PICMG 1.3 LGA 775 Intel® Core 2 Duo™ Pentium® D/4 CPU
Card with VGA, Dual PCIe GbE and SATAII
Quick Installation Guide

Package Contents

PCIE-9450 package includes the following items:
1 x PCIE-9450 single board computer
1 x mini jumper pack
1 x ATA 66/100 flat cable
4 x SATA cable
2 x SATA power cable
1 x KB/MS Y cable
1 x Dual RS-232 cable
1 x USB cable
1 x Utility CD
1 x QIG (quick installation guide)
©2006 Copyright by IEI Technology corp.
PCIE-9450
Version 2.0
Jun 01, 2007
All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCIE-9450 and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology PCIE-9450

  • Page 1 PCIE-9450 Quick Installation Guide Version 2.0 Jun 01, 2007 Package Contents PCIE-9450 package includes the following items: 1 x PCIE-9450 single board computer 1 x mini jumper pack 1 x ATA 66/100 flat cable 4 x SATA cable 2 x SATA power cable...
  • Page 2 Specifications CPU: LGA 775 Intel® Core 2 Duo / Pentium® D/4/Celeron® D with 533/800/1066 MHz FSB System Chipset: Intel® 945G+ ICH7R BIOS: AMI Flash BIOS SMIBIOS(DMI) compliant Console redirection function support PXE(Pre-Boot Execution Environment) support USB booting support System memory: 4 x 240-Pin dual channel DDRII 400/533/667 MHz up to 4GB Ethernet: Dual Broadcom BCM5787 PCIe GbE chipsets I/O Interface...
  • Page 3 Dimension:388mm x 122mm Weight: GW: 1.2 Kg Ordering Information PCIE-9450-R20 PICMG 1.3 LGA 775 533/800/1066 MHz FSB CPU Card with VGA, PCIe GbE, SATA II and USB2.0 AC-KIT08R-R10: 5.1Channel AC’97 Audio kit with Realtek ALC655 AC-KIT883HD-R10: 7.1Channel HD Audio kit with Realtek ALC883...
  • Page 4 FAN1: Fan Connector CPU12V1 Power connector Pin Description Pin Description Pin Description +12V +12V +12V Sensor IR1: IrDA connector DIO1: Digital I/O Pin Description Pin Description Pin Description PWR(+5V) XOUT0 XOUT1 XOUT2 XOUT3 XIN0 XIN1 XIN2 XIN3 CN2: KB SDVO1:3Pin SDVO Control Pin Description Signal Pin Header KB_CLK...
  • Page 5 AUDIO1: Audio Connector for Audio Module Description Description AC_SYNC AC_CLK AC_SDOUT PC_BEEP AC_SDIN AC_RST- PWR (+5V) PWR (+12V) CPU_FAN: Fan Connector Description +12V Sensor Control LPT1:26Pin Parallel Port Connector Pin Description Description STB- AFD- PDR0 ERR- PDR1 INITP- PDR2 SLIN- PDR3 PDR4 PDR5...
  • Page 6 FDD1:34Pin FDD Connector Pin Description Description REDWC- INDEX- MOTEA- DRVSA- DIR- STEP- WDATA- WGATE- TRK0- WPT- RDATA- SIDE- DSKCHG- IDE1:40Pin IDE Connector Description Description IDERST- PD10 PD11 PD12 PD13 PD14 PD15 PDREQ PDIOW- PDIOR- PDIORDY PDACK- IDEIRQ PDA1 P66DET PDA0 PDA2 PDCS- PDCS3-...
  • Page 7 Board Layout: Jumper and Connector Locations...
