Industrial Digital
Pressure Gauge
Model PD213, PD214, PD224
Operating
Instructions
I&M008-10136-07/2011 (dwg. 83B234-01 Rev. C 3/06)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PD213 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PRECISION DIGITAL PD213

Summary of Contents for PRECISION DIGITAL PD213

  • Page 1 Industrial Digital Pressure Gauge Model PD213, PD214, PD224 Operating Instructions I&M008-10136-07/2011 (dwg. 83B234-01 Rev. C 3/06)
  • Page 2 Congratulations on your purchase of the Precision Digital Industrial Gauge. This feature- packed gauge offers a menu-driven display for easy customization. User selectable features include 12 units of measurement, password protected calibration and disable functions, adjustable bargraph and update rate.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Quick Reference ..........4-5 Keypad Functions ..........6-8 • ON/OFF KEY • ZERO/CLEAR KEY • MIN/MAX KEY (down arrow key) • MENU KEY • BACKLITE KEY (up arrow key) • ENTER KEY MENU Functions (MENU Mode) ........8-15 • Engineering Units •...

  • Page 4: Quick Reference

    QUICK RE .88˝ high digital display (4 ⁄ ˝ case) .60 high digital display(3˝ case) Bargraph % of full scale Flashing display when unit pressured below zero Press to indicate minimum or maximum pressure gauge has measured Press again to return to pressure units Press to read menu UPDATE RATE...
  • Page 5 EFERENCE Press to turn unit on or off While in unit of measurement mode (eg: psi), press the ZERO CLEAR button to rezero the gauge. This feature functions when displayed pressure is within ±5% or 10% of zero value Flashing display when unit pressurized beyond full-scale This Bargraph indicates battery level;...

  • Page 6: Keypad Functions

    KEYPAD FUNCTIONS Turns the gauge on and off. When pressing the ON/OFF key while in the off position, gauge start- ON/OFF up display first indicates the software version followed by the gauge pressure range. The gauge will then display indicated pressure and be ready for use.

  • Page 7: (Down Arrow Key)

    KEYPAD FUNCTIONS This key allows for customization of the gauge. Pressing the MENU key allows cycling through MENU the main MENU items; UNITS, CONFIG, GRAPH, OFF, UPDAT & DAMP. Any item changed in the Menu become the new default setting(s). Revised settings are saved in the event of power loss.

  • Page 8: Keypad Functions

    KEYPAD FUNCTIONS This key allows for selecting gauge features in the menu finalizing selection. Use of the enter key is ENTER described throughout operating instructions. MENU OPTIONS UNITS: 12 units of measurement are available: psi, mmHG, O with three temperature options: 20°C, 60°F, 4°C*, mBar, inHg, ftH O, mPa, kPa, kg/cm and bar.

  • Page 9: Menu Functions (Menu Mode)

    KEYPAD FUNCTIONS MENU FUNCTIONS How to Use Your Menu Functions To set a user password (SETPW): Step 1: Press the Menu key on the keypad Step 2: Press the (up arrow key) or (down arrow key) until the word CONFIG appears. Step 3: Press Enter.
  • Page 10 MENU FUNCTIONS To use RECAL option: Step 1: Press the Menu key on the keypad Step 2: Press the (up arrow key) or (down arrow key) on the keypad until the word CONFIG appears. Step 3: Press Enter. Step 4: Enter user password if it has been programmed. Step 5: Press (up arrow key) or (down arrow key)
  • Page 11 MENU FUNCTIONS Note: Calibration of Zero, mid-scale or span can be set inde- pendently of each other. For instance, if only full-scale cali- bration is required, press the (down arrow key) until the gauge display indicates full-scale pressure. Press Enter and proceed as indicated above.
  • Page 12 MENU FUNCTIONS Step 3: press ENTER. The current setting (ENAB or dISAB) will be displayed. Step 4: Press the (up arrow key) or (down arrow key) on the keypad to select a setting. Step 5: Press ENTER To finalize the setting. GRAPH: This option allows the user to change the bar- graph on the gauge display to correspond to any desired pressure within the pressure limits of the gauge.
  • Page 13 MENU FUNCTIONS Step 5: Press the ENTER key to finalize your choice. The gauge display will now display SET. After two seconds the screen will display the pressure value for 0% on the top line. The middle line indicates the bargraph at 100% of fullscale.
  • Page 14 MENU FUNCTIONS Step 2: Press the (up arrow key) or (down arrow key) until the word UPDATE appears. Step 3: Press Enter. Step 4: Press the (up arrow key) or (down arrow key) to select an update rate. Step 5: Press ENTER to finalize the selection. DAMP or dampening: with five different options, this mode allows for taking process pressure readings and averaging them.
  • Page 15 MENU FUNCTIONS Note: Setpoints are limited to the full-scale pressure range of the gauge. Step 4: Press the (up arrow key) or (down arrow key) on the keypad to increase or decrease switch set-point Step 5: Press the ENTER key to finalize switch setpoint. The gauge will display SET.

  • Page 16: Engineering Units

    Optional Power Options: Battery, loop-powered, or 12-36 VDC Bargraph: 10-segment %FS, programmable Battery Life: PD213 3˝ >1000 hrs., PD214 and PD224 4 ⁄ ˝ >3600 hrs. Agency Approvals: CE, FM and CSA (Intrinsically Safe Class I, Div 1) KEYPAD FUNCTIONS...

