Charlton & Jenrick PARAGON 2016 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
PARAGON 2016 & PARAGON 2016 Hi
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 2505 (ISS 13)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARAGON 2016 and is the answer not in the manual?

Questions and answers

Related Manuals for Charlton & Jenrick PARAGON 2016

Summary of Contents for Charlton & Jenrick PARAGON 2016

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions PARAGON 2016 & PARAGON 2016 Hi Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Important Information (user instructions) ..............5 EXTENDED FIVE YEAR PARTS SECTION TWO Introduction (user instructions) ..7 WARRANTY SECTION THREE Operation (user instructions) ... 7 SECTION FOUR Cleaning and Replacing Fuel Bed (user In order to validate your extended 5 years parts instructions) ..............

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: PARAGON 2016 Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Important Information (User Instructions)

    Like all appliances incorporating an aerated burner a low frequency noise may be heard, this may be more noticeable on the low setting. • It is advised that the PARAGON 2016 & 16 Hi is serviced annually this is more likely to provide trouble-free operation. www.charltonandjenrick.co.uk...
  • Page 6 The PARAGON 2016 fire does not normally require purpose-built ventilation in the United Kingdom. In the Republic of Ireland permanent ventilation must be provided in accordance with the regulations in force. The PARAGON 16Hi requires 11.25cm (1.8 ins. sq.) purpose-built permanent ventilation in the United Kingdom.

  • Page 7: Section Two Introduction (User Instructions)

    SECTION TWO Introduction (user instructions) • The PARAGON 2016 & 16 Hi, incorporate a single gas control, which selects ignition pilot, low and high settings. • The appliances incorporate a safety device in the form of an Oxygen Depletion System, which constantly monitors the oxygen in the room and will cause the fire to switch off if the oxygen level reduces.

  • Page 8: Section Four Cleaning And Replacing Fuel Bed (User Instructions)

    SECTION FOUR Cleaning and Replacing Fuel Bed (user instructions) Important: - Refer to the Health & Safety Notice located on page 5 of this booklet before cleaning or replacing any refractory material. Note: Soot deposits on the fuel bed, may be burnt off by operating the fire for approximately 1 hour on high. The fuel bed components are delicate and they should be handled with great care.
  • Page 9 Note the loose coals consist of :- 11off shaped as coal "A" 9 off shaped as coal "B" • Locate the LEFT HAND and RIGHT HAND FRONT COALS as shown so that they sit on the front rail and lean back against the BASE MATRIX.
  • Page 10 Separate the coal into the two size groups. • Lay first row of loose coal 3 off "B" and 2 off "A" coals as shown so that they bridge across • Lay second row of loose coal 3 off "A" and 2 off "B" coals as shown so that they rest on the high projections of the BASE MATRIX behind the previous row.
  • Page 11 • The finished coal arrangement should look as shown FUEL BED LAYOUT (PEBBLE OPTION) PEBBLE Fuel Bed Components • Base Matrix • L & R Front Pebbles In the following instructions the number • L & R Side Pebbles identification of the pebbles must be followed but •...
  • Page 12 PEBBLE LAYOUT • Ensure the BASE MATRIX is in position as shown located against the rear edge of the burner outlet. • Ensure the LEFT SIDE PEBBLE is located into the space between the BASE MATRIX and the left-hand side of the fire back with the marking "LH"...
  • Page 13 • Lay one row of pebbles at the front of the fire as shown. A second row (numbers positioned toward the rear of fire) is place between the base matrix and the rear of the chairbrick as shown. • Lay a rows of loose pebbles shown. •...
  • Page 14 FUEL BED LAYOUT (DRIFTWOOD OPTION) DRIFTWOOD FUEL BED COMPONENTS • Driftwood shapes numbered 1 to 10. • Three No.5 grey pebbles. • Left and right hand front matrices. • Left and right hand side pebbles. • Base matrix. • Ensure the LEFT SIDE PEBBLE is located into the space between the BASE MATRIX and the left-hand side of the fire back with the marking "LH"...
  • Page 15 • Place driftwood SHAPE No. 1 at the rear of the appliance as shown. The arrow marked on the base of the driftwood should point to the rear of the appliance. • Place driftwood SHAPE No. 2 in position as shown. The recess in the base should locate over shape no.1 and the arrow, marked on the base, should point towards the rear of the appliance.
  • Page 16 • Place driftwood SHAPE No. 5 in position as shown. The arrow, marked on the base, should point towards the rear of the appliance. • Place driftwood SHAPE No. 6 in position as shown. The arrow, marked on the base, should point towards the rear of the appliance.

