Charlton & Jenrick PARAGON P9 Owner's Manual

Paragon gas fire
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
P9
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 6974 (ISS 4)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARAGON P9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick PARAGON P9

Summary of Contents for Charlton & Jenrick PARAGON P9

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 EXTENDED FIVE Benchmark Scheme ............. 3 YEAR PARTS SECTION ONE Introduction (user instructions) ..5 SECTION TWO Operating the Appliance (user WARRANTY instructions) ..............7 SECTIONTHREE Cleaning (users instructions) ..... 9 In order to validate your extended 5 years parts SECTION FOUR Fuel Bed Cleaning and Layout (user warranty please read the Benchmark Scheme on the instructions) ...............

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: PARAGON P9 Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Introduction (User Instructions)

    INTRODUCTION  The Paragon P9 has been designed and tested to the requirements of EN 613 and is suitable for use in GB (Great Britain) and IE (Ireland). ...
  • Page 6 The Paragon P9 is battery operated; therefore no mains electrical supply is required. Power to the appliance is provided by 6 high power alkaline 1.5V batteries (AA size) (a spare set of 6 AA batteries is supplied with the appliance).

  • Page 7: Section Two Operating The Appliance (User Instructions)

    SECTION TWO Operating the Appliance (user instructions) Before attempting to operate the appliance check that nothing has been placed in front of the appliance that may interfere with the remote sensor operation. To light the appliance using the remote hand set: A.
  • Page 8 Low Battery Indication (Hand Set) If while pressing any of the buttons on the remote hand set the low battery indicator lamp either stops flashing or appreciably slows then the battery should be changed. To Replace Batteries In Hand SET (AAA 1.5 v lr3 X2 ) Remove the cover from the rear of the handset and fit replacement batteries, taking care not to strain the battery connections.

  • Page 9: Sectionthree Cleaning (Users Instructions)

    SECTIONTHREE Cleaning (users instructions) Warning: - Before you clean any part of the appliance ensure that the appliance is turned off and cold. CLEANING: PILOT ASSEMBLY (With Fireplace frame fitted) (Before cleaning ensure that the appliance is turned off and cold) In some instances you may experience ignition problems even when the appliance is new.
  • Page 10 REMOVING GLASS PANEL  Remove the two side covers LH and RH which are held on with magnets.  Undo the two M4 nuts retaining the glass fixing bracket using the tool provided then pull clear from location studs.  Carefully lift the glass panel from within the bottom location slot.

  • Page 11: Section Four Fuel Bed Cleaning And Layout (User Instructions)

    SECTION FOUR Fuel Bed Cleaning and Layout (user instructions)  Before you clean any part of the appliance ensures that the appliance is turned off and cold.  Use only the fuel bed components provided and no additional parts must added. ...
  • Page 12  Place a single layer of black bark chippings across the burner top plate. Place two off the log shapes along the back edge of the air tray as shown. Finally place a single layer of the large bark chippings along the front and sides of the air tray.
  • Page 13  Place the two log shapes as shown.  Place the final two log shapes as shown www.charltonandjenrick.co.uk LT6974 (ISS 4)

  • Page 14: Section Five General Points (User Instructions)

    SECTION FIVE General Points (user instructions) Like all appliances incorporating an aerated burner a low frequency noise may be heard, particularly on the low setting, this is quite normal and does not affect the operation of the appliance. It is advised that a competent person service the P9 fire annually. The fire is more likely to provide trouble-free operation.
  • Page 15 www.charltonandjenrick.co.uk LT6974 (ISS 4)

  • Page 16: Section Six Appliance Data (Installation Instructions)

    SECTION SIX Appliance Data (installation instructions) NATURAL GAS L.P.G Gas Type: CATEGORY I 2 H CATEGORY I 3 P Gas Pressure: 20 mbar +/- 1.0mbar 37 mbar +/- 1.0mbar Pressure Test Point Location: Gas inlet elbow Gas inlet elbow Gas Input: 7.6 kW Gross (Max.) 7.1 KW Gross (Max) 2.4 kW Gross (Min.)

