Figure 15. Removing the SSD cage cover to access the SSD slots in an expanded function system
15. With the SSD drive bay handle (A) in the unlocked position, pull the lever outward to gain access to
the guide rails in the SSD slot. Support the bottom of the SSD as you align it with the guide rails in
the SSD slot. See Figure 16 on page 20.
Note: Support the drive by holding the drive by its sides.
16. Slide the drive halfway into the system.
17. On the console, select the drive that you want to install and then press Enter.
18. When the identify LED turns on solid, slide the drive all the way into the system until the drive
stops.
19. Lock the drive by rotating the bay handle (A) in the direction that is shown in Figure 16 on page 20.
Important: When you install an SSD, ensure that the SSD is fully seated and is all the way into the
system.
B
Disk drives or solid-state drives
19
