Series 2000 Reader System
Micro-reader RI-STU-MRD1
Reference Guide
May 2000
SCBU027

Advertisement

Table of Contents
loading

Related Manuals for Texas Instruments 2000 Series

Summary of Contents for Texas Instruments 2000 Series

  • Page 1 Series 2000 Reader System Micro-reader RI-STU-MRD1 Reference Guide May 2000 SCBU027...
  • Page 2 Series 2000 Reader System Micro-reader RI-STU-MRD1 Reference Guide Literature Number: SCBU027 May 2000...

  • Page 3: Table Of Contents

    Contents ..........................Preface ....................Product Description ......................General ....................Product Description ..................... 1.2.1 Power Supply ....................1.2.2 Antenna ................... 1.2.3 Synchronization ....................1.2.4 Trigger Mode ..................1.2.5 Continuous Mode ................... 1.2.6 Serial Communication ....................Connector Pins ................1.3.1 Pin Connection Description ..............
  • Page 4 ................5.1.2 Program R/W Transponder ................5.1.3 General Read Page of MPT ................... 5.1.4 Program Page of MPT ..................5.1.5 Lock Page of MPT ............... 5.1.6 Selective Read Page of SAMPT ..............5.1.7 Selective Program Page of SAMPT ................ 5.1.8 Selective Lock Page of SAMPT ....................
  • Page 5 List of Figures ....................... Micro-reader Module .................... Micro-reader Pin Connections ..................Block Diagram of the Micro-reader ................... Antenna Circuit Block Diagram ..............Top, Front, and Side Views (Measurements in mm) ......................Read Function ..........Programming Data Format of the 64-bit Read/Write Transponder ..............
  • Page 6 List of Tables SCBU027 – May 2000 Submit Documentation Feedback...
  • Page 7 For more information, please contact your nearest TIRIS Sales and Application Center. The contact addresses can be found on our home page: http://www.tiris.com Trademarks The TIRIS logo and the word TIRIS are registered trademarks of Texas Instruments. SCBU027 – May 2000 Submit Documentation Feedback...
  • Page 8 www.ti.com SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 9: Product Description

    Chapter 1 SCBU027 – May 2000 Product Description This chapter describes the hardware of the Micro-reader. It tells you about the module and how to integrate it....................Topic Page ..................General ..............Product Description ................. Connector Pins SCBU027 – May 2000 Product Description Submit Documentation Feedback...

  • Page 10: Micro-Reader Module

    www.ti.com General General The Micro-reader is an intelligent module providing RF and Control functions to read and program TIRIS transponders. It is equipped with a Serial Communications Interface (SCI) which may be directly connected to commonly used system controllers. The Micro-reader works together with a 47 µH, low-Q antenna, and therefore the system does not need tuning.

  • Page 11: Power Supply

    www.ti.com Product Description 1.2.1 Power Supply There are two separate 5V supplies to the Micro-reader, one for the output stage (VSP) and the other for the logic (VSL). On power up VSL should rise faster than 0.1 V/ms to ensure a reliable operation. The Micro-reader has an on-board reset circuit which will reset it should the supply fall below 4 V (±...

  • Page 12: Trigger Mode

    www.ti.com Product Description 1.2.4 Trigger Mode When the Micro-reader is in idle mode it is possible to trigger a single charge-only read with a power burst duration of 50 ms by taking the RDEN- pin to logic high for 100 µs. The single read will start on the falling edge of the 100 µs pulse.

  • Page 13: Micro-Reader Pin Connections

    www.ti.com Connector Pins Connector Pins The Micro-reader module has 30 pin connections which are shown in Figure 1-2 and listed in Table 1-1. Figure 1-2. Micro-reader Pin Connections Table 1-1. Pin Connections Signal Name Function SYNC Output for wired synchronization RDEN- Input for wired synchronization and single read trigger –...

  • Page 14: Pin Connection Description

    www.ti.com Connector Pins 1.3.1 Pin Connection Description SYNC (1) Output for wired synchronization. This output is at GND level until the Micro-reader starts its read cycle, at which time it goes to VSL until the complete reading, programming or locking cycle is finished. RDEN- (2) Input for wired synchronization.

  • Page 15: Block Diagram Of The Micro-Reader

    www.ti.com Connector Pins OKT (29) This output is set to logic high for approx. 60 ms if a valid transponder was read. It can be connected to an LED externally to indicate the result of the read cycle. STAT(30) Pin 30 is set to logic low when the RF-transmitter is activated. Supplying an external LED with this signal makes the status of the Micro-reader visible.

