Guide...
Page 161 Invisible Body Tag Using Logs This chapter describes the DS-24M2 logs. Using Logs ..................6-2 Audit Log ....................6-4 Event Log ....................6-6 Hardware Log..................6-8 Link Incident Log................6-9 Threshold Alert Log................. 6-11 Using Logs...
Page 162: Using Logs
Save window will then be those that are stored in your home directory. If you choose, you can create a folder for your home directory and save the file there. Connectrix DS-24M2 User Guide...
Page 163: Expanding Columns
Using Logs To save a log file in ASCII format to a location on your system’s hard drive or to a diskette, use the following steps. You can open this file in any desktop publisher for viewing or printing. a. Click Export on the log window. b.
Page 164: Audit Log
If the string Connectrix Manager does not appear, the time stamp is from the switch. Action — User action that caused the configuration change, such as offline status, port name change, or change of address. Connectrix DS-24M2 User Guide...
Page 165 Using Logs Source — Identifies the user making the change through the switch Product Manager and IP or DNS host name address of the remote user’s workstation: • Maintenance Port: Change was made by a user connected to the maintenance port. •...
Page 166: Event Log
Date/Time — The date and time of the event on the switch. Event — A unique code that identifies the event. The same code that appears in the Product Manager Event Log also appears in the operator panel Event Log. Connectrix DS-24M2 User Guide...
Page 167 Using Logs Event codes include: 000 – 199 System events 200 – 299 Power supply events 300 – 399 Fan module events 400 – 499 CTP events 500 – 599 Port events Description — A short description of the event. Severity —...
Page 168: Hardware Log
PWR = Power supply module Position — Physical position relative to identical components in the switch. Action — Inserted or Removed. Part Number — Part number of the component. Serial Number — Serial number of the component. Connectrix DS-24M2 User Guide...
Page 169: Link Incident Log
Using Logs Link Incident Log The Link Incident log displays the 1000 most recent link incidents with the date each incident occurred, the time it occurred, and the port on which the incident took place. The information in this log is useful to maintenance personnel for isolating port problems (particularly E_Port segmentation problems) and repair verification.
Page 170 NOS receive state and after NOS is no longer recognized. • Invalid primitive sequence received for the current link state — Either a link reset or a link reset response primitive sequence was recognized while waiting for the offline sequence. 6-10 Connectrix DS-24M2 User Guide...
Page 171: Threshold Alert Log
Using Logs Threshold Alert Log This log provides details of threshold alert notifications. Besides the date and time that the alert occurred, the log also displays details about the alert as configured through the Configure Threshold Alert(s) option under the Configure menu. (Refer to Configuring Threshold Alerts on page 5-33.) Threshold Alert Log Figure 6-6...
Page 172: Configure Threshold Alerts Window
This is set through the Configure Threshold Alerts window. Interval — The time interval during which the throughput is measured and an alert can generate. This is set through the Configure Threshold Alerts window. 6-12 Connectrix DS-24M2 User Guide...
Page 173 Invisible Body Tag Using Maintenance Features Invisible Body Tag This chapter describes the options that appear on the Product Manager Maintenance menu. Running Port Diagnostics ..............7-2 Collecting Maintenance Data ............7-3 Executing an IPL ................7-4 Setting the Online State ..............7-6 Managing Firmware Versions ............7-7 Enabling E-Mail Notification............7-8 Enabling Call-Home Notification ............7-9 Backing Up and Restoring the Configuration ......7-10...
Page 174: Using Maintenance Features
Using Maintenance Features Running Port Diagnostics The Port Diagnostics option is for use by service personnel to run internal and external loopback tests on a port. Connectrix DS-24M2 User Guide...
Page 175: Collecting Maintenance Data
Using Maintenance Features Collecting Maintenance Data The Collect Maintenance Data option is used by service personnel to collect maintenance data that can help diagnose system problems. Store this data on the Connectrix service processor hard disk or send it to another network PC using file transfer protocol (FTP). You can also save the maintenance data to a Zip disk and mail it to the technical support personnel.
Page 176: Executing An Ipl
Resets the Ethernet interface on the CTP subsystem, causing the connection to the Connectrix service processor to drop momentarily. The status icon for the switch in the Connectrix Manager Products view changes to a gray square until the connection is reestablished. Connectrix DS-24M2 User Guide...
Page 177 Using Maintenance Features Stops normal switching functions for ports. (Functions resume after the IPL.) After the IPL: All Fabric services databases containing information about current Fabric logins, name server registrations, and other data remain intact, making the operation transparent to attached devices.
Page 178: Setting The Online State
State field of the OFFLINE DS-24M2 Status table in the Hardware view. LED indicators on all ports with attached devices stay green, but the switch is sending offline sequences (OLS) to these devices. Connectrix DS-24M2 User Guide...
Page 179: Managing Firmware Versions
Using Maintenance Features Managing Firmware Versions Firmware refers to the internal operating code for the switch. You can maintain up to eight firmware versions on the Connectrix service processor for downloading to an switch. This option is for use by service personnel. Managing Firmware Versions...
Page 180: Enabling E-Mail Notification
Product Manager menu bar and select Enable E-Mail Notification on the drop-down menu. When the box to the left of Enable E-Mail Notification is checked, notification is enabled. To change the enabled/disabled state of e-mail notification, click the box to remove/add the checkmark. Connectrix DS-24M2 User Guide...
Page 181: Enabling Call-Home Notification
Enabling Call-Home Notification The call-home feature enables the Connectrix service processor to automatically dial out to the EMC Support Center to report system problems. The support center server accepts calls from the Connectrix service processor, logs reported events, and notifies one or more support center representatives.
Page 182: Backing Up And Restoring The Configuration
You cannot modify the location or file name of the saved configuration. Also, you can restore the configuration only to a switch with the same IP address. 7-10 Connectrix DS-24M2 User Guide...
Page 183: Backup
Using Maintenance Features Backup Follow these steps to perform a backup: 1. Click Maintenance on the Product Manager menu bar and select Backup & Restore Configuration on the drop-down menu. This displays the window in Figure 7-2. Backup and Restore Configuration Window Figure 7-2 Following is a list of configurations that are backed up to the Connectrix service processor:...
Page 184: Automatic Backup To Zip Disk
Zip EfcData disk includes the following: All Connectrix Manager configuration including: • Product definitions • User names, encrypted passwords, and user rights. • Nicknames • Session options • Connectrix Manager SNMP configurations • E-mail configuration 7-12 Connectrix DS-24M2 User Guide...
Page 185 Using Maintenance Features All log files (both Connectrix Manager log files and individual Product Manager log files). Zoning library (all zone sets and zone definitions). Firmware library. Call-home configuration (including phone numbers and dialing options). Configuration data saved to the directory through the EfcData Backup &...
Page 186: Using Quiksync
1. From the Windows taskbar, click Start, Programs, Iomega QuikSync, QuikSync. This displays the Iomega QuikSync dialog box (Figure 7-4). Iomega QuikSync Dialog Box Figure 7-4 2. To enable QuikSync, select On and click OK. 7-14 Connectrix DS-24M2 User Guide...
Page 187: Iomega Quiksync Dialog Box
Using Maintenance Features QuikSync Settings Do not change the default settings for automatic backup of the directory. If you feel that QuikSync is not functioning EfcData properly, check the settings using the following steps: 1. Open the QuikSync dialog box using one of these steps: •...
Page 188: Resetting The Configuration
Reset Configuration on the drop-down menu. CAUTION This operation will reset all switch configuration data and non-volatile settings to factory default values. All optional features will also be disabled. The switch must be off line to continue. 7-16 Connectrix DS-24M2 User Guide...
Page 189: Data Default Values
Using Maintenance Features 2. Set the switch off line. For instructions, refer to Setting the Online State on page 7-6. 3. To continue the reset operation, click Reset on the Reset Configuration dialog box. If you want to cancel the operation, click Cancel.
Page 190 Number of Zone Members Number of Zones Number of Zone Sets Zone Names None Zone Sets Names None Zone Members None Default Zone State Enabled Active Zone Set State Disabled Active Zone Set Name NULL string 7-18 Connectrix DS-24M2 User Guide...
Page 191 Invisible Body Tag Using SNMP to Manage the Switch This appendix describes Connectrix support for the Simple Network Management Protocol (SNMP). Introduction ..................A-2 MIB-II Support ..................A-7 Fabric Element MIB Support ............A-29 Fibre Alliance MIB (fcmgmt.mib) ..........A-49 Connectrix Private Enterprise MIB (fceos.mib) ......A-86 Using SNMP to Manage the Switch...
Page 192: Using Snmp To Manage The Switch
Refer to Fabric Element MIB Support on page A-29. Connectrix Private Enterprise MIB. Refer to Connectrix Private Enterprise MIB (fceos.mib) on page A-86. All groups and variables in the supported MIBs are read-only by SNMP management stations unless noted otherwise. Connectrix DS-24M2 User Guide...
Page 193: Snmp Tree Structure
Using SNMP to Manage the Switch You can download all of these MIBs from the Connectrix Manager’s web page. The URL for the web page depends on the Connectrix service processor’s host name on your network. SNMP Tree Structure Each group is a branch and each variable is a leaf within the MIB tree. The tree begins with the root.
Page 194: Snmp Commands
— Reports that the SNMP agent is reinitializing due to a power-on reset. warmStart — Reports that the agent is reinitializing due to an Initial Machine Load (IML) or Initial Program Load (IPL). authorizationFailure — Reports access by an unauthorized SNMP manager. Connectrix DS-24M2 User Guide...
Page 195: Protocol Definition
Using SNMP to Manage the Switch Protocol Definition The SNMP agent supports the SNMPv1 protocol and data formats as defined in RFCs 1157 and 1155 respectively. The SNMPv2C protocol is not supported. Configuring an Use the Identification and SNMP Agent options on the Configure SNMP Agent menu to configure the following parameters: Identification:...
Page 196 No changes were made to this MIB with the 7.01 release. Connectrix Enterprise Connectrix Enterprise-specific MIB V2.0 (fceos.mib) is implemented by the SNMP agent that runs on Connectrix M-series Fibre Channel switch products. No changes were made to this MIB with the 7.01 release. Connectrix DS-24M2 User Guide...
Page 197: Mib-Ii Support
Using SNMP to Manage the Switch MIB-II Support mgmt (2) mib-2 (1) system (1) interface (2) at (3) ip (4) icmp (5) tcp (6) udp (7) snmp (11) SNMP MIB-II Support Figure A-2 The switch agent supports eight groups specified in MIB-II: System Group —...
Page 198: The System Group
DisplayString(0..255) A textual description of the entity. This value should include the full name and version identification of the system's hardware type, software operating system, and networking software. This description must contain only printable ASCII characters. Connectrix DS-24M2 User Guide...
Page 199: The Interfaces Group
Using SNMP to Manage the Switch The Interfaces Group Table A-2 Interfaces Group MIB-2 Object Name Type Access Description ifNumber INTEGER The number of network interfaces (regardless of their current state) present on this system. The Interfaces Table The Interfaces table contains information on the entity's interfaces. Each interface is thought of as being attached to a subnetwork.
Page 200: Interfaces Table
The size of the largest datagram which can be sent/received on the interface, specified in octets. For interfaces that are used for transmitting network datagrams, this is the size of the largest network datagram that can be sent on the interface. Connectrix DS-24M2 User Guide A-10...
Page 201 Using SNMP to Manage the Switch Table A-3 Interfaces Table (continued) MIB-2 Object Name Type Access Description ifSpeed Gauge An estimate of the interface's current bandwidth in bits per second. For interfaces which do not vary in bandwidth or for those where no accurate estimation can be made, this object should contain the nominal bandwidth ifPhysAddress PhysAddress...
