FEATURES CLIMATE CONFIGURATION SCREEN 4

The fourth Climate Setting screen is accessed
by pressing the Left Down Arrow on the first

FEATURES CLIMATE CONFIGURATION SCREEN 5

The fifth Climate Setting screen is accessed by

FEATURES CLIMATE CONFIGURATION SCREEN 6

The sixth Climate Setting screen is accessed by
pressing the Left Down Arrow on the fourth
Climate Setting screen or by the Left Up Arrow
on the fifth Climate Setting screen.
This screen determines the Zone Labels that are
displayed on the Climate control screens and
has the following settings:
Zone 1 Name
Select using the Up / Down Arrows
Zone 2 Name
Select using the Up / Down Arrows
Zone 3 Name
Select using the Up / Down Arrows
Zone 4 Name
Select using the Up / Down Arrows
pressing the Left Down Arrow on the third
Climate Setting screen or by the Left Up Arrow
on the sixth Climate Setting screen.
This screen sets the Cool Source to the HVAC
Zones.
Cool Instance 1
Select using the Up / Down Arrows
Cool Instance 2
Select using the Up / Down Arrows
Cool Instance 3
Select using the Up / Down Arrows
Cool Instance 4
Select using the Up / Down Arrows
Climate Setting screen or by the Left Up Arrow
on the seventh Climate Setting screen.
This screen sets the Heat Source to HVAC
Zones.
Heat Instance 1
Select using the Up / Down Arrows
Heat Instance 2
Select using the Up / Down Arrows
Heat Instance 3
Select using the Up / Down Arrows
Heat Instance 4
Select using the Up / Down Arrows
Set to LvRm
Set to Kitch
Set to Bath
Set to Bed
Set to 1
Set to 2
Set to 0
Set to 4
Set to 1
Set to 2
Set to 166
Set to 4
