12
Forced HPD Troubleshooting Tool
When ON, Hot Plug Detection voltage is fixed on to the connected display
»
Standard HPD behavior when set to OFF position
»
Auto Sensing
ON » Unit will automatically select a newly detected active source. If current source is disconnected
»
or becomes inactive, auto sensing will sequentially advance to an active input/source
OFF » Unit is in normal mode and regular switching functionality will occur
»
IF Auto sensing has been set via any method other than the front toggle switch, it will be
»
automatically disabled when the KD-Pro2x1X/4x1X is manually controlled by the front panel button, IR,
RS-232, TCP/IP, or USB control. If fixed Auto Sensing is required, please set via the front toggle switch
IR Sensor
Used to collect line-of-sight IR from remote control
»
Receives signals from a 90° angle at up to 30ft away.
»
Mount an IR emitter from Compass Control Pro or to control by another professional control system
»