  • Page 17: Section Five Replacement Parts (User Instructions)

    • Place driftwood SHAPE No. 9 in position as shown. The recess in the base should locate over shape no.6 and the short leg should be located behind the LH side pebble. The arrow, marked on the base, should point towards the left hand side of the appliance.

  • Page 18: Section Six Appliance Data (Installation Instructions)

    390 mm Depth (without fret) 210 mm Weight (boxed without fret) Gas type: G20 Natural G31 Propane Gas Pressure: 20 mbar 37mbar PARAGON 2016 PARAGON 2016Hi PARAGON 2016 Gas input: (Nat Gas) (Nat Gas) (PROPANE) Max (Gross) 7.0kW 9.55 kW 7.0kW...

  • Page 19: Section Seven Regulations And Warnings (Installation Instructions)

    • The PARAGON 2016 is for use ONLY with the GAS STATED ON THE DATA BADGE this may be G20 for Natural Gas or G31 for Propane Gas CHECK YOU HAVE THE CORRECT APPLIANCE FOR THE GAS YOU ARE USING. There is not a propane version of the Paragon 2016Hi.
  • Page 20 The installer must satify this point by carrying out a mandatory spillage test. In the Republic of Ireland permanent ventilation must comply with the rules in force. PARAGON 2016 Hi In the United Kingdom requires 11.25cm (1.8 ins. sq.) purpose-built permanent ventilation.

  • Page 21: Section Eight To Install The Appliance (Installation Instructions)

    SECTION EIGHT To Install the Appliance (installation instructions) Prior to any installation-taking place, the flue must be checked for satisfactory operation, a smoke test must be carried out to determine that all the smoke is drawn into the flue. The builders opening must be constructed of non-combustible material. Any permanent flue restriction must be removed and any variable dampers locked fully open or removed.
  • Page 22 CHECKING GAS SOUNDNESS Check for gas soundness in accordance with current code of practice. FUEL BED LAYOUT Important: - Refer to Health & Safety Notice (See Page 5) at the front of this booklet before proceeding. Lay fuel bed as shown in User’s Section of these instructions. CHECKING OPERATION OF FIRE Remove the screw from the pressure test point on the inlet elbow and fit pressure gauge.

  • Page 23: Section Nine Maintenance Instructions (Maintenance Instructions)

    SECTION NINE Maintenance Instructions (maintenance instructions) • Servicing should be carried out annually by a competent GAS SAFE-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance. • Before commencing any service or replacement of parts, turn off the main gas supply. After servicing check for gas soundness.
  • Page 24 REPLACEMENT OF OXY-PILOT ASSEMBLY NOTE: If the pilot assembly is replaced it must be replaced by an identical unit from the same manufacturer and replaced as a complete unit it is a NON SERVICABLE ITEM. 1. Repeat operations 1-4 for removal of gas control. 2.
  • Page 25 Register your appliance online today to active your warranty www.charltonandjenrick.co.uk LT2505 (ISS 13)

  • Page 26: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 27: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 28 0317 Product 0531 Product Serial No Serial No ID Label ID Label Prefix Prefix 0528 0532 Burner Tray / Box Assembly Burner Tray / Box Assembly Coal Set (2547) Pebble Set (2967) Coal Set (2459) Pebble Set (3066) Restrictor Elbow Restrictor Elbow Front Support Front Support...
