This document explains the power, cooling, weight, and rack placement
requirements for the EMC departmental switches listed below. It also
describes the kits available for mounting them in EMC and non-EMC
racks and includes installation instructions as well.
Device
16-Port Departmental Switch (2Gb) DS-16M2-0D
32-Port Departmental Switch (2Gb) DS-32M2-0D
Major sections are
• Device Power, Cooling, and Weight Information ................................. 2
• Device Dimensions.................................................................................... 2
• Device Placement Requirements............................................................. 2
• Switch Mounting Kit (DS-16M or DS-32M)........................................... 3
• Installing the DS-16M and DS-32M Rails............................................... 5
• Installing the DS-16M2 and DS-32M2 Switches.................................. 17
EMC Departmental Switches
DS-16M2 and DS-32M2

Installation Guide

Device Model
Mounting Kit Model
DS16M-CRKH/CRKL
DS32M-CRKH/CRKL
P/N 014003063
REV A02
August 1, 2002
