Charlton & Jenrick PARAGON 2000 Plus SLIDE CONTROL Owner's Manual page 22

NOTE LOW LINTEL VERSION
The 460mm measurement up from the bottom eye's can be reduced to 410mm on the Low Lintel Version.
Fix the fire casing back into the opening using the cable
fixing system as shown in do not cut off loose ends of
cable after fixing, coil and tuck carefully back
Note: when using the cable fixing kit with the spacer, fix and
seal the spacer to the rear of the appliance flange with the
screws and foam seal provided.
CHECKING GAS SOUNDNESS
After completing the gas connection to the appliance, check for gas soundness in accordance with current codes of
practice.
CONNECTING CONTROL LEVER
Flip the slide control lever round so
that the rubber-capped end is
protruding out to the right as shown
in the left-hand picture. Check that
it slides freely up and down in the
nylon slide guides. Remove the
nylock nut with a 7mm A/F spanner
as shown.
Connect the link lever to the stud at
the end of the slide control lever
and replace the nylock nut.
IMPORTANT TURN THE NUT UNTIL
IT JUST TIGHTENS AND THEN TURN
IT BACK A HALF TURN. Check the
operation on the lever and
mechanism ensure that the lever
springs back to the low position
when it is released after pushing
down.
22 LT5049 (ISS 2)
