EN
INSTRUCTION MANUAL
SILENCE 9
SILENCE 11
TRINITY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SILENCE 9 and is the answer not in the manual?

Questions and answers

Related Manuals for EVA Stampaggi SILENCE 9

Summary of Contents for EVA Stampaggi SILENCE 9

  • Page 1 INSTRUCTION MANUAL SILENCE 9 SILENCE 11 TRINITY...
  • Page 2 9. The burn pot and the combustion chamber MUST BE CLEANED DAILY. The manufacturer declines any liability for any malfunctioning due to a failure to do so. Eva Stampaggi S.r.l. declines any liability for any damage to persons or property arising from the failure to comply with the points mentioned...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 01. PRODUCT SAFETY ........................ 3 01.1 SAFETY WARNINGS ....................3 01.2 GENERAL SAFETY REGULATIONS ................4 01.3 EC CERTIFICATE OF CONFORMITY ................6 02. PRODUCT DESCRIPTION ....................... 9 03. PRODUCT INSTALLATION ....................10 03.1 INTRODUCTION ..................... 10 03.2 VENT PIPE ......................

  • Page 4: Product Safety

    Read this manual carefully before use or any maintenance operation. Eva Stampaggi aims to provide as much information as possible to ensure safer use and to avoid damage to persons, property or parts of the stove itself.

  • Page 5: General Safety Regulations

    01. PRODUCT SAFETY 01.2 GENERAL SAFETY PRECAUTIONS  Use the stove only as described in this manual. Any other use not recommended by the manufacturer may cause fires or accidents to people.  Make sure that the electrical power available corresponds to the value indicated on the data plate (230V~/50Hz). ...
  • Page 6 01. PRODUCT SAFETY  Do not use the appliance as waste incinerator or for any other purpose other than the intended one.  Do not use liquid fuels.  Do not modify the appliance without prior authorisation.  Use only original spare parts recommended by the manufacturer. ...

  • Page 7: Ec Certificate Of Conformity

    EN 14785 :2006 Residential space heating appliances fired by wood pellet Apparecchi per il riscaldamento domestico alimentato a pellet di legno Type: SPCN9 Model: SILENCE 9 5 cm Rear Distance to adjacent combustible materials 20 cm Sides Distanza da materiali combustibile...
  • Page 8 01. PRODUCT SAFETY EVA STAMPAGGI S.r.l. Via Cal Longa Z.I. 31028 Vazzola (TV) – ITALY Trademark: EVA CALòR EN 14785 :2006 Residential space heating appliances fired by wood pellet Apparecchi per il riscaldamento domestico alimentato a pellet di legno Type: SPCN11...
  • Page 9 01. PRODUCT SAFETY EVA STAMPAGGI S.r.l. Via Cal Longa Z.I. 31028 Vazzola (TV) – ITALY Trademark: EVA CALòR EN 14785 :2006 Residential space heating appliances fired by wood pellet Apparecchi per il riscaldamento domestico alimentato a pellet di legno Type: SPRV...

  • Page 10: Product Description

    02. PRODUCT DESCRIPTION DISEGNO TECNICO SILENCE 9 / SILENCE 11 / TRINITY DATI TECNICI Technical data of the appliance: SILENCE 9 SILENCE 11 TRINITY Dati tecnici dell’apparecchio: Designation: Nominal heat Reduced heat Reduced heat output Nominal heat output Reduced heat output...

  • Page 11: Product Installation

    INSTALLATION WITH WALL FUME OUTLET IS PROHIBITED. INSTEAD THE FUME OUTLET MUST BE ROOF-TYPE AS PROVIDED FOR BY NATIONAL REGULATIONS. Eva Stampaggi S.r.l. declines any liability for any damage to persons or property arising from the failure to comply with the points mentioned above and from non-compliant product installation.
  • Page 12 03. INSTALLING THE PRODUCT IMPORTANT: THE LENGTH OF THE CHIMNEY MUST HAVE A MAXIMUM OF 6 METERS OF PIPE DIAMETER THAT IS EQUAL TO OR GREATER THAN THAT SPECIFIED FOR EACH APPLIANCE. EVERY 90° ELBOW OR (T) COUPLING IS THE EQUIVALENT OF 1 METER OF PIPE.
  • Page 13 03. INSTALLING THE PRODUCT EXISTING VENT PIPE (TRADITIONAL) Types of vent pipe Examples of vent pipe: Steel vent pipe with Traditional clay vent pipe double chamber with cavities. Optimal insulated with material efficiency. resistant 400°C. Optimum efficiency. Avoid vent pipes with Refractory vent pipe with internal rectangular...

