Key Features
HDMI Switching: 2/4 HDMI sources to 1 HDMI output/display
›
Ultra HD/4K: Supports up to 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to
›
18Gbps bandwidth)
HDCP Licensing: Fully licensed and compatible with HDCP 2.2
›
HDR10 and Dolby Vision: More life-like images through a greater range of luminance levels
›
Audio De-embedding: Audio of the selected HDMI input is de-embedded at the analog
›
(3.5mm stereo & L/R balanced/unbalanced) and digital (optical & PCM) connectors.
Key Digital App Ready: Scan & detect population for pre-built GUI and TCP/IP control via
®
›
Key Digital App
®
KD-AMP220 Control Mode: Command forward to KD-AMP220 for an all-in-one user-friendly
›
control UI of video switching, audio and speech enforcement
Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected
›
source via hot plug detection voltage when enabled
Resolution Support: Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) up to
›
4096x2160p.
Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
›
Full Buffer System
›
source & display, and EDID Control handshake
EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in
›
addition to native EDID data copied from the output/display 1
Lossless Compressed Digital Audio: Dolby
›
and Dolby Atmos
®
CEC Pass-thru: From connected display to selected HDMI source
›
Control: Front panel button, serial IR, optical IR, RS-232, trigger in, and TCP/IP controllable
›
Control System Support: Key Digital
›
all IR, RS-232, and TCP/IP supported control systems via open API.
Included Accessories
Power Supply: KD-PS12W5VC 5V/2.4A DC power jack, screw-in type
›
IR Remote Control: KD-RMSWPROK
›
6ft USB 2.0 (Micro) to USB A cable
›
Rack Ears: 1x long, 1x short rack ear for mounting in full-width rack
›
2x 6-pin terminal blocks for control, analog audio
›
: Manages TMDS re-clocking / signal re-generation, HDCP authentication to
™
App ready. Compass Control
®
TrueHD, Dolby Digital Plus, DTS-HD Master Audio
® ®
Pro ready. Fully controllable by
®
