FEATURES MONITOR CONFIGURATION SCREEN 6

The sixth Monitor Configuration Screen is
accessed by pressing the Next Button located
on the fifth Monitor Configuration Screen or

FEATURES MONITOR CONFIGURATION SCREEN 7

The seventh Monitor Configuration Screen is
accessed by pressing the Next Button located
from the "Prev" Button located on seventh
Monitor Configuration Screen. This Screen
allows you to set the following Display Settings:
Transfer Switch Type
(Automatic if RV-C Communications Port Used)
Select using the Up / Down Arrows
Inverter Model
Select using the Up / Down Arrows
Floor Heat Mats
Heat Installed / Set to "3" if Floor Heat Installed
Select using the Up / Down Arrows
Floor Heat Schedule
Time Zone)
Select Appropriate Setting using the Up /
Down Arrows
on the sixth Monitor Configuration Screen or
from the "Prev" Button located on eighth
Monitor Configuration Screen.
This Screen allows you to set the following:
Power management Installed
Select using the Up / Down Arrows
Tile Heat System Installed
Timed – if Floor Heat is installed
Select using the Up / Down Arrows
Autotemp AGS Installed
Autotemp for Temperature Autogen Control
Select using the Up / Down Arrows
Block Heater Instance
Select using the Up / Down Arrows
Set to "Generic"
Set to "Basic Magnum"
Set to "0" if no Floor
(None, 2 Time Zone or 4
Set to TM-250
Set to TM-220
Set to
Set to 1
Page 20
