Figure 74. Removing a disk drive from a base function system
Figure 75. Removing a disk drive from an expanded function system
6. Support the bottom of the drive as you slide it out of the system. Hold the drive by its sides.
7. Press Enter on the console to indicate that you removed the drive. The identify LED turns off.
76
Disk drives or solid-state drives
A
A
B
B
