Rikon Power Tools 50-114 Operator's Manual page 17

8. Replace and tighten the two screws (C, D) and push the tension lever (E) in to
apply tension onto the belt.
9. Replace the belt sander support rod (A) back onto the machine.
10. Push the belt by hand and check if the sanding belt tends to run to one side or
the other of the two drums. If the belt does not track properly in the center of the
drums, it will need to be adjusted to do so. See page 13 for this procedure.
11. Re-adjust and fine-tune the belt tracking with the tracking knob (I), as necessary.
12. Move the belt frame to your desired work position, keep it horizontal or adjust
it up to vertical, and tighten the inner hex screw (B) to secure the frame in position.
LUBRICATION
Ball bearings are grease packed at the factory and require no further lubrication.
Use a paste wax to ensure smooth operation on all moving table parts. Do not use any
lubrication on the belt plate as this might end up on the wheels, causing them to slip.
the outlet prior to adjusting or maintaining the sander. DO NOT attempt to repair
or maintain the electrical components of the motor. Take the sander to a qualified
service technician for this type of maintenance.
MAINTENANCE REQUIRED
1. Check the power cord for any damage.
2. Check sanding belts and discs for damage or wear.
3. Check all guards and hardware to make sure they are secure. Before each use.
4. Check all moving parts for alignment and binding issues.
4. Dress/Clean sanding surfaces for best abrasive action.
5. Replace sanding belts or discs when worn or damaged.
6. Clean/vacuum dust from the motor housing all other machine parts.
7. Keep tables free of sap, dirt etc. Apply paste wax or silicon spray.
Service beyond recommended maintenance on these tools should only be
performed by an authorized, qualified technician.
debris from blowing into eyes.
MAINTENANCE
Turn the power switch "OFF" and disconnect the plug from
If blowing sawdust, wear proper eye protection to prevent
FREQUENCY
Before each use.
Before each use.
Before each use.
As needed.
As needed.
As needed.
As needed.
Page 17
