7.6 Technical parameters of WiFi

WiFi
Antenna connector
Supported WiFi band
Standards
2.4 GHz supported channels
5 GHz supported channels
Type of device
Max. clients in AP mode
WiFi TX Output Power
WiFi RX Sensitivity

7.7 Technical parameters of I/O port

Characteristics of inputs:

logical 0 / 1
log. 1 max
log. 0 min
log. 0 type
log. 0 max
The binary input status in the Shell is returned via io get bin0 or io get bin1.
Binary output parameters:
– 60 V AC / 300 mA
– 60 V DC / 300 mA
The number of supported channels depends on selected Country Code.
R-SMA – 50
2.4 GHz, 5 Ghz
802.11a, 802.11b, 802.11g, 802.11n
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 100, 104, 108,
112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157,
161, 165
Access point, station
10
17,3 dBm
-96,3 dBm
Table 24: Technical parameters of WiFi
Voltage Current
3 V 0.4 mA
5 V 0.7 mA
12 V 2 mA
60 V 7 mA
Table 25: Characteristics of inputs
36
SmartMotion ST355
Web interface status
Off
On
On
On