Page 202 If this information is not present, its value should be set to the OBJECT IDENTIFIER { 0 0 }, which is a syntactically valid object identifier, and any conforming implementation of ASN.1 and BER must be able to generate and recognize this value. Connectrix DS-24M2 User Guide A-12...
Page 203: The Address Translation Group/Table
Using SNMP to Manage the Switch The Address Implementation of the Address Translation group is mandatory for Translation all systems. Note however that this group is deprecated by MIB-II. Group/Table That is, it is being included solely for compatibility with MIB-I nodes, and will most likely be excluded from MIB-III nodes.
Page 204: The Ip Group
(for example, for lack of buffer space). Note that this counter does not include any datagrams discarded while awaiting re-assembly. ipInDelivers Counter The total number of input datagrams successfully delivered to IP user-protocols (including ICMP) Connectrix DS-24M2 User Guide A-14...
Page 205 Using SNMP to Manage the Switch Table A-5 IP Group Table (continued) MIB-2 Object Name Type Access Description ipOutRequests Counter The total number of IP datagrams which local IP user-protocols (including ICMP) supplied to IP in requests for transmission. Note that this counter does not include any datagrams counted in ipForwDatagrams.
Page 206: Ip Address Table
An alternate routing metric for this route. The semantics of this metric are determined by the routing-protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1. Connectrix DS-24M2 User Guide A-16...
Page 207 Using SNMP to Manage the Switch Table A-7 IP Routing Table (continued) MIB-2 Object Name Type Access Description ipRouteMetric3 INTEGER An alternate routing metric for this route. The semantics of this metric are determined by the routing-protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Page 208 If this information is not present, its value should be set to the OBJECT IDENTIFIER { 0 0 }, which is a syntactically valid object identifier, and any conforming implementation of ASN.1 and BER must be able to generate and recognize this value. Connectrix DS-24M2 User Guide A-18...
Page 209: Ip Address Translation Table
Using SNMP to Manage the Switch The IP Address The IP address translation table contains the IpAddress to physical Translation Table address equivalences. Some interfaces do not use translation tables for determining address equivalences (e.g., DDN-X.25 has an algorithmic method); if all interfaces are of this type, then the Address Translation table is empty;...
Page 210: The Icmp Group
The number of ICMP Destination Unreachable messages sent. icmpOutTimeExcds Counter The number of ICMP Time Exceeded messages sent icmpOutParmProbs Counter The number of ICMP Parameter Problem messages sent. icmpOutSrcQuenchs Counter The number of ICMP Source Quench messages sent. Connectrix DS-24M2 User Guide A-20...
Page 211 Using SNMP to Manage the Switch Table A-10 ICMP Group Table MIB-2 Object Name Type Access Description icmpOutRedirects Counter The number of ICMP Redirect messages sent. For a host, this object will always be zero, since hosts do not send redirects. icmpOutEchos Counter The number of ICMP Echo (request) messages sent...
Page 212: The Tcp Group
The number of times TCP connections have made a direct transition to the CLOSED state from either the ESTABLISHED state or the CLOSE-WAIT state. tcpCurrEstab Gauge The number of TCP connections for which the current state is either ESTABLISHED or CLOSE- WAIT. Connectrix DS-24M2 User Guide A-22...
Page 213 Using SNMP to Manage the Switch Table A-11 TCP Group Table (continued) MIB-2 Object Name Type Access Description tcpInSegs Counter The total number of segments received, including those received in error. This count includes segments received on currently established connections. tcpOutSegs Counter The total number of segments sent, including those on current connections but...
Page 214: Tcp Connection Table
0.0.0.0 is used. tcpConnLocalPort INTEGER The local port number for this TCP connection (0..65535 tcpConnRemAddress IpAddress The remote IP address for this TCP connection tcpConnRemPort INTEGER The remote port number for this TCP connection (0..65535) Connectrix DS-24M2 User Guide A-24...
Page 215: The Udp Group
Using SNMP to Manage the Switch Additional TCP Objects Additional TCP Objects Table A-13 MIB-2 Object Name Type Access Description tcpInErrs Counter The total number of segments received in error (e.g., bad TCP checksums). tcpOutRsts Counter The number of TCP segments sent containing the RST flag. The UDP Group Table A-14 UDP Group...
Page 216: The Snmp Group
`readOnly'. It should be noted that it is a protocol error to generate an SNMP PDU which contains the value `readOnly' in the error-status field, as such this object is provided as a means of detecting incorrect implementations of the SNMP. Connectrix DS-24M2 User Guide A-26...
Page 217 Using SNMP to Manage the Switch Table A-16 SNMP Group (continued) MIB-2 Object Name Type Access Description snmpInGenErrs Counter The total number of SNMP PDUs which were delivered to the SNMP protocol entity and for which the value of the error-status field is `genErr'. snmpInTotalReqVars Counter The total number of MIB objects which have been retrieved successfully...
Page 218 Note that it is strongly recommended that this object be stored in non-volatile memory so that it remains constant between re-initializations of the network management system. Values: enabled(1), disabled(2) Connectrix DS-24M2 User Guide A-28...
Page 219: Fabric Element Mib Support
Using SNMP to Manage the Switch Fabric Element MIB Support experimental fibre channel (42) fcFabric (2) fcFe (1) fcConfig (1) fcFeOp (2) fcFeError (3) fcFeAcct (4) fcFeCap (5) Fibre Channel Fabric Element MIB Supported Figure A-3 The Fibre Channel Fabric Element MIB enables users on network management stations to monitor, control, and configure the switch remotely using functions specifically for Connectrix switches and directors.
Page 220: Predefined Types
0 – other, bit 1 – oneEighth, bit 2 – quarter, bit 3 – half, bit 4 – full, bit 5 – double, (0..127) bit 6 – quadruple, bit 7 – reserved for future. Connectrix DS-24M2 User Guide A-30...
Page 221 Using SNMP to Manage the Switch Table A-17 Fabric Element Management MIB: Predefined Types (continued) Type Syntax Description Fc0MediaCap INTEGER bit 0 – unknown, bit 1—single mode fibre (sm), bit 2 – multi-mode fibre 50 micron (0..65535) (m5), bit 3 -- multi-mode fibre 62.5 micron (m6), bit 4 –...
Page 222: Mib Objects Defined In The Fabric Element Mib
For example, this object could take the value 1.3.6.1.4.1.99649.3.9 if vendor ‘Neufe Inc.’ was assigned the subtree 1.3.6.1.4.1.99649, and had assigned the identifier 1.3.6.1.4.1.99649.3.9 to its ‘FeFiFo-16 PlugInCard. This is a fixed object identifier assigned from the McDATA enterprise subtree (1.3.6.1.4.1.289.2.1.1.2). Connectrix DS-24M2 User Guide A-32...
Page 223 Using SNMP to Manage the Switch Table A-19 Fabric Element MIB Modules (continued) Fabric Element MIB Provided Object Name Type Access Description fcFeModuleOperStatus INTEGER SNMP This object indicates the operational status of the module: online(1) – the module is functioning properly;...
Page 224: Fxport Configuration Table
The total number of receive buffers available for holding Class 1 connect-request, Class 2 or 3 frames from the attached NxPort. It is for buffer-to-buffer flow control in the direction from the attached NxPort (if applicable) to Fport. Connectrix DS-24M2 User Guide A-34...
Page 225 Using SNMP to Manage the Switch Table A-20 FxPort Configuration Table (continued) Fabric Element MIB Object Provided Name Type Access Description FcFxPortRxBufSize FcRxDataFieldSize LOGIN The largest Data_Field Size (in octets) for an FT_1 SERVER frame that can be received by the FxPort. This is fixed at 2112.
Page 226 1, unknown (long distance laser) 2, Longwave Laser (LC version) 3, Shortwave Laser 6 Shortwave Laser-no OFC FcFxPortDistance Fc0Distance The FC-0 distance range of the FxPort transmitter: 1, Unknown 2, Long 3, Intermediate 4, Short Connectrix DS-24M2 User Guide A-36...
Page 227: Fxport Operation Table
Using SNMP to Manage the Switch FxPort Operation A table that contains, one entry for each FxPort in the Fabric Element, Table operational status and parameters of the FxPorts. FxPort Operation Table Table A-21 Fabric Element MIB Provided Object Name Type Access Description fcFxPortOperFxPortIndex...
Page 228: Fxport Physical Level Table
The pstateUNBLOCKD and pstateBLOCKD indicate the online(1) and offline(2) respectively. If the port cannot be set to testing because it is inactive or in a failed state, the return value will be resource_unavailable(13). Connectrix DS-24M2 User Guide A-38...
Page 229 Using SNMP to Manage the Switch Table A-22 FxPort Physical Level Table (continued) Fabric Element MIB Provided Object Name Type Access Description FcFxPortPhysOperStatus INTEGER FPM, The current operational status of the FxPort. The SNMP testing(3) indicates that no operational frames can be passed.
Page 230: Fxport Fabric Login Table
128 to 2112 inclusive. FcFxPortCosSuppAgreed FcCosCap Login A variable indicating that the attached Server NxPort has requested the FxPort for the support of classes of services and the FxPort has granted the request. Connectrix DS-24M2 User Guide A-40...
Page 231: Fxport Fabric Login Table
Using SNMP to Manage the Switch Table A-23 FxPort Fabric Login Table (continued) Provided Fabric Element MIB Object Name Type Access Description FcFxPortIntermixSuppAgreed INTEGER SNMP A variable indicating that the attached NxPort has requested the FxPort for the support of Intermix and the FxPort has granted the request.
Page 232 FC-PH [1] is used between the F_Port and the N_Port. For FL_Ports, the Alternate Buffer-to-Buffer flow control mechanism as defined in FC-AL [4] is used between the FL_Port and any attached NL_Ports. This is fixed at regular(1). Connectrix DS-24M2 User Guide A-42...
Page 233: Fxport Error Table
Using SNMP to Manage the Switch FxPort Error Table A table that contains one entry for each FxPort, counters that record the numbers of errors detected. FxPort Error Table Table A-24 Fabric Element MIB Object Provided Name Type Access Description fcFxPortErrorFxPortIndex FcFeFxPortIndex SNMP...
Page 234: Class 1 Accounting Table
This value is not supported; therefore it is always zero. FcFxPortC2FbsyFrames Counter PSCC The number of F_BSY frames generated by this FxPort against Class 2 frames. FcFxPortC2FrjtFrames Counter PSCC The number of F_RJT frames generated by this FxPort against Class 2 frames. Connectrix DS-24M2 User Guide A-44...
Page 235: Class 3 Accounting Table
Using SNMP to Manage the Switch Class 3 Accounting A table that contains one entry for each FxPort in the Fabric Element, Table Class 3 accounting information recorded since the management agent has re-initialized. Class 3 Accounting Table Table A-26 Fabric Element MIB Object Provided Name...
Page 236: Fxport Capability Table
This value is fixed at 1. FcFxPortCapRxDataFieldSizeMax FcRxDataFieldSize SNMP The maximum size in bytes of the Data Field in a frame that the FxPort is capable of receiving from its attached NxPort. This value is fixed at 2112. Connectrix DS-24M2 User Guide A-46...
Page 237 Using SNMP to Manage the Switch Table A-27 FxPort Capacity Table (continued) Provided Fabric Element MIB Object Name Type Access Description FcFxPortCapRxDataFieldSizeMin FcRxDataFieldSize SNMP The minimum size in bytes of the Data Field in a frame that the FxPort is capable of receiving from its attached NxPort.
