by
Charlton & Jenrick
Inset Electric Fire
INSTRUCTION MANUAL
Valor Range
MODEL: LEX2/LEX3/LEX4
Read and understand this entire owner's manual,
WARNING
including all safety information, before plugging in
or using this product. Failure to do so could result in
fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you
CAUTION
sell or give this product away, make sure this manual
accompanies this product.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Charlton & Jenrick Valor LEX2
Summary of Contents for Charlton & Jenrick Valor LEX2
- Page 1 Charlton & Jenrick Inset Electric Fire INSTRUCTION MANUAL Valor Range MODEL: LEX2/LEX3/LEX4 Read and understand this entire owner's manual, WARNING including all safety information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury. Keep this owner's manual for future reference.
- Page 3 Important Safety Information ………………………………………………… 2. Technical Specifications ……………………………………………………… Parts And Hardware …………………………………………………………… 4. Appliance Dimensions ………………………………………………………… 5. Installation Instructions ……………………………………………………… Operating Instructions ………………………………………………………… 12 Manual Control Panel …………………………………………………… 1 3 6b. Remote Control ………………………………………………………… 12 7. Maintenance …………………………………………………………………… 18 8. Service Parts list ………………………………………………………………… 19...
- Page 4 1.1 Read all instructions before using this heater! 1.2 This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater and keep them away from the sides and rear.
- Page 5 1.11 Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons. 1.12 ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with an extension cord or relocatable power tap (outlet/power strip).
- Page 6 before unplugging it from the outlet. 1.23 ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace. 1.24 NEVER leave this heater unattended. ALWAYS unplug this heater when not in use. 1.25 ALWAYS store this heater in a dry location.
- Page 7 Model No. : LEX2/LEX3/LEX4 Supply Voltage: AC 120V 60Hz Maximum power consumption: 1500W Power for flame and fuel bed effect: Model LEX2 LEX3 LEX4 Power 40.1W 48.1W 50.1W Power for mood light: DC12V 9W 0.75A Heat Output: Nominal heat output (Pnom): 1500W Minimum heat output (indicative) (Pmin): 750W Maximum continuous heat output (Pmax): 1500W Auxiliary Electricity Consumption:...
- Page 8 Lower Brackets (2pcs) ST4*40 Screw (4pcs) Wall Plug (18pcs) (To be used when the wall hanging bracket(I) is used) Wall hanging bracket is attached on firebox (1pc) Edging Strips (2pcs) Edging Strips (2pcs) Remove from the appliance if you are not fixing to wall Suction Cup LEX2 (1pc) Black Ember Glass...
-
Page 9: Preparation Before Installation
Unit: Inch Model 49 3/16’’ 50 3/8’’ 15 13/16’’ 22 1/16’’ 8 7/16’’ 11 13/16’’ 9/16’ 3 1/8’’ LEX2 ’ 59 1/16’’ 60 1/4’’ 15 13/16’ 22 1/16’’ 8 7/16’’ 11 13/16’’ 9/16’ 3 1/8’’ LEX3 ’ 70 7/8’’ 72 1/16’’ 15 13/16’’... - Page 10 The interface of the mood light cable is on the top of the appliance, near the position of the power cord. Please also check the function after connecting the mood light. N o t e : compatible mood light devices are available from Valor Electric Fire and their dealers.
- Page 11 Front view (only the front window is visible) When you unpack the appliance, you will notice that the side panels have been fixed on the appliance, which makes the appliance visible on only one front side. Front and one side view (the front and one of the side windows are visible) Front and two sides view (the front and both sides windows are visible) Remove the side panels from the ends you want to view to enable dual or triple aspect as required .Then fix the edging strips using the screws taken from the...
- Page 12 5.2 Installing the Appliance The following is only given as a general guide because it can be installed in so many ways. Provided you ensure electric connections are safely made in accordance with the codes, various materials can be used for the framework and cladding.
- Page 13 Cladding the framework. Note: Hard surfaces can amplify sound. ⚫ Consider adding some underlay or similar to the inside surface of the cladding. Wall mounted installation Remove the wall bracket from the rear of the appliance, and place it ⚫ horizontally against the wall.
- Page 14 Mount the appliance carefully on the hooks of the wall bracket, secure the ⚫ appliance to the wall bracket with the screws provided one into each end. Use four screws to fix the bottom brackets to the corresponding holes on ⚫...
-
Page 15: Preparation Before Use
PREPARATION BEFORE USE 6.1 The appliance can be operated by both remote control and the manual controls on the appliance. NOTE: To use both remote and manual functions, the manual on/off switch must be in 'ON' position. In order to prevent the product becoming too hot, there is 10s delay when turning on the heater and a 10s delay when turning off the heater fan. - Page 16 6a.4 FUEL BED: Press button FUEL BED to select 14 kinds of fuel bed effects and OFF setting. If the fuel bed was turned off by pressing button LIGHTS ON/OFF and the fuel bed was not at OFF, the fuel bed effect will be memorized.
- Page 17 Before Day/Time Set Up 6b.1 The screen shown to the right is when the remote controls is in standby mode . Turn on/off 6b.2 Press to turn on/off the appliance. Flame Effect After Day/Time Set Up 6b.3 Press to enter the flame effect adjustment screen.
- Page 18 NOTE: It is normal for the fan heater to stop running for periods of time. This happens because the room temperature is at or above the temperature set on the remote control. The heater indicator will be turned off after 10s if you have the flame ON.
- Page 19 6b.20 Press until shows at the upper right corner of the screen, then enter the daily timer heating mode. 6b.21 Hold the button for 6 seconds to enter the daily timer setting. Up to 3 heating start time periods can be set. Press ' ' or ' ' to choose hour or minute,...
- Page 20 6b.27 Hold button for 6 seconds to enter the weekly timer setting. Press ' ' or ' ' to move the cursor (a flashing ⚫ underline), press the button in the corresponding week position to select (the character is highlighted) or cancel (the character is displayed normally) the current setting.
- Page 21 Window Open Detection 6b.34 When the transmitter detects a rapid drop in room temperature, it will be judged as a window open, the warning icon will be displayed, and the heater will be turned off automatically. 6b.35 After the indoor temperature has risen or a manual override of the warning (by operating remote control) has been done, the fire will return to normal working state.
- Page 22 6b.42 Different types of batteries or new and used batteries are not to be mixed. 6b.43 Batteries are to be inserted with the correct polarity. If the appliance is to be stored unused for a long period, the batteries 6b.44 should be removed.
- Page 23 Cleaning the Fireplace Cleaning or polishing products are not recommended. Fingerprints or other marks on the front glass panel can be removed by a piece of soft, damp, lint-free cloth with a good quality household glass cleaner. The front glass panel should always be completely dried with a clean, lint- free cloth or paper towel.
- Page 26 RD/20AWG...
- Page 28 Distributed in Canada and USA exclusively by Valor Fireplaces – Head Office: #190, 2255 Dollarton Hwy, North Vancouver, BC V7H 3B1 Phone: 604.984.3496 Email: info@valorfireplaces.com Manufactured by Charlton & Jenrick Ltd Unit D, Stafford Park 2, Telford, Shropshire, TF3 3AR, UK. Tel: ++ 44 1952 200 444 Fax ++ 44 1952 200 480 w: www.charltonandjenrick.co.uk e: sales@charltonandjenrick.co.uk...
