The INT-KNX module integrates the INTEGRA alarm system with the KNX system, so the
control panel can control the actuators connected to the KNX bus, and the bus devices can
control the alarm system. The module interfaces with the INTEGRA control panels with
software version 1.10 or later. This manual applies to the module with electronics version 1.2.
Note: The INT-KNX module has no integrated Bus Coupling Unit (BCU). The BCU in BTM
version must be purchased separately (e.g. Bus Coupling Unit (BTM) UP117/11 made
by Siemens).
1. Features
• Expansion of the alarm system by adding virtual outputs dedicated to control actuators
connected to the KNX bus.
• The number of virtual outputs determined by means of DIP switches (from 8 to 64 – a
multiple of 8).
• Sending a predefined telegram after changing the virtual output status.
• The status of virtual outputs automatically changes with changing the status of
communication objects having the same group address as the output.
• Capability to control the KNX system with macro commands available in the INT-KSG
keypad, without using the virtual outputs.
• Receiving commands sent by the bus devices and sending them to the alarm system
Zones (support for "On" and "Off" commands).
• RS-232 port for connecting the module to the BCU.
• Dedicated adapter (interface) and cable for connecting the module to the BCU.
2. Installation
Disconnect power before making any electrical connections.
The INT-KNX module should be installed indoors, in spaces with normal air humidity.
1. Secure the module electronics board in its enclosure.
2. Using the DIP switches, set the appropriate address for the module and determine the
number of outputs that will be added to the system (see: DIP
3. Connect the CK, DT and COM terminals with wires to the appropriate terminals of the
control panel expander bus. To make a connection, it is recommended to use an
unscreened straight-through cable. When using the twisted-pair type of cable, the CK
(clock) and DT (data) signals must not be sent through one twisted pair. The wires must
be run in one cable. The cable length should not exceed 1000 m. If it exceeds 300
meters, it may be necessary to use several wires connected in parallel for each signal.
4. Connect the tamper switch wires of the enclosure where the module is installed to the
TMP and COM terminals. If the status of tamper switch is not to be controlled by the
module, short-circuit the TMP and COM terminals.
5. Connect the power leads to the +12 V and COM terminals. If the distance to the control
panel is less than 300 meters, the module can be supplied directly from the control panel.
KNX INTEGRATION MODULE
®
INT-KNX
int-knx_en 09/11
).
SWITCHES
Advertisement
Table of Contents
Related Manuals for Satel INT-KNX
Summary of Contents for Satel INT-KNX
- Page 1 1.10 or later. This manual applies to the module with electronics version 1.2. Note: The INT-KNX module has no integrated Bus Coupling Unit (BCU). The BCU in BTM version must be purchased separately (e.g. Bus Coupling Unit (BTM) UP117/11 made by Siemens).
- Page 2 6. Install and connect the BCU to the KNX bus (in accordance with the BCU manufacturer's recommendations). 7. Connect the adapter delivered with the INT-KNX module to the BCU (see: Fig. 1). Fig. 1. Correct connection of the adapter to BCU.
- Page 3 SATEL INT-KNX 2.1 Description of the electronics board Fig. 3. View of the INT-KNX module electronics board. Explanations for Fig. 3: 1 - DIP switch package for setting the individual address and the number of virtual outputs (see DIP SWITCHES 2 - STATUS LED indicator: −...
- Page 4 Number of outputs Table 2. The relationship between the numerical value set on the switches 6-8 and the number of outputs that will be assigned to the INT-KNX module. Fig. 4. Examples of the DIP switch setting. A – address: 5, number of outputs: 8. B – address: 22, number of outputs: 24.
- Page 5 (see Fig. 5). The "Read" button is not intended to read the data from the control panel and the "Write" button – to write the data to the control panel. Fig. 5. Programming the INT-KNX module parameters and options in the D X program.
- Page 6 INT-KNX SATEL The names of parameters and options stored in the module memory are shown in white text on black background. Name – individual device name (up to 16 characters). In the LCD keypad, the name is programmed in the N...
-
Page 7: Specifications
Electronics board dimensions ................. 57 x 80 mm Weight..........................140 g Note: If the telegrams sent by the INT-KNX module are blocked by the line/area couplers, use the so-called "dummy application" available from the manufacturer of BCU or another company (e.g. GIRA large dummy application 900201). This will allow group... - Page 8 The declaration of conformity may be consulted at www.satel.eu/ce SATEL sp. z o.o. ul. Schuberta 79 80-172 Gdańsk POLAND tel. + 48 58 320 94 00 info@satel.pl www.satel.pl...
