Alarm Lock DK3000 Brochure

Trilogy ® T2 standalone digital lock
DL2700 Series – Our Most Popular Cylindrical Lock
• Grade 1 Durability – BHMA Grade 1 Lockset with
rugged clutch plus, vandal-proof all metal keypad.
• All IC Core models include a large format key in
knob cylinder, supporting Best, Falcon, Arrow and
KSP. Other interchangeable core preps available:
Yale, Medeco, Sargent, Corbin/Russwin, Schlage
• Multi-level user capability: Master, manager,
emergency, service codes
• Up to 15 different user codes (3-5 digits)
• Individual, group or total user lockout codes
• Non-handed for easy installation and versatility
• 2-wire remote override or key bypass capability
• Passage mode
• Visual and audible entry indicators
• "WP" weatherproof models -31°F to
+151°F (-35°C to +66°F)
• Retrofits knobsets using slightly
modified ANSI A115 Series
Prep
• Battery operated; uses 5 AA
batteries
Trilogy ® economical
audit trail lock
DL2800 Cylindrical Lock
• Rugged clutch mechanism
ensures long life & durability
• 150 scheduled events
• 200 user codes: Master, manager,
supervisor and basic users. Also one-
time service code (3-6 digits)
• 1000 event log
• "WP" weatherproof -31° to +151°F (-35° to
+66°C)
• Timed entry allowance from 5-15 seconds
• Temporary Keypad Lockout after 3 unsuccessful
code-entry attempts
• Audit trail with time/date stamp for a printable
record of all electronic activity
• Real time clock; 150 event schedule
• Relay may be programmed to energize when one or
more selected events occur Battery operated; uses
5 AA batteries
PC Programming Windows-based Curved Regal
port/audit trail
Trilogy software handle option
access DL-WINDOWS on all Trilogys.
Trilogy ® T3 advanced digital lock with audit trail
DL3000 Series Audit Trail Cylindrical Lock
Similar features to DL2700 and DL2800 Series, but with:
• 300 user codes: Master, manager, supervisor &
basic users
• 4 programming levels, 4 user groups
• 3, 4, 5 or 6 digit codes, one-time service code
• 1600 event audit trail with time/date stamp for a
printable record of all electronic activity
• Real time clock
• 150 scheduled events (lock/unlock, code disable/
enable)
• 4 Quick schedules of the most common routines
• "WP" weatherproof models -31° to +151°F
Trilogy privacy/residency
®
locks
DL4100 Cylindrical Special
Applications PIN Lock
PDL4100 PIN/Prox
Version
Similar to the DL3000, but
with
• 2000 user codes; 500
scheduled events; 40,000
audit trail
< plus >
• Programmable Privacy
feature: Push button
on back of door to
temporarily lock-out
keypad codes
• Occupied and multi-status
LED indicator, flashes when Privacy
session is active.
• Programmable Residency
feature allows users to close
door remaining unlocked (until
manually relocked with prox
device).
Ideal anywhere key-free,
temporary privacy is
required:
• Single-occupancy restrooms
• Dressing rooms
• Hospital on-call/sleeping rooms
• Darkrooms
• Executive offices
• Confidential file rooms
Mortise and Prox Mortise models
Prox/mortise -
of above also available, DL4500 &
Privacy Lock
PDL4500.
PDL4500
Trilogy prox lock with audit trail
PDL3000 PIN/Prox Cylindrical
• Accepts HID prox cards and keyfobs
• 2000 user codes: Master; manager;
supervisor; basic users (3-6 digits)
• Users are individually programmed
to use a card only, code only, or both
card and code
• Cards can be added via
the lock, card enroller
(AL-PRE) or PC software
• Batch enroll feature allows many cards
to be quickly added withoutPC
• 500 event scheduling
• Program data transferred to lock
via AL-PCI (PC interface) or AL-
DTM2 (data transfer module)
• Up to 40,000 event audit trail
with printed time/date stamped
log of all electronic activity can be extracted from
lock using the AL-IR1 (infrared printer), the AL-DTM2
or AL-PCI
• Quick Passage mode enabled with an authorized
user code and function code (does not require lock
to be in program mode)
Trilogy PL3000 Prox (keypad-less) version of above,
for superior vandal resistance.
Weatherproof 12V/24V digital access keypads
Trilogy DK3000
• Ideal for use with 12V or 24V (AC
or DC) electric door strikes, mag
lock PM1200, PM600 or Alarm Lock
Remote Release Mag Lock Kit.
• Easiest installation in minutes: Wall
mount or single gang box
• Timed egress input allows door to
open for 5, 10 or 15 seconds
• 2 High-current rated 8A relays for entry, alarm zone
shunting or lock release by real-time schedule
• Weatherproof, rugged all-metal 12-button keypad
• 2,000 users, master, manager, supervisor and basic
• 100% Fingertip or PC Programmable with familiar
Trilogy software
• 40,000 Event Audit Trail: Query by PC or Handheld
Printer or DTM2 Module
Digital access keypad with prox reader
Trilogy PDK3000
• Same features as DK3000 above, plus
built-in proximity reader
• Accepts HID cards and keyfobs as well
as digital PIN codes
Trilogy mortise locks all the features
of the T3 DL3000 in a high security
mortise lock
DL3500 Series Mortise PIN Lock
Similar in functionality to T3 DL3000 Series,
plus:
• 300 User codes: Master, manager,
supervisor & basic users
• Weatherproof -31°F to +151°F (-35°C to
+66°C)
• Fingertip or Windows PC-programmable
• Up to 500 scheduled
events and holiday
schedules
• 40,000 event audit trail
• Classroom or deadbolt versions and left or
right handing (field reversible.)
• 1 / " – 1 / " (3.5 cm) mortise cylinder supplied
1 1
4 2
Trilogy prox mortise lock (not shown)
PDL3500 Series
• As above, but with prox capabilities and 2000 users
TrilogyExit adds audit trail to panic exit bars
OUTSIDE: Rugged, field-proven
Trilogy PIN/prox lock. (rim cyl.)
INSIDE: Existing panic exit device –
Most major brands supported
Trilogy Exit ETPDL (with prox)
Eliminates physically "dogging-down" exits by
•
automatically locking/unlocking them on daily/weekly
schedule
Fingertip and/or Windows programmable
•
2000 user codes: Master, manager, supervisor and users
•
40,000 audit trail events
•
Up to 500 lock/unlock schedules (with time zone support)
•
Non-handed; field reversible
•
• Supports most manufacturers of RIM and RIM IC
cylinders
Battery operated; uses 5 AA batteries
•
Also available in keypad PIN model
- ETDL
Side view