Page 238 A value indicating the set of baud rates that the FxPort is capable of supporting. This variable has been deprecated and may be implemented for backward compatibility. FcFxPortCapMedia Fc0MediaCap A value indicating the set of media that the FxPort is capable of supporting. Connectrix DS-24M2 User Guide A-48...
Page 239: Fibre Alliance Mib (Fcmgmt.mib
Using SNMP to Manage the Switch Fibre Alliance MIB (fcmgmt.mib) Type Definitions FibreAlliance MIB Type Definitions Table A-28 Type Syntax Description FcNameId OCTET STRING (SIZE(8)) Represents the Worldwide Name (WWN; IEEE 60-bitvariety; standard part of T11 definitions for fibre channel) associated with a Fibre Channel (FC) entity. FcGlobalId OCTET STRING (SIZE(16)) Represents the Worldwide Name (WWN;...
Page 240: Connectivity Unit Group
URL to invoke or launch the program referenced. FcConnUnitSnsMaxRows Unsigned32 The number The maximum number of rows in the (Same as entries in the Name fcConnUnitSnsTable table. Gauge). Server Table. Connectrix DS-24M2 User Guide A-50...
Page 241: Fcconnunittable
Using SNMP to Manage the Switch fcConnUnitTable Contains general information on the system’s units. Table A-30 fcConnUnitTable FA MIB Object Name Type Product Mapping Access Description *fcConnUnitId OCTET STRING Switch WWN The unique identification for this connectivity unit among those within this proxy domain.
Page 242 PCCard, the hub should have an independent ID. FcConnUnitType FcUnitType switch(4) The type of this connectivity unit. FcConnUnitNumports Unsigned32 Number of ports from Number of physical ports in the PROD_CNFG. connectivity unit (internal/embedded, external). Connectrix DS-24M2 User Guide A-52...
Page 243 Using SNMP to Manage the Switch Table A-30 fcConnUnitTable (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitState INTEGER online and coming-online This object reports the overall state of will indicate online state the connectivity unit. The meaning of all (2), and offline and values is essentially self-explanatory.
Page 244 Writable and persistent between boots. across IPL. FcConnUnitInfo SnmpAdminString A textual description of the Information about this connectivity unit. product. This object value should be persistent between boots. Writable and persistent across IPL. Connectrix DS-24M2 User Guide A-54...
Page 245 Using SNMP to Manage the Switch Table A-30 fcConnUnitTable (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitControl INTEGER Always return unknown (1) This object is used to control the on read operation. addressed connectivity unit. ResetConnUnitWarmStart NOTE: ‘ColdStart’ and ‘WarmStart’ are (4), offlineConnUnit (5), as defined in mib-2 and are not meant and onlineConnUnit (6) will...
Page 246 The current event index is The last used event id used as the last used event (fcConnUnitEventIndex) recorded in the fcConnUnitEventTable. When no events are presently recorded in the fcConnUnitEventTable, the value of this object MUST be zero. Connectrix DS-24M2 User Guide A-56...
Page 247: Firmware Table
Using SNMP to Manage the Switch Firmware Table The revisions table lists the revisions supported by the associated connectivity units. Firmware Table Table A-31 FA MIB Object Name Type Product Mapping Access Description *fcConnUnitRevsIndex Unsigned32 Not accessible A unique value among all fcConnUnitRevsEntrys with the same value of fcConnUnitId, in the range between 1 and...
Page 248: Sensor Table
(5) B indicates the unit is non-functional. FcConnUnitSensorInfo SnmpAdminString The serial number of the Miscellaneous static information FRUs. It’s not supported about the sensor such as its serial if the module is failed. number. Connectrix DS-24M2 User Guide A-58...
Page 249: Sensor Table
Using SNMP to Manage the Switch Table A-32 Sensor Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitSensorMessage SnmpAdminString The textual description This describes the status of the of the FRU status, such sensor as a message. It may also as “active”...
Page 250: The Port Table
(13) – parallel SCSI Gx_Port = gPort(10) port, escon (14) – escon port, lan G_Port = gPort(10) (15) – LAN port, wan (16) – WAN port. Fx_Port = flPort(7) F_Port = fPort(8) E_Port = ePort(9) Connectrix DS-24M2 User Guide A-60...
Page 251: Port Table
Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortFCClassCap FcPortFCClass If the port is not Bit mask that specifies the classes installed, of service capability of this port. If fcConnUnitPortFCClas this object is not applicable, the sCap = 0...
Page 252 Any value for this object may co-exist with any value for the fcConnUnitPortStatus object. The values are defined as follow: unknown (1), online (2), offline (3), bypassed (4). Connectrix DS-24M2 User Guide A-62...
Page 253 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortStatus INTEGER Refer to Port State The current overall protocol status Descriptions on for the port. The warning value (4) page A-100.
Page 254 SnmpAdminString Not applicable. The port vendor (e.g., for a GBIC). FcConnUnitPortSpeed Gauge32 Return 100000 The speed of the port in kilobytes kilobytes for 1 Gb/s per second. switches and 200000 kilobytes for 2 Gb/s switches. Connectrix DS-24M2 User Guide A-64...
Page 255 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortControl INTEGER ResetConnUnitPort(3), This object is used to control the offlineConnUnitPort(6), addressed fcConnUnit’s port. Valid onlineConnUnitPort(7), commands are: and portFailure(42501) Unknown (1) and invalid (2) are are the only only used as values that are read.
Page 256 For Sets specifying varbinds for instances of this object and values not supported by a given implementation, the agent will return the SNMP WrongValue PDU error code. FcConnUnitPortName SnmpAdminString Port Name A string describing the addressed port. Connectrix DS-24M2 User Guide A-66...
Page 257 Using SNMP to Manage the Switch Table A-33 Port Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitPortPhysicalNumber Unsigned32 Physical port number This is the internal port number this from 0 to Maximum port is known by. In many port number –...
Page 258 (3) – FCAL bypass, loop only, active (4) – connected to a device, loopback (5) – Port in ext loopback, txfault (6) – Transmitter fault, noMedia (7) – media not installed, linkDown (8) – waiting for activity (rx sync). Connectrix DS-24M2 User Guide A-68...
Page 259: The Event Table
Using SNMP to Manage the Switch The Event Table The table of connectivity unit events. Errors, warnings, and information should be reported in this table. Event Table Table A-34 FA MIB Object Name Type Product Mapping Access Description *fcConnUnitEventIndex Unsigned32 An event index.
Page 260 It can be the supported. OID of a connectivity unit or of another object like fcConnUnitPortStatus[...] fcConnUnitEventDescr SnmpAdminString “Reason code XX”, XX The description of the event. is the event reason code. Connectrix DS-24M2 User Guide A-70...
Page 261: Link Table
Using SNMP to Manage the Switch Link Table The link table is intended to organize and communicate any information the agent which would assist a management application to discover the Connectivity Units in the framework and the topology of their interconnect. That is, the goal is to assist the management application not only to list the elements of the framework, but to map them.
Page 262: Link Table
F ports. E port SNMP agent then the value of this nodeIdY can be object must be equal to its retrieved from fcConnUnitId. RNID, F port NodeIdY is supported by FLOGI. Connectrix DS-24M2 User Guide A-72...
Page 263 Using SNMP to Manage the Switch Table A-35 Link Table (continued) FA MIB Object Name Type Product Mapping Access Description FcConnUnitLinkPortNumberY Integer32 The attached port The port number on the unit number on the link. specified by This information is fcConnUnitLinkNodeIdY if known, available only for E otherwise –1.
Page 264: Port Statistics Table
The number of frames/packets/Ios/etc that have been received by this port. Note: A Fibre Channel frame starts with SOF and ends with EOF. FC loop devices should not count frames passed through. This value represents the sum total for all other Rx objects. Connectrix DS-24M2 User Guide A-74...
Page 265 Using SNMP to Manage the Switch Table A-36 Port Statistics Table (continued) FA MIB Object Name Type Access Product Mapping Description FcConnUnitPortStatCountTxElements Counter64 stTxOctets (64 bit counter) The number of octets or bytes that have been transmitted by this port. One second periodic polling of the port.
Page 266 Counter64 Not supported Count of times that FRJT was returned to this port as a result of a Class 1 Frame that was rejected by the fabric. Note, this is a Fibre Channel only stat. Connectrix DS-24M2 User Guide A-76...
Page 267 Using SNMP to Manage the Switch Table A-36 Port Statistics Table (continued) FA MIB Object Name Type Access Product Mapping Description FcConnUnitPortStatCountClass1PRJTFrames Counter64 Not supported Count of times that FRJT was returned to this port as a result of a Class 1 Frame that was rejected at the destination N_Port.
Page 268 Note, this is a Fibre Channel only stat. FcConnUnitPortStatCountRxOfflineSequences Counter64 stOlssIn (Supports only low 32 bits of Count of Offline Primitive OLS received at this port. Note, this is a Fibre counter; high 32 bits are set to zero). Channel only stat. Connectrix DS-24M2 User Guide A-78...
Page 269 Using SNMP to Manage the Switch Table A-36 Port Statistics Table (continued) FA MIB Object Name Type Access Product Mapping Description FcConnUnitPortStatCountTxOfflineSequences Counter64 stOlssOut (Supports only low 32 bits of Count of Offline Primitive OLS transmitted by this port. Note, this is a Fibre counter;...
Page 270 2 start and a class 3 at the end. Note, this is a Fibre Channel only stat. FcConnUnitPortStatCountEncodingDisparityErrors Counter64 Not supported. Count of disparity errors received at this port. Note, this is a Fibre Channel only stat. Connectrix DS-24M2 User Guide A-80...
Page 271: Name Server Table
Using SNMP to Manage the Switch Name Server Table This table is accessed either directly (if the management software has an index value) or via GetNexts. The value of the indexes need not be contiguous. Each entry created in this table will be assigned an index. This relationship is kept presistent until the entry is removed from the table or the system is reset.
Page 272 DisplayString Symbolic port name The Symbolic Port Name of this (SIZE (0..79) entry in the SNS table. fcConnUnitSnsSymbolicNodeName DisplayString Symbolic node name The Symbolic Node Name of (SIZE (0..79)) this entry in the SNS table. Connectrix DS-24M2 User Guide A-82...
Page 273: Trap Registration Group
Using SNMP to Manage the Switch Trap Registration Group Table A-38 Trap Registration Group FA MIB Object Name Type Product Mapping Access Description fcTrapMaxClients Unsigned32 The maximum number of SNMP The maximum number of SNMP trap trap recipients can be supported recipients supported by the in the system.
Page 274 (6): supplied by a management application wishing to delete an existing conceptual row. Connectrix DS-24M2 User Guide A-84...
Page 275: Trap Types
Using SNMP to Manage the Switch Trap Types Table A-40 Trap Types FA MIB Object Name Type Product Mapping Number OID and Value Description fcConnUnitStatusChange Generated when the switch’s online status or operational status changes. “.1.3.6.1.2.1.8888.1.1.3.1.6” + unitId The overall status of the connectivity unit has changed. fcConnUnitStatus, “.1.3.6.1.2.1.8888.1.1.3.1.5”...
Page 276: Private Enterprise Mib Support
Connectrix Private Enterprise MIB (fceos.mib) private (4) enterprise (1) McDATA (289) commDev (2) fibrechannel fcSwitch (1) fcEos (2) fcEos fcEosZoning fcEosTA (6) fcEosSys (1) fcEosFru (2) fcEosPort (3) PortBinding (4) Private Enterprise MIB Support Figure A-4 Connectrix DS-24M2 User Guide A-86...
Page 277: Connectrix Private Enterprise Mib (Fceos.mib
Using SNMP to Manage the Switch The fcEos Private Enterprise MIB defines and supports six groups: System group ( fcEosSys Field replaceable unit (FRU) group ( fcEosFru Fibre Channel port group ( fcEosPort Port binding group ( fcEosPortBinding Zoning group ( fcEosZoning Threshold alert group ( fcEosTA...
