TOP BRACKETS
STEP 1
Remove screw end cap from bracket and feed wire through
the screw end cap hole (Fig 2).
STEP 2
Feed wire through adjustable fastener (as pictured) and
tighten with Allen key (provided). Leave approximately
1/ 4 in. wire overhang. If the wire won't feed through the
adjustable wire fasteners, you will need to use an allen key
to open it up (Fig 3).
STEP 3
Pull wire and adjustable wire fastener back through the
screw end cap, and screw back onto the top wire guide
bracket (Fig 4).
STEP 4
Repeat steps 1 – 4 for other top side wire guide bracket.
Fig 1
Fig 2
Fig 4
Fig 5
