B. To determine if the Heater Coil is shed, go to the Load Shed screen and look at the AC Heat
status. If the Heater Coil is shed, then change the shed configuration values to allow the Heater
Coils to turn on.
C. To determine if AC power (Shore Power of Generator) is available, look at the AC power
readings on the Home screen. If the Home screen indicates that there is AC power available,
then verify that the main Oasis unit is turned on and that the AC circuit breakers are on.

Holding Tanks, Water Pump and Auto Fill Issues

If the Holding Tank Displays do not Read Correctly:

1. Verify that the Tank is empty, then go to the Tank Configuration screen and press the "Set Dry
Point" button associated to that tank.
2. If the Tank still does not read correctly, then verify that the TM102 Tank Configuration settings are
correct. Including that the "CPI" setting is set to 10.
Correct settings as required.

If the Water Pump turns off during Auto Fill:

1. Verify that the TM102 AutoFill Configuration "Do Not Turn Off Water Pump When Filling" check
box is checked.
If not, check the box and verify that the pump no longer turns off during the Auto Fill cycle.

If the Water Pump will not Turn On:

1. Verify that the Water Pump button is highlighted Blue.
If not, then press the Water Pump button.
2. If the button is highlighted, then verify that the Water Pump Relay (#3) on the 12V Relay Interface
Board is energized.
If the relay is on, then the associated LED (#3) located on the bottom of the board will be lit.
If the LED is not lit, then verify that the wiring is correct (see appropriate wiring diagram).Also,
verify that the relay can be energized by actuating the momentary switch (#3) on the relay
board.
3. If the relay will not energize manually, then check that DC power is available on the board.
If DC power is not available at the board, then supply the missing power and re-test.
4. If there is DC power Available to the board and the relay will not energize, then replace the board.
5. If the LED is lit, then verify that the Fuse is not blown and that it is in the correct location.
If the fusing is correct and the relay is energized, then the problem is in the pump or the wiring.
If the Auto Fill will not Fill:
1. Verify that the Auto Fill button is highlighted Light Blue.
If the button is not highlighted, then press the Auto Fill button and check if the tank is now
filling.
Page 63