Page 278: System Group
The ASCII manufacturer of the switch. (SIZE (1..64)) fcEosSysPlantOfMfg DisplayString McK DEV-TBL The ASCII plant of manufacturer of the (SIZE (1..64)) switch. fcEosSysEcLevel DisplayString McK DEV-TBL The ASCII EC level ID of the switch. (SIZE (1..64)) Connectrix DS-24M2 User Guide A-88...
Page 279: System Group Variables
Using SNMP to Manage the Switch Table A-42 System Group Variables (continued) FCEOS MIB Object Name Type Provided By Access Description fcEosSysSerialNum DisplayString McK DEV-TBL The ASCII system serial number of the (SIZE (1..64)) switch. Returns the switch OEM serial number. fcEosSysOperStatus FcEosSysOperStatus The current operational status of the switch.
Page 280: Fru Table (Module Group
The number of the hours that the FRU has been in DEV-TBL operation. For the fan FRU, the returned value is NULL. fcEosFruTestDate DisplayString The final test date of the module. For the fan FRU, the (SIZE (0..64)) DEV-TBL returned value is NULL. Connectrix DS-24M2 User Guide A-90...
Page 281: Port Table (Port Group
Using SNMP to Manage the Switch Port Table (Port Group) Table A-44 Port Table FCEOS MIB Object Provid Name Type ed By Access Description fcEosPortIndex fcEosPortIndex SNMP The fixed physical port number on the switch. It ranges from 1 to the number of physical ports that can be supported in the switch.
Page 282 (Primitive signals and primitive sequence are not included.) fcEosPortRxWords32 Counter PSCC A 32 bit counter for the number of words within frames that the port has received. (Primitive signals and primitive sequence are not included.) Connectrix DS-24M2 User Guide A-92...
Page 283 Using SNMP to Manage the Switch Table A-44 Port Table (continued) FCEOS MIB Object Provid Name Type ed By Access Description fcEosPortTxFrames32 Counter PSCC A 32 bit counter for the number of (Fibre Channel) frames that the port has transmitted. fcEosPortRxFrames32 Counter PSCC...
Page 284 A 64 bit counter for the number of (Fibre Channel) frames (SIZE (8)) that the port has transmitted. fcEosPortRxFrames64 OCTET STRING PSCC A 64 bit counter for the number of (Fibre Channel) frames (SIZE (8)) that the port has received. Connectrix DS-24M2 User Guide A-94...
Page 285 Using SNMP to Manage the Switch Table A-44 Port Table (continued) FCEOS MIB Object Provid Name Type ed By Access Description fcEosPortTxC2Words64 OCTET STRING PSCC A 64 bit counter for the number of class 2 4-byte words that (SIZE (8)) the port has transmitted.
Page 286: Port Binding Table
The count of zones included in the active zone set. fcEosDefaultZoneSetState ZoneSetState The state of the default zone set fcEosActiveZoneSetState ZoneSetState The state of the active zone set fcEosHardwareEnforcedZoning INTEGER Indicates if zoning is hardware enforced (1=Hardzoning, 0=Nameserver zoning only). Connectrix DS-24M2 User Guide A-96...
Page 287: Active Zone Table
Using SNMP to Manage the Switch Active Zone Table Table A-47 Active Zone Table FCEOS MIB Object Name Type Provided By Access Description fcEosZoneIndex INTEGER Zone index number. This number will range from 1 to the number of zones specified by the ActiveZoneCount.
Page 288: Threshold Alert Table
INTEGER This only applies when the alert type is a Counter Threshold Alert. It specifies statistical counter or counter set to be monitored. (This object is not supported in the current release.) Connectrix DS-24M2 User Guide A-98...
Page 289: Enterprise Specific Traps
Using SNMP to Manage the Switch Enterprise Specific Traps Table A-50 Enterprise-Specific Traps Type FCEOS MIB Object Name Number Product Mapping OID and Value Description fcEosPortScn Generated when fcEosPortOpStatus An fcEosPortScn(1) is Fibre Channel port generated whenever a operational state Fc_Port changes its changes.
Page 290: Port State Descriptions
STAT_BLOCKED Offline offline(3) ok(3) active(4) offline(2) The Director port has been configured as “Blocked” and is transmitting the Fibre Channel Offline Sequence (OLS) to the attached device. Connectrix DS-24M2 User Guide A-100...
Page 291 Using SNMP to Manage the Switch Table A-51 Port State Descriptions (continued) Port Status Used Port State in Connectrix Connectrix Manager Green Amber Internally by Connectrix Manager Alert Symbol Port LEDS Port LEDs Manager FibreAlliance MIB FibreAlliance MIB FibreAlliance MIB connUnitPortState connUnitPortStatus connUnitPortHWState...
Page 292 View, and in the Alert column of the Port List View. It indicates that a corrective action is required to return the port back to a normal operating state. b. connUnitPortState(1)unknown, (2)online, (3)offline, (4)bypassed connUnitPortStatus(1)unknown, (2)unused, (3)ok, (4)warning, (5)failure, (6)notparticipating, (7)initializing, (8)bypassed connUnitPortHWState(1)unknown, (2)failed, (3)bypassed, (4)active, (5)loopback, (6)txfault, (7)noMedia, (8)linkDown c. fcFxPortPhysOperStatus(1)online, (2)offline, (3)testing, (4)link-failure Connectrix DS-24M2 User Guide A-102...
Page 293: Configuring Network Addresses
Ivisible Body Tag Configuring Network Addresses This appendix describes the procedure for configuring unique addresses for each switch. • Configuring Network Addresses ........... B-2 Configuring Network Addresses...
Page 294 If multiple switches, other managed products, and the Connectrix Service Processor are delivered in an EMC EC1200 cabinet, all devices are configured with unique IP addresses that do not require change. The addresses require change only if multiple equipment cabinets are LAN-connected.
Page 295: Connection Description Dialog Box
Configuring Network Addresses The following tools are required: A maintenance terminal (desktop or notebook PC) with: • The Microsoft Windows 98, Windows 2000, or Windows Millennium Edition operating system installed. • RS-232 serial communication software (such as ProComm Plus or HyperTerminal) installed. HyperTerminal is provided with Windows operating systems.
Page 296: Connect To Dialog Box
6. Ensure that the Connect using field displays COM1 or COM2 (depending on the serial communication port connection to the switch), and click OK. This displays the COM1 (or 2) Properties dialog box (Figure B-3). Figure B-3 Com 1, 2 Properties Dialog Box Connectrix DS-24M2 User Guide...
Page 297 Configuring Network Addresses 7. Configure the Port Settings parameters as follows: • Bits per second — 115200 • Data bits — 8 • Parity — None • Stop bits — 1 • Flow control — Hardware When the parameters are set, click OK. This displays the HyperTerminal window (Figure B-4).
Page 298: Hyperterminal Window
11. Select the Exit option from the File pull-down menu to close the HyperTerminal application. The following message box appears: 12. Click Yes. The following message box appears: 13. Click No to exit and close the HyperTerminal application. Connectrix DS-24M2 User Guide...
Page 299 Configuring Network Addresses 14. Power off the maintenance terminal: a. From the Windows taskbar, click Start, Shut Down. b. At the Windows NT Workstation menu, select the Shut Down option. c. At the Shut Down Windows window, select Shut down the Computer and click Yes to power off the PC.
Page 300 Configuring Network Addresses Connectrix DS-24M2 User Guide...
Page 301 Ivisible Body Tag Configuring the Switch from the Embedded Web Server This appendix describes the procedures for configuring the DS-24M2 from the Embedded Web Server if the switch does not have access to a Connectrix service processor. • Introduction ..................C-2 •...
Page 302: Introduction
EWS. Therefore, if you configure the switch with a public IP address, EMC recommends that the EWS be disabled, using Connectrix Manager. If you intend to use the EWS (even though EMC does recommend and/or support its use), verify that it is enabled in Connectrix Manager;...
Page 303: Management Support - Connectrix Manager Vs. Embedded Web Server
Connectrix environment with Connectrix Manager. If Connectrix Manager is already used on site, or if it was purchased for management of ED-140Ms, ED-64Ms, and/or ED-1032s, EMC highly recommends that the DS-xxM switch(es) be purchased with a Product Manager license as well. If this license is purchased, when...
Page 304 7 days a week. The Embedded Web Server does not have this feature built in. Call-home support for standalone DS-xxM switches is done using the new MIB in microcode 1.2/1.4/2.0. EMC ControlCenter WebEdition 4.3 and OnAlert interface with this MIB to provide call-home support.
Page 305: Required Browsers
Configuring the Switch from the Embedded Web Server Required Browsers To use the Embedded Web Server, you need a PC platform with Internet access and either of these browsers: Netscape Navigator 4.6 or higher Microsoft Internet Explorer 4.0 or higher Opening the Web To open the Web Server application: Server Application...
Page 306: Embedded Web Server - View Window
Connectrix Manager. Clicking Help provides comprehensive information on performing these operations. Accessing To access configuration operations, click Configure on the left side of Configuration the window. This displays the window shown in Figure C-3 on Operations page C-7. Connectrix DS-24M2 User Guide...
Page 307: Configuring Switch Ports
Configuring the Switch from the Embedded Web Server Configuring Switch Ports Perform the procedure in this section to configure names and operating characteristics for the switch ports. Refer to Configuring Ports on page 5-17 for more information on some of the parameters. Figure C-3 shows the Configure window, opened to the default page.
Page 308 • 10-100 km — Enable/disable extended distance buffering for a port by clicking the checkbox to add/remove a checkmark. • Type — Select E_Port, F_Port, or G_Port. • Speed — 1 Gb/sec, 2 Gb/sec, Negotiate. Connectrix DS-24M2 User Guide...
Page 309: Configuring Switch Identification
If the switch is installed on a public LAN, the name should reflect the switch’s Ethernet network DNS host name. For example, if the DNS host name is DS-24M21.emc.com, enter DS-24M21 in this dialog box. Configuring Switch Identification...
Page 310 Configuring the Switch from the Embedded Web Server • Description — Up to 255 alphanumeric characters. • Location — Up to 255 alphanumeric characters. • Contact person — Up to 255 alphanumeric characters. 3. Click Activate to save the information. Connectrix DS-24M2 User Guide C-10...
Page 311: Configuring The Date And Time
Configuring the Switch from the Embedded Web Server Configuring the Date and Time The operation described here allows you to configure the effective date and time for the switch. Refer to Configuring the Date and Time on page 5-31 for information on performing this operation through the Connectrix Manager.
Page 312: Configuring Switch Parameters
• Insistent Domain ID — If this option is Enabled, the Preferred Domain ID will become the active domain identification when the fabric initializes. Refer to Insistent on page 5-6 for more information. Connectrix DS-24M2 User Guide C-12...
Page 313 Configuring the Switch from the Embedded Web Server • Rerouting Delay Ensures (if Enabled) that frames are — delivered in order through the fabric to their destination. Refer to Rerouting Delay on page 5-7 for more information. • Domain RSCNs — If this option is Enabled, Domain RSCNs (register for state change notifications ) are sent between end devices in a fabric to provide additional connection information to host bus adapters (HBAs) and storage devices.
Page 314: Configuring Fabric Parameters
Click Set Offline. This message appears: Your operations changes have been successfully activated 2. On the Configure:Switch window (Figure C-4 on page C-9), click Fabric Parameters. This displays the window in Figure C-7 on page C-15. Connectrix DS-24M2 User Guide C-14...
