- Page 1 INSTRUCTION MANUAL PELLET HYDRO STOVES ISOTTA PELLET COOKING STOVE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TECHNICAL DRAWING…..………………………………………………………………………………………………………………. p. 3 TECHNICAL DATA ……………………………………………………………………………………………………………………….. p. 3 FLUE PIPE …………………………………………………………………………………………………………………………………. p. 4 INSTALLATION WARNINGS…………………………………………………………………………………………………………….. p. 4 04.1 MINIMUM FREE INSTALLATION DISTANCES …………………………………………………………………………………. p. 4 04.2 MINIMUM RECESSED INSTALLATION DISTANCES ………………………………………………………………………….. p. 5 04.3 SYSTEM CONNECTION AND DIAGRAMS………………………………………………………………………………………. p. 6 COMPONENTS AND CONNECTIONS………………………………………………………………………………………………….. -
Page 3: Technical Drawing
01. TECHNICAL DRAWING TP20 PELLET COOKING STOVE 02. TECHNICAL DATA Technical data of the appliance: TP20 COOKING STOVE / HYDRO MODE TP20 COOKING STOVE / OVEN MODE Dati tecnici dell’apparecchio: Designation: Nominal heat output Reduced heat output Nominal heat output Reduced heat output Potenza termica nominale Potenza termica ridotta... -
Page 4: Flue Pipe
03. FLUE PIPE FLUE PIPE CHARACTERISTICS 19 KW PELLET COOKING STOVE Chimney flue draught 12 Pa Fume temperature 119 °C Maximum flue gas flow rate 13.4 g/s 04. INSTALLATION WARNINGS 04.1 MINIMUM FREE INSTALLATION DISTANCES If the stove is to be installed in rooms where it is surrounded by combustible materials (e.g. furniture, wood cladding, etc.), the following minimum clearances must be complied with: Isolating shim Convective air... -
Page 5: Minimum Recessed Installation Distances
04.2 MINIMUM RECESSED INSTALLATION DISTANCES Symbol (mm) Convective air Isolating shim (mm) (mm) RECESSED INSTALLATION Rear wall (under, above hob) C1, C2 50 of which Side wall (under hob) 50 of which Floor Front 1000 1000 Side (hob irradiation area) Above (hob irradiation area) -
Page 6: System Connection And Diagrams
04.3 SYSTEM CONNECTION AND DIAGRAMS... -
Page 8: Components And Connections
05. COMPONENTS AND CONNECTIONS NOTES DELIVERY ¾“ RETURN ¾“ SYSTEM LOAD / DISCHARGE ½" ELECTRONIC PUMP 1” - 230 V 50 Hz BALL VALVE ¾“ AUGER MOTOR 5.3 RPM SPARK PLUG 300 W PRESSURE TRANSDUCER 505 3/8” SAFETY AND DISCHARGE VALVE 3 BAR –... - Page 9 NOTES AUTOMATIC RELEASE VALVE ½" LCD DISPLAY FIRE DOOR OVEN DOOR OVEN OVEN ADJUSTMENT ON/OFF HYDRO/OVEN ADJUSTMENT...
-
Page 10: Installation
06. INSTALLATION In compliance with the current regulations for installation, the pellet heating stove should be installed in a ventilated place with air that is sufficient to ensure correct combustion and therefore good operation. The room must have a volume no less than 20 m³. In order to ensure good combustion (40 m³/h of air) there must be a "combustion air intake"... -
Page 11: Method Of Use
07. METHOD OF USE 07.1 HYDRO MODE In this mode, the cooking stove uses the heat generated from pellets to heat the home hydraulic system. The cooking stove should be positioned in this manner: The lever of the Hydro/Oven adjustment must be completely extracted while the Oven adjustment must be turned anti-clockwise until it is completely positioned. In this case, the heat output of the stove is regulated based on the temperature of the water in the stove or the ambient temperature or by an external thermostat. -
Page 12: Oven Mode
07.2 OVEN MODE In this mode the cooking stove uses the heat generated from pellets to heat the top plate and the oven. The cooking stove adjustments should be positioned in this manner: The lever of the Hydro/Oven adjustment must be completely inserted while the Oven adjustment must be turned clockwise until it is completely positioned. In this case, the heat output of the stove is regulated according to the oven temperature. -
Page 13: Summary Of Symbols
07.3 SUMMARY OF SYMBOLS HYDRO/OVEN adjustment OVEN HYDRO ADJUSTMENT ADJUSTMENT COMPLETELY COMPLETELY INSERTED EXTRACTED OVEN adjustment ADJUSTMENT HYDRO OVEN CAUTION: The HYDRO/OVEN adjustment lever can be removed by unscrewing it... -
Page 14: Electronics With 6-Button Lcd Display
08. ELECTRONICS WITH 6 BUTTON LCD DISPLAY 08.1 HYDRO MODE CONSOLE ROOM TEMPERATURE STOVE TEMPERATURE 10:56 18.5 ° 75 ° The control panel shows the information concerning the stove status. A variety of data can be displayed and settings carried out according to the level of access by using the menu. -
Page 15: Oven Mode Console
08.2 OVEN MODE CONSOLE OVEN TEMPERATURE 10:56 t-o 150 ° BUTTON 1 (P1) – Oven temperature SET increase: The button in working/off mode increases the temperature of the oven SET temperature. By keeping button P1 pressed, the pellet loading seconds and the actual boiler power will be displayed. - Page 16 Sub-menu M3 – 03 PROGRAM WEEK: The weekly programmable chrono-thermostat functions can be enabled, disabled and set. The weekly programmer has 4 independent programs whose final effect involves the combination of the 4 individual programs. The weekly programmer can be enabled or disabled. Moreover, if the time is set to OFF, the time clock ignores the corresponding command.
-
Page 17: User Functions
STATIC mode: the cooking stove is turned off. In this case the oven will be heated by the electric heating element inside it. The output of the heating element varies according to the oven SET which in this case varies from 80°C to 230°C. It is also possible to set the oven SET to OFF in order to keep the heating element off. - Page 18 HOTTEST SURFACE OF THE PLATE TRAY POSITIONED IN THE HOTTEST PART OF THE OVEN CAUTION: In THERMO-S mode it is possible that the cooking stove will need to dispose of the heat produced by the pellet also through the hydraulic system. In this case, when the water temperature reaches a pre-set threshold, the SMALTIRE message will appear on the display.
-
Page 19: Alarms
Pr48 = T seconds After a power outage, one of the following conditions may occur depending on the stove previous status: previous status power outage duration new status switched off switched off ignition < T ignition pellet loading without pre-load <... -
Page 20: Connections
11. CONNECTIONS CODE MOTHERBOARD L023+CHRONO+F.BLACK+RELAY 951066300 1200 W 230V OVEN HEATING ELEMENT 95110021100 RELAY 951089800 OVEN CONTACT 505 PRESSURE TRANSDUCER CABLE NTC TYPE OVEN PROBE FUME MOTOR ENCODER STOVE PROBE ROOM PROBE EXTERNAL THERMOSTAT FUME PROBE AUGER MOTOR OVEN BULB PUMP / CIRCULATOR DEPRESSOR SAFETY THERMOSTAT... - Page 21 Tel: +39 0438 740433 Fax: +39 0438 740821 I dati e le caratteristiche indicate non impegnano Eva Stampaggi S.r.l., che si riserva il diritto di apportare le modifiche ritenute opportune senza obbligo di preavviso o di sostituzione. Tutti i diritti riservati. Vietata riproduzione totale o parziale senza espressa autorizzazione di Eva Stampaggi S.r.l.
