CLIMATE BATH SCREEN

The Climate "Bath" Screen only controls the
Bathroom Oasis heating system. There is no Air
Conditioner or Heat Pump available for this
zone, therefore the Cool Button is not displayed
on this screen.

CLIMATE BED SCREEN

The Climate "Bed" Screen displays the Heating
and Cooling controls for Bedroom zone. The Air
Conditioner for cooling and both the Heat Pump
and Oasis heating systems for the Bedroom are
controlled from this page

CLIMATE OASIS SCREEN

The Oasis Screen is accessed from the Oasis
Button displayed in the Climate All Screen. This
screen controls the Oasis Burner and both AC
Heating Elements. The Burner, AC #1 and AC #2
Buttons will highlight when active. This screen
also displays the Oasis System operational
Status and Faults.
Page 11