Page 315: Embedded Web Server - Configure Fabric Parameters
In addition, the E_D_TOV must be less than the R_A_TOV. • Switch Priority — EMC recommends leaving the setting at Default. Refer to Switch Priority on page 5-9 for more information.
Page 316 4. Click Activate to save the information. 5. Set the switch on line: a. Click Operations at the left side of the Web Server window. b. On the Operations window, click the Online State tab. c. Click Set Online. Connectrix DS-24M2 User Guide C-16...
Page 317: Configuring Network Information
Configuring the Switch from the Embedded Web Server Configuring Network Information Verify the type of LAN installation with the customer’s network administrator: If one switch (or one EC-1200 cabinet) is installed on a dedicated LAN, network information (IP address, subnet mask, and gateway address) does not require changing.
Page 318 • Gateway Address — Default is 0.0.0.0 3. Click Activate to save the information. A message displays the new address information. After a few moments, the browser automatically redirects the display to the new URL (the newly-entered IP address). Connectrix DS-24M2 User Guide C-18...
Page 319: Configuring Management
Configuring the Switch from the Embedded Web Server Configuring Management The Management screens allow you to: Configure SNMP community names, write authorizations, and network addresses Enable or disable the command line interface Configure the Management Server (if installed) Configuring SNMP The operation described here allows you to configure community Trap Message names, write authorizations, and network addresses for up to 12...
Page 320: Embedded Web Server - Configure Snmp
• Trap Recipient — IP address or DNS host name of the SNMP management workstation, up to 64 alphanumeric characters. EMC recommends using the IP address. • UDP Port Number — The default user datagram protocol (UDP) port number for trap recipients is 162. To override this port number, enter a decimal port number in the associated UDP Port Number field.
Page 321: Enabling/Disabling The Cli
Configuring the Switch from the Embedded Web Server Enabling/Disabling To enable of disable the command line interface: the CLI 1. On the Management window, click the CLI tab. This displays a message similar to the following: CLI Enabled/Disabled Message Figure C-10 2.
Page 322: Configuring Zoning
2. On the Zone Set window you can add, delete (clear), or rename a zone set, or enable/disable the default zone. 3. To add, delete, or modify a zone, click Zones to display a Zones window (Figure C-12 on page C-23). Connectrix DS-24M2 User Guide C-22...
Page 323: Embeded Web Server - Configure Zone
Configuring the Switch from the Embedded Web Server Figure C-12 Embeded Web Server — Configure Zone 4. Any zones in the zone set are listed in the lower part of the window. If the zone list extends past the bottom of the window, you can display more by clicking Display More Zones or by using the scroll bar at the right.
Page 324: Embedded Web Server - Modify Zone
Clicking the new zone name displays a Modify Zone window. Add new members to the zone. 7. To save the configuration, click Zone Set. Then click Save and Activate Zoning Configuration. This also changes the zone set status from Unsaved to Saved. Connectrix DS-24M2 User Guide C-24...
Page 325: Configuring User Names And Passwords
Configuring the Switch from the Embedded Web Server Configuring User Names and Passwords The operation described here allows you to to configure the administrator-level and operator-level passwords (as specified by the customer’s network administrator) used to access the Embedded Web Server application. 1.
Page 326: Configuring Port Binding
Security tab; then click the Port Binding tab on the Security window. This displays the window in Figure C-15 on page C-27. 2. Configure tht parameters as described under Configuring Port Binding on page 5-22. 3. Click Activate to save the information. Connectrix DS-24M2 User Guide C-26...
Page 327: Embedded Web Server - Configure Port Binding
Configuring the Switch from the Embedded Web Server Embedded Web Server — Configure Port Binding Figure C-15 Configuring Port Binding C-27...
Page 328: Configuring Feature Keys
Once the optics are installed and you have obtained the appropriate FlexPort feature key from the EMC Powerlink website ), follow these steps to configure the http://powerlink.emc.com feature key using the Embedded Web Server: Refer to Adding FlexPorts on page 5-22 for information on adding ports.
Page 329: Embedded Web Server - Feature Installation
Configuring the Switch from the Embedded Web Server Enterprise Fabric Extensions, 16 FlexPorts, Open Trunking Offline Offline Embedded Web Server — Feature Installation Figure C-16 3. Type the feature key in the Feature Key field; then click Activate. 4. The interface displays a confirmation page with a warning, stating that this action overrides the current set of switch features.
Page 330 Configuring the Switch from the Embedded Web Server Connectrix DS-24M2 User Guide C-30...
Page 331: Command Line Interface
Invisible Body Tag Command Line Interface This appendix describes the commands that can be entered through the command line interface (CLI) for the DS-24M2. Access through a Telnet client is presumed. Telnet Sessions ...................D-2 CLI Overview ..................D-3 The config Branch ................D-16 maint ....................D-59 perf ....................D-63 show ....................D-78...
Page 332: Telnet Sessions
Open an Embedded Web Server or Connectrix Manager Product Manager window. c. Toggle the enabled state of the CLI, thereby clearing the client connection. d. Restart the client connection. Once the client connection is reestablished, verify your configuration’s completeness and accuracy. Connectrix DS-24M2 User Guide...
Page 333: Cli Overview
Because the CLI is not an interactive interface, no prompts are displayed to guide the user through a task. If an interactive interface is needed, use the Connectrix Manager or Embedded Web Server. For day-to-day operations, EMC recommends using the Connectrix Manager, not the CLI, unless absolutely necessary. CLI Overview...
Page 334: Entering Cli Commands
IP address, EMC recommends that the CLI be disabled, using Connectrix Manager. If you intend to use the CLI (even though EMC does recommend and/or support its use), verify that it is enabled in Connectrix Manager; however, be sure to change the default passwords of the CLI.
Page 335 Command Line Interface Navigation Basic command line navigation conventions are supported. Table D-1 Conventions includes the asynchronous commands that are recognized by the CLI. Table D-1 CLI Command Tree Navigation Conventions Character Sequence Common Name Action or Description <CR> Carriage Return Pass a completed line to the parser.
Page 336: Cli Command Tree Navigation Conventions
CLI Command Tree Table D-2 config -------------------- enterpriseFabMode setState features ----------------- installKey enterpriseFabMode openSysMS ip -------------------------- ethernet show port ----------------------- blocked extDist name speed show type openSysMS ----------- setState Connectrix DS-24M2 User Guide...
Page 337 Command Line Interface Table D-2 CLI Command Tree (continued) security ----------------- fabricBinding ----------- activatePending addMember clearMemList deleteMember replacePending setState showActive showPending portBinding ------------- bound show switchBinding ---------- addMember deleteMember setState show userRights -------------- administrator operator show snmp --------------------- addCommunity authTraps deleteCommunity show switch -------------------- bbCredit...
Page 338 --------------------- port ----------------------- beacon reset system ------------------ beacon clearSysError resetConfig setOnlineState perf ----------------------- class2 class3 clearStats errors link traffic thresholdAlerts -------- setState deleteAlert counter ------------------ addAlert addPort Connectrix DS-24M2 User Guide...
Page 339 Command Line Interface Table D-2 CLI Command Tree (continued) removePort setCounter setParams show show --------------------- eventLog features frus ip -------------------------- ethernet loginServer nameServer nameServerExt port ----------------------- config info status technology security ----------------- fabricBinding portBinding switchBinding switch system zoning Navigating the CLI Command Tree Once the administrator or operator logs in and sees the Root>...
Page 340 Root> Whenever the position in the CLI command tree moves to a new branch (for example, config to maint, config to config.port, or config.port to config), the history log is cleared. In this case, any Connectrix DS-24M2 User Guide D-10...
Page 341: Login
Command Line Interface asynchronous commands (for example, the up-arrow command <ESC>[A or the up-arrow keyboard symbol) cannot move the position back towards the root, as shown in this example: Root> config Root.Config> port Root.Config.Port> <ESC>[A Root.Config.Port> Whenever the position in the CLI command tree moves to a new branch (config, maint, perf, or show), the history log is cleared.
Page 342: Logout
Embedded Web Server. Parameters This command has no parameters. Command Examples login Username: Administrator Password: password login Username: Operator Password: password logout Syntax logout Purpose This command allows a Telnet client to disconnect from the switch. Connectrix DS-24M2 User Guide D-12...
Page 343: Commadelim
Command Line Interface Description This command logs out the single Telnet client connected to the switch. This command can be entered at any point in the command tree. Parameters This command has no parameters. Command Examples Root> logout config> logout config.port>...
Page 344: Handling Command Line Interface Errors
- password <password> If the question mark is used after one or more characters of a keyword, any keywords at that level of the CLI command tree appear. Root> config s? security snmp switch system Connectrix DS-24M2 User Guide D-14...
Page 345: Commenting Scripts
Command Line Interface Commenting Scripts The pound sign (#) can be used to add comments in a script file. The pound sign must be the first character in the line; the CLI ignores everything after the pound sign in that line. The following lines are valid: Root>...
Page 346: The Config Branch
Syntax setState enterpriseFabModeState Purpose This command sets the Enterprise Fabric Mode state for the fabric. The EMC Enterprise Fabric Extensions feature key must be installed to activate the Enterprise Fabric Mode state. Parameters This command has one parameter: Specifies whether entrepriseFabMode enterpriseFabModeState is active.
Page 347: Config.features.installkey
Syntax enterpriseFabMode enterpriseFabModeState Purpose This command sets the Enterprise Fabric Mode state for the fabric. The EMC Enterprise Fabric Extensions feature key must be installed to activate the Enterprise Fabric Mode state. Parameters This command has one parameter: Specifies whether entrepriseFabMode enterpriseFabModeState is active.
Page 348: Config.features.opensysms
Command Example Root> config features openSysMS 1 config.features.show Syntax show Purpose This command shows the product feature information configured for this switch. Parameters This command has no parameters. Command Example Root> config features show Connectrix DS-24M2 User Guide D-18...
Page 349: Config.ip.ethernet
Command Line Interface Output The product feature data is displayed as a table that includes the following properties. Installed Feature Set The feature set installed using a feature key. Only installed keys are displayed. Feature Individual features within each set. In many cases, there is only one feature within each feature set.
Page 350: Config.ip.show
Output Example The output of config.ip.show appears as in this example: IP Address: 10.0.0.0 Gateway Address: 0.0.0.0 Subnet Mask: 255.0.0.0 config.port.blocked Syntax blocked portNumber blockedState Purpose This command sets the blocked state for a port. Connectrix DS-24M2 User Guide D-20...
Page 351: Config.port.name
Command Line Interface Parameters This command has two required parameters: Specifies the port number. Valid values for the portNumber DS-24M2 are 0 through 23. Specifies the blocked state for the port. Valid blockedState values are true and false. Boolean 1 or 0 may be substituted as values.
Page 352: Config.port.type
Specifies the port number. Valid values for the portNumber DS-24M2 are 0 through 23. Specifies the type of the port. Valid values are portType eport, fport, and gport. Command Example Root> config port type 4 fport Connectrix DS-24M2 User Guide D-22...
Page 353: Config.port.show
Command Line Interface config.port.show Syntax show portNumber Purpose This command displays the port configuration for a single port. Parameters This command has one parameter: Specifies the port number. Valid values for the portNumber DS-24M2 are 0 through 23. Command Example Root>...
Page 354: Config.security.fabricbinding
This command takes effect immediately. The CLI verifies the list before activating it to the fabric and adds the managed switch to the list if it is not already present. Parameters This command has no parameters. Root> config security fabricBinding activatePending Connectrix DS-24M2 User Guide D-24...
Page 355: Config.security.fabricbinding.addmember
Command Line Interface config.security.fabricBinding.addMember Syntax addMember wwn domainId Purpose This command adds a new member to the Fabric Member List in the pending fabric binding work area. The number of entries is limited to the maximum available domain IDs for the fabric (31). Changes from this command are not activated to the fabric until the activatePending command is issued.