  • Page 14: Chimney Cowl

    03. INSTALLING THE PRODUCT 03.3 CHIMNEY COWL A properly installed chimney cowl ensures optimum stove functioning. The anti-downdraught chimney cowl consists of a number of components whose outlet section sum always doubles the vent pipe section. Make sure the chimney cowl is at least 150cm above the roof top so that it is fully exposed to the wind.

  • Page 15: Draught

    03. INSTALLING THE PRODUCT 03.4 DRAUGHT Fumes heat up during combustion, increasing their volume. Their density is therefore lower than the one of the surrounding colder air. This difference between the inside and outside temperatures of the chimney results in a negative pressure which increases proportionally to the vent pipe length and the temperature.

  • Page 16: Stove Efficiency

    03. INSTALLING THE PRODUCT 03.5 STOVE EFFICIENCY Highly efficient stoves may pose difficulties for fume extraction. In order for a vent pipe to work properly its internal temperature must increase as a consequence of the fumes generated during combustion. Importantly, the efficiency of a heater is determined by its ability to transfer most of the heat produced to the environment to be heated: consequently, the greater the efficiency of the stove, the "colder"...

  • Page 17: Installation

    03. INSTALLING THE PRODUCT 03.6 INSTALLATION Using coaxial tubes the air will be pre-warmed contributing to improved combustion and lower emissions into the atmosphere Follow the instructions before installing your stove: Select the position where the stove is to be installed and: ...
  • Page 18 03. INSTALLING THE PRODUCT  The combustion air intake must be connected directly to the outside or to adjacent rooms provided they are fitted with external air supply vents and are not used as bedrooms or bathrooms or, whenever a fire hazard exists, as storage rooms, garages, combustible material warehouses, etc.
  • Page 19 03. INSTALLING THE PRODUCT HERMETIC APPLIANCES These stoves draw the combustion air and the air necessary for glass cleaning directly from outside and not from the room where they are installed, preserving the oxygen in the room. Using coaxial tubes the air will be pre-warmed contributing to improved combustion and lower emissions into the atmosphere.
  • Page 20 03. INSTALLING THE PRODUCT EXAMPLE OF INCORRECT INSTALLATION:...
  • Page 21 03. INSTALLING THE PRODUCT HANDLING AND UNPACKING At the time of transportation do not position the product horizontally. Unloading of the product must be performed using lifting means that are suitable and that have characteristics that are consistent with the weight of the stove. The operator must make sure that during offloading and lifting of the stove there are no persons or objects nearby.

  • Page 22: Product Use

    04. PRODUCT USE...

  • Page 23: Radio Control

    04. PRODUCT USE 04.1 RADIO CONTROL Proper functioning and control adjustment devices Console The radio control shows the information concerning the stove operating status. Several types of data can be displayed and the settings available according to the access level can be modified by entering the menu. Depending on the selected mode and on their position on the display, the data visualised may acquire different meanings.
  • Page 24 04. PRODUCT USE Emergency console The emergency console is used when the radio control does not work or in case of loss of the latter. BUTTON P1: On / Off Keeping this button pressed, the stove will switch on or off according to the last settings recorded by the radio control. P2 BUTTON: to increase/decrease the heat output With this button it is possible to select the stove heat output manually.
  • Page 25 04. PRODUCT USE The menu Press the P4 button to access the menu. It includes several items and levels to access settings and control board programming. USER MENU The table below briefly describes the menu structure, focusing in particular on the functions available to users. STAND-BY In this menu it is possible to activate or deactivate the automatic stand-by of the stove.
  • Page 26 04. PRODUCT USE STOVE STATUS Enter the STOVE STATUS menu, after pressing the P4 button, the display scrolls the status of a number of variables during operation of the stove at work. WI FI STATUS Enter the WI FI STATUS menu, after pressing the P4 button, the status of a number of variables of the Wi-Fi status scrolls on the display.
  • Page 27 04. PRODUCT USE Room temperature reaches the set value (SET temperature) When the set room temperature value is reached, the stove heat output is automatically set to the minimum value. During this phase the display shows the message "Modula". If room temperature falls below the set value (Set temperature value), the stove will go back to the "Work"...
  • Page 28 04. PRODUCT USE TEST PASSED MODEL: =CODICE ARTICOLO / ITEM NUMBER SERIAL: =SERIAL NUMBER FIRMWARE: At this point your electronic device (pellet stove, boiler, etc.) has been added and can now be managed via the Web App from your device (computer/tablet/smartphone). You are now able to autonomously manage all the available functions of the product you have purchased from your device.
  • Page 29 04. PRODUCT USE Alarms In the event that an operating anomaly occurs, the board intervenes and signals the occurrence of an irregularity, turning on the alarm LED (alarm LED on) and emitting acoustic signals. The possible alarm messages are listed below: Display shows Cause ALARM BLACK-OUT...
  • Page 30 04. PRODUCT USE Connections...

