Summary of Contents for Key Digital KD-SW4x1
- Page 1 Model KD-SW4x1 HD Fl a sh 4 4 to 1 Component & RGBHV A/V Switcher OPERATING INSTRUCTIONS Featuring 4 Inputs of Component (YPrPb) Video and Audio (Analog L & R, Digital PCM) or up to 4 Inputs Video (R,G,B,H,V) and Audio (Digital PCM)
- Page 2 / Model KD-SW4x1...
- Page 3 ® HD Flash 4 (Model KD-SW4x1) is a versatile multi-input audio/video switcher for connecting video and audio sources to a TV video display or monitor. It is the ideal solu- tion when your TV, monitor, or receiver does not have enough video and audio inputs. It fea- tures 4 independent component video/audio inputs with one component video/audio output.
- Page 4 Page 4 of 12 HD Flash 4 Operating Instructions Using the Flash 4 , you can switch the virtaully any A/V input device • DVD players • Electronic game boxes • Cable TV, satellite, and terrestrial DTV set-top receivers • Digital video recorders (DVRs) •...
- Page 5 Page 5 of 12 HD Flash 4 Operating Instructions Warning - do not connect a digital audio output signal to analog inputs on your TV or moni- tor! It may damage your speakers! The Flash 4 is wired with RCA female connectors. Switching S-Video will require special S-Video to RCA breakout cables for inputs and outputs.
- Page 6 Page 6 of 12 HD Flash 4 Operating Instructions Connecting a DVD player or game console with component YPrPb (three-wire) video outputs to the Flash 4 Connect the three-wire green, red, and blue (YPrPb) jacks on your DVD player or other A/V component to the green, red, and blue (YPrPb) jacks on the Flash 4 .
- Page 7 Page 7 of 12 HD Flash 4 Operating Instructions Connecting devices with S-Video or composite video outputs to the Flash 4 S-Video connection: You will need an S-Video to RCA breakout cable to connect your satel- lite receiver, DVR, or S-VHS VCR to the Flash 4 (A S-Video to composite video adapter is also available with a single output connection.
- Page 8 R3 Optional Mode of Operation. The Flash 4 may be located where other Key Digital Flash 4 shares some remote commands with other Key Digital press the R1 button before entering a remote command. If you do not have any other Key Digital ®...
-
Page 9: Technical Specifications
Page 9 of 12 HD Flash 4 Operating Instructions RS232 Commands Switching Command CCx (x=video/audio input [1..4]) Status Command Since both commands are of a defined length, no terminator is required Both commands give the following respose. Uuyn y – currently selected video/audio input [1..4] n –... - Page 10 Page 10 of 12 HD Flash 4 Operating Instructions Compatible Video Signals: All standard analog video signal formats that use 50 Hz or 60 Hz refresh are accepted, including 480i, 480p, 576i, 576p, 540p/1080i, and 720p Bandwidth: -3 dB @ 300 MHz, linear phase passband Video Gain: Unity gain for Y, Pr, Pb, channels Mechanical:...
-
Page 11: How To Contact Key Digital
HOW TO CONTACT KEY DIGITAL Repairs and Warranty Service: Should your HD Flash 4 require warranty service, please contact Key Digital Returned Materials Authorization (RMA) number Please contact us at either: 1-914-667-9700 email tech@keydigital.com Technical Support: For technical questions about using our products, please contact us at either: 1-914-667-9700 or Toll-free 1-888-258-2028 email tech@keydigital.com... - Page 12 HD Flash 4 Operating Instructions www.keydigital.com Phone 914-667-9700 Key Digital , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging is important. Our products are used by professional broadcasters, corporations, cus- tom installers, home theater retailers, and consumers.