Page 356: Config.security.fabricbinding.deletemember
Root> config security fabricBinding deleteMember 2 config.security.fabricBinding.replacePending Syntax replacePending Purpose This command replaces the pending working area with the fabric binding configuration that is currently loaded on the fabric. Parameters This command has no parameters. Root> config security fabricBinding replacePending Connectrix DS-24M2 User Guide D-26...
Page 357: Config.security.fabricbinding.setstate
Command Line Interface config.security.fabricbinding.setState Syntax setState fabricBindingState Purpose This command sets the fabric binding state for the pending fabric binding configuration work area. This state is not saved to the fabric until the activatePending command is issued. Parameters This command has one parameter: Specifies the fabric binding state for the fabricBindingState pending fabric binding configuration work...
Page 358: Config.security.fabricbinding.showactive
If no changes have been made to the pending environment, the CLI displays the active membership list. Parameters This command has no parameters. Connectrix DS-24M2 User Guide D-28...
Page 359: Config.security.portbinding.bound
Command Line Interface Output The fabric binding configuration data is displayed as a table that includes the following properties. Fabric Binding The pending fabric binding state: Inactive or State Active Restricting fabric The pending fabric membership list. membership list Output Example The output from the config.security.fabricBinding.showPending command displays as follows.
Page 360 If the boundWwn is configured and the portBindState is: Active — Only the device described by boundWwn is able to connect to the specified port. Inactive — The WWN is retained, but any device can connect to the specified port. Connectrix DS-24M2 User Guide D-30...
Page 361: Config.security.portbinding.show
Command Line Interface Instead of the WWN, either of two values can be boundWwn entered in this parameter: (continued) attached — Automatically configures the currently attached device WWN as the bound WWN. remove — Changes the WWN to the default value, 00:00:00:00:00:00:00:00.
Page 362: Config.security.switchbinding.addmember
Root> config security switchBinding addMember AA:99:23:23:08:14:88:C1 config.security.switchBinding.deleteMember Syntax deleteMember wwn Purpose This command removes a member from the Switch Member List. The user cannot remove a member that is currently logged in to the switch. Connectrix DS-24M2 User Guide D-32...
Page 363: Config.security.switchbinding.setstate
Command Line Interface Parameters This command has one parameter: Specifies the switch or N_Port device WWN of the member to be removed from the switch membership list. The value of the WWN must be in colon-delimited hexadecimal notation (for example, AA:00:AA:00:AA:00:AA:00). The user may also enter all for this argument to clear the switch membership list completely.
Page 364 — Enable switch binding and restrict E_Port and F_Port connections. Both E_Ports and F_Ports prohibit connections with all devices unless explicitly identified in the switch membership list. Root> config security switchBinding setState allRestrict Connectrix DS-24M2 User Guide D-34...
Page 365: Config.security.switchbinding.show
Command Line Interface config.security.switchBinding.show Syntax show Purpose This command displays the switch binding configuration. Parameters This command has no parameters. Output This command displays the following switch binding configuration data: Disabled switchBindingState Enabled and Restricting F_Ports Enabled and Restricting E_Ports Enabled and Restricting All Ports.
Page 366: Config.security.userrights.operator
The default is set to password. This parameter is 1 to 15 characters. Valid characters include all characters in the USASCII character set, excluding control characters. Command Example Root> config security userRights operator “Operator” “newpassword” Connectrix DS-24M2 User Guide D-36...
Page 367: Config.security.userrights.show
Command Line Interface config.security.userRights.show Syntax show Purpose This command shows the user rights for the CLI access levels. Parameters This command has no parameters. Command Example Root> config security userRights show Output The user rights configuration data is displayed as a table, as shown in the following example.
Page 368: Config.snmp.authtraps
Root> config snmp addCommunity 1 "CommunityName1" enabled 123.123.123.123. 162 config.snmp.authTraps Syntax authTraps enabledState Purpose This command enables or disables the authorization traps to be sent to SNMP management stations when unauthorized stations try to access SNMP information from the switch. Connectrix DS-24M2 User Guide D-38...
Page 369: Config.snmp.deletecommunity
Command Line Interface Parameters This command has one parameter. Specifies whether the authorization traps are enabledState enabled. Valid values are true and false. Boolean 1 or 0 may be substituted as values. Command Examples Root> config snmp authTraps true Root> config snmp authTraps 1 config.snmp.deleteCommunity Syntax deleteCommunity commIndex...
Page 370: Config.switch
If these commands are entered while the switch is on line, an error message results. config.switch.domainRSCN Syntax domainRSCN domainRSCNState Purpose This command sets the domain RSCN state for the switch. The switch can be either off line or on line when this command is executed. Connectrix DS-24M2 User Guide D-40...
Page 371: Config.switch.insistdomainid
Command Line Interface Parameters This command has one parameter. Specifies whether the domain RSCN state is domainRSCNState enabled. Valid values are enable and disable. Boolean 1 and 0 may be substituted as values. Command Example Root> config switch domainRSCN 1 config.switch.insistDomainId Syntax insistDomainId insistentDomainIdState...
Page 372: Config.switch.interopmode
The switch must be off line before issuing this command. Use maint.system.setOnlineState to set the switch off line. Parameters This command has one parameter. Specifies the new preferred domain ID value. domainId This parameter must be an integer in the range 1 through 31. Connectrix DS-24M2 User Guide D-42...
Page 373: Config.switch.priority
Command Line Interface Command Example Root> config switch prefDomainId 1 config.switch.priority Syntax priority switchPriority Purpose This command sets the switch priority. Description The switch must be off line before issuing this command. Use maint.system.setOnlineState to set the switch off line. Parameters This command has one parameter.
Page 374: Config.switch.ratov
This may result in frames being delivered to a destination out of order because frames sent over the new, shorter path may arrive ahead of older frames still in route over the older path. Connectrix DS-24M2 User Guide D-44...
Page 375: Config.switch.show
Command Line Interface If rerouting delay is enabled, traffic ceases in the fabric for the time specified in the config.switch.edTOV command. This delay allows frames sent on the old path to exit to their destination before new frames begin traversing the new path. Note that during this delay period, frames addressed to the destinations that are being rerouted are discarded if they are Class 3 frames and rejected if they are Class 2 or Class F frames.
Page 376: Config.switch.zoningrscn
(These changes include activating and deactivating the zone set, or enabling and disabling the default zone.) Refer to Suppress RSCNs on Zone Set Activations on page 5-7 for more information. Connectrix DS-24M2 User Guide D-46...
Page 377: Config.system.contact
Command Line Interface This parameter is structured differently in different interfaces. To suppress fabric-format RSCNs from the Product Manager or Embedded Web Server, you enable the parameter Suppress RSCNs on Zone Set Activations. To accomplish the same result from the CLI, you set zoningRSCN to disable. Parameters This command has one parameter.
Page 378: Config.system.date
This command sets the system description string. Parameters This command has one parameter. Specifies the new system description string systemDescription for the switch. The name can contain up to 255 characters. Command Example Root> config system description “DS-24M2 Fibre Channel Switch” Connectrix DS-24M2 User Guide D-48...
Page 379: Config.system.location
Command Line Interface config.system.location Syntax location “systemLocation” Purpose This command sets the system location attribute. Parameters This command has one parameter. Specifies the new system location for the switch. systemLocation The location can contain up to 255 characters. Command Example Root>...
Page 380: Config.zoning
Specifies whether the default zone is defaultZoneState enabled. Valid values are true and false. Boolean 1 or 0 may be substituted as values. Command Examples Root> config zoning setDefZoneState false Root> config zoning setDefZoneState 0 Connectrix DS-24M2 User Guide D-50...
Page 381: Config.zoning.activatezoneset
Command Line Interface config.zoning.activateZoneSet Syntax activateZoneSet Purpose This command activates the zone set contained in the work area to the fabric and takes effect immediately. Description This command takes effect immediately in the fabric. Parameters This command has no parameters. Command Example Root>...
Page 382: Config.zoning.clearzoneset
Specifies the name of the new zone. The zoneName zoneName must contain 1 to 64 characters. Valid characters are: ABCDEFGHIJKLMNOPQRSTUVWXYZabcd efghijklmnopqrstuvwxyz0123456789$-^_ Spaces are not permitted, and the first character must be alphabetical. Command Example Root> config zoning addZone TheUltimateZone Connectrix DS-24M2 User Guide D-52...
Page 383: Config.zoning.deletezone
Command Line Interface config.zoning.deleteZone Syntax deleteZone “zoneName” Purpose This command deletes a zone from the zone set in the work area. Description Changes are not activated on the switch until the config.zoning.activeZoneSet command is issued. Parameters This command has one parameter. Specifies the name of the zone to be deleted.
Page 384: Config.zoning.addwwnmem
Valid values are integers 1 through 15. Specifies the port number of the member to be portNumber added to the zone. Valid port number values for the DS-24M2 are 0 through 23. Connectrix DS-24M2 User Guide D-54...
Page 385: Config.zoning.clearzone
Command Line Interface Command Example Root> config zoning addPortMem TheUltimateZone 10 6 config.zoning.clearZone Syntax clearZone “zoneName” Purpose This command clears all zone members for the specified zone in the work area. Description This command does not change the zone name. Parameters This command has one parameter.
Page 386: Config.zoning.deleteportmem
Specifies the new zone name. The name must newZoneName contain 1–64 characters. Valid characters are: ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefgh ijklmnopqrstuvwxyz0123456789$-^_ Spaces are not permitted, and the first character must be alphabetical. Command Example Root> config zoning renameZone TheOldUltimateZone TheUltimateZone Connectrix DS-24M2 User Guide D-56...
Page 387: Config.zoning.showpending
Command Line Interface config.zoning.showPending Syntax showPending Purpose This command shows the zoning configuration in the work area of the zone set that has not yet been activated. Parameters This command has no parameters. Command Example Root> config zoning showPending Output The zoning configuration data is displayed as a table that includes the enabled/disabled status, name, and member zones of the zone set.
Page 388 TheUltimateZone ZoneMember: Domain 10, Port 6 ZoneMember: Domain 15, Port 2 ZoneMember: Domain 2, Port 63 ZoneMember: 10:00:00:00:C9:22:9B:64 ZoneMember: 10:00:00:00:C9:22:9B:BD Zone: TheNotSoUltimateZone ZoneMember: 10:00:00:00:C9:22:9B:AB ZoneMember: 10:00:00:00:C9:22:9B:C6 ZoneMember: 10:00:00:00:C9:22:9B:AB Zone: TheNotUltimateAtAllZone ZoneMember: Domain 2, Port 63 Connectrix DS-24M2 User Guide D-58...
Page 389: Maint
Command Line Interface maint The maint branch of the CLI command tree contains commands that relate to maintenance activities. The commands in the maint branch can be used only by the Administrator. Note that the maint.system.resetConfig command resets all configuration data and non-volatile settings, including network information, to their default values (factory settings).
Page 390: Maint.system.beacon
Command Examples Root> maint system beacon false Root> maint system beacon 0 maint.system.clearSysError Syntax clearSysError Purpose This command clears the system error light. Parameters This command has no parameters. Command Example Root> maint system clearSysError Connectrix DS-24M2 User Guide D-60...
Page 391: Maint.system.ipl
Command Line Interface maint.system.ipl Syntax Purpose This command IPLs the switch. Description Connection to the CLI is lost when this command runs. Parameters This command has no parameters. Command Example Root> maint system ipl maint.system.resetConfig Syntax resetConfig Purpose This command resets all NV-RAM configuration parameters (including feature keys and IP addresses) to their default values.
