Key Digital KD-Pro4x1X Operating Instructions Manual page 18

16
Connection Protocol:
Baud Rate = 57,600 bits per second
»
Data Bits = 8
»
Stop Bits = 1
»
Notes:
›
Commands are not case-sensitive
»
Spaces are shown for clarity; commands should NOT have any spaces
»
After a new command is received, a prompt should be sent back
»
KD-Pro2x1X Help Command (H). Returns entire API in readable format:
-------------------------------------------------------------------------
--
-------------------------------------------------------------------------
-- KD-Pro2x1X
--
-- Azz : All Commands may have Prefix System Address zz=[01-99] --
-- H : Help
-- PF : Power Off
-- PN : Power ON
-- STA : Show Global System Status
--
-- Video Output Setup Commands: yy = [01-02,U,D]
-- SPO SI yy
-- SPO01 SI yy
-- SPO ON/OFF
-- SPO DBG ON/OFF : Set Output Debug Mode ON/OFF
--
-- Audio Output Setup Commands: [E=Enable, D=Disable]
-- SPO AA E/D : Enable/Disable External Analog Audio Output
-- SPO DA E/D : Enable/Disable External Optical Audio Output
-- SPO AMP ON/OFF : Set AMP220 Control Mode ON/OFF
-- SPO MIC ON/OFF : Set AMP220 MIC Mode ON/OFF
--
-- Input/Output/Device Naming Commands (Max. 16 Chars)
-- SPI xx WN cccccccccccccccc : Write Input xx Name
-- SPI xx RN
-- SPO xx WN cccccccccccccccc : Write Output xx Name
-- SPO xx RN
-- SPC WN cccccccccccccccc
-- SPC RN
--
-- Network Setup, ( xxx=[000-255], zzzz=[0001~9999] )
-- SPCETIPA xxx.xxx.xxx.xxx : Set Host IP Address to xxx.xxx.xxx.xxx
-- SPCETIPM xxx.xxx.xxx.xxx : Set Net Mask to xxx.xxx.xxx.xxx
-- SPCETIPR xxx.xxx.xxx.xxx : Set Route IP Address to xxx.xxx.xxx.xxx
-- SPCETIPP zzzz
-- SPCETIPB
--
-- System Address Setup Command: xx = [00-99], 00 = Single
-- SPC Axx : Set System Address to xx
--
-- System Control Setup Commands:
-- SPC AS x
-- SPC FB E/D
-- SPC RSB z : Set RS232 Baud Rate to z bps, z=[0-4]
Key Digital Systems HELP
System Address = 00
: Set Output to Video Input yy
: Set Output to Video Input yy
: Set Output ON/OFF
: Read Input xx Name
: Read Output xx Name
: Write Device Name
: Read Device Name
: Set TCP/IP Port to zzzz
: Apply New Network Config
: Set Auto Sense Mode x = [0:OFF,1=AUTO,2=FORCED ON]--
: Enable/Disable Front Panel Buttons
Parity = Non
»
Flow Control = None
»
Carriage Return: Required at end of string
»
F/W Version : 1.00
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