  • Page 31: Cleaning And Maintenance

    05. CLEANING AND MAINTENANCE 05.1 INTRODUCTION The stove requires a simple yet constant cleaning to guarantee top efficiency and proper functioning. Constant maintenance by a qualified technician is recommended. The stove should be cleaned before the cold season because it can sometimes get clogged during the summer (by nests for example) preventing exhaust fumes to flow regularly.

  • Page 32: Troubleshooting

    06. TROUBLESHOOTING PROBLEM CAUSE SOLUTION IT MAY BE NECESSARY TO REPEAT THE FIRST LOAD PHASE A FEW TIMES TO FACILITATE THE APPLIANCE INITIAL START-UP FIRST START-UP AS THE AUGER TUBE IS COMPLETELY EMPTY AND IT MAY TAKE A SPECIFIC PERIOD OF TIME TO FILL. POWER OUTAGE CHECK PLUG AND POWER SUPPLY.
  • Page 33 06. TROUBLESHOOTING LET STOVE COOL DOWN, LET STOVE COOL DOWN, MANUALLY RESET THERMOSTAT ON BACK. IF THE MANUALLY RESET PROBLEM REMAINS UNSOLVED, CONTACT A SPECIALISED TECHNICIAN. THERMOSTAT ON BACK LET STOVE COOL DOWN, MANUALLY RESET THERMOSTAT ON BACK. SWITCH TEMPORARY POWER OUTAGE ALARM SIC FIREBOX STOVE ON AGAIN.

  • Page 35: Certificate Of Installation And Testing

    07. CERTIFICATE OF INSTALLATION AND TESTING CERTIFICATE OF INSTALLATION AND TESTING CUSTOMER: __________________________ Installer's stamp: ROAD: ______________________________ CITY: ______________________________ POSTAL CODE: _________________________ PROVINCE: __________________________ TEL: _________________________________ Delivery date:______________________ First name: __________________________ Delivery date: ________________ Last Name: _________________________ Equipment mod.: _____________________ Address: ___________________Postal code.: Serial number: Year:...

  • Page 37: Yearly Scheduled Maintenance

    08. YEARLY SCHEDULED MAINTENANCE Date 1st maintenance ____________ / ____________ /____________ (Technical Assistance Centre stamp) Date 2nd maintenance ____________ / ____________ /____________ (Technical Assistance Centre stamp) Date 3rd maintenance ____________ / ____________ /____________ (Technical Assistance Centre stamp)

  • Page 38: Warranty Certificate

    09. WARRANTY CERTIFICATE Congratulations! Thank you for purchasing an Eva Stampaggi product. Warranty The warranty period is two years if fiscally described as sold to an individual (Legislative Decree no. 24 of 02.02.2002) and one year if sold to a company or profession (subject to VAT).
  • Page 39 INSTALLATION IS OBLIGATORY BY LAW, EVA STAMPAGGI STRONGLY RECOMMENDS THE INITIAL IGNITION OF PRODUCTS BY QUALIFIED TECHNICIANS. EVA STAMPAGGI IS NOT RESPONSIBLE FOR ONLINE SALES AND FOR RELATED OFFERS AS IT DOES NOT OFFER DIRECT SALES TO THE PUBLIC. FOR ANY TECHNICAL ISSUES DURING THE PERIOD OF LEGAL WARRANTY, THE PROCEDURE REQUIRES CONTACTING OF THE RETAILER OR DIRECTLY OF OUR AFTER SALES.

This manual is also suitable for:

Silence 11Trinity
