The Programming Level defines the range of programming
tasks a User is allowed to perform. The higher the Level, the
more programming tasks the User is allowed (with Master
allowing ALL tasks).
Note: Since the Programming Level is closely associated
with the type of User and their abilities, a User who holds a
certain Programming Level is sometimes referred to by their
"User Type".
For example, PDL series locks can hold up to 5000 Users in
its programming memory, and each User is associated with a
User Number (see definition of "User Number" in the previous
"Terminology" section) and therefore a specific Programming
Level, as follows:
Master: Always associated with User number 1. Is al-
ways enabled and can program all functions. (Abbreviated
as Programming Level = M).
Installer: Always associated with Users 2 and 3. Can pro-
gram all functions except changing the Master Code.
(Abbreviated as Programming Level = 4).
Manager: Always associated with Users 4, 5, and 6. Can
program all functions except functions relating to lock
configuration. (Abbreviated as Programming Level = 3).
Users added will default to a Group Association and a Programming Level ability as follows:
USER TYPE
Master Code
Installer Codes
Manager Codes
Supervisor Codes
(Reserved)
Basic User Codes
Basic User Codes Group 1
Basic User Codes Group 2
Basic User Codes Group 3
Basic User Codes Group 4
Basic User Codes
Quick Enable User 300 Code
(Reserved--see page 8)
Guard Tour Code*
Service Code
Basic User Codes
*This code is a Non-Pass code and therefore does not allow passage through the door.

Programming Levels

Lock Defaults for PDL6200 & PDL8200
USER NUMBER
1
2 & 3
4 - 6
7 - 9
10 - 11
12 - 50
51 - 100
101 - 150
151 - 200
201 - 250
251 - 296
297
298
299
300
301-5000
Supervisor: Always associated with Users 7, 8 and 9.
Can only program functions relating to day to day
operation. (Abbreviated as Programming Level = 2).
Print Only Users: In previous versions of the ALARM
LOCK Trilogy series locks, Print Only Users were always
associated with User Numbers 10 & 11 and were restricted
to printing event logs only, using a special AL-IR1
handheld printer. With the Networx series wireless lock no
longer requiring (or allowing) the use of this AL-IR1 printer,
Print Only Users are also no longer required. Although the
attributes of User Numbers 10 and 11 have been changed
to replicate those of "Basic Users", to ensure compatibility
with previous lock model versions the use of User Num-
bers 10 and 11 with the PDL6200 and/or PDL8200 lock is
not recommended.
Basic Users: Always associated with User number 12 and
higher (except 297-300). No programming ability allowed.
Programming Levels are hierarchical--higher levels are al-
lowed to do anything the levels below them can do. For exam-
ple, if you are a Manager, you are allowed to do anything that
Supervisors and Basic Users can do in addition to those tasks
allowed for Managers (Level 3).
GROUP DEFAULT
ASSOCIATION
-
none
none
none
none
none
1
2
3
4
none
none
none
none
none
none
MINIMUM PROGRAM
LEVEL (See page 7)
M
4
3
2
--
none
none
none
none
none
none
none
none
none
none
none
