CELLULAR INFORMATION
Antenna Specifications
Category
Frequency Range
Impedance
VSWR
Peak Radiated Gain
Radiation
Polarization
Connector
20
Description
2.4000 to 2.4835 GHz
50 Ohms
VSWR should not exceed 2.0:1 at any point across the bands of operation
2.3 dBi on azimuth plane
Omni-directional
Linear Vertical
RP-SMA(M)
®
MultiConnect
rCell 100 MTR-H6 Hardware Guide
