Figure 57. Covering the SSD cage in an expanded function system
4. If applicable, replace the front cover. For instructions to replace the front cover on an expanded
function system, see "Installing the front cover on a rack-mounted 5148-21L, 5148-22L, 8247-21L,
8247-22L, 8284-21A, or 8284-22A system" on page 153.
5. To configure the newly installed disk drive or solid-state drive, see "Configuring a disk drive or
solid-state drive for use in an AIX system or AIX logical partition" on page 114.
6. To rebuild the data on the replacement disk drive or solid-state drive, see "Rebuilding data on a
replacement disk drive or solid-state drive in a system or logical partition running the AIX operating
system" on page 119.
Removing and replacing a disk drive or solid-state drive in the
8284-21A or 8284-22A system with the power turned on in IBM i
Learn how to remove and replace a disk drive or solid-state drive (SSD) in a system with the IBM i
operating system or IBM i logical partition that controls the drive location powered on.
To remove and replace a disk drive or solid-state drive in a system, complete the following steps:
1. "Preparing the 8284-21A or 8284-22A system to remove and replace a disk drive or solid-state drive
with the power turned on in IBM i" on page 59.
2. "Removing a disk drive or solid-state drive from the 8284-21A or 8284-22A system with the power
turned on in IBM i" on page 63.
3. "Replacing a disk drive or solid-state drive in the 8284-21A or 8284-22A system with the power
turned on in IBM i" on page 66.
4. "Preparing the 8284-21A or 8284-22A system for operation after removing and replacing a drive with
the power turned on in IBM i" on page 70.
Note: Removing or replacing this feature is a customer task. You can complete this task yourself, or
contact a service provider to complete the task for you. You might be charged a fee by the service
provider for this service.
