IR Remote Control

Model: KDRMSWPROK (uses CR2025 battery)
Please note that some remote buttons may have no functionality
Discreet
Input Select
Auto Sensing
Enable
Device Select
(Used for
addressing
mode)
Auto Sensing
See Auto Sensing section of Connections, LEDs, Buttons, Slide Switches, Rotaries section for more
information.
TCP/IP & RS-232 Commands
KD-Pro2x1X/KD-Pro4x1X allows control over serial interface for bi-directional communication.
Use pins 4, 5, and 6 for RS-232 communication
Serial interface may also be accessed using a TCP/IP connection
Default IP address is 192.168.1.239, with default port 23
›
Incremental
Input Select
Reserved
15
