5 Technical data

5.1 Data and measurements

Model: Loop
SORG
Type: 802
Measurements ± 5%
Designation
Size 1
Size 2
Size 3
Back height
Back unit
Leg support
Tilting
Back angle:
Lower leg length:
ETRTO wheel size
ETRTO wheel size
ETRTO wheel size
ETRTO wheel size
Handrim diameter
Handrims
Camber
Seat height (SH)
with horizontal seat and hor-
izontal frame
Width seat shell-underframe
absolute
Length seat shell-underframe
absolute
Height seat shell-underframe
absolute
Height seat shell-underframe
back folded in
Permissible incline
Permissible downward gradient
Resistance to tilting
Turn radius
Load (max.)
Empty weight min.
Individual weight
Tyres
Corrosion protection
Usage life
Service life
Normative requirements
2019-08-16
Dimensions
usable width = WW 300-420 mm
frame + 40 mm in 40 mm increments
usable width = WW 340-460 mm
frame + 40 mm in 40 mm increments
usable width = WW 380-500 mm
frame + 40 mm in 40 mm increments
430 or 580 mm
can be shifted backwards by approx. 60 mm
can be shifted forward by approx. 60 mm
from -5 ° to +35 °
from +2.5 ° to +40 °
90 - 120 °
120 - 550 mm
at 20" Ø 451 mm
at 22" Ø 489 mm
at 24" Ø 540 mm
at 12" Ø 203 mm
at 20" 444 mm
at 22" 481 mm
at 24" 533 mm
Ø 19 mm
0° or 2°
A-wheel 20"/22" 410 mm size 1
Caster 5"/5.5" 430 mm size 3
A-wheel 20"/22" 420 mm at size 1
Caster 6"/7" 440 mm at size 3
A-wheel 24" 430 mm at size 1
Caster 5"/6" 450 mm at size 3
A-wheel 24" 445 mm size 1
Caster 7" 465 mm size 3
min. WW + 220 mm
max. WW + 300 mm
min. 610 mm at frame size 1, 12" wheels and normal footrest (160 mm)
max. 1130 mm at frame size 3, 24" wheels, wheel base extension and wide
footrest (230 mm)
min. 900 - 1000 mm
max. 1050 - 1150 mm
min. 1000 - 1100 mm
1150 - 1250 mm
min. 550 mm
max. 620 mm
12% = 7°
12% = 7°
12% = 7°
approx. 1100 mm
120 kg
fit for use at: 15.1 kg
WW 300 mm, wheels
12", swivel casters 4"
polyurethane
Driving wheels 1.2 - 2.2 kg
Conventional pneumatic tyres (1" or 1 3/8" for 12"/ 16" wheels) or puncture proof
tyres
(same dimensions), see tyre casing for tyre pressure - usually 3-10 bar
Material Stainless steel, aluminium
Coating Powder coating, galvanising
3 years in case of non-excessive strain
5 years
The seat shell-underframe complies with the requirements of ISO 7176-8 and the re-
quirements against ignition.
Instructions for use Loop
Remarks
suitable from ST 320 mm, per WW + 40 mm
growable
suitable from ST 380 mm, per WW + 40 mm
growable
suitable from ST 440 mm, per WW + 40 mm
growable
optional
optional
with drum brakes (TRB), conventional pneu-
matic tyres in sizes 1" (25.4 mm), 1 3/8"
(35 mm) - sizes 355 mm (20"), 451 mm (22"),
540 mm, (24"). All puncture-proof tyres in
the specified dimensions. As well as 12"/ 16"
in the size ETRTO 47-203
Tube diameter
4° only limited
Height adjustment
+20/+40/+60 mm
Height adjustment
+20/+40/+60 mm
Height adjustment
+20/+40/+60 mm
Height adjustment
+20/+40 mm
dependent on camber and wheel type
at WH 430 mm and 45° push bail
at WH 580 mm and 45° push bail
at 0° tilt and 0° inclination of the back
angle
dependent on the seat shell-underframe
size
incl. seat shell
Frame, seat plate, drum brakes, handrims,
swivel casters, leg supports, push bail, tilt
mechanism
SORG
