13.2 Warning Messages Application
When the highest bit in the Warning messages is set, a "Warning Message Application" is present.
The Application warning messages are given via parameter
according to the following scheme.
Application Warnings
Parameter
the PC software tool VPlus.
Application Warnings
Use Parameter
Bit-No. Warning
Code
0 0x0001
1 0x0002
2 0x0004
3 0x0008
4 0x0010
5 0x0020
6 0x0040
7 0x0080
8 0x0100
9 0x0200
10 0x0400
11 0x0800
12 0x1000
13 0x2000
14 0x4000
15 0x8000
Note: The meaning of the individual warnings are described in detail in the operating instruc-
tions.
13.3 Error Messages
Watchdog for X21-Connection. Communication error according to Parameter
10
Bus Watchdog Timer
F20
Watchdog for Communication Module. Communication error according to Parameter
11
CM: VABus Watchdog Timer
The Actual error message can also be read out by parameter access via parameter
Actual Error
Parameter
software tool VPlus.
76
273 shows the warnings in clear text on the operator panel and
274 to access the Application warning codes via Modbus.
Warning Messages
BELT
(reserved)
(reserved)
(reserved)
(reserved)
(reserved)
SERVICE
User 1
User 2
(reserved)
(reserved)
(reserved)
(reserved)
(reserved)
(reserved)
(reserved)
VABus
1502.
413.
259 shows the actual error in clear text on the operator panel and the PC
Modbus Agile
Application Warnings
Description
Annex
274, bit-coded
X21: VA-
Actual Fault
260.
