MVI71-DNPSNET ♦ PLC Platform
Distributed Network Protocol Interface Module
Word Variable Name
12 Block number error
13 DNP Slave Port total
number of message
frames received by
slave
14 DNP Slave Port total
number of response
message frames sent
from slave
15 DNP Slave Port total
number of message
frames seen by slave
DNP Slave
16
synchronization error
count (Physical Layer
Error)
17 DNP Slave overrun error
count (Physical Layer
Error)
18 DNP Slave length error
count (Physical Layer
Error)
19 DNP Slave bad CRC
error (Data Link Layer
Error)
20 DNP Slave user data
overflow error (Transport
Layer Error)
DNP Slave sequence
21
error (Transport Layer
Error)
22 DNP Slave address
error
(Transport Layer Error)
23 DNP Slave Binary Input
Event count
24 DNP Slave Binary Input
Event count in buffer
25 DNP Slave Analog Input
Event count
26 DNP Slave Analog Input
Event count in buffer
27 DNP Slave bad function
code error (Application
Layer Error)
28 DNP Slave object
unknown error
(Application Layer Error)
Page 30 of 100
Description
Number of BTW requests that resulted in an incorrect BTW
identification code.
This value represents the total number of message frames
that have matched this slaves address on this port. This
count includes message frames which the slave may or may
not be able to parse and respond.
This value represents the number of good (non-error)
responses that the slave has sent to the master on this port.
The presumption is that if the slave is responding, the
message was good. Note: This is a frame count.
This value represents the total number of message frames
received by the slave, regardless of the slave address.
This value counts the number of times a sync error occurs.
The error occurs when extra bytes are received before the
start bytes (0x05 and 0x64) are received.
This value counts the number of times the overrun error
occurs. This error occurs when the mainline Data Link Layer
routine cannot read the data received on the communication
port before it is overwritten.
This value counts the number of times an invalid length byte
is received. If the length of the message does not match the
length value in the message, this error occurs.
This value counts the number of times a bad CRC value is
received in a message.
This value counts the number of times the application layer
receives a message fragment buffer which is too small.
This value counts the number of times the sequence
numbers of multi-frame request fragments do not increment
correctly.
This value counts the number of times the source addresses
contained in a multi-frame request fragments do not match.
This value contains the total number of binary input events
which have occurred.
This value represents the number of binary input events
which are waiting to be sent to the master.
This value contains the total number of analog input events
which have occurred.
This value represents the number of analog input events
which are waiting to be sent to the master.
This value counts the number of times a bad function code
for a selected object/variation is received by the slave
device.
This value counts the number of times a request for an
unsupported object is received by the slave device.
Ladder Logic
