Parameter List; Actual Values ("Actual" Menu); Parameters ("Para" Menu) - BONFIGLIOLI Vectron Agile Communications Manual

12 Parameter List

The parameter is available in the four data sets.

12.1 Actual Values ("Actual" Menu)

No.
11 VABus SST-Error-Register
249 Active Data Set
260 Actual Error
270 Warnings
274 Application Warnings
282 Reference Bus Frequency
283 Reference Ramp Frequency
411 Status Word

12.2 Parameters ("Para" Menu)

No.
392 state-transition 5
395 Protocol (CM / X21)
410 Control Word
412 Local/Remote
414 Data Set Selection
484 Reference Frequency RAM
524 Reference Percentage RAM
1375 Modbus Parity
1376 Modbus Address
1503 Modbus Mode
1504 Modbus Baud rate
1505 Modbus Watchdog Timer
74
Actual Value Parameters
Description
RS485/RS232
Actual Frequency Inverter Values
Bus Control
Parameter
Description
Bus Control
RS485/RS232
Bus Control
Fixed Frequency Values
Fixed Percentage Values
Modbus (RTU/ASCII)
Modbus Agile
Units Value Range
- 0 ... 15
- 0 ... 4
0 ... 0xFFFF
-
0 ... 0xFFFF
-
0 ... 0xFFFF
-
Hz -999,99 ... 999,99
Hz -999,99 ... 999,99
- 0 ... 0xFFFF
Units Value Range
- Selection
- Selection
- 0 ... 0xFFFF
- Selection
- 0 ... 4
Hz -999,99 ... 999,99
% -300,00 ... 300,00
- Selection
- 1 ... 247
- Selection
Baud Selection
s 0 ... 1000
Parameter List
Chapter
7.3.9
10
13.3
13.1
13.2
11
11
10
Chapter
10.4
5.4
10
10
10
10
10
6
6
6
6
6
