Coolaroo AutoSun Custom Made Instruction Manual page 8

BOTTOM BRACKETS
STEP 1
Extend roller blind out to your full desired length. The two
'bottom' wire guide brackets will sit below the base rail (as
pictured in Fig 1).
NOTE: Allow for any kind of obstacles such as window
winders and window sills, etc.
STEP 2
Remove screw end cap from bottom wire guide bracket and
feed wire through (Fig 2).
STEP 3
Feed wire through adjustable wire fastener. If the wire won't
feed, use allen key to open it (Fig 3).
8
Fig 1
Fig 2
Fig 3
