Start Here
1.3
Setting Jumpers
Note: The Setup Jumper acts as "write protection" for the module's flash memory. In "write
protected" mode, the Setup pins are not connected, and the module's firmware cannot be
overwritten. Do not jumper the Setup pins together unless you are directed to do so by ProSoft
Technical Support.
ProSoft Technology, Inc.
September 22, 2008
MVI71-DNPSNET ♦ PLC Platform
Distributed Network Protocol Interface Module
Page 11 of 100