  • Page 17: Section Seven Regulations And Warnings (Installation Instructions)

    SECTION SEVEN Regulations and Warnings (installation instructions)  This appliance must only be installed in Great Britain or Ireland.  The appliance is suitable for use on natural gas and L.P.G.  GB (Great Britain) This fire does not normally require purpose build ventilation in accordance with 2010 document “J”...

  • Page 18: Section Eight Siting The Appliance (Installation Instructions)

    SECTION EIGHT Siting the Appliance (installation instructions) CLASS ONE That is a conventional brick or stone chimney as used for a solid fuel appliance with an effective cross-sectional dimension of 225 x 225 mm (9” x 9”) or a lined flue with a minimum diameter of 125mm (5”). The chimney must have a minimum effective height of at least 3 metres.
  • Page 19 Clearance to Shelf Minimum clearance from hearth or base of opening to underside of combustible shelf should be 800mm provided the shelf depth is 75mm (3”). This gives a minimum clearance above the appliance of 140mm. For a shelf of 150mm (6”) the minimum height above the hearth or base of opening must be 880mm.

  • Page 20: Section Nine To Install The Appliance (Installation Instruction)

    SECTION NINE To Install the Appliance (installation instruction) GAS SUPPLY ROUTING Use rigid or semi – rigid tube to connect the supply. Determine the gas supply pipe route to the appliance before installing the fire. Please note that if the fireplace frame option is required the inlet cover retaining screws and nut should be fitted from the rear of the firebox flange at this stage.
  • Page 21  Inset the inlet Cover within the fireplace frame and glass panel location bracket.  Operate the handset as described in section one.  Lay the fuel bed as described in section four.  Place the Glass panel within the location bracket within the fire box shelf assembly. ...
  • Page 22 CHECKING GAS SOUNDNESS AND RUNNING PRESSURE. *Batteries must be connected before proceeding with any soundness testing*  Turn on the gas supply to the appliance and check for soundness in accordance with current codes of practice.  Turn off the gas supply at the external Isolation valve. ...

  • Page 23: Section Ten Checking Operation Of Fire (Installation Instructions)

    SECTION TEN Checking Operation of Fire (installation instructions) CHECKING FOR COMBUSTION PRODUCTS CLEARENCE IMPORTANT:-The smoke test must be carried out with the fire starting from cold.  Light the fire and leave at maximum input.  Close all the doors and windows. ...

  • Page 24: Section Eleven Maintenance (Maintenance Instructions)

    SECTION ELEVEN Maintenance (maintenance instructions) GENERAL  Servicing should be carried out annually by a competent person such as a Gas safe-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance.  Before commencing any service or replacement of parts, turn off the gas supply to the fire.
  • Page 25 REPLACEMENT OF OXY-PILOT ASSEMBLY NOTE: If the pilot assembly is replaced it must be replaced by an identical unit from the same manufacturer and replaced as a complete unit.  Follow the burner tray removal sequence.  Undo the compression nut on the supply pipe at the pilot. ...

  • Page 26: Section Twelve Wiring Diagram (Maintenance Instructions)

    SECTION TWELVE Wiring Diagram (maintenance instructions) Attach to the valve LT6974 (ISS 4)
  • Page 27 www.charltonandjenrick.co.uk LT6974 (ISS 4)
  • Page 28 LT6974 (ISS 4)
  • Page 29 www.charltonandjenrick.co.uk LT6974 (ISS 4)

  • Page 30: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 31: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 32 A-0572 QE (NG) Product Serial No ID Label Prefix A-0670 RQ (L.P.G) Burner Tray / Box Assembly Box Ceramics Fitted Complete Log Fuel Bed (7224) Grommet (1092) Glass Panel Air Tray (6888) Silicone Sealing Strip (4818) ‘AA’ Battery (12) Remote Control Hand Set Additional Fixings (A - 0411) Battery Holder 7mm Nut Spinner...
