Digi-Sense TC9600 Advanced User Manual page 36

Specifications for TC9600 Controller — Model 89800-14
Power input: 230 VAC ±10%, 50/60 Hz ±3%, 10 amp, 2300 watts max load
Operating environment: 32 to 77ºF (0 to 25ºC); 90% RH, noncondensing
Maximum altitude: 2187 yd (2000 m)
Pollution degree: 2 (normally only nonconductivity pollution occurs)
Installation category II: local level (connect to branch circuit and not directly to a main cir-
cuit,
such as a fuse panel)
Storage: 32 to 140ºF (0 to 60ºC); 5 to 80% RH, noncondensing
Fuse: 250 volt, 10 amp rated (fast-acting)
AC line cord: SJT-14-3 14 AWG, 15 amp, 240 VAC, less than 9 ft (3 m) in length
Heater/cooler output: max voltage: 240 VAC ±10%, 15 amp, 50/60 Hz ±3%, 3600 watts max
load
External alarm output: SPDT relay — 24 VAC/VDC, 1 amp
Process memory: data retention upon power failure via nonvolatile memory
Dimensions (W x H x D): 8" x 3.75" x 9" (20.3 x 9.5 x 22.9 cm)
