OPERATION INSTRUCTIONS
Telis RTS Remote Controls Single and Five Channel.
A. PROGRAMMING - ADDING A NEW REMOTE OR OPERATING
PROGRAMMING – ADDING A NEW REMOTE OR OPERATING CHANNEL
CHANNEL
A previously programmed remote can be used in order to add a
A previously programmed remote can be used in order to add a new remote or channel to the Motorized Window Covering.
If a Telis Transmitter has not been previously programmed, please refer to the installation instructions of the relevant RTS
new remote or channel to the Motorized Window Covering. If a
motorized window covering.
Telis Transmitter has not yet been previously programmed, please
refer to the installation instructions of the relevant RTS motorized
window covering.
Adding a Telis 1 RTS Transmitter only:
1. Using the previously programmed Telis
remote, press and hold the programming
1. ADDING A TELIS 1 RTS TRANSMITTER ONLY
button on back of remote until
window covering "jogs."
a. Using the previously programmed Telis remote, press and hold
the programming button on the back of the remote until the
window covering "jogs". (fig. 1)
b. Using the new Telis 1 remote, briefly press the programming
button until the window covering "jogs". The window covering
has now learned the commands of the new Telis remote. (fig. 2)
Adding a Telis 5 RTS Transmitter only:
1. Using the previously programmed Telis
remote, press and hold the programming
2. ADDING A TELIS 5 RTS TRANSMITTER ONLY
button on back of remote until window
covering "jogs."
a. Using the previously programmed Telis remote, press and hold
the programming button on the back of the remote until the
window covering "jogs". (fig. 3)
b. Using the new Telis 5 remote, select the desired channel using
the CHANNEL SELECTOR BUTTON. (The led will illuminate each
time the Channel Selector Button is pressed, indicating the
selected channel. (fig. 4)
c. Using the new Telis 5 remote, briefly press the programming
button until the window covering "jogs". The RTS motorized
window covering has now learned the commands of the new Telis
5 remote. (fig. 5)
