Coolaroo AutoSun Custom Made Instruction Manual

Motorization exterior sun shade
Hide thumbs

Advertisement

Quick Links

Download this manual
CUSTOM MADE
4YR
Limited
Warranty
EXTERIOR SUN SHADE
M O T O R I Z A T I O N I N S T R U C T I O N M A N U A L

Advertisement

loading
Need help?

Need help?

Do you have a question about the AutoSun Custom Made and is the answer not in the manual?

Questions and answers

Related Manuals for Coolaroo AutoSun Custom Made

Summary of Contents for Coolaroo AutoSun Custom Made

  • Page 1 CUSTOM MADE Limited Warranty EXTERIOR SUN SHADE M O T O R I Z A T I O N I N S T R U C T I O N M A N U A L...
  • Page 2 Wand STEP 1 You may also need (A) Full Valance (Motorized) (C) Solar Panel (B) Battery (G) Shade (F) Bottom Rail (D) Bottom Rail Cap with ring (E) Quick Mount Brackets This device complies with part 15 of the FCC Rules. Operating is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept...

  • Page 3: Important: Please Read

    You may also need: IMPORTANT: PLEASE READ PLEASE PLACE YOUR AUTOSUN™ SOLAR POWERED EXTERIOR SUN SHADE IN THE SUN IMMEDIATELY. PLEASE PLACE YOUR BATTERY CONNECTED TO THE SOLAR PANEL, WITH THE SOLAR PANEL FACING THE SUN. NOTE: a. Approximate installation time is 10-20 minutes. b.
  • Page 4 Wire guide F U L L V A L A N C E I N S T A L L A T I O N Bottom exposed aluminium rail COMPONENTS Wand Take all parts out of the box and ensure they are all present. STEP 1 You may also need Full Valance (Motorized)

  • Page 5: Install The Shade

    (9) Idle End Plug (H) Shade (8) Idle End Unit (B) Crank Handle (G) Bottom Rail (E) Bottom Rail Cap 1. DETERMINE DESIRED MOUNTING METHOD with ring (A) Full Valance (6) Bottom Rail (F) Quick Mount (D) Bungee (6) Quick Mount Brackets Brackets Ceiling...
  • Page 6 W I R E G U I D E S Y S T E M A S S E M B L Y COMPONENTS Take all parts out of the box and ensure they are all present. Bottom Brackets (small) Wires (13 ft.
  • Page 7 TOP BRACKETS Fig 1 STEP 1 Remove screw end cap from bracket and feed wire through the screw end cap hole (Fig 2). STEP 2 Feed wire through adjustable fastener (as pictured) and tighten with Allen key (provided). Leave approximately 1/ 4 in.
  • Page 8 BOTTOM BRACKETS STEP 1 Extend roller blind out to your full desired length. The two ‘bottom’ wire guide brackets will sit below the base rail (as pictured in Fig 1). Fig 1 NOTE: Allow for any kind of obstacles such as window winders and window sills, etc.
  • Page 9 STEP 4 Tighten adjustable fastener with Allen key provided at your desired length, at least 3/ 4 in. below the base rail (Fig 5 & 6). IMPORTANT: Fig 5 a. Locate an area on the wall/floor that is suitable for the bottom bracket to be screwed into. Ensure wire guide reaches the suitable drilling point for the bottom bracket.
  • Page 10 STEP 9 Drill holes for screws (Fig 9). STEP 10 Screw bottom bracket into the wall/floor. Ensure bottom wire guide bracket anchor points up (Fig 8). NOTE: Use masonry plugs if installing directly into concrete/brick wall. Do not install directly into mortar Fig 9 between bricks.
  • Page 11 CHANGE DIRECTION OF BRACKET ANCHOR POINTS (IF DESIRED) STEP 1 Remove screw end cap (Fig 1). Fig 1 STEP 2 Locate Philips head screw inside thread. Use a Philips head screw driver to remove screw and thread (Fig 2). STEP 3 Reattach in the desired direction.
  • Page 12 A U T O S U N ™ I N S T R U C T I O N S COMPONENTS Take all parts out of the box and ensure they are all present. The AutoSun™ system is a complete solar powered motor system. It is comprised of: AutoSun™...
  • Page 13 VISUAL COMPONENT GUIDE SOLAR PANEL MOUNTING OPTIONS AND RECOMMENDATIONS battery 12V - 2.2Ah ref.: 9014734 1. PRESENTATION Fig. 1 a. By converting solar energy to electrical energy, the solar panel (Ref: 9019032) charges the battery pack. b. Current supplied by the panel (Isc): 196 mA +/- 10% battery 12V - 2.2Ah ref.: 9014734 T3.5 DC EHz c.
  • Page 14 SOLAR PANEL MOUNTING OPTIONS AND RECOMMENDATIONS 9019683 = (continued) Fig. 1 1. FASTENING THE SOLAR PANEL USING THE MOUNTING ❶ ❶ BRACKETS ❶ 10,5 a. The solar panel should always be placed on an open area, either on a pergola, gazebo, or wall so as to be exposed as possible to Ø...
  • Page 15 The battery pack used in the Autosun solar system has the follow - Store electrical energy provided by the solar panel. - Supply electrical energy required by the motor. - Enable programming of the motor using the programming but Technical data: BATTERY MOUNTING OPTIONS - NiMh battery - 12V / 2,2 Ah - Battery life: approx.
  • Page 16 (direction of rotation, end limits and control points). tion 2.1c then operation 3 to programme a new indiv YOUR SOLAR POWERED EXTERIOR SUN SHADE COMES FROM THE FACTORY AT COOLAROO WITH AN INITIAL CHARGE, 9. Complete cancelling of programming 10. Battery protection against excessive discharge PLEASE INSTALL YOUR SHADE PROMPTLY OR PLACE THE - Press the “PROG”...
  • Page 17 210 min. - Minimum charging time to be able to open th need to purchase a charger via our website, www.coolaroo.com, 4- Connect the charger to the battery. The LED changes colour from green to red. or contact customer service at 1-800-560-4667.
  • Page 18 MFY INSTRUCTIONS A previously programmed remote can be used in order to add a new remote or channel 1810643 Telis 1 RTS Patio LED Lights 1810650 Telis 1 RTS Lounge Programming If a Telis Transmitter has not been previously programmed, please refer to the installatio 1810645 Telis 5 RTS Patio Indicator 1810652 Telis 5 RTS Lounge...
  • Page 19 In addition to standard OPEN and CLOSE features, the Telis remote enables the user to pre-e 1. Using the UP ( window covering “jogs.” Favorite position is Button to stop the window covering ) or DOWN ( ) Buttons, In addition to standard OPEN and CLOSE features, the Telis remote enables the user to pre Button to stop the window covering when the “MY”...
  • Page 20 appropriate channel using the CHANNEL once position is reached. Example: Briefly press the “MY”( ) button once position is reached. once position is reached. once position is reached. In addition to standard OPEN and CLOSE features, the Telis remote enables the user to pre SELECTOR BUTTON.
  • Page 21 OPERATION INSTRUCTIONS (continued) E. ADJUSTING THE END LIMITS AFTER THE MOTOR HAS BEEN PROGRAMMED a. To change the upper limit run the motor to its upper limit and let it stop. Press the UP and DOWN buttons simultaneously until the motor jogs. Run the motor to the new desired upper limit. Press and hold the MY/STOP button until the motor jogs.
  • Page 22 The best under the sun. Coolaroo is the leader in exterior fabric technology. Our extensive range of attractive, fashionable shade and landscape solutions are carefully manufactured to beautify your home and provide protection for your family and garden from the harsh sun.
