7. Technical Parameters

7.1 Basic parameters

SmartMotion Router
Temperature range
Cold start
Humidity
Altitude
Degree of protection
Supply voltage
Battery for RTC
Consumption
Dimensions
Weight
Antenna connectors
User interface
Operating -20 C to +60 C
Storage -40 C to +85 C
-15 C Data transfers via mobile network are available
immediately
-20 C Data transfers via mobile network are available
approximately in five minutes after the start of
the router. Everything else is functional imme-
diately.
Operating 0 to 95 % relative humidity non condensing
Storage 0 to 95 % relative humidity non condensing
Operating 2000 m / 70 kPa
IP30
10 to 60 V DC
CR1225
Idle 2.5 W
Average 4 W
Peak 11 W
Sleep mode 10 mW
55 x 97 x 125 mm (DIN 35 mm, EN 60715)
Metal box approximately 420 g (depends on the version)
5x SMA – 50
1x R-SMA – 50 Ohm (only for versions with
WiFi module!)
2x ETH Ethernet (10/100 Mbps)
USB USB 2.0
I/O 6-pin panel socket
Micro SD SDHC, SDXC
Table 18: Basic parameters
30
SmartMotion ST355
