The Climate Screens are used to display the
status and control the HVAC system. The
Climate "All" Screen displays and provides
global control of the Heating and Cooling for all
of the HVAC zones.

CLIMATE SCREENS CLIMATE ALL SCREEN

CLIMATE LVRM SCREEN

CLIMATE KITCH SCREEN

Pressing the Heat or Cool Button activates all of
the zones for the selected function at one time.
The set points can be changed by pressing the
associated up and down arrows or by dragging
the associated circular temperature wheel to
the desired set point.
The Heat or Cool Buttons will highlight and
Icons will be displayed when the functions are
active.
The Oasis control screen is only accessed from
this screen.
The Leave function is also accessed from this
screen. The Leave function allows you to set
different temperature set-points to control the
HVAC system when you leave the coach.
The Climate "LvRm" Screen displays the Heating
and Cooling controls for Living Room zone. The
Air Conditioner for cooling and both the Heat
Pump and Oasis heating systems for the Living
Room are controlled from this page.
The Climate "Kitch" Screen displays the Heating
and Cooling controls for Kitchen zone. The Air
Conditioner for cooling and only the Heat Pump
for heating are controlled from the page. There
is no Oasis heat available in this zone.
Page 10
