ASP-200
Wireless outdoor siren
Firmware version 1.00
asp-200_en 01/19
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASP-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Satel ASP-200

Summary of Contents for Satel ASP-200

  • Page 1 ASP-200 Wireless outdoor siren Firmware version 1.00 asp-200_en 01/19 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
  • Page 2 The rating plate of the device is located on the enclosure base. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.

  • Page 3: Specifications

     ABAX 2: ACU-220 / ACU-280 controller,  ABAX: ACU-120 / ACU-270 controller (firmware version 5.04 or newer). Up to 8 ASP-200 sirens can be registered in the ABAX 2 / ABAX controller. The siren is not supported by the ACU-100 and ACU-250 controllers, ARU-200 and ARU-100 radio signal repeaters and INTEGRA 128-WRL control panel.
  • Page 4 ASP-200 SATEL Environmental class according to EN50130-5 ............... IV Operating temperature range................-40C …+55C Maximum humidity ......................93±3% Dimensions ....................148 x 254 x 64 mm Weight..........................860 g 3 Description enclosure cover. enclosure base. battery cover. piezoelectric transducer. antenna. tamper switch.
  • Page 5 The siren connects to the controller every 15 minutes. If any value different from 0 is programmed for the “Filter” parameter for the ASP-200 siren, the lack of presence will be reported if no transmission from the siren is received within one hour.
  • Page 6 Power supply The siren is powered from a 3.6 V lithium thionyl chloride battery. It is a high-current battery, characterized by high capacity. The battery is offered by SATEL. The siren provides information about battery condition during each transmission. If you want to replace the low battery with a fresh one, follow the procedure described in the “Battery replacement”...

  • Page 7: Battery Replacement

    1. Start the service mode in the control panel (if the ABAX 2 / ABAX controller is connected to a SATEL alarm control panel) or the test mode in the ABAX 2 / ABAX system. 2. After the leftmost LED on the siren starts flashing every 3 seconds, you can open the siren enclosure.
  • Page 8 ASP-200 SATEL 4. Remove the battery cover (grasp the upper part of the cover with your fingers and pull it down). 5. Remove the old battery and place the new one in the battery cover. 6. Install the battery cover in the siren enclosure.