  • Page 17: Display Messages

    PRESSURE RANGES: in.Hg Comp. mmHg in.Hg Bar/ mBar (vacuum) (psi) (pressure) (pressure) -15/0/15 1000 -15/0/30 1000 1500 -15/0/60 2000 1000 2000 -15/0/100 3000 2500 5000 4000 10,000 5000 1000 6000 1000 1600 10,000 2500 15,000 4000 1000 20,000 6000 1500 10,000 2000 16,000...

  • Page 18: Wiring Diagrams

    WIRING DIAGRAM Loop Powered 4-20mA 2 conductor, 20 AWG shielded (+ exec.) A Black (– exec.) B Shield LOOP+ LOOP– ECND D10 C14 T9 F1D1 FID2 FID6 R22 R20 FID4 Sensor Input FID3 Battery Input 321CO21– DQ/TB 2003 +24V EGND Keypad Input POWER SUPPL Y...
  • Page 19 WIRING DIAGRAM Load Limitations 4-20mA Output Only 1000 OPERATING REGION Loop Supply Voltage (Vdc) Vdc MIN = 12V + [0.022A X (RL) ] = Loop Resistance (ohms) = Sense Resistance (ohms) = Wiring Resistance (ohms) – 19 –...
  • Page 20 WIRING DIAGRAM Line Powered 2 conductor, 20 AWG shielded F1D1 FID2 FID6 R22 R20 FID4 Sensor Input FID3 Battery Input 321CO21– DQ/TB 2003 +24V EGND Keypad Input Shield Black (–exec.) D Red (+exec.) C POWER SUPPL Y – Red (C) GAUGE ( –...

  • Page 21: Wiring Diagrams

    WIRING DIAGRAM Line Powered with (1) SPDT switch 5 conductor, 22 AWG shielded (–exec.) F (+exec.) E POWER SUPPL Y – (–) Black (F) GAUGE V– White (NO) • Brown (Common) Green (NC) Installation Procedure ESD precautions should be taken. See page 31 for details. 1.
  • Page 22 WIRING DIAGRAM Line Powered with (2) SPDT switches 8 conductor, 22 AWG shielded SWITCH 1 (N.O .) White (N. C. ) Green (COM) Brown ISO 1 F1D1 SWITCH 2 FID2 ISO 2 (N.O.) Yellow FID6 (N.C.) Blue R22 R20 FID4 (COM) Orange R1 8 Sensor Input...
  • Page 23 Installation Procedure ESD precautions should be taken. See page 31 for details. 1. Ensure all power is off/disconnected from the circuit. 2. Connect the red wire (G) to the positive power terminal. 3. Connect the black wire (H) to the positive meter terminal. Wiring Switch 1: Normally Open: Use the white and brown wires.

  • Page 24: Gauge Installation & Maintenance

    WIRING DIAGRAM Line Powered/Loop Powered 4-20mA 4 conductor, 20 AWG shielded Black (J) LOOP+ LOOP– ECND D10 C14 T9 F1D1 FID2 FID6 R22 R20 FID4 Sensor Input FID3 Battery Input 321CO21– DQ/TB 2003 +24V EGND Keypad Input Shield Green (L) White (K) POWER SUPPLY...
  • Page 25 Installation Procedure for ESD precautions should be taken. See page 31 for details. 1. Ensure all power is off/disconnected from the circuit. 2. Connect the white wire (K) to the positive power terminal. 3. Connect the green wire (L) to the negative power terminal. 4.
  • Page 26 WIRING DIAGRAM Line Powered/Loop Powered 4-20mA with (1) SPDT switch 7 conductor, 22 AWG shielded Red M Blac k N (N.O.) Blue (N.C.) Orange (COM) Brown LOOP+ LOOP– ECND D10 C14 T9 ISO1 F1D1 FID2 ISO2 FID6 R22 R20 FID4 Sensor Input FID3 Battery Input...
  • Page 27 Installation Procedure ESD precautions should be taken. See page 31 for details. 1. Ensure all power is off/disconnected from the circuit. 2. Connect the white wire (P) to the positive power terminal. 3. Connect the green wire (O) to the negative power terminal. 4.
  • Page 28 WIRING DIAGRAM Line Powered/Loop Powered 4-20mA with (2) SPDT switches 10 conductor, 22 AWG shielded SWITCH 1 Red Q Blac k R (N.O .) Blue (N.C .) Orang e (COM) Br ow n LOOP+ LOOP– ECND D10 C14 T9 ISO1 F1D1 FID2 SWITCH 2...
  • Page 29 Installation Procedure ESD precautions should be taken. See page 31 for details. 1. Ensure all power is off/disconnected from the circuit. 2. Connect the white wire (T) to the positive power terminal. 3. Connect the green wire (S) to the negative power terminal. 4.
  • Page 30 GAUGE INSTALLATION: The Precision Digital industrial gauge comes standard with either ⁄ ⁄ NPT connection. Good piping practices recommend using teflon tape or a pipe sealant on the gauge threads. Utilize a ⁄ ˝ (3˝ case), ⁄ ˝ (4 ⁄...
  • Page 31 ESD PRECAUTIONS Care should be taken to minimize exposure to ESD. Proper proto-call should be followed as outlined in: ANSI/ESD S20.20-2007 ESD ADV1.0-2009 ANSI/ESD S541-2008 Additional ESD Precautions on Proper Handling: Avoid carpets in cool, dry areas as well as other static generating materials such as plastic, cellophane, paper, or cardboard.

  • Page 32: Mounting

    Notes: 1) Do not mix ages or brands of batteries. 2) Do not replace batteries in hazardous areas. 3) To provide maximum battery life, replace both batteries 4) To provide maximum battery life, replace both batteries. Pipe to which gauge is attached must be properly grounded.