  • Page 16: Antenna Circuit Block Diagram

    www.ti.com Connector Pins RECEIVE TXHI from RESONANCE ASIC CAPACITOR ANT1 TXLO from ANT2 ASIC ANTCAP Figure 1-4. Antenna Circuit Block Diagram Product Description SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 17: Communications Protocol

    Chapter 2 SCBU027 – May 2000 Communications Protocol This chapter describes the protocol that you need to use to send instructions from your PC to the Micro-reader. It also describes the protocol that the Micro-reader uses to respond to the PC....................

  • Page 18: Start Mark

    www.ti.com Protocol PC to Micro-reader Protocol PC to Micro-reader Start Length Cmd 1 Cmd 2 Data Byte Contents (hexadecimal value) Start Mark (SOH, 01 Length Command Field (1) Command Field (2) (optional) 4(3) Data Field (1) N+3(2) Data Field (N) N+4(3) BCC Note: The total number of bytes sent within a protocol frame (including Start Mark and BCC) is...
  • Page 19 www.ti.com Protocol PC to Micro-reader If bit 5 (Power Burst II, for example: for programming and locking) is set, the Microreader automatically operates in single mode. Thus the user is enabled to validate the programming or lock response before a further cycle is started.

  • Page 20: Protocol Micro-Reader To Pc

    www.ti.com Protocol Micro-reader to PC 2.1.4 Data Field The presence of the relevant data field depends on the setting of the bits in the Command Field. If the relevant bit (for example: Command bit 3 “Power Burst I”) is set to “1”, then Data Field 1 is present defining the Power Burst length.
  • Page 21 www.ti.com Protocol Micro-reader to PC 2.2.1 Start Mark The 'Start-Mark' signifies the beginning of a message. It is represented by the ASCII character SOH (Start Of Header: 01 2.2.2 Length The 'Length' byte indicates the length, in bytes, of the following Status and Data Fields. 2.2.3 Status The 'Status' byte provides feedback from the preceding read or program operation.
  • Page 22 www.ti.com Communications Protocol SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 23: Specifications

    Chapter 3 SCBU027 – May 2000 Specifications This chapter provides the specifications for the Micro-reader, its inputs and outputs, and its timing....................Topic Page .......... Recommended Operating Conditions ..................Timings ................ Mechanical Data SCBU027 – May 2000 Specifications Submit Documentation Feedback...
  • Page 24 www.ti.com Recommended Operating Conditions Recommended Operating Conditions Operating free-air temperature range T_oper –25 to +70°C Storage temperature range T_store –40 to +85°C Note: Free-air temperature: air temperature immediately surrounding the Module. If the module is incorporated into a housing, it must be guaranteed by proper design or cooling that the internal temperature does not exceed the absolute maximum ratings.

  • Page 25: Top, Front, And Side Views (Measurements In Mm)

    www.ti.com Mechanical Data Mechanical Data Parameter Unit Length 37.9 38.3 38.7 Width 28.8 29.3 29.6 Height including pins 12.5 13.5 14.0 Weight Recommended finished pin hole size is 1 mm diameter. Figure 3-1. Top, Front, and Side Views (Measurements in mm) SCBU027 –...
  • Page 26 www.ti.com Specifications SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 27: Transponder Commands

    Chapter 4 SCBU027 – May 2000 Transponder Protocols This chapter describes the protocols used when sending commands to the transponder and the protocols used by the transponder when responding....................Topic Page ............Transponder Commands ............Transponder Responses SCBU027 – May 2000 Transponder Protocols Submit Documentation Feedback...

  • Page 28: Read Function

    www.ti.com Transponder Commands Transponder Commands This section describes the protocols that need to be sent by the PC to the transponder via the Micro-reader in order to execute the required function. 4.1.1 Read RO, R/W POWER BURST READ RF TRANSMITTER 50 ms 20 ms Figure 4-1.

  • Page 29: Data Format Of The General Read

    www.ti.com Transponder Commands 4.1.3.1 General Read Page of MPT/SAMPT 8 bit 128 bit WRITE POWER BURST I RF TRANSMITTER READ ADDRESS 50 ms 16 ms 20 ms 86 ms Figure 4-3. Data Format of the General Read Page Function 4.1.3.2 Program Page of MPT/SAMPT 104 bit 128 bit...

  • Page 30: Data Format Of The Selective Program

    www.ti.com Transponder Responses 4.1.3.5 Selective Program Page of SAMPT 112 - 136 bit 128 bit 8 - 32 WRITE SELECTIVE READ OR RF TRANSMITTER POW ER BURST I WRITE DATA WRITE FRAME BCC PB II ADDRESS ADDRESS DISCHARGE 50 ms 16 ms 16 - 64 ms 160 ms...

