PD2-6080/PD2-6081
Helios Super Snooper
Modbus
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Precision Digital corPoration
Find Quality Products Online at:
Scanners
®
PD2-6080
Large 1.80" Digits
Dual-Line 6-Digit Display
Readable from up to 100 Feet (30 Meters) Away
Superluminous Sunlight Readable Display
NEMA 4X, IP65 Rated Field Mountable Enclosure
Operating Temperature Range of -40 to 65°C (-40 to 150°F)
Modbus
RTU Master, Slave, or Snooper Mode
®
Poll and Display up to 16 Process Variables
Addition, Difference, Average, Multiplication, Division, Min,
Max, Weighted Average, Ratio, Concentration, & More
Universal 85-265 VAC, or 12-24 VDC Input Power Models
2 or 4 Relays + Isolated 4-20 mA Output Options
Onboard USB & RS-485 Serial Communication Options
Program the Meter from a PC with onboard USB and ScanView
UL & C-UL Approved
GlobalTestSupply
www.
Actual Size Digit
MODBUS
S C A N N E R S
.com
sales@GlobalTestSupply.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Helios PD2-6080 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PRECISION DIGITAL Helios PD2-6080

Summary of Contents for PRECISION DIGITAL Helios PD2-6080

  • Page 1 2 or 4 Relays + Isolated 4-20 mA Output Options Onboard USB & RS-485 Serial Communication Options • Program the Meter from a PC with onboard USB and ScanView • • UL & C-UL Approved Precision Digital corPoration GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 2: Key Features

    Custom Tag and Units for Each PV Modbus RTU Master, Slave, or Snooper. As a Master, the Helios PD2-6080/81 reads up to 16 slave devices, Each process variable has an independently programmable tag scales the data from each, and displays each on an alternating and unit name.
  • Page 3 PD2-6080/PD2-6081 Helios Super Snooper Modbus Scanners ® Typical Modbus Application Example Modbus Application Capabilities The PD6080 & PD6081 scanners can communicate with any Modbus device using the ever-popular Modbus communications protocol. Take advantage of the Modbus capabilies in the level and flow transmitters you already have by using Master Mode to read more data, more accurately.

  • Page 4: Digital Communications

    Scanners ® DIgITAL COMMUNICATIONS Three Tier Password Protection The Helios PD2-6080/81 offers 3 levels of password protection: Free USB Programming Software (ScanView) • Level 1 protection allows the operator use of only the 3 pre- The Helios comes with free programming software that connects configured function keys without a password.
  • Page 5 Isolated Transmitter Power Supply A powerful 24 V @ 200 mA power supply is a standard feature on the Helios PD2-6080/81. It can be configured for 5, 10, or 24 V (default) by means of a simple internal jumper (see manual). An additional power supply (24 V @ 40 mA) is standard with the 4-20 mA output option.

  • Page 6: Specifications

    PD2-6080/PD2-6081 Helios Super Snooper Modbus Scanners ® Master & Snooper Settings SPECIFICATIONS Except where noted all specifications apply to operation at +25°C. PV Number: PV1–PV16 Enable or disable the process variables to be polled by the Master. general Slave Id: Assign the slave ID or address (1-247, 256-259 for mA or volts inputs) containing the process variables to be displayed by the selected PV.

  • Page 7: Math Functions

    PD2-6080/PD2-6081 Helios Super Snooper Modbus Scanners ® Isolated 4-20 mA Transmitter Output Math Functions Output Source: Process Variable 1-16, math channels C1-C4, set points Math Operation (Examples) 1-4, or manual control mode Name Setting (P = Adder, F = Factor) Scaling Range: 1.000 to 23.000 mA for any display range Addition (PV1+PV2+P)*F...

  • Page 8: Ordering Information

    Suppressor (snubber): 0.01 μF/470 Ω, 250 VAC Disclaimer 2.63" (67 mm) The information contained in this document is subject to change without notice. Precision Digital Corporation makes no representations or warranties with respect to the contents hereof, and Side View specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
