MVI71-DNPSNET ♦ PLC Platform
Distributed Network Protocol Interface Module
100 Mbytes of free hard disk space (or more based on application
requirements)
256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color
1024 × 768 recommended)
CD-ROM drive
3.5 inch floppy disk drive
HyperTerminal or other terminal emulator program capable of file transfers
using Zmodem protocol.
1.2

Package Contents

The following components are included with your MVI71-DNPSNET module, and
are all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name
1 MVI71-
DNPSNET
Module
1 Cable
3 Cable
2 Adapter
1 ProSoft
Solutions CD
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
Page 10 of 100
Part Number Part Description
MVI71-DNPSNET Distributed Network Protocol Interface Module
Cable #15, RS232 For RS232 Connection to the CFG Port
Null Modem
Cable #14, RJ45 to For DB9 Connection to Module's Port
DB9 Male Adapter
cable
1454-9F Two Adapters, DB9 Female to Screw Terminal. For
RS422 or RS485 Connections to Port 1 and 2 of the
Module
Contains sample programs, utilities and
documentation for the MVI71-DNPSNET module.
Start Here
ProSoft Technology, Inc.
September 22, 2008