Page 392 Specifies whether the switch is on line. Valid onlineState values are true and false. Boolean 1 or 0 may be substituted as values. Command Examples Root> maint system setOnlineState true Root> maint system setOnlineState 1 Connectrix DS-24M2 User Guide D-62...
Page 393: Perf
Command Line Interface perf The perf branch of the CLI command tree contains commands that relate to performance services. The commands in the perf branch can by used by either the administrator or the operator. The counters in perf command output are 32-bit values that wrap at 4,294,967,296.
Page 394: Perf.class3
Rx Frames — The number of Fibre Channel Class 3 frames the port has received. Tx Frames — The number of Fibre Channel Class 3 frames the port has transmitted. Rx Words — The number of Class 3 4-byte words within frames the port has received. Connectrix DS-24M2 User Guide D-64...
Page 395: Perf.clearstats
Command Line Interface TX Words — The number of Class 3 4-byte words within frames the port has transmitted. Disc Frames — The number of Class 3 frames that have been discarded upon receipt by this port. There are no FBSYs or FRJTs generated for Class 3 frames.
Page 396: Perf.errors
CRC Errs — The number of frame CRC errors detected by the port. Dlim Errs — The number of invalid frame delimiters (SOF or EOF) received by the port. Addr Id Errs — The number of frames received with unknown addressing. Connectrix DS-24M2 User Guide D-66...
Page 397: Perf.link
Command Line Interface Output Example The output from perf.errors is similar to the following: Port 2 Statistic Count ----------- ---------- Prim Seq Err 753452 Disc Frms 351269 Inv Tx Wrds 2953184 CRC Errs 1842953 Delim Errs 2953184 Addr Id Errs 1842953 perf.link Syntax link portNumber...
Page 398: Perf.thresholdalerts
(Refer to perf.thresholdAlerts.counter.setCounter on page D-73.) 3. Configure the threshold alert using other perf.threshold alert commands. For example, you should assign the threshold alert to a port using perf.thresholdAlerts.counter.addAlert. (Refer to perf.thresholdAlerts.counter.addPort on page D-71.) Connectrix DS-24M2 User Guide D-68...
Page 399: Threshold Alert Counters
Command Line Interface 4. Once the alert is fully configured, it can be activated using perf.thresholdAlerts.setState. (Refer to perf.thresholdAlerts.setState on page D-76.) An alert cannot be modified unless it is in the disabled state. Threshold Alert Counters Table D-3 Number Threshold Alert Counter or Counter Set Link Resets Sent Link Resets Received...
Page 400 The new alert is assigned default settings which can then be changed using the other counter threshold alert commands. The default settings for a new counter threshold alert are: Ports: None Counter: None Increment: 100 Interval: 60 minutes State: Disabled Connectrix DS-24M2 User Guide D-70...
Page 401: Perf.thresholdalerts.counter.addport
Command Line Interface Parameters This command has one parameter. Specifies the name of the new counter name threshold alert. This name can consist of any ASCII characters up to a maximum length of 64 characters. To use spaces or special characters in this name, put quotation marks around the name.
Page 402: Perf.thresholdalerts.counter.deletealert
D-70.) Specifies the port number. Valid values are 0 portNumber through 23, or all, which removes every port on the product from the counter threshold alert. Command Example Root> perf thresholdAlerts counter removePort checklinks Connectrix DS-24M2 User Guide D-72...
Page 403: Perf.thresholdalerts.counter.setcounter
Command Line Interface perf.thresholdAlerts.counter.setCounter Syntax setCounter name counterNumber Purpose This command sets the counter statistic that will be used to trigger the counter threshold alert. Use this command to associate a counter with the threshold alert name created using the perf.thresholdAlerts.setState command.
Page 404 = 30 minutes The increment value takes place in an interval that is a fixed length amount of time. This interval is not a rolling window interval. Command Example Root> perf thresholdAlerts counter setParams checklinks 5 30 Connectrix DS-24M2 User Guide D-74...
Page 405: Perf.thresholdalerts.counter.show
Command Line Interface perf.thresholdAlerts.counter.show Syntax show name Purpose This command displays the settings for an individual counter threshold alert. Parameters This command has one parameter. The name of a threshold alert as defined by the name command perf.thresholdAlerts.counter.addAlert. (Refer to perf.thresholdAlerts.counter.addAlert on page D-70.) Command Example Root>...
Page 406: Perf.thresholdalerts.setstate
The name of a threshold alert as defined by name the command perf.thresholdAlerts.counter.addAlert. (Refer to perf.thresholdAlerts.counter.addAlert on page D-70.) Sets the counter threshold alert enabled state. enabledState Valid values are enabled and disabled. Boolean 1 and 0 values may also be substituted. Connectrix DS-24M2 User Guide D-76...
Page 407: Perf.traffic
Command Line Interface Command Example Root> perf thresholdAlerts setState checklinks enabled perf.traffic Syntax traffic portNumber Purpose This command displays port traffic counters for a single port. Parameters This command has one parameter. Specifies the port number to be reset. Valid portNumber values for the DS-24M2 are 0 through 23.
Page 408: Show
• Minor —Unit operational (minor failure). • Severe —Unit not operational. • Info—Unit operational (information only). FRU — The FRU and FRU position, where applicable. Event Data — The 32-byte hexidecimal description of the event in words. Connectrix DS-24M2 User Guide D-78...
Page 409: Show.features
Command Line Interface Output Example The output from show.eventLog is similar to the following: Date/Time Code Severity Event Data ---------------- ---- -------- ----- ---------------------------------- 04/12/01 10:58A 375 Major CTP-0 00010203 04050607 08090A0B 0C0D0E0F 04/12/01 09:58A 385 Severe CTP-0 00010203 04050607 08090A0B 0C0D0E0F 04/11/01 07:18P 395 Severe CTP-0 00010203 04050607 08090A0B 0C0D0E0F...
Page 410: Show.frus
The output from show.frus is similar to the following: Position State Serial Num Part Num Beacon Pwr On Hrs -------- -------- ------ ---------- -------------- ------ ---------- Active 118031905 S802578490 Power Active Power Active Active Active Active Active Active Active Connectrix DS-24M2 User Guide D-80...
Page 411: Show.ip.ethernet
Command Line Interface show.ip.ethernet Syntax ethernet Purpose This command displays Ethernet attributes. Parameters This command has no parameters. Command Example Root> show ip ethernet Output The ethernet attributes data is displayed as a table that includes the following properties. IP Address — The IP address for the Ethernet adapter as set in the config.lan.ipAddress command.
Page 412: Show.loginserver
The output from show.loginServer is similar to the following: Port BB Crdt RxFldSz Port Name Node Name ---- ------- ------- ----------------------- ----------------------- 00:11:22:33:44:55:00:77 20:11:22:33:44:55:66:77 00:11:22:33:44:55:00:78 20:11:22:33:44:55:66:78 00:11:22:33:44:55:00:79 20:11:22:33:44:55:66:79 00:11:22:33:44:55:00:80 20:11:22:33:44:55:66:80 00:11:22:33:44:55:00:81 20:11:22:33:44:55:66:81 00:11:22:33:44:55:00:82 20:11:22:33:44:55:66:82 00:11:22:33:44:55:00:83 20:11:22:33:44:55:66:83 00:11:22:33:44:55:00:84 20:11:22:33:44:55:66:84 00:11:22:33:44:55:00:85 20:11:22:33:44:55:66:85 00:11:22:33:44:55:00:86 20:11:22:33:44:55:66:86 Connectrix DS-24M2 User Guide D-82...
Page 413: Show.nameserver
Command Line Interface show.nameServer Syntax nameServer Purpose This command displays information from the name server database for devices attached to this switch. Parameters This command has no parameters. Command Example Root> show nameServer Output The device information data is displayed as a table that includes the following properties: Type —...
Page 414 9: CP IPI-3 Peer 10: SBCCS-Channel 11: SBCCS-Control Unit 12: FC-SB-2 Channel to Control Unit 13: FC-SB-2 Control Unit to Channel 14: Fibre Channel Service 15: FC-FG 16: FC-SW 17: FC-AL 18: SNMP 19: HIPPI-FP 20: Vendor Unique Connectrix DS-24M2 User Guide D-84...
Page 415: Show.nameserverext
Command Line Interface show.nameServerExt Syntax nameServerExt Purpose This command displays information from the name server database for devices attached to this director. It displays the exact same information as shown in the show.nameServer command, but also includes display of the Symbolic Nameserver information. Note that it is possible to have more than one device per port for any public loop devices attached to an FL_Port.
Page 416: Sshow.port.config
Type — The port type as set in the config.port.type command. Speed — The port speed as set in the config.port.speed command. Output Example The output from show.system is similar to the following: Connectrix DS-24M2 User Guide D-86...
Page 417: Show.port.info
Command Line Interface Port Name Blocked Ext Dist Type Speed ---- ------------------------ ------- -------- ----- --------- Port 1 false false fPort 1 Gb/sec Port 2 true true fPort 1 Gb/sec Port 3 false false gPort 1 Gb/sec Port 4 false false fPort 2 Gb/sec...
Page 418: Show.port.status
The port status data is displayed as a table that includes the following properties. Port — The port number. State — The port state; for example: • Segmented E_Port • Invalid Attachment • Not Installed • Online • Offline • Not Operational • No Light Connectrix DS-24M2 User Guide D-88...
Page 419 13 = External loopback adapter connected to the port 14 = N_Port connection not allowed on this port 15 = Non-EMC switch at other end of the ISL 16 = ISL connection not allowed on this port 17 = ISL connection not allowed to external fabrics 18 = Port binding violation—unauthorized WWN...
Page 420 No Light fPort 10:00:80:00:11:22:33:56 false Online fPort 10:00:80:00:11:22:33:59 false Invalid Attachment fPort 10:00:80:00:11:22:33:64 false Online fPort 10:00:80:00:11:22:33:66 false 03: Duplicate Domain ID(s) 04: Switch Speed Conflict 10: ISL connection not allowed on this port Connectrix DS-24M2 User Guide D-90...
Page 421: Show.port.technology
Command Line Interface show.port.technology Syntax technology Purpose This command displays port technology information for all ports. Parameters This command has no parameters. Command Example Root> show port technology Output The port technology data is displayed as a table that includes the following properties.
Page 422: Show.security.fabricbinding
Domain 1 (00:11:22:33:44:55:66:77) Domain 2 (88:99:AA:BB:CC:DD:EE:FF) Domain 14 (11:55:35:45:24:78:98:FA) show.security.portBinding Syntax portBinding Purpose This command shows the port binding configuration for all ports. Parameters This command has no parameters. Command Example Root> show security portBinding Connectrix DS-24M2 User Guide D-92...
Page 423: Show.security.switchbinding
Command Line Interface Output The port binding configuration data is displayed as a table that includes the following properties. Port — The port number. Port Binding — The state of port binding for the specified port (Active or Inactive). Bound WWN — The WWN of the device that is bound to the specified port.
Page 424: Show.switch
E_D_TOV — The E_D_TOV as set in the config.switch.edTov command. Preferred Domain Id — The domain ID as set in the config.switch.domainId command. Switch Priority — The switch priority as set in the config.switch.priority command. Connectrix DS-24M2 User Guide D-94...
Page 425 Command Line Interface Speed — The switch speed as set in the config.switch.speed command. Rerouting Delay — The rerouting delay as set in the config.switch.rerouteDelay command. Operating Mode — The operating mode (Open Systems). Interop Mode — The interoperability mode as set in the config.switch.interopMode command.
