WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. Please read all instructions before assembly and use. Two or more people are recommended for safe assembly. Keep all children and pets away from assembly area.
Page 3
ASS EM BLY G UI DE 3.5m 2.7m 2.8m SQUARE ROUND STEP 1 Take all of the parts out of box 1 and 2 to ensure they are all present before starting construction.
Page 4
STEP 2 If you want the base to be portable, attach the wheels (o) to the underside of the base (n). The wheels have a locking function. Rotate the metal lock to stop the wheels from turning. Note: Always lock the wheels to prevent unwanted movement and ensure they are unlocked when moving to desired position.
Page 5
STEP 6 Lower the umbrella frame and canopy (f) onto the base (a) ensuring that the screw holes match up. Push the plastic cover (i) down until it clicks into the plastic cone (j). Secure the poles together using the screw with plastic cap (h).
Page 6
STEP 11 To tilt the canopy, release the lever on the handle and rotate to the desired angle. Return the lever to the lock position to keep the desired angle. STEP 12 To close the umbrella, wind the canopy down with the crank handle. Move the easy glide handle to the bottom position and wrap the Velcro straps around the canopy.
Page 7
WARRANTY CLAIMS AND LIMITATION OF LIABILITY 1) Upon purchasing the Product, the customer must register their warranty by completing the Coolaroo online warranty Coolaroo products are manufactured by Gale Pacific Limited registration at www.coolaroo.com. Alternatively, the ACN 082 263 778 (Gale). Gale provides the following customer can contact Coolaroo Customer Service on warranty in relation to Coolaroo products (“Product”).
Page 8
Sun Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade under your premium Coolaroo umbrella. To register your product, go to coolaroo.com. The product code can be found printed above the barcode on the product packaging, alternatively you can find it on the relevant coolaroo.com product page.