  • Page 31: Mpt/Sampt Read Data Format

    www.ti.com Transponder Responses 4.2.3 MPT/SAMPT START READ DISCHARGE ADDR. FBCC PRE BITS READ DATA IDENTIFICATION DATA DBCC 128 bit Figure 4-11. MPT/SAMPT Read Data Format The Read Address consists of a 2-bit status field and a 6-bit page field. The status field provides information about the function the multipage transponder has executed and the page field shows which page was affected.
  • Page 32 www.ti.com Transponder Protocols SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 33: Communication Protocol Examples

    Chapter 5 SCBU027 – May 2000 Communication Protocol Examples This chapter provides some examples of some actual commands sent to a transponder and some possible responses....................Topic Page ..............PC to Micro-reader ..............Micro-reader to PC SCBU027 – May 2000 Communication Protocol Examples Submit Documentation Feedback...

  • Page 34: Read Ro, R/W

    www.ti.com PC to Micro-reader PC to Micro-reader 5.1.1 Read RO, R/W Content Byte Comment Description (hex) Start Mark Length Two bytes follow excluding BCC Command Field (1) Perform Single command, send Power Burst I Data Field (1) Power Burst I with 50 ms duration (charge-up) BCC over previous bytes excluding Start Mark 5.1.2 Program R/W Transponder The following sequence of bytes programs a R/W transponder with:...

  • Page 35: General Read Page Of Mpt

    www.ti.com PC to Micro-reader 5.1.3 General Read Page of MPT The following sequence of bytes reads page 2 of an MPT. Content Byte Comment Description (hex) Start Mark Length Four bytes follow excluding BCC Command Field (1) Perform Single command, send Power Burst I with data Data Field (1) Power Burst I with 50 ms duration (charge-up) Data Field (2)

  • Page 36: Lock Page Of Mpt

    www.ti.com PC to Micro-reader 5.1.5 Lock Page of MPT The following sequence of bytes locks page 2 of an MPT. Content Byte Comment Description (hex) Start Mark Length Five bytes follow excluding BCC Command Field (1) Perform Single command, calculate FBCC, send Power Burst I & II with data Data Field (1) Power Burst I with 50 ms duration (charge-up) Data Field (2)

  • Page 37: Selective Program Page Of Sampt

    www.ti.com PC to Micro-reader 5.1.7 Selective Program Page of SAMPT The following sequence of bytes selective programs page 2 of an SAMPT with: MSByte LSByte The 24 bit selective address = MSByte LSByte Content Byte Comment Description (hex) Start Mark Length 18 bytes follow excluding BCC Command Field (1)

  • Page 38: Selective Lock Page Of Sampt

    www.ti.com Micro-reader to PC 5.1.8 Selective Lock Page of SAMPT The following sequence of bytes locks page 2 of an SAMPT. The 24 bit selective address = MSByte LSByte Content Byte Comment Description (hex) Start Mark Length 8 bytes follow excluding BCC Command Field (1) Perform Single command, calculate FBCC, send Power Burst I &...

  • Page 39: Successful Program Page 2 Of Mpt

    www.ti.com Micro-reader to PC 5.2.2 Successful Program Page 2 of MPT Content Byte Comment Description (hex) Start Mark Length 10 bytes follow excluding BCC Status Valid MPT, Startbyte detected, DBCC O.K., FBCC O.K. Data Field (1) New Identification Data (LSByte) Data Field (2) New Identification Data Data Field (3)
  • Page 40 www.ti.com Communication Protocol Examples SCBU027 – May 2000 Submit Documentation Feedback...
  • Page 41 Appendix A SCBU027 – May 2000 CE Declaration The Micro-reader module complies with the European CE requirements specified in the EMC Directive 89/336/EEC. The relevant documentation numbers are: Declaration of Conformity 11-06-02-005 Type Examination Certificate 11-06-05-001 If the Micro-reader is operated from a mains power supply, all power connections and additional components of the final device must comply with the European EMC directive.
  • Page 42 www.ti.com CE Declaration SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 43: Micro-Reader Demonstration Circuit

    Appendix B SCBU027 – May 2000 Demonstration Circuit The Micro-reader module can be demonstrated using the circuit shown in Figure B-1. ANTENNA + DC IN L78M05CV 10 µF 10 µF 10 µF 0.1 µF MICROREADER 16 2 10 µF RDEN 10 µF CRDM WLSC...
  • Page 44 www.ti.com Demonstration Circuit SCBU027 – May 2000 Submit Documentation Feedback...

  • Page 45: C.1 Introduction

    Appendix C SCBU027 – May 2000 Antenna Design Introduction This appendix gives an example of how you could construct an antenna to work with the Micro-reader. It also provides information about calculating the Q factor and adapting the inductance range. The antenna properties should be: Q factor less than 20 Inductance between 46 µH and 48 µH...

  • Page 46: C.3 Q Factor

    www.ti.com Q Factor Q Factor If the antenna’s Q factor exceeds 20: 1. The output capacitors will be overloaded and long term damage could result. 2. The antenna may still be resonating when the response from the transponder is received. Without built-in damping the data will not be correctly received.