Page 426: Show.system
001, except 1 Gb switch models, which are 002. EC Level — The engineering change level installed. Firmware Version — The current firmware version installed. Beaconing — The enabled state of unit beaconing (enabled or disabled). Connectrix DS-24M2 User Guide D-96...
Page 427: Show.thresholdalerts.alert
Command Line Interface Output Example The output from show.system is similar to the following: System Information Name: Joe’s Switch Description: Connectrix DS-24M2 Switch Contact: Location: Everywhere Date/Time: 10/16/2001 10:34:01AM Serial Number: 123456789 Type Number: Model Name; DS-24M2 Model Number; EC Level: Firmware Version: 01.03.00 Build 34...
Page 428 The output from show.thresholdAlerts.alert is similar to the following: Name Type State ------------------------------------ ----------------- -------- Throughput Threshold #1 Rx Util Enable Threshold for CRC CRC Errors Disabled Safety #2 Logic Lnk Err Set Enabled Safety #1 Cls2 BusiedFrms Disabled Connectrix DS-24M2 User Guide D-98...
Page 429: Show.thresholdalerts.log
Command Line Interface show.thresholdAlerts.log Syntax log [clear] Purpose This command shows the contents of the threshold alert log. This log shows all the threshold alerts that have been triggered, including both counter threshold alerts (CTAs) and throughput threshold alerts (TTAs). Parameters This command has one parameter.
Page 430: Show.zoning
This command shows the zoning configuration saved on the fabric. Parameters This command has no parameters. Command Example Root> show zoning Output The zoning configuration data is displayed as a table that includes the enabled/disabled status, name, and member zones of the zone set. Connectrix DS-24M2 User Guide D-100...
Page 431 Command Line Interface Output Example The output from show.zoning is similar to the following: Active ZoneSet ------------- Default Zone Enabled: False ZoneSet: TheUltimateZoneSet Zone: TheUltimateZone ZoneMember: Domain 10, Port 6 ZoneMember: Domain 15, Port 2 ZoneMember: Domain 2, Port 63 ZoneMember: 10:00:00:00:C9:22:9B:64 ZoneMember: 10:00:00:00:C9:22:9B:BD Zone:...
Page 432 Command Line Interface Connectrix DS-24M2 User Guide D-102...
Page 433: Specifications
Invisible Body Tag Specifications This appendix lists the physical characteristics and operating environment of the DS-24M2. Specifications ..................E-2 Specifications...
Page 434: Specifications
Input voltage 90 to 264 VAC, 47 to 63 Hz Requirements Current Plan for single-phase or phase-to-phase connections and 5-amp dedicated service. Average Power • 120Vrms Irms = 1.61 A Consumption • 220Vrms Irms = 0.94 A Connectrix DS-24M2 User Guide...
Page 435 Specifications Table 0-3 Storage and Protective packaging must be provided to protect the DS-16M Shipping under all shipping methods (domestic and international). Environment ° ° ° ° Shipping Temperature F to 140 F (-40 C to 60 ° ° ° °...
Page 436 ° ° ° ° Operating Temperature F to 104 F (4 C to 40 Environment Relative Humidity 8% to 80% ° ° Maximum Wet-Bulb F (27 Temperature Maximum Altitude 10,000 ft (3,048 m) Inclination 10° maximum Connectrix DS-24M2 User Guide...
Page 437 Body Tag Customer Support This appendix reviews the EMC process for detecting and resolving software problems, and provides essential questions that you should answer before contacting the EMC Customer Support Center. Overview of Detecting and Resolving Problems ......F-2 Troubleshooting the Problem ............F-3 Before Calling the Customer Support Center ........F-4...
Page 438: Customer Support
Customer Support Overview of Detecting and Resolving Problems EMC software products are supported directly by the EMC Customer Support Center in the United States. EMC uses the following process to resolve customer problems with its software products (Figure F-1). Problem...
Page 439: Troubleshooting The Problem
3. Run some test cases to reproduce the problem. If you encounter a problem that requires technical programming or analysis, call the nearest EMC office or contact the EMC Customer Support Center at one of the following numbers: United States: (800) 782-4362 (SVC-4EMC)
Page 440: Before Calling The Customer Support Center
For an MVS problem, the JESLOG, SYSPRINT, all STDOUT DD members of the server job output and similar output for the client, and the relevant portion of the SYSLOG Connectrix DS-24M2 User Guide...
Page 441: Documenting The Problem
Customer Support Documenting the Problem If the EMC Customer Support Center requests information regarding the problem, please document it completely, making sure to include the following information: Your company name and address Your name Your telephone number The importance of the problem, so that it can be assigned a...
Page 442: Reporting A New Problem
Message numbers and complete text of any messages that the system produced Log file dated near the time the error occurred Results from tests that you have run Other related system output Other information that may help solve the problem Connectrix DS-24M2 User Guide...
Page 443: Sending Problem Documentation
Customer Support Sending Problem Documentation Use one of the following methods to send documentation of the problem to the EMC Customer Support Center: E-mail U.S. mail to the following address: EMC Customer Support Center 45 South Street Hopkinton, MA 01748-9103...
Page 444 Customer Support Connectrix DS-24M2 User Guide...
Page 445: Glossary
Glossary This glossary contains terms related to EMC Connectrix. Many of these terms are used in this manual. The glossary includes terms and definitions from: • The Dictionary of Computing, ZC20-1699. • The American National Standard Dictionary for Information Systems, ANSI X3.172-1990, copyright 1990, by the American National...
Page 446: Audit Log
A log containing summaries of actions taken by a Connectrix Management software user, recording an audit trail of changes. For example: adding, modifying, or deleting user or product administration records the operation, including the date and time, in the audit log. Connectrix DS-24M2 User Guide...
Page 447 A fabric rebuilding process that retrieves information from all switches in the fabric and assigns the principal switch. A Build Fabric follows any of these occurrences: • Multiple switches are interconnected to form a fabric. • A switch is removed from the fabric. Connectrix DS-24M2 User Guide...
Page 448 The agent counts these failures and reports the count to the manager program upon request, or sends an authentication failure trap message to the manager program. Connectrix DS-24M2 User Guide...
Page 449 (1) A piece of equipment, such as a server or storage device, that is attached to a Connectrix switch or a similar product. A device as defined here is not controlled by the Connectrix Product Manager and its operating parameters. (2) In EMC Symmetrix, a uniquely Connectrix DS-24M2 User Guide...
Page 450 Symmetrix subsystem, such as a disk. (This description is presented here only to clarify a term used in other EMC documents.) Dialog Box A pop-up window containing informational messages or fields to be modified with desired options.
Page 451: Event Log
Any active switch or director in the fabric. Fabric Login Process used by N_Ports to establish their operating parameters including the presence or absence of a fabric, paths to other N_Ports, and specific operating characteristics for each port. Connectrix DS-24M2 User Guide...
Page 452 Glossary Fabric Manager Software application that is the system management framework and the user interface for managing EMC Fibre Channel connectivity products. The Connectrix Manager can run either locally on the Connectrix service processor or remotely on a user workstation.
Page 453: Hardware Log
A record of FRU insertions and removals in a Connectrix switch. See Host Bus Adapter. Hexadecimal Pertaining to a numbering system with base of 16; valid numbers use the digits 0 through 9 and characters A through F (which represent the numbers 10 through 15). Connectrix DS-24M2 User Guide...
Page 454 The concept includes the specification of the connection of two devices having different functions. (2) Hardware, software, or both, that links systems, programs, or devices. Internet Protocol See IP. g-10 Connectrix DS-24M2 User Guide...
Page 455 A problem detected on a fiber optic link; for example, loss of light, or invalid sequences. Load Balancing The ability to distribute traffic over all network ports that are the same distance from the destination address by assigning different paths to different messages. Increases effective network bandwidth. g-11 Connectrix DS-24M2 User Guide...
Page 456 Multicast is used when multiple copies of data are to be sent to designated, multiple, destinations. Multiswitch Fabric Fibre Channel fabric created by linking more than one switch or director together to allow communication. See also ISL. g-12 Connectrix DS-24M2 User Guide...
Page 457 Domain Name Service (DNS) name as administered on a customer network. All DNS names have a host name component and (if fully qualified) a domain component, such as host1.emc.com. In this example, host1 is the host name and EMC.com is the domain component. Nickname A name representing one or more port numbers or World Wide Names.
Page 458 (1) An access point for data entry or exit. (2) A receptacle on a device to which a cable for another device is attached. Port Card Field replaceable hardware component that provides the connection for fiber cables and performs specific device-dependent logic functions. g-14 Connectrix DS-24M2 User Guide...
Page 459 Managed Products. Protocol (1) A set of semantic and syntactic rules that determines the behavior of functional units in achieving communication. (2) A specification for the format and relative timing of information exchanged between communicating parties. g-15 Connectrix DS-24M2 User Guide...
Page 460 SMTP protocols specify how messages are passed across a link from one system to another. They do not specify how the mail application accepts, presents or stores the mail. g-16 Connectrix DS-24M2 User Guide...
Page 461 To change the state of a feature/function that has only two states. For example, if a feature/function is enabled, toggling changes the state to disabled. Upper Layer Protocol, the protocol user of FC-4, including IPI, SCSI, IP, and SBCCS. g-17 Connectrix DS-24M2 User Guide...
Page 462 Zoning allows an administrator to group several devices by function or by location. All devices connected to a connectivity product, such as a Connectrix switch, may be configured into one or more Zones. Zone Set A set of Zones. g-18 Connectrix DS-24M2 User Guide...
Page 463 (pending), fabric, activating via CLI D-24 command tree D-6 binding configuration (pending), fabric, replacing enabling/disabling using Embedded Web via CLI D-26 Server C-21 binding state (pending), fabric, setting via CLI errors, handling D-14 D-27 help, using D-14 navigation conventions D-5 Connectrix DS-24M2 User Guide...
Page 464 1 accounting table A-44 via CLI D-40 class 2 accounting table A-44 via Embedded Web Server C-12 class 3 accounting table A-45 via Product Manager 5-4 described A-29 FxPort capability table A-46 FxPort configuration table A-34 Connectrix DS-24M2 User Guide...
Page 465 A-74 IPL procedure port table A-60 via CLI D-61 sensor table A-58 via Product Manager 7-4 trap registration group A-83 trap registration table A-83 trap types A-85 type definitions A-49 keyboard navigation 3-6 firmware, updating 1-15 Connectrix DS-24M2 User Guide...
Page 466 Embedded Web Server C-12 FibreAlliance. See FibreAlliance MIB via Product Manager 5-4 private enterprise. See FCEOS MIB operation, monitoring 4-5 MIB-II operational states additional IP objects A-19 ports 4-35 additional TCP objects A-25 switch 1-15 Connectrix DS-24M2 User Guide...
Page 467 7-12 port state descriptions in FCEOS MIB A-100 data, restoring 7-13 port statistics opening 3-10 clearing overview 3-2 via CLI D-65 using 3-5 via Product Manager 4-27 described 4-27 displaying via Product Manager 4-27 Connectrix DS-24M2 User Guide...
Page 468 Embedded Web Server C-14 show command (CLI) D-78 via Product Manager 5-4 SNMP described 5-9 access A-2 switch properties 4-13 commands A-4 system error light, clearing community, deleting via CLI D-39 via CLI D-60 configuring via Product Manager 4-14 Connectrix DS-24M2 User Guide...
Page 469 Product Manager 5-31 transceivers 1-3 traps A-4 zoning RSCNs. See RSCNs on zone set activations zoning, configuring via CLI D-50 Unit Type 4-22 via Connectrix Manager. See Connectrix Manager User Guide via Embedded Web Server C-22 Connectrix DS-24M2 User Guide...
Page 470 Index Connectrix DS-24M2 User Guide...
