- Page 1 INSTRUCTION MANUAL TRINITY TREVISI...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT DESCRIPTION………………………………………………………………………………………………………………. page 3 PRODUCT INSTALLATION..…….……………………………………………………………………………………………………… page 4 USING THE PRODUCT……………………………...………………………………………………………………………………….. page 7 USER FUNCTIONS……………………………...……………………………………………………………………………………….. page 9 ALARMS……………………………...…………………………………………………………………………………………………… page 10 INTRODUCTION………………...……………………………...………………………………………………………………………… page 11 CONNECTIONS………………………………………...………………………………………………………………………………… page 12... -
Page 3: Product Description
01. PRODUCT DESCRIPTION TECHNICAL DRAWING TRINITY TREVISI 3 - English... -
Page 4: Product Installation
60 W Stand-By electrical consumption: 3 W Stand-By electrical consumption: 3 W 02. INSTALLING THE PRODUCT 02.1 FLUE PIPE FLUE PIPE SPECIFICATIONS STOVE TRINITY 9 KW STOVE TREVISI 9 KW Chimney flue draught Chimney flue draught Fume temperature 195 °C... - Page 5 HANDLING AND UNPACKING When transporting do not position the product horizontally. Unloading of the product must be performed using suitable lifting means and that have characteristics that comply with the weight of the stove. The operator must make sure that during offloading and lifting of the stove there are no persons or objects nearby. When unpacking, avoid damaging the product with cutters or blunt tools.
- Page 6 02.6 IGNITION First connect the stove plug to the mains and load the pellet hopper. Care must be taken not to empty the entire bag at once, but to carry out this procedure slowly so as not to place any pellet dust from the bag into the hopper. If present, take care not to damage the seal on the pellet hopper door and keep the pellet hopper support surface clean.
-
Page 7: Using The Product
03. PRODUCT USE 03.1 RADIO CONTROL Proper functioning and control adjustment devices Console The remote control displays information regarding the operating status of the stove. A variety of data can be displayed and settings carried out according to the level of access by using the menu. Depending on the selected mode and on their position on the display, the data visualised may acquire different meanings. PANEL DESCRIPTION Button P1 –... - Page 8 03.2 EMERGENCY CONSOLE The emergency console is used when the remote control does not work or in case of loss of the latter. Button P1 – ON/OF: Keeping this button pressed, the stove will switch on or off according to the last settings recorded by the remote control. Button P2 –...
-
Page 9: User Functions
Sub-menu M3 – 4 – Chrono week-end It is used to enable/disable and to set the chronothermostat functions on weekends (days 6 and 7, i.e. Saturday and Sunday). To enable, press the P1 and P2 buttons. Setting the times Start 1 and Stop 1 sets the operating period for Saturday, while Start 2 and Stop 2 are used to set the stove operation for Sunday. -
Page 10: Alarms
Room temperature reaches the set value (SET temperature) When the set room temperature value is reached, the stove heat output is automatically set to the minimum value. During this phase, “MODULAT-” appears on the display. If room temperature falls below the set value (Set temperature), the stove will return to “WORK” mode and to the previously set heat output (Set heat output). -
Page 11: Introduction
06. INTRODUCTION The stove requires a simple yet constant cleaning to guarantee top efficiency and proper functioning. Constant maintenance by a qualified technician is recommended. The stove should be cleaned before the cold season because it can sometimes get clogged during the summer (by nests for example) preventing exhaust fumes to flow regularly. -
Page 12: Connections
07. CONNECTIONS CODE CIRCUIT BOARD 951095900 BURN POT CLEANER CONTACT 951067700 ROOM PROBE EXTERNAL THERMOSTAT FUME PROBE AUGER MOTOR EXCHANGER DEPRESSOR CONTACT SAFETY THERMOSTAT CONTACT DOOR CONTACT BURN POT CLEANER MOTOR FUME FAN SPARK PLUG 12 - English... - Page 13 Tel: +39 0438 740433 Fax: +39 0438 740821 I dati e le caratteristiche indicate non impegnano Eva Stampaggi S.r.l., che si riserva il diritto di apportare le modifiche ritenute opportune senza obbligo di preavviso o di sostituzione. Tutti i diritti riservati. Vietata riproduzione totale o parziale senza espressa autorizzazione di Eva Stampaggi S.r.l.
